Stanley J7C09D User manual

116
7. Permita que la unidad se enfríe antes de almacenarla.
8. Almacene la manguera del compresor, la boquilla Sure Fit®y el adaptador de la
boquilla en el compartimiento de almacenamiento cuando no está en uso.
CUIDADO Y MANTENIMIENTO
Con el tiempo, todas las baterías pierden energía debido a la descarga automática y
con mayor rapidez en ambientes con temperaturas elevadas. Cuando la unidad no
esté en uso, recomendamos cargar la batería al menos cada 30 días.
De vez en cuando, limpie el exterior del aparato con un paño suave. No sumerja el
aparato en agua.
No hay ningún usuario-sustituibles piezas. Periódicamente inspeccione la condición
de adaptadores, conectores y alambres. Contacto fabricante para sustituir los
componentes que han pasado a ser gastado o rotas.
Batería
Veuillez noter que la batterie est conçue pour durer toute la durée de vie
de l’unité et n’est pas remplaçable, amovible ou réparable. La durée de vie
utile dépend de certains facteurs, y compris, mais sans s’y limiter, du nombre de
cycles de recharge et de l’entretien et de la maintenance appropriés de la batterie
effectués par l’utilisateur final. Pour obtenir tout renseignement supplémentaire,
communiquer avec le fabricant.
ELIMINACIÓN SÛRE DE LA BATERÍA
Contiene una batería de plomo ácido, que se deben desechar de
manera adecuada. Reciclar es necesario. El incumplimiento de
regulaciones locales, estatales y federales, puede resultar en multas
o prisión.
Por favor recicle.
ADVERTENCIAS:
• No deseche la batería en el fuego ya que puede ocasionar una explosión.
• Antes de desechar la batería, proteja las terminales descubiertas con cinta eléctrica
para trabajos pesados. De esta manera previene cortos circuitos (los cortos circuitos
pueden ocasionar lesiones e incendios).
• No exponga la batería al fuego o al calor extremo ya que puede explotar.
DETECCIÓN DE PROBLEMAS
La unidad no cargará
• Cerciórese de que todas las funciones de la unidad estén desactivadas.
• Cerciórese de que una cuerda de extensión del calibrador correcto esté conectada
correctamente con la unidad y un enchufe de funcionamiento de la CA.
La unidad no puede arranque del motor
• Asegúrese de que la unidad no esté funcionando en el modo compresor.
• Asegúrese de que se han realizado las conexiones de los cables con la polaridad
correcta.
• Asegúrese de que el Interruptor del puente auxiliar de arranque de la unidad está
en la posición encendido.
• Compruebe que la unidad tiene una carga completa. Recargue la unidad en caso
de necesidad.
El puerto de la energía del USB no accionará la aplicación
• Asegúrese de que el botón de encendido/apagado del puerto de carga USB se ha
presionado para activar los puertos USB.
• Si existe una condición de falla en cualquiera de los puertos USB, el ícono de
falla en la pantalla LCD parpadeará. Consulte las notas importantes en la sección
“Puertos USB” para solucionar cualquier fallo.
• Asegúrese de que la extracción total de todos los dispositivos USB conectados a los
puertos USB izquierdos no exceda los 3.1A (5V).
• Algunos productos electrónicos de uso doméstico alimentados por USB no
funcionan con esta puerto de carga / potencia del USB. Compruebe el manual del
dispositivo electrónico correspondiente para confirmar que se puede utilizar con
este tipo de puerto de carga / potencia del USB.
• Compruebe que la unidad tiene una carga completa. Recargue la unidad en caso
de necesidad.
La luz de área LED no enciende
• Cerciórese de que el botón de encendido de la luz de área LED se ha presionado
para activar la luz de área LED.
• Compruebe que la unidad tiene una carga completa. Recargue la unidad en caso
de necesidad.
El compresor portátil no inflará
• Asegúrese de que la unidad no esté funcionando en el modo de inicio de salto.
• Asegúrese de que el conector de la boquilla Sure Fit®está firmemente atornillada
al vástago de válvula cuando se intenta inflar los neumáticos; o que el adaptador
de la boquilla se atornilla firmemente en el conector de la boquilla Sure Fit®y está
insertado correctamente en el elemento a ser inflado en todos los otros objetos
inflables.
• Asegúrese de que el botón de encendido del compresor se ha presionado para
activar el compresor.
• El compresor puede sobrecalentarse. Pulse el botón de encendido del compresor
para apagar el compresor. Reinicie después de un período de enfriamiento de 30
minutos aproximadamente.
• Compruebe que la unidad tiene una carga completa. Recargue la unidad en caso
de necesidad.
ACCESORIOS
Accesorios recomendados para uso con esta unidad puede ser disponibles a través
del fabricante. Si necesita ayuda con respecto a los accesorios, por favor póngase en
contacto con el fabricante al 1-877-571-2391.
El uso de cualquier accesorio no recomendado para el uso con esta unidad podía
ser peligroso.
INFORMACIÓN DE SERVICIO
Si usted necesita asesoramiento técnico, reparación, o partes genuinas del
fabricante, póngase en contacto con el fabricante al 1-877-571-2391.
UN AÑO DE GARANTÍA LIMITADA
El fabricante garantiza este producto contra defectos de materiales y mano de obra
durante un período de UN (1) AÑO a partir de la fecha de compra del producto
por el comprador usuario final (“Período de Garantía”). Si hay un defecto y una
reclamación válida se recibe dentro del período de garantía, el producto defectuoso
puede ser reemplazado o reparado en el las siguientes maneras: (1) Devuelva el
producto al fabricante para reparación o reemplazo, a opción del fabricante. La
prueba de compra puede ser requerida por el fabricante. (2) Devuelva el producto
a la tienda donde el producto fue comprado para un intercambio (siempre y
cuando se trate de un minorista participante). Devoluciones al minorista deben
hacerse dentro del plazo de póliza de devoluciones del minorista para intercambios
solamente (por lo general 30 a 90 días después de la fecha de compra). La prueba
de compra puede ser requerida por el minorista. Por favor consulte la póliza de
devoluciones del minorista sobre devoluciones que están fuera del plazo establecido
para intercambios.
