Standard Living PEORIA JAVA 415000V User manual

Read instructions carefully prior to assembly.
Thank you for purchasing this quality product. Check carefully for small parts which may have come loose
during shipment. It is recommended to use two or more persons during the assembly process. Identify and count
all parts as specified below.
Made in Vietnam
ASSEMBLY INSTRUCTIONS
GROUP : 415000V - PEORIA JAVA
Step 1:
Attach Backrest (B/C/D) to the Seat (A)
ITEM NO. : 4150961V
DESCRIPTION : SOFA,MANUAL-DROPDOWN TABLE-JAVA
PAGE 1 OF 1
Parts List
NO. DESCRIPTION SKETCH Q'TY
A Seat 1 PC
Step 2:
Attach the Left ear (E) and Right ear (F) to Left Backrest (B)
and Right Backrest (D)
Step 3:
Open the footrest by pull out the handle
Cleaning instructions: Clean with the soft cloth
BLeft Backrest 1 PC
CMiddle Backrest 1 PC
DRight Backrest 1 PC
ELeft ear 1 PC
FRight ear 1 PC
A
B
C
D
E
F
A
BCD

Read instructions carefully prior to assembly.
Thank you for purchasing this quality product. Check carefully for small parts which may have come loose
during shipment. It is recommended to use two or more persons during the assembly process. Identify and count
all parts as specified below.
Made in Vietnam
ASSEMBLY INSTRUCTIONS
GROUP : 415000V - PEORIA JAVA
Step 1:
Attach Backrest (B/D) to the Seat (A)
ITEM NO. : 4150431V
DESCRIPTION : LOVESEAT,MANUAL CONSOLE – JAVA
PAGE 1 OF 1
Parts List
NO. DESCRIPTION SKETCH Q'TY
A Seat 1 PC
Step 2:
Attach the Left ear (E) and Right ear (F) to Left Backrest (B)
and Right Backrest (D)
Step 3:
Place the Console Backrest (C) to right location and then
attach to the Seat (A) by turning the Knob Screws (G)
clockwise
Cleaning instructions: Clean with the soft cloth
BLeft Backrest 1 PC
CConsole Backrest 1 PC
DRight Backrest 1 PC
ELeft ear 1 PC
FRight ear 1 PC
GKnob Screws 2 PCS
A
B
D
E
F
G
A
C
A
B C D
E F
Step 4:
Open the footrest by pull out the handle
A
BD

Read instructions carefully prior to assembly.
Thank you for purchasing this quality product. Check carefully for small parts which may have come loose
during shipment. It is recommended to use two or more persons during the assembly process. Identify and count
all parts as specified below.
Made in Vietnam
ASSEMBLY INSTRUCTIONS
GROUP : 415000V - PEORIA JAVA
Step 1:
Attach Backrest (A) to the Seat (B)
ITEM NO. : 4150991V
DESCRIPTION : RECLINER, GLIDER MANUAL - JAVA
PAGE 1 OF 1
Parts List
NO. DESCRIPTION SKETCH Q'TY
A
B
C
D
Backrest
Seat
Right ear
Left ear
1 PC
1 PC
1 PC
1 PC
A
D C
B
Step 2:
Attach the Left ear (D) and Right ear (C) to Backrest (A)
A
B
A
B
D
C
Step 3:
Open the footrest by pull out the handle
Cleaning instructions: Clean with the soft cloth
