MPEG 2.5 LAYER III TECHNICAL INTRODUCTION
An Overview
Since 1988 MPEG group has been working on the standardisation of high-quality low-bitrate audio cod-
ing techniques. Two standards have been completed: MPEG 1 (coding of mono and stereo signals at
sampling rates of 32, 44.1, and 48 KHz) and MPEG 2 (backward-compatible coding of 5+1 multichannel
sound signals and low-bitrate coding of mono and stereo at sampling rates of 16, 22.05, 24 KHz).
A non standardized evolution of MPEG 2 has been developed by industry, called MPEG 2.5.
It is practically the extension to the sampling rates 8, 11.025, and 12 KHz, of the current MPEG 2 stand-
ard.
The basic idea behind perceptual coding, the general audio coding theory implemented by MPEG, is to
hide the quantisation noise below the signal-dependent tresholds of hearing. In this view, the most im-
portant question in perceptual coding is: "how much noise can be introduced to the signal without being
audible?". The most prominent feature in psychoacoustics is masking in the frequency domain. A fainter
signal is completely masked by a masker that is louder and has a similar frequency content.
The overall processing chain of an MPEG encoder can summarised in the following four steps:
•A filter bank is used to decompose the input signal into subsampled spectral components (time to
frequency domain). Together with the corresponding filter bank in the decoder it forms an analysis-
synthesis system.
•Using either the time-domain input signal or the output of the analysis filter bank, an estimate of the
actual (time-dependent) masked threshold is computed using rules known from psychoacoustic.
This is called the perceptual encoding system.
•The spectral components are quantized and coded with the aim of keeping the noise, which is intro-
duced by quantizing, below the masking treshold. Depending on the algorithm, this step is done in
different ways, from simple block companding to analysis-by-synthesis system using additional
noiseless compression.
•A bitstream formatter is used to assemble the bitstream, which typically consists of the quantized
and coded spectral coefficients and some side information, such as bit allocation information.
March 1999
®
AN1090
APPLICATION NOTE
STA013 MPEG 2.5 LAYER III SOURCE DECODER
by Ruggero DE LUCA
This Application Note helps the user to work with STA013 Evaluation Board, installing the PC Soft-
ware Driver, understanding how STA013 MPEG 2.5 Layer III Source Decoder works, and explaining
how to control the device functions.
The document is composed by 5 main points:
-
MPEG 2.5 Layer III Technical Introduction
-
STA013 Device Description
- STA013 Evaluation Board Description
-
STA013 PC Software Driver Description
- General Information on STA013 Evaluation Environment
1/17

The Layers
Recognizing a variety of application needs, the concept of a generic coding system was envisaged. De-
pending on the application, one of the three layers of the coding system with increasing complexity and
performances is chosen. In all the three layers the input PCM audio signal is converted from the time
into a time-frequency domain.
This is done by a poliphase filter bank consisting of 32 subbands.
In Layer I and II, a filter bank creates 32 subbands representation of the input audio stream, which are
then quantized and coded under control of the psychoacoustic model from which a blockwise adaptive
bit allocation is derived.
Layer I is a simplified version of the MUSICAM coding scheme, most appropriate for consumer applica-
tions, where the very low bitrate is not mandatory.
Layer II introduces further compression with respect to Layer I, by redundance and irrelevence removal
on the scale factors, and it uses more precise quantisation.
Layer III consists of a combination of the most effective modules of the ASPEC and MUSICAM coding
schemes. Additional frequency resolution is provided by the use of a hybrid filter bank. Every subband is
thereby further split into higher resolution frequency lines by a MDCT that operates on 18 subband sam-
ples in each subband. The frame lenght is 24 ms, identical to Layer II. In Layer III, nonuniform quantisa-
tion, adaptive segmentation, and entropy coding of the quantized values are employed for better coding
efficiency. The basic block diagram of a Layer III Decoder is described in Fig. 1.
Layer III uses a short-term buffer to help the system cope with the short term difference in the bit rate
demand. Only Layer III may operates in a variable rate mode, without violating the minimum require-
ments of the standard. This layer is most useful in telecommunication, in particular with narrow band
ISDN, satellite links, and in all cases where the best quality at low bitrates is mandatory.
STA013 DEVICE DESCRIPTION
The STA013 is an MPEG 2.5 Layer III Audio Decoder capable of decoding elementary streams from 8
up to 320 Kbit/sec.
The full sampling frequencies range is supported, from 8 up to 48 KHz. For this reason we use the name
"MPEG 2.5".
•Supports all ISO Layer III Functionalities and WorldSpace Extensions.
•Programmable Input Data Interface.
•Programmable Audio Data Interface.
•Automatic Output Sampling Rate Generation.
•Programmable Oversampling Clock Frequency for DAC.
Stereophonic Audio Signal
(2*768Kbit/s)
DEMULTIPLEXING
&
ERROR CHECK
HUFFMAN
DECODING
INVERSE
QUANTISATION
&
DESCALING
SIDE
INFORMATION
DECODING
IMDCT
INVERSE
FILTERBANK
32 Subbands
Ancillary Data
Encoded Audio Bitstream
(8 Kbit/s .... 320 Kbit/s)
Figure 1: STA013 Block Diagram
STA013
AN1090 APPLICATION NOTE
2/17