Esta garantía no se aplica a los accesorios, bombillos, fusibles y baterías; defectos a
consecuencias de desgaste normal; accidentes; daños y perjuicios sufridos durante el
envío y manejo, alteraciones, reparaciones o uso no autorizado, negligencia, abuso,
y si no se siguen instrucciones para el cuidado y mantenimiento del producto.
Esta garantía le otorga al comprador usuario final, derechos legales específicos y
usted puede tener otros derechos que varían de estado a estado o de provincia a
provincia. Este producto no está diseñado para uso comercial.
Asegúrese de registrar su producto en https://www.baccusglobal.com/registration
para recibir información importante sobre el producto, promociones y ofertas
especiales, y más.
ESPECIFICACIONES
Amperios de impulso: 12V CC, 700A instantánea
Tipo de batería: De plomo sin necesidad de mantenimiento,
sellada, 12V CC
Entrada de CA: 120V CA, 60Hz, 13W
Luz de área: 1 LED blanco
Puertos USB: 3.1A max., 5V CC
Tomacorriente de la CA: 120V CA, 60Hz, 500W continuo
Presión máxima del aparato
para compresor: 120 PSI
Sure Fit®son marcas registradas o licenciados de los EE. UU. Propiedad de Baccus Global, LLC.
STANLEY®Y EL LOGOTIPO DE STANLEY®SON
MARCAS REGISTRADAS DE STANLEY BLACK + DECKER
INC. O DE UNA DE SUS FILIALES
Y SE UTILIZAN BAJO LICENCIA.
Importados por Baccus Global LLC,
621 NW 53rd St., Suite 450, Boca Raton, FL 33487
www.baccusglobal.com 1-877-571-2391
RD060921
PORTABLE POWER STATION
INSTRUCTION MANUAL
FUENTE DE ENERGÍA PORTÁTIL
MANUAL DE INSTRUCCIÓN
SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
CONSERVE ESTE MANUAL PARA FUTURAS CONSULTAS.
© 2021 Baccus Global LLC
Boca Raton, FL 33432
[phone]
J7C09D
English page 5
Español pagina 11
BC
x
J7C09D_ManualENSP_060921.indd 16-1J7C09D_ManualENSP_060921.indd 16-1 6/9/2021 1:56:27 PM6/9/2021 1:56:27 PM

2 3
FEATURES
CARACTERÍSTICAS
1
6 7 8
2
4 5
910
3
11
12 13
14 15
16
17
FEATURES
1. Rubber Grip Handle
2. Pivoting LED Area Light
3. Jump-Starter Power Switch
4. Backlit LCD Screen
5. USB Ports
6. Decrease Compressor Pressure Control Button (–)
7. Compressor Power Button
8. Increase Compressor Pressure Control Button (+)
9. Area Light Power Button
10. USB Power Button
11. Built-in 120 Volt AC Charger (under protective cover)
12. Negative (–) Black Clamp
13. Positive (+) Red Clamp
14. Air Hose and Sure Fit®Nozzle
15. Nozzle and Air Hose Storage
16. Nozzle Adapter
17. 12V DC Charging Adapter (optional)
CARACTERÍSTICAS
1. Manija de goma
2. Lúz LED giratoria de área
3. Interruptor de encendido del puente auxiliar de arranque
4. Pantalla LCD retroiluminada
5. Puertos USB
6. Botón de disminución de control de presión del compresor (–)
7. Botón de alimentación del compresor
8. Botón para aumentar la presión del compresor (+)
9. Botón de encendido de la luz de área
10. Botón de alimentación USB
11. Cargador de CA de 120 voltios incorporado (bajo cubierta protectora)
12. Pinza negra del negativo (–)
13. Pinza roja del positivo (+)
14. Manguera e boquilla Sure Fit®
15. Almacenamiento de boquilla y manguera de aire
16. Adaptador de boquilla
17. Adaptador de carga de CC (opcional)
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not approved by the party responsible for compliance could void user’s authority to operate the equipment.
Este dispositivo cumple con la parte 15 de las normas de la Comisión Federal de Comunicaciones de Estados Unidos (FCC). La operación está sujeta a las dos condiciones siguientes: (1) este dispositivo no puede causar interferencia
perjudicial y (2) este mecanismo debe aceptar cualquier interferencia recibida, incluida la in-terferencia que puede provocar una operación no deseada.
Este equipo ha sido probado y se encontró que cumple con los límites para dispositivo digital Clase B, según la parte 15 de las normas de la FCC. Estos límites están diseñados para brindar protección razonable contra interferencia
perjudicial en una instalación residencial. Este equipo genera, usa y puede irradiar energía en frecuencia de radio y, si no se instala y se usa de acuerdo con las instrucciones, puede provocar interferencia perjudicial en las
comunicaciones de radio. Sin embargo, no hay garantía de que la interferencia no ocurra en una instalación en particular. Si el equipo provoca interferencia perjudicial en la recepción de radio o televisión, lo que se puede
determinar al apagar y encender el equipo, el usuario debe tratar de corregir la interferencia mediante una o más de las siguientes medidas:
• Cambiar la orientación o la ubicación de la antena de recepción.
• Aumentar la separación entre el equipo y el receptor.
• Conectar el equipo a un tomacorriente sobre un circuito diferente de aquel al que está conectado el receptor.
• Consultar al vendedor o pedir la ayuda de un técnico en radio y televisión con experiencia.
Los cambios o las modificaciones no aprobados por el partido responsable de conformidad podían anular la autoridad del usuario para funcionar el equipo.
