st model Seawind User manual

This electric R/C model plane is not a toy.
SAFETY PRECAUTIONS
Assemble the plane according to the instructions. Do not alter or modify the model, If you make any
modifications, you will void your warranty.
Children under 14 years old must use it accompanied by an adult.
Test the operation of the model before each flight to insure that all equipment is operating properly,
and that the model remains structurally sound.
Fly only on calm days (with wind speeds less than 10 mph) and in large open areas free of trees,
people, building or any other obstacles.
REMEMBER:
Take your time and follow the instructions to end up with a well-built model that is durable and easy to fly.
PRODUCT MANUAL
Wing span:
Length:
Wing area:
Flying weight:
Wing loading:
1460mm/57.48in
1112mm/43.78in
27.74dm²/429.96in²
1600g/56.50oz
57.68g/dm²
SPECIFICATIONS

www.sheng-teng.com 1
I N T R O D U C T I O N
Before starting to build, inspect the parts to make sure they are of acceptable quality. If any parts are missing
are not of acceptable quality, or if you need assistance with assembly, contact Product Support. When reporting
defective or missing part, use the part names exactly as they are written in the Kit Contents List.
01. Fuselage
02. Left Wing
03. Right Wing
04. Horizontal Stabilizer
05. Fin Tip
06. Propeller
07. Propeller Adapter
08. Spinner
09. Carbon Rod
10. Left Landing Gear
11. Right Landing Gear
..........................................................x1
..........................................................x1
........................................................x1
..........................................x1
..............................................................x1
..........................................................x1
..............................................x1
............................................................x2
......................................................x1
..............................................x1
............................................x1
12. Screw (M2.5x14)
13. Screw (M3.0x16)
14. Screw (M2.5x10)
15. Battery Pack
16. “Y” Servo Extension
17. Charger
18. Transmitter
19. Decals
20. Instruction
21. Sucking Bottle
...............................................x1
...............................................x1
...............................................x6
.....................................................x1
...........................................x2
............................................................x1
.......................................................x1
.............................................................x1
........................................................x1
..................................................x1
O r d e r N O . D e s c r ip ti o n
ST 141 40AMP U-BEC ESC
ST 112 11.1V Lipo 2200mAh Battery
ST 172 ST6DF 2.4Ghz 6CH Transmitter
ST 180 ST6DF 2.4Ghz 6CH Receiver
ST 204 11x8 Propeller
ST 121 9g Servo
ST 122 17g Servo (P)
ST 124 36g Servo
O r d e r N O . D e s c r ip ti o n
ST 185 Servo Speed Reducer (SSR)
ST 160 3S Lipo Smart Balancing Charger
STSE 010 Fuselage Set
STSE 020 Wing Set
STSE 030 Staibilizer
STSE 040 Tip Fin
STSE 050 Landing Gear (L&R)
STSE 011 Brushless Motor
R e p l a c e m e n t P a r t s L i s t
Replacement part for the ST MODEL SeaWind are available using the numbers in the Replacement Parts List
that follows.
T O O L S R E Q U I R E D
Sharp Hobby Knife
Needle Nose Pliers
Hex Wrench
Ruler
Awl
Flathead Screwdrivers (size:M,S)
≥85mm

www.sheng-teng.com
2
P R E P A R E T H E R A D I O C O N T R O L S Y S T E M
1. Locate the transmitter (PIC.01).
2. The transmitter requires eight alkaline “AA” batteries. To install the batteries, remove the battery hatch by
sliding it down and inserting them into place (PIC.02). Be sure to follow the polarity diagram inside the battery
compartment. Reinstall the battery hatch (PIC.03).
C A U T IO N :
(1). Do not use rechargeable (NiCd & NiHy) batteries.
(2). Do not mix old and new batteries.
(3). Do not mix alkaline and standard (carbon zinc) batteries.
3. Switch the transmitter on and check the LED on the front of the
transmitter (PIC.04). If the green LED is on, it is safe to fly. If the
red LED is flashing, install fresh batteries. Also check to make
sure that the batteries are installed correctly.
4. Switch the transmitter off and stand by for later use.
PIC.01
PIC.02 PIC.03 PIC.04
L1
L2
Motor ESC
LiPo Battery Aileron
Servo
Receiver
Antenna
Aileron
Servo
Elevator
Servo
Rudder
Servo
Flap
Servo
Light Unit
Servo Speed
Reducer
Nose Gear
Servo
Rear Gear
Servo
LED
Neck strap
attachment point
Throttle trim lever <Mode 1>
Elevator trim lever <Mode 2>
Throttle <Mode 1>
Elevator <Mode 2>
/Aileron stick
Aileron trim lever
Antenna
Carrying bar
Elevator trim lever <Mode 1>
Throttle trim lever <Mode 2>
Elevator <Mode 1>
Throttle <Mode 2>
/Rudder stick
Rudder trim lever
Power switch
In the upper position,
the power is turned on.
C ha n n el d is p la y
AIL. :
ELE. :
------------------------------------------------
Aileron
Elevator
O p e r a ti n g d i r e c ti o n d i s p la y
----------------------------------------
REV. :
NOR. :
Reverse side
Normal side
Throttle
Rudder
THR. :
RUD. :
CH.6 switch
CH.6 movement adjuster
CH.5 switch
CH.5 movement adjuster