•Automatic MPEG Synchronisation, Sync Error Detection and Bistream Error Detection.
•Automatic Error Cancelment Techniques.
•Automatic DSP Speed Regulation for Power Consumption Optimisation.
•Low Power 3.0V and CMOS Technology.
•10, 14.31818, 14.7456 MHz Input Clock.
STA013 can decode Layer III compressed streams only, because the lower layers I and II are not sup-
ported by this device.
It is particulary suitable for Multimedia application, because it can drive the data demand by a dedicated
pin. This signal can be used by the system controller to syncronize the data to STA013 input port.
It can work with three different standard commercial crystals, 10.00, 14.31818, and 14,7456 MHz.
The device can perform both digital Volume and Tone Control, avoiding the use of the correspondant
analog components on the application.
The most important DAC data format (I2S, etc.) are supported.
The Figure 2 describes the STA013 chip partitioning.
For any other technical information, refer to STA013 data sheet.
STA013 EVALUATION BOARD DESCRIPTION
(see Figure 4 Electrical Schematic and Figure 3 Functional Diagram)
The STA013 Evaluation Board (STA013EVB) is useful to perform functional verification of the device op-
eration.
The board is connected to an external data source by means of the
Input Connector
which provides to
the user the connection points in order to input the serial data to STA013 and to control the input data
flow speed. The
Input Connector
is indicated on STA013EVB with J6. The Serial Input Clock line for
STA013 has to be connected to pin no. 1 of J6. On the STA013EVB, it is connected to pin no. 6 of
STA013 (SCKR). The polarity of the STA013 receiver clock can be programmed, as described in the
data sheet.
The Serial Input Data line for STA013 has to be connected pin 2 of J6. The speed of input data can be
controlled by the DATA_REQ signal of STA013 (pin no. 28) and it is connected on STA013EVB to pin 4
of J6.
The STA013EVB
I2C Connector
(JP3) is used to interface the PC interface board to STA013. The JP3
connection point no. 2 is connected to pin 4 of STA013 and is the I2C Serial Clock line (SCL). The maxi-
mum speed for this clock is 400 KHz, as specified by I2C standard.
Stereophonic Digital Audio Signal
MPEG
Input
Bitstream
Digital
Tone
Control
Digital
Volume
Control
Reconstruction
Filterbank
Demux
&
Error Check
Huffman
Decoder
Frequency
to Time
Transform
Side Info
Decoding
Main Layer III Decoder Diagram
Digital Audio Effects
Output
Buffer
Input
Buffer
Serial
Input
Interface
Serial
Audio
Interface
Clocks
Generation
System
I2C
Interface
Specific Software on Standard 24 Bit DSP Core
Specific Hardware Blocks
Embedded RAM Memories
µP
Figure 2. STA013 Chip Partitioning
AN1090 APPLICATION NOTE
3/17