J7C09D_ManualENSP_060921.indd 2-3J7C09D_ManualENSP_060921.indd 2-3 6/9/2021 1:56:29 PM6/9/2021 1:56:29 PM

2 3
FEATURES
CARACTERÍSTICAS
1
6 7 8
2
4 5
910
3
11
12 13
14 15
16
17
FEATURES
1. Rubber Grip Handle
2. Pivoting LED Area Light
3. Jump-Starter Power Switch
4. Backlit LCD Screen
5. USB Ports
6. Decrease Compressor Pressure Control Button (–)
7. Compressor Power Button
8. Increase Compressor Pressure Control Button (+)
9. Area Light Power Button
10. USB Power Button
11. Built-in 120 Volt AC Charger (under protective cover)
12. Negative (–) Black Clamp
13. Positive (+) Red Clamp
14. Air Hose and Sure Fit®Nozzle
15. Nozzle and Air Hose Storage
16. Nozzle Adapter
17. 12V DC Charging Adapter (optional)
CARACTERÍSTICAS
1. Manija de goma
2. Lúz LED giratoria de área
3. Interruptor de encendido del puente auxiliar de arranque
4. Pantalla LCD retroiluminada
5. Puertos USB
6. Botón de disminución de control de presión del compresor (–)
7. Botón de alimentación del compresor
8. Botón para aumentar la presión del compresor (+)
9. Botón de encendido de la luz de área
10. Botón de alimentación USB
11. Cargador de CA de 120 voltios incorporado (bajo cubierta protectora)
12. Pinza negra del negativo (–)
13. Pinza roja del positivo (+)
14. Manguera e boquilla Sure Fit®
15. Almacenamiento de boquilla y manguera de aire
16. Adaptador de boquilla
17. Adaptador de carga de CC (opcional)
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not approved by the party responsible for compliance could void user’s authority to operate the equipment.
Este dispositivo cumple con la parte 15 de las normas de la Comisión Federal de Comunicaciones de Estados Unidos (FCC). La operación está sujeta a las dos condiciones siguientes: (1) este dispositivo no puede causar interferencia
perjudicial y (2) este mecanismo debe aceptar cualquier interferencia recibida, incluida la in-terferencia que puede provocar una operación no deseada.
Este equipo ha sido probado y se encontró que cumple con los límites para dispositivo digital Clase B, según la parte 15 de las normas de la FCC. Estos límites están diseñados para brindar protección razonable contra interferencia
perjudicial en una instalación residencial. Este equipo genera, usa y puede irradiar energía en frecuencia de radio y, si no se instala y se usa de acuerdo con las instrucciones, puede provocar interferencia perjudicial en las
comunicaciones de radio. Sin embargo, no hay garantía de que la interferencia no ocurra en una instalación en particular. Si el equipo provoca interferencia perjudicial en la recepción de radio o televisión, lo que se puede
determinar al apagar y encender el equipo, el usuario debe tratar de corregir la interferencia mediante una o más de las siguientes medidas:
• Cambiar la orientación o la ubicación de la antena de recepción.
• Aumentar la separación entre el equipo y el receptor.
• Conectar el equipo a un tomacorriente sobre un circuito diferente de aquel al que está conectado el receptor.
• Consultar al vendedor o pedir la ayuda de un técnico en radio y televisión con experiencia.
Los cambios o las modificaciones no aprobados por el partido responsable de conformidad podían anular la autoridad del usuario para funcionar el equipo.
J7C09D_ManualENSP_060921.indd 2-3J7C09D_ManualENSP_060921.indd 2-3 6/9/2021 1:56:29 PM6/9/2021 1:56:29 PM

54
DIGITAL LCD SCREEN
PANTALLA DEL LCD DIGITAL
BATTERY STATUS ICON
ICONO DE ESTADO DE LA BATERÍA
DIGITAL DISPLAY (VARIES BY FUNCTION) INDICADOR DIGITAL (VARÍA DEPENDIENDO DE LA FUNCIÓN)
ALARM ICON ICONO DE ALARMA
REVERSE POLARITY ICONS ICONOS DE POLARIDAD INVERSA
CLAMP ICONS ICONOS DE PINZAS
COMPRESSOR PRESSURE INDICATOR INDICADOR DE PRESIÓN DEL COMPRESOR
USB ICON ICONO DE USB
COMPRESSOR ICON ICONO DEL COMPRESOR
JUMP-STARTER ICON ICONO DEL PUENTE AUXILIAR DE ARRANQUE
FAULT ICON ICONO DEL FALLO
VOLTAGE INDICATOR INDICADOR DEL VOLTAJE
SAFETY GUIDELINES /
DEFINITIONS
DANGER: Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided,
may result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
Used without the word, indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not
avoided, may result in property damage.
RISK OF UNSAFE OPERATION. When using tools or equipment, basic
safety precautions should always be followed to reduce the risk of personal injury.
Improper operation, maintenance or modification of tools or equipment could
result in serious injury and property damage. There are certain applications for
which tools and equipment are designed. Manufacturer strongly recommends that
this product NOT be modified and/or used for any application other than for which
it was designed. Read and understand all warnings and operating instructions
before using any tool or equipment.
READ ALL
INSTRUCTIONS
WARNING: Read and understand this instruction manual before
using this unit. Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
IMPORTANT SAFETY
INSTRUCTIONS
GENERAL SAFETY WARNINGS AND INSTRUCTIONS
• This unit was designed for household use only.
WARNING – Risk of fire, electric shock, burst hazard, or injury to
persons or property:
• Avoid dangerous environments. Don’t use appliances in damp or wet locations.
Don’t use appliances in the rain.
• Keep children away. All visitors should be kept at a distance from work area.