www.sheng-teng.com 3
A S S E M B L E T H E M O D E L
Landing Gears
Mount the landing gears to both side of fuselage using six
M2.5x10mm. Pay attentin to the marks “L” & “R” on the
bottom of the landing gears.
The “L” landing gear should be mounted in left side of
fuselage; The “R” landing gear should be mounted in right
side of fuselage.
Fit the horizontal stabilizer onto the fin.
Then lock it with M3.0x16mm screw.
Guide the pushrod into the screw-lock connector on elevator
horn, and lock it to avoid loosening.
Horizontal Stabilizer
2
2.5x10mm Screw
--------------------------6
3.0x16mm Screw
----------------------1

www.sheng-teng.com
4
Main Wing
4
Fin Tip
3
Attach the fin tip onto its foundation on the top of fin as
illustration.
Slide the fin tip to the end to avoid loosening.
Insert the carbon rod through one of the wings, and then put
the other end of carbon rod through the fuselage.
Put the servo wire & light wire and the flap pushrod through
the fuselage into the canopy.

www.sheng-teng.com 5
Main Wing
6
Main Wing
5
Insert the carbon rod through the other wing.
And also put the sero wire & light wire and falp pushrod
through the fuselage into the canopy.
Fit the wings and the fuselage in place, then lock then to
acoid looseing.
Guide the flap pushrod into the screw-lock connector on the
flap servo arm.
Take the aileron servo wire and connect to the servo
extension leads.
Take the wing tip light wires and connect to the light unit.
Ensure the polarity should be contacted correctly.

www.sheng-teng.com
6
Spinner
8
Propeller
7
Install the propeller adapter with propeller over the motor
shaft.
6.0mm Nut
------------------1
Make sure the screw are secured safely!
Fix the spinner with the screw M2.5X14mm as shown.
Tighten the screws securely. If it comes off during
flights, you may lose control of your airplane, resulting
in an accident!
Put the propeller washer on the adapter shaft.
Take the propeller nut and screw it on the adapter shaft.
Tighten the nut with a hex wrench.
2.5x14mm Screw
------------------------1

www.sheng-teng.com 7
Adjustment
10
Battery
9
Remove the seat in the cockpit and fix the battery with velcro
tape, accord to the C of G on step11.
Adjust the travel of each control surface to the values in the diagrams.
<Aileron> & <Flap> <Elevator> <Rudder>
20mm
20mm
20mm
15mm
15mm
35mm
35mm
Position for
diagram. Position for
diagram. Position for
diagram.
Position for
diagram.

www.sheng-teng.com
8
C of G position
11
The standard CG is positioned the line as the picture shows.
The movement of the CG should not exced ±5mm.
Otherwise,it will have an effect on flying performance.
Do not fly before confirming the correct location of the CG.
If the CG is incorrect, you may lose control of your airplane and way lead to accidents.
52mm±5mm52mm±5mm

O P E R AT I N G Y O U R M O D E L S A F E T Y
Cautions for SafetyBefore Flying Flying After Flying
Before flying your airplane,
ensure the airfield is spacious
enough. Always fly it outdoors
in safe areas with no debris or
obstacles!
For proper radio handing, re-
fer to it’s instruction manual.
Ensure the spinner and prop-
eller are securely installed.
Switch on the transmitter.
Plug in the battery.
Warning!
Beware of spinning
propeller! With some
electronic speed controllers,
the motor (proprller) starts
spinning as soon as battery
is connected.
Do not fly your airplane on
days with strong winds or
side winds.
If the green LED is on, it is
safe to fly. If the red LED is
flashing install fresh batteries.
Also check to make sure that
the batteries are installed
correctly.
Unplug the battery.
Warning!
Beware of spinning propellers!
Switch off the transmitter.
Don’t use defective propeller.
Batteries and chargers
become hot. Keep away
flammable materials.
Never try to modify battery.
This is very dangerous.
Do not dispose of used
batteries, return them to the
shop.
Do not dispose of batteries in
a fire. They explode and
release harmful materials.
www.sheng-teng.com 9
Always land airplane into the
wind. Do not allow people watching
to get too close to rotaing
propeller.
If your airplane does not
function correctly, land it at
once and find out the reason.
Launch your airplane into the
wind.
Ensure the main wing & stabi-
lizer is securely installed.
Move the sticks on your tran-
smitter to ensure that all con-
trols move according to your
input and the way you adjust-
ed them.
Unplug the battery when not
in use.
Remove grime, check the
plane carefully and make sure
no parts have gotten loose or
damaged.