The JP3 connection point no. 3 is connected to pin no. 3 of STA013 and is the I2C Serial Data line
(SDA). The STA013 I2C interface is used to:
•Bootstrap the device by downloading the appropriate configuration file. This is done to program
STA013 working with one of the three possible cristal frequencies, to select the appropriate output
data format depending on the DAC used in the other application.
•Monitor STA013 decoding operation. It is possible to read in real time all the audio program informa-
tion, as sampling frequency, channels configuration, input bitstream speed, device interface configu-
ration, and ancillary data.
•Control STA013 operation. The device implements a fully Digital Volume and Tone Control with
parameters programmable via I2C interface. A microcontroller, connected to STA013 I2C interface,
can change the parameters to control the volume level, the tones configurations, and the output data
format.
The STA013EVB can be used by connecting the I2C port to the Parallel Port of a commercial PC. The
I2C protocol is emulated by a dedicated PC Software Driver (STA013SDR) allowing the user to have on
STA013 a full control. STA013SDR has a graphical user interface for an easy control of the device func-
tions.
The pin no. 4 of STA013EVB I2C Connector is connected to the pin 26 of STA013, System Reset, to re-
set the device even by using a STA013SDR button.
The ouptut of STA013 is a digital audio signal in standard format (as described in the data sheet at page
no. 6/30). The pins no. 9, 10, 11, 12 STA013 are connected to the correspondent DAC pins no. 1, 2, 3.
and 4. The DAC used on the STA013EVB is a Sigma-Delta 18 bit architecture (CS4331-KS).
The analog output of the converter is sent to the active
Speakers Connectors
J1 (RCA-OUTL) and J2
(RCA-OUTR). The amplified analog outputs are even sent to the J5
Headphone Connector
. The am-
plification is produced by means of an audio amplifier (TDA 2822).
On STA013EVB all the MPEG Decoder input and ouput digital signals can be monitored by the following
test points:
3
28
26
RESET
INPUT
CONNECTOR
J6
4
I2C
CONNECTOR JP3
SDA
SCL
CLK/DATA
5
SDI
6
SCKR
STA013
9 1
10 2
11 3
12 4
SDO
SCKT
LRCLKT
OCLK
DAC
5
8
67
AUDIO
AMP 3
1
AOUTL
AOUTR
D98AU944
J1
J2
J5
HEADPHONE
CONNECTOR
STA013
MPEG 2.5 LAYER III DECODER
EVALUATION BOARD
SO28 SO8
SO8
Figure 3. STA013EVB Functional Diagram
AN1090 APPLICATION NOTE
4/17

TEST POINT NAME(TP) DESCRIPTION REFERENCE PIN of U2
RESET I2C Data Pin 26
SDA I2C Data Pin 3
SCL I2C Clock Pin 4
DATA_REQ Data Request Line Input Pin 28
SDI Serial Data Input Pin 5
SCKR Serial Clock Input Pin 6
SDO1 Serial Data Output Pin 9
SCKT Serial Clock Output Pin 10
LRCLK Left/Right Clock Output Pin 11
OCLK DAC Oversampling Clock Output Pin 12
(see figure 4 for details)
1
2
3
4
VDD
GND
SDA
SCL
C12
0.1µF
R8
4.7K
R7
4.7K
VDDVDD
SDA
SCL
GND
2
31
26
OUT_CLK/DATA_REQ
RESET
28
14
VDD
VDD
C11
0.1µF13
GND
5
SDI
6
SCKR
4
3
2
1
R23
10K
R22
10K
VDD VDD 7
BIT-EN
8
SRC_INT
JP2JP1
VDD 24
TESTEN
C8
0.1µF
VDD23 VDD
22 GND
C1
0.1µF
VDD
16 VDD
15 GND C2
47pF C3 47pF
X1 XTAL
R5 1M
21 XTI
20 XTO
R1
0R3 100 R2 100
J3
SMB
VDD17 PVDD
18 PGND
C5
0.1µF
C4
1nF R14 4.7
R13 4.7
19 FILT
C6
470pF
C7
4.7nF
R4
1K
25 SCANEN
27
RESET
C10
4.7µF
VDD
C9
10nF SW1 SMD
R6 8.2K
9
SDO
12
OCLKLRCLKTSCKT
1110
SDATA
DEM/SCLK
LRCK
MCLK
C16
10µF
C15
0.1µF
AVCC
7
VA+
R11 2.7K
C17 10µF
R10
56K C29
680pF
R12 2.7K
R21
56K
C18 10µF
C19
680pF
8
6
5
J1 RCA
J2 RCA
R19 56K
R20 56K
C27 0.33µF
C28 0.33µF
R17
1K
R18
1K
C25 100µF
C26 100µF
AOUTL
AGND
AOUTR
1
2
3
4
8
6
5
7
IN1-
IN1+
IN2+
IN2-
1
2
3
4
C24 100µF
C23 10µF
C22 100µF
C21 0.1µFGND
R16 4.7
C20 0.1µF
OUT1
VCC
OUT2
AVCC
4
PHONEJACK STEREO
J5
TDA2822D
CS4331-KS
U3
STA013
JP3
AMP
U1F
OUTL
OUTR
U1E
J6
EXT
D1
RED
74LVX0474LVX04
R24
330
74LVX04
74LVX04
74LVX04
74LVX04
U1BU1A
U1DU1C
11 13
24
68
12
3
9
10
1
5
L1
ferrite
R9 470
AMP6 2 ways
J4
AVCC VDD
12
ALL GROUNDS
CONNECTED AT ONLY ONE
POINT BENEATH THE BOARD
D2
GREEN
2.7V/3.3V
C13
47µFC14 0.1µF
D98AU935A
R26
4.7K
R27
4.7K
U2
U4
TP
TP
TP
75119
86
13
1210 14
TP
TP
VDD
C30
0.1µF
GND TP
TP
TP
TP
TP
R15 4.7
Figure 4. STA013EVB Electrical Schematic
AN1090 APPLICATION NOTE
5/17