• Dress properly. Do not wear loose clothing or jewelry. They can be caught in
moving parts. Rubber gloves and substantial, non-skid footwear are recommended
when working outdoors. Wear protective hair covering to contain long hair.
• Store idle appliance indoors. When not in use, appliances should be stored
indoors in dry, and high or locked-up place – out of reach of children.
• Don’t abuse cord. Never carry appliance by cord or yank it to disconnect from
receptacle. Keep cord from heat, oil, and sharp edges.
• Disconnect appliances. Disconnect the appliance from the power supply when
not in use, before servicing, and when changing accessories.
• Ground Fault Circuit Interrupter (GFCI) protection should be provided on
the circuits or outlets to be used. Receptacles are available having built in GFCI
protection and may be used for this measure of safety.
• Use of accessories and attachments. The use of any accessory or attachment
not recommended for use with this appliance could be hazardous. Refer to the
accessory section of this manual for further details.
• Stay alert. Use common sense. Do not operate this equipment when you are
tired or impaired.
• Check for damaged parts. Any part that is damaged should be replaced by the
manufacturer before further use. Do not use tool if switch does not turn it on and
off. Contact the manufacturer at 1-877-571-2391 for more information.
• Do not operate this appliance near flammable liquids or in gaseous or
explosive atmospheres. Motors in these tools normally spark, and the sparks
might ignite fumes.
• Never submerge this unit in water; do not expose it to rain, snow or use
when wet.
• To reduce risk of electric shock, disconnect the unit from any power source
before attempting maintenance or cleaning. Turning off controls without
disconnecting will not reduce this risk.
• This equipment employs parts (switches, relays, etc.) that produce arcs or
sparks. Therefore, if used in a garage or enclosed area, the unit MUST be placed
not less than 18 inches above the floor.
• Do not insert foreign objects into the USB ports or the 120V AC outlet.
SPECIFIC SAFETY INSTRUCTIONS FOR CHARGING
THIS UNIT
• IMPORTANT: This unit is delivered in a partially charged state. Fully charge unit
with a household extension cord for a full 40 hours or until the battery status icon
shows 4 solid bars before using for the first time. You cannot overcharge the unit
using the AC charging method.
• To recharge this unit, use only the built-in AC charger.
• All functions should be turned off when the unit is charging or not in use. Make
sure all switches are in the OFF position before connection to a power source or
load.
EXTENSION CORDS:
WARNING: Use of improper extension cord could result in a risk of fire
and electric shock. When using an extension cord, make sure that the pins of the
extension cord are the same number, size and shape as those in the charger; and
be sure to use one heavy enough to carry the current your product will draw. An
undersized cord will cause a drop in line voltage resulting in loss of power and
overheating. The following table shows the correct size to use depending on cord
length and nameplate ampere rating. If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord.
MINIMUM GAUGE FOR CORD SETS
Volts Total Length of Cord in Feet (meters)
120V 0-25 26-50 51-100 101-150
(0-7.6m) (7.6-15.2m) (15.2-30.4m) (30.4-45.7m)
240V 0-50 51-100 101-200 201-300
(0-15.2m) (15.2-30.4m) (30.4-60.9m) (60.9-91.4m)
Ampere Rating Extension Cord Length
More Not more 0’-25’ 26’-50’ 51’-100’ 101’ -150’
Than Than American Wire Gauge (AWG)
0 - 6 18 16 16 14
6 - 10 18 16 14 12
10 - 12 16 16 14 12
12 - 16 14 12 Not Recommended
When an extension cord is used, make sure that:
– the pins of extension cord are the same number, size and shape as those in
the charger,
– the extension cord is properly wired and in good electrical condition,
– the wire size is large enough for the AC rating of the charger.
CAUTION – To reduce the risk of injury or property damage:
Pull the extension cord by the plug rather than the cord when disconnecting from
the built-in 120 volt AC charger or the AC outlet.
SPECIFIC SAFETY INSTRUCTIONS FOR JUMP-STARTERS
WARNING: Burst hazard:
Do not use the unit for charging dry-cell batteries that are commonly used with
home appliances. These batteries may burst and cause injury to persons and
damage property. Use the unit for charging/boosting a lead-acid battery only. It is
not intended to supply power to a low-voltage electrical system other than in a
starter-motor application.
• Use of an attachment not supplied, recommended or sold by manufacturer
specifically for use with this unit may result in a risk of electrical shock and injury
to persons.
WARNING: Risk of explosive gases:
• Working in the vicinity of a lead acid battery is dangerous. Batteries generate
explosive gases during normal battery operation. For this reason, it is of the
utmost importance that each time before using the jump-starter you read this
manual and follow instructions exactly.
• To reduce the risk of battery explosion, follow these instructions and those
published by the battery manufacturer and manufacturer of any equipment you
intend to use in the vicinity of the battery. Review cautionary markings on these
products and on the engine.
CAUTION – To reduce the risk of injury or property damage:
• NEVER ATTEMPT TO JUMP-START OR CHARGE A FROZEN BATTERY.
J7C09D_ManualENSP_060921.indd 4-5J7C09D_ManualENSP_060921.indd 4-5 6/9/2021 1:56:29 PM6/9/2021 1:56:29 PM

54
DIGITAL LCD SCREEN
PANTALLA DEL LCD DIGITAL
BATTERY STATUS ICON
ICONO DE ESTADO DE LA BATERÍA
DIGITAL DISPLAY (VARIES BY FUNCTION) INDICADOR DIGITAL (VARÍA DEPENDIENDO DE LA FUNCIÓN)
ALARM ICON ICONO DE ALARMA
REVERSE POLARITY ICONS ICONOS DE POLARIDAD INVERSA
CLAMP ICONS ICONOS DE PINZAS
COMPRESSOR PRESSURE INDICATOR INDICADOR DE PRESIÓN DEL COMPRESOR
USB ICON ICONO DE USB
COMPRESSOR ICON ICONO DEL COMPRESOR
JUMP-STARTER ICON ICONO DEL PUENTE AUXILIAR DE ARRANQUE
FAULT ICON ICONO DEL FALLO
VOLTAGE INDICATOR INDICADOR DEL VOLTAJE
SAFETY GUIDELINES /
DEFINITIONS
DANGER: Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided,
may result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
Used without the word, indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not
avoided, may result in property damage.
RISK OF UNSAFE OPERATION. When using tools or equipment, basic
safety precautions should always be followed to reduce the risk of personal injury.
Improper operation, maintenance or modification of tools or equipment could
result in serious injury and property damage. There are certain applications for
which tools and equipment are designed. Manufacturer strongly recommends that
this product NOT be modified and/or used for any application other than for which
it was designed. Read and understand all warnings and operating instructions
before using any tool or equipment.
READ ALL
INSTRUCTIONS
WARNING: Read and understand this instruction manual before
using this unit. Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
IMPORTANT SAFETY
INSTRUCTIONS
GENERAL SAFETY WARNINGS AND INSTRUCTIONS
• This unit was designed for household use only.
WARNING – Risk of fire, electric shock, burst hazard, or injury to
persons or property:
• Avoid dangerous environments. Don’t use appliances in damp or wet locations.
Don’t use appliances in the rain.
• Keep children away. All visitors should be kept at a distance from work area.
• Dress properly. Do not wear loose clothing or jewelry. They can be caught in
moving parts. Rubber gloves and substantial, non-skid footwear are recommended
when working outdoors. Wear protective hair covering to contain long hair.
• Store idle appliance indoors. When not in use, appliances should be stored
indoors in dry, and high or locked-up place – out of reach of children.
• Don’t abuse cord. Never carry appliance by cord or yank it to disconnect from
receptacle. Keep cord from heat, oil, and sharp edges.
• Disconnect appliances. Disconnect the appliance from the power supply when
not in use, before servicing, and when changing accessories.
• Ground Fault Circuit Interrupter (GFCI) protection should be provided on
the circuits or outlets to be used. Receptacles are available having built in GFCI
protection and may be used for this measure of safety.
• Use of accessories and attachments. The use of any accessory or attachment
not recommended for use with this appliance could be hazardous. Refer to the
accessory section of this manual for further details.
• Stay alert. Use common sense. Do not operate this equipment when you are
tired or impaired.
• Check for damaged parts. Any part that is damaged should be replaced by the
manufacturer before further use. Do not use tool if switch does not turn it on and
off. Contact the manufacturer at 1-877-571-2391 for more information.
• Do not operate this appliance near flammable liquids or in gaseous or
explosive atmospheres. Motors in these tools normally spark, and the sparks
might ignite fumes.
• Never submerge this unit in water; do not expose it to rain, snow or use
when wet.
• To reduce risk of electric shock, disconnect the unit from any power source
before attempting maintenance or cleaning. Turning off controls without
disconnecting will not reduce this risk.
• This equipment employs parts (switches, relays, etc.) that produce arcs or
sparks. Therefore, if used in a garage or enclosed area, the unit MUST be placed
not less than 18 inches above the floor.
• Do not insert foreign objects into the USB ports or the 120V AC outlet.
SPECIFIC SAFETY INSTRUCTIONS FOR CHARGING
THIS UNIT
• IMPORTANT: This unit is delivered in a partially charged state. Fully charge unit
with a household extension cord for a full 40 hours or until the battery status icon
shows 4 solid bars before using for the first time. You cannot overcharge the unit
using the AC charging method.
• To recharge this unit, use only the built-in AC charger.
• All functions should be turned off when the unit is charging or not in use. Make
sure all switches are in the OFF position before connection to a power source or
load.
EXTENSION CORDS:
WARNING: Use of improper extension cord could result in a risk of fire
and electric shock. When using an extension cord, make sure that the pins of the
extension cord are the same number, size and shape as those in the charger; and
be sure to use one heavy enough to carry the current your product will draw. An
undersized cord will cause a drop in line voltage resulting in loss of power and
overheating. The following table shows the correct size to use depending on cord
length and nameplate ampere rating. If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord.
MINIMUM GAUGE FOR CORD SETS
Volts Total Length of Cord in Feet (meters)
120V 0-25 26-50 51-100 101-150
(0-7.6m) (7.6-15.2m) (15.2-30.4m) (30.4-45.7m)
240V 0-50 51-100 101-200 201-300
(0-15.2m) (15.2-30.4m) (30.4-60.9m) (60.9-91.4m)
Ampere Rating Extension Cord Length
More Not more 0’-25’ 26’-50’ 51’-100’ 101’ -150’
Than Than American Wire Gauge (AWG)
0 - 6 18 16 16 14
6 - 10 18 16 14 12
10 - 12 16 16 14 12
12 - 16 14 12 Not Recommended
When an extension cord is used, make sure that:
– the pins of extension cord are the same number, size and shape as those in
the charger,
– the extension cord is properly wired and in good electrical condition,
– the wire size is large enough for the AC rating of the charger.
CAUTION – To reduce the risk of injury or property damage:
Pull the extension cord by the plug rather than the cord when disconnecting from
the built-in 120 volt AC charger or the AC outlet.
SPECIFIC SAFETY INSTRUCTIONS FOR JUMP-STARTERS
WARNING: Burst hazard:
Do not use the unit for charging dry-cell batteries that are commonly used with
home appliances. These batteries may burst and cause injury to persons and
damage property. Use the unit for charging/boosting a lead-acid battery only. It is
not intended to supply power to a low-voltage electrical system other than in a
starter-motor application.
• Use of an attachment not supplied, recommended or sold by manufacturer
specifically for use with this unit may result in a risk of electrical shock and injury
to persons.