STA013 MASTER CLOCK
The STA013 can use three different Master Clock frequencies, each one obtained by an external crystal
oscillator X1. The user can even evaluate these three different input frequencies by connecting a func-
tion generator to J3-SMB connector.
On STA013EVB the mounted crystal is a standard SMD SXA Packaged commercial one.
STA013EVB SIGNAL LEVELS
The STA013 and all the components on the board work at 3V of power supply. The STA013 EVB Input
Connector is bufferized by an interface IC stage (U1A - U1F are six inverters included an 74lVX04 IC) by
allowing the user to use directly a data source with signals level up to 5V without further stages.
POWER SUPPLY
STA013EVB has to be supplied by the J4 connector. This board uses a particular layout technique to
minimizing digital and analog noise, including grounding and power supply decoupling.. The allowed
supply voltage range is 2.7V - 3.3V.
L
ACTIVE
SPEAKERS
R
TO PC INTERFACE BOARD Vcc = 3V
HEADPHONES
MP3
SOURCE
- +
Figure 5. STA013EVB Component Side Silkscreen (not in scale)
AN1090 APPLICATION NOTE
6/17

Figure 6. 1134-137.7 PC INTERFACE BOARD (not in scale)
AN1090 APPLICATION NOTE
7/17

Figure 7. PC Interface Schematic.
AN1090 APPLICATION NOTE
8/17

STA013SDR Panel
The graphical user interface of STA013SDR is composed by:
Volume Control Bars called DAL, DAR, DBL, and DBR. The function implemented is the
same than the corresponding Volume Control I2C registers.
Tone Control Bars called Bass Gain, Bass Freq, Treble Gain, and Treble Freq.The
functions implemented are equivalent to the corresponding Tone
Control I2C Registers.
Tone Atten Bar it has equivalent function than the Tone_Atten I2C register.
Read Button it is used to read the current I2C registers status, corresponding to the
Panel Functions. By pressing this button the Panel will show the status
of all the displayed registers.
Write Button it is used to write the current I2C registers status, corresponding to the
Panel Functions. By pressing this button the software will update the
status of all the displayed registers.
STA013 PC CONTROL SOFTWARE
The STA013EVB is provided with a PC Control Software Driver (STA013SDR), allowing the user evalu-
ating all the device functions and controlling the device operation. The STA013SDR is a Win3.x / Win 95
software that can be installed directly by the user on a standard PC. (see Installation Procedure Section)
AN1090 APPLICATION NOTE
9/17

Status Button
Registers Button
this function allow the read and/or the write op-
eration on all the STA013 registers. To write the
registers the user has to update the register set-
ting before pressing the write button.
by pressing this button the user open a window
displaying the status of STA013. The possible
status are described in the STATUS register de-
scription.
In the lower part of the Status window the
MPEG Frame Counter value is displayed.
Run Button the function implemented by this button is
equivalent to the RUN I2C register.
.
Firmware Button
by pressing this button the user opens a window
to download the STA013 Patch File (if needed).
This action is suggested to be preceeded by an
HW Reset (by the software or by the button on
the STA013EVB).
HW Reset This button implemet a System Reset. The
output of the PC is, in this case, connected to
the STA013 pin no. 26. The reset performed
by the software and by the hardware button on
the STA013 are equivalent.
.
AN1090 APPLICATION NOTE
10/17

Tone Button
by selecting this function, the user opens a window
describing the ideal frequency response of the
Tone Control function.
The window is updated when the Tone Control pa-
rameters are modified by the users.
Header Button
by pressing this button the STA013SDR displays all
the relevant information contained in the MPEG
Frame Headers of the incoming compressed bit-
stream.
AN1090 APPLICATION NOTE
11/17

Ancillary Button
this function allow the user to read the Ancillary
Data coded in the MPEG stream. The Ancillary
Data are displayed as ASCII characters.
PLL Button
by pressing this button, all the PLL configuration
register become visible and can be read or writ-
ten.
AN1090 APPLICATION NOTE
12/17