WARNING: Risk of explosive gases:
• Working in the vicinity of a lead acid battery is dangerous. Batteries generate
explosive gases during normal battery operation. For this reason, it is of the
utmost importance that each time before using the jump-starter you read this
manual and follow instructions exactly.
• To reduce the risk of battery explosion, follow these instructions and those
published by the battery manufacturer and manufacturer of any equipment you
intend to use in the vicinity of the battery. Review cautionary markings on these
products and on the engine.
CAUTION – To reduce the risk of injury or property damage:
• NEVER ATTEMPT TO JUMP-START OR CHARGE A FROZEN BATTERY.
J7C09D_ManualENSP_060921.indd 4-5J7C09D_ManualENSP_060921.indd 4-5 6/9/2021 1:56:29 PM6/9/2021 1:56:29 PM

6 7
• Vehicles that have on-board computerized systems may be damaged if vehicle
battery is jump-started. Before jump-starting, read the vehicle’s owner’s manual to
confirm that external-starting assistance is suitable.
• Never smoke or allow a spark or flame in vicinity of vehicle battery, engine or
power station
• Stay clear of fan blades, belts, pulleys, and other parts that can cause injury to
persons.
• Be extra careful to avoid dropping a metal tool onto the battery. It might spark or
short-circuit the battery or another electrical part and could cause an explosion.
• Jump-start procedures should only be performed in a safe, dry, well-ventilated area.
• Always store battery clamps when not in use. Never touch battery clamps together.
This can cause dangerous sparks, power arcing and/or explosion.
• When using this unit close to the vehicle’s battery and engine, stand the unit on a
flat, stable surface, and be sure to keep all clamps, cords, clothing and body parts
away from moving vehicle parts.
• Never allow red and black clamps to touch each other or another common
metal conductor – this could cause damage to the unit and/or create a sparking/
explosion hazard.
– For negative-grounded systems, connect the positive (red) clamp to the positive
ungrounded battery post and the negative (black) clamp to the vehicle chassis
or engine block away from the battery. Do not connect the clamp to the
carburetor, fuel lines or sheet-metal body parts. Connect to a heavy gauge
metal part of the frame or engine block.
– For positive-grounded systems, connect the negative (black) clamp to the
negative ungrounded battery post and the positive (red) clamp to the vehicle
chassis or engine block away from the battery. Do not connect the clamp to
the carburetor, fuel lines or sheet-metal body parts. Connect to a heavy gauge
metal part of the frame or engine block.
• If the clamps are connected incorrectly with regard to polarity, the backlit LCD
screen will display the Battery Status Icon, Battery Voltage Indicator, and the Clamp
Icons. The Alarm Icon, the “+” and ”–” signs and the Reverse Polarity Icons will
flash and the unit will sound a continuous alarm until the clamps are disconnected.
Disconnect the clamps and reconnect to battery with correct polarity.
• Always disconnect the negative (black) jumper cable first, followed by the positive
(red) jumper cable, except for positive grounded systems.
• Do not expose battery to fire or intense heat since it may explode. Before
disposing of the battery, protect exposed terminals with heavy-duty electrical tape
to prevent shorting (shorting can result in injury or fire).
• Place this unit as far away from the battery as cables permit.
• Never allow battery acid to come in contact with this unit.
• Do not operate this unit in a closed area or restrict ventilation in any way.
• This system is designed to be used only on vehicles with a 12 volt DC battery
system. Do not connect to a 6 volt or 24 volt battery system.
• This system is not designed to be used as a replacement for a vehicular battery. Do
not attempt to operate a vehicle that does not have a battery installed.
• Excessive engine cranking can damage a vehicle’s starter motor. If the engine
fails to start after the recommended number of attempts, discontinue jump-start
procedures and look for other problems that may need to be corrected.
• Do not use this Jump-Starter on a watercraft. It is not qualified for marine
applications.
• Although this unit contains a non-spillable battery, it is recommended that unit be
kept upright during storage, use and recharging. To avoid possible damage that
may shorten the unit’s working life, protect it from direct sunlight, direct heat and/
or moisture.
SPECIFIC SAFETY INSTRUCTIONS FOR THE USB PORTS
• Do not insert foreign objects into the USB Ports.
• Do not attach USB hubs or more than one personal electronic device to each USB
Port.
• Do not use this unit to operate appliances that require more than 3.1A (5V) to
operate from each of the USB Ports.
• Some household USB-powered electronics will not operate with this unit.
SPECIFIC SAFETY INSTRUCTIONS FOR COMPRESSORS
CAUTION – To reduce the risk of injury or property damage:
• Never leave the compressor unattended while in use.
• Do not operate compressor continuously for longer than approximately 10
minutes, depending on ambient temperatures, as it may overheat. This could
damage the compressor. Follow the instructions in the “Portable Compressor”
section.
WARNING – Burst hazard: Bursting articles can cause serious injury.
• Carefully follow instructions on articles to be inflated.
• Never exceed the recommended pressure listed in instructions on articles to be
inflated. If no pressure is given, contact article manufacturer before inflating.
• Monitor the pressure at all times on the LCD screen.
PERSONAL SAFETY
When working with lead acid batteries, always make sure immediate assistance is
available in case of accident or emergency.
Remove personal metal items such as rings, bracelets, necklaces and watches when
working with a lead acid battery. A lead acid battery can produce a short circuit
current high enough to weld a ring, or similar metal object, to skin, causing a
severe burn.
Do not wear vinyl clothing when jump-starting a vehicle. Friction can cause
dangerous static-electrical sparks.
Always have protective eyewear when using this product: contact with battery acid
may cause blindness and/or severe burns. Be aware of first aid procedures in case of
accidental contact with battery acid.
Have plenty of fresh water and soap nearby in case battery acid contacts skin.
• SKIN: If battery acid comes in contact with skin, rinse immediately with water,
then wash thoroughly with soap and water. If redness, pain, or irritation occurs,
seek immediate medical attention.
• EYES: If battery acid comes in contact with eyes, flush eyes immediately, for a
minimum of 15 minutes and seek immediate medical attention.
• LCD LIQUID CRYSTAL DISPLAY: If liquid crystal comes in contact with
your skin: Wash area off completely with plenty of water. Remove contaminated
clothing. If liquid crystal gets into your eye: Flush the affected eye with clean
water and then seek medical attention. If liquid crystal is swallowed: Flush
your mouth thoroughly with water. Drink large quantities of water and induce
vomiting. Then seek medical attention.
SAVE THESE
INSTRUCTIONS
INTRODUCTION
Congratulations on purchasing your new Portable Power Station. Read this
Instruction Manual and follow the instructions carefully before using this
unit.
OVERVIEW
Common Actions and Unit Responses
The following actions turn the unit on and activate the LCD screen:
Press the LED Area
Light Power Button.
(Refer to the "LED Area
Light" section.)
A beep will sound and the Area Light will turn on.
The backlight will turn on for 10 seconds (only).
The LCD screen will continue to display the Battery
Status Icon and Battery Voltage Indicator. The unit
remains on until the LED Area Light Power Button
is pressed again to turn it off.
Press the USB Power
Button. (Refer to the
"USB Ports" section.)
A beep will sound and the USB Ports will turn on.
The backlight will turn on for 10 seconds (only).
The LCD screen will display the Battery Status
Icon, Battery Voltage Indicator, and the USB Icon;
indicating the three USB Ports are active. The unit
remains on until the USB Power Button is pressed
again to turn it off.
Press the Compressor
Power Button. (Refer
to the "Portable
Compressor" section.)
A beep will sound and the backlit LCD screen will
display the Battery Status Icon, "XXX" PSI and the
Compressor Icon. If no further actions are taken
after 1 minute, the unit will display the Battery
Status Icon and Battery Voltage Indicator for 10
seconds before automatically turning off.
If the Jump-Starter
Switch has been
turned to the on
position and the
clamps are not
connected to a battery
(refer to the “Jump-
Starting Your Vehicle”
section) ...
... a two-second warning will sound every 10
seconds. The backlit LCD screen will display the
Battery Status Icon, Battery Voltage Indicator, the
Clamp Icons, and the “+” and ”–” signs. The Alarm
Icon and the Jump-Starter Icon will flash. The unit
remains on until the Jump-Starter Power Switch is
switched off and then displays the battery status
icon and the voltage of digital display for 10
seconds before automatic shut down.
If the clamp
connections to the
battery’s positive and
negative terminals
are reversed (refer
to the "Jump-Starter"
section) …
… the backlit LCD screen will display the Battery
Status Icon, Battery Voltage Indicator, and the
Clamp Icons. The Alarm Icon, the “+” and ”–”
signs and the Reverse Polarity Icons will flash and
the unit will sound a warning continuously until
the clamps are disconnected from the battery.
Whenever the
clamps are properly
connected to a battery
(refer to the “Jump-
Starting Your Vehicle”
section) ...
... a beep will sound and the backlit LCD screen
will display the Battery Status Icon, Battery Voltage
Indicator, the Clamp Icons, and the “+” and ”–”
signs. The Jump-Starter Icon will flash. The unit
remains on until the clamps are
disconnected from the battery.
When the unit is
charging or recharging
using the built-in
120 Volt AC Charger
(refer to the "Charging/
Recharging" section) …
… the backlight will turn on for 10 seconds (only).
The LCD screen will continue to display the Battery
Status Icon and Battery Voltage Indicator. The bars
on the Battery Status Icon will change from empty
to solid (bottom to top) repeatedly.
Note: The unit will automatically power off once ALL the functions are turned off.
VIEWING BATTERY STATUS
The Battery Status Icon and Battery Voltage Indicator indicate the battery charge
level as follows.
• If the battery charge level is at full capacity, four solid bars will display.
• If the battery is partially charged, two or three solid bars will display.
• If the battery is nearly empty, one solid bar will display. The unit should be
charged at this time.
• If the battery is completely empty, four blank bars will display. The unit MUST be
charged at this time or the unit’s built-in low voltage protection will activate. The
empty Battery Status Icon will flash for a short period of time before automatic
shut down. The unit will not operate until the battery is recharged.
CHARGING/RECHARGING
This unit is delivered in a partially charged state – you must fully charge it before
using it for the first time. Initial AC charge should be for 40 hours or until the Battery
Status Icon shows 4 solid bars.
Lead-acid batteries require routine maintenance to ensure a full charge and long
battery life. All batteries lose energy from self-discharge over time and more
rapidly at higher temperatures. Therefore, batteries need periodic charging to
replace energy lost through self-discharge. When the unit is not in frequent use,
manufacturer recommends the battery should be recharged at least every 30 days
and after each use.
Failure to keep the battery charged will cause permanent damage and result in
poor Jump-Starting performance.
IMPORTANT NOTES:
• Recharging the battery after each use will prolong battery life; frequent heavy
discharges between recharges and/or overcharging will reduce battery life.
• Make sure all other unit functions are turned off during recharging, as this can
slow the recharging process.
• If you know the unit is discharged, but the battery icon displays four solid bars as
if the unit is fully charged when connected to a charging power source, this may
be due to the internal battery having high impedance. The manufacturer suggests
leaving the unit charging for a period of 40 hours using the built-in AC charger
before use.
Charging/Recharging Using the Built-In 120 Volt AC
Charger and AC Extension Cord (not included)
1. Lift the protective cover of the built-in 120 Volt AC Charger (refer to the
“Features section to locate). Connect an extension cord to the unit. Plug the
other end of the cord into a standard 120-volt AC wall outlet. When the unit
is properly connected to an AC power source, the LCD screen will display the
following:
The bars on the Battery Status Icon represent the charge level of the unit’s
internal battery. The bars on the Battery Status Icon will change from empty to
solid (bottom to top) repeatedly to indicate the unit is charging. The backlight
will turn on for 10 seconds (only).