PCM Button
this button, if selected, opens a window to read
or change the PCM audio interface configura-
tion.
Init Button by pressing this button the user download the
initialisation file to bootstrap the STA013 on
the application board. The initialisation file
must be called sta013.ini and must be placed
in the directory where the STA013SDR is
installed
AN1090 APPLICATION NOTE
13/17

STA013 PC TRANSMISSION SOFTWARE DRIVER DESCRIPTION
The STA013EVB is provided with the PC Software Transmission Driver (STA013TXD), allowing the user
to send the MPEG bitstream to the device.
The STA013TXD is a Win 3xx/Win95 software and can be installed by the user on a standard PC (see
Installation Procedure Section)
STA013TXD Panel
The STA013TXD user interface is composed by a graphical panel. The File button is used to select the
.MP3 file to be transmitted to STA013EVB.
Set LPT Button
this panel is used to configure the PC Parallel Port address.
AN1090 APPLICATION NOTE
14/17

NOTE:
Before start working with STA013TXD it is suggested to configure the PC Parallel Port to EPP 1.9 Mode by BIOS setup. This is possible only
for new versions of Pentium PCs.
This configuration enables a DMA channel from the PC HDD to the Parallel Port hardware, improving the performances.
Even with this configuration the user may note audio dropouts, due to the Parallel Port performance.
To minimise the effect, it is suggested to copy the mp3 files on the P.C. HDD and run a de fragmentation tool.
The STA013TXD can handle data rates up to 128Kbit/sec.
13121110987654321
25 24 23 22 21 20 19 18 17 16 15 14
STA013 SERIAL DATA (to STA013EVB J6)
STA013 SERIAL CLOCK (to STA013EVB J6)STA013 DATA REQUEST (from STA013EVB J6)
(STA013EVB J6-GROUND)
DB25 FEMALE
D98AU977A
PC Parallel Port Pinout for STA013TXD
AN1090 APPLICATION NOTE
15/17

1
3
2
4
5
6
7
8
9
26
25
24
23
22
20
21
19
27
10
28
SO28
11
12
13
18
16
17
1514
STA013
STA013EVB
J1
J2
J5
J4
J3
J6
PC
Interface
PC 1: STA013SDR
+ 3.0 V
PC 2: STA013TXD
+
Evaluation Environment
DEMOBOARD SET-UP SEQUENCE
Note: Supply voltage of the I2C board is 7 V
Supply voltage of STA013EVB is 3.3 V
1. Run "setup.exe" program from STA013SDR software
2. Click on "HWRst" button
3. Click on "Registers" button
4. Select "Ident" register
5. Click on "Read" button and verify that the read value is "172"
6. From the control panel, click on "Firmware" button
7. Click on "HWRst" button
8. Click on "File" button to load the configuration file .reg into the PATCH Ram;
9. Wait until the whole file is downloaded
10. Click on "Cancel" button to exit from the menu
11. Click on "Run" button: now the red led on the board should be switched off
12. Run "STA013TXD" software and, clicking on "File" button, select the mp3 file to be tested.
The red led must be now switched on and the music start to play.
GENERAL INFORMATION ON STA013 EVALUATION ENVIRONMENT
The STA013 Evaluation toolkit is composed by a set of components, as follows:
STA013EVB
STA013 Evaluation Board
(already described in the previous section).
STA013TXD
STA013 Software Transmission Driver
(already described in the
previous section).
STA013SDR
STA013 Software Driver
(already described in the previous section).
PC Interface Board useful to avoid electrical shocks due to the operating voltage difference
between the PC Parallel Port and the STA013EVB.
All the kit components are provided with flat cables to connect the different units.
AN1090 APPLICATION NOTE
16/17

Information furnished is believed to be accurate and reliable. However, STMicroelectronics assumes no responsibility for the consequences
of use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No license is
granted by implication or otherwise under any patent or patent rights of STMicroelectronics. Specification mentioned in this publication are
subject to change without notice. This publication supersedes and replaces all information previously supplied. STMicroelectronics products
are not authorized for use as critical components in life support devices or systems without express written approval of STMicroelectronics.
The ST logo is a registered trademark of STMicroelectronics
© 1999 STMicroelectronics – Printed in Italy – All Rights Reserved
STMicroelectronics GROUP OF COMPANIES
Australia - Brazil - Canada - China - France - Germany - Italy - Japan - Korea - Malaysia - Malta - Mexico - Morocco - The Netherlands -
Singapore - Spain - Sweden - Switzerland - Taiwan - Thailand - United Kingdom - U.S.A.
http://www.st.com
AN1090 APPLICATION NOTE
17/17