2. Charge for approximately 40 hours or until the Battery Status Icon shows 4
solid bars.
3. When charging is complete, unplug the AC extension cord from the AC outlet
and then disconnect it from the unit.
12 VOLT DC CHARGING METHOD
Charging the unit from an external 12 volt DC power source requires the use of the
optional 12 Volt DC adapter (not included).
1. Lift the protective cover of the Built-in 120 V AC Charger located on the back
of the unit. Make sure the AC extension cord is disconnected from the 120 V
AC Charger.
2. Insert the barrel tip of the 12 V DC Charging Adaptor into the 12 V DC
Charging Port on the back of the unit.
3. Insert the grooved tip of the 12 V DC Charging Adaptor into the vehicle’s 12
V DC accessory outlet or other functioning 12 V DC power source. The 12V
DC Charging Adapter LED Indicator will light to indicate the unit is properly
plugged into the 12V DC power source and is in charging.
4. Charge the unit until the Battery Status Icon shows 4 solid bars when either
the Area Light, USB or Compressor Power Button is pressed (with the adapter
unplugged from the unit).
5. When charging is complete, remove the DC Charging Adaptor from the unit
and the 12 V DC power source when not in use and store in a safe place.
Notes: Some vehicles require that the ignition be switched to the accessory outlet position in order to power
the accessory outlet. Do not leave the unit unattended when charging using the this method.
JUMP-STARTER
This Jump-Starter is equipped with an On/Off Power Switch. Once the connections
are properly made, turn the switch on to jump-start the vehicle.
IMPORTANT: Make sure the Compressor Power Button has been turned off before
attempting to use the unit as a Jump-Starter.
1. Turn off vehicle ignition and all accessories (radio, A/C, lights, connected cell
phone chargers, etc.). Place vehicle in “park” and set the emergency brake.
2. Make sure the Jump-Starter Power Switch is turned to off.
3. Remove jumper clamps from clamp tabs. Connect the red clamp first, then the
black clamp.
4. Procedure for jump-starting a NEGATIVE GROUNDED SYSTEM (negative
battery terminal is connected to chassis) (MOST COMMON)
4a. Connect positive (+) red clamp to vehicle battery’s positive terminal.
4b. Connect negative (–) black clamp to chassis or a solid, non-moving, metal
vehicle component or body part. Never clamp directly to negative battery
terminal or moving part. Refer to the automobile owner’s manual.
5. Procedure for jump-starting POSITIVE GROUND SYSTEMS
Notes: In the rare event that the vehicle to be started has a Positive Grounded System (positive battery
terminal is connected to chassis), replace steps 4a and 4b above with steps 5a and 5b, then
proceed to step 6.
5a. Connect negative (–) black clamp to vehicle battery’s negative terminal.
5b. Connect positive (+) red clamp to vehicle chassis or a solid, non-moving,
metal vehicle component or body part. Never clamp directly to positive
battery terminal or moving part. Refer to the automobile owner’s
manual.
6. When clamps are connected properly, turn the Jump-Starter Power Switch to
ON. The backlit LCD screen will display the following:
J7C09D_ManualENSP_060921.indd 6-7J7C09D_ManualENSP_060921.indd 6-7 6/9/2021 1:56:29 PM6/9/2021 1:56:29 PM

6 7
• Vehicles that have on-board computerized systems may be damaged if vehicle
battery is jump-started. Before jump-starting, read the vehicle’s owner’s manual to
confirm that external-starting assistance is suitable.
• Never smoke or allow a spark or flame in vicinity of vehicle battery, engine or
power station
• Stay clear of fan blades, belts, pulleys, and other parts that can cause injury to
persons.
• Be extra careful to avoid dropping a metal tool onto the battery. It might spark or
short-circuit the battery or another electrical part and could cause an explosion.
• Jump-start procedures should only be performed in a safe, dry, well-ventilated area.
• Always store battery clamps when not in use. Never touch battery clamps together.
This can cause dangerous sparks, power arcing and/or explosion.
• When using this unit close to the vehicle’s battery and engine, stand the unit on a
flat, stable surface, and be sure to keep all clamps, cords, clothing and body parts
away from moving vehicle parts.
• Never allow red and black clamps to touch each other or another common
metal conductor – this could cause damage to the unit and/or create a sparking/
explosion hazard.
– For negative-grounded systems, connect the positive (red) clamp to the positive
ungrounded battery post and the negative (black) clamp to the vehicle chassis
or engine block away from the battery. Do not connect the clamp to the
carburetor, fuel lines or sheet-metal body parts. Connect to a heavy gauge
metal part of the frame or engine block.
– For positive-grounded systems, connect the negative (black) clamp to the
negative ungrounded battery post and the positive (red) clamp to the vehicle
chassis or engine block away from the battery. Do not connect the clamp to
the carburetor, fuel lines or sheet-metal body parts. Connect to a heavy gauge
metal part of the frame or engine block.
• If the clamps are connected incorrectly with regard to polarity, the backlit LCD
screen will display the Battery Status Icon, Battery Voltage Indicator, and the Clamp
Icons. The Alarm Icon, the “+” and ”–” signs and the Reverse Polarity Icons will
flash and the unit will sound a continuous alarm until the clamps are disconnected.
Disconnect the clamps and reconnect to battery with correct polarity.
• Always disconnect the negative (black) jumper cable first, followed by the positive
(red) jumper cable, except for positive grounded systems.
• Do not expose battery to fire or intense heat since it may explode. Before
disposing of the battery, protect exposed terminals with heavy-duty electrical tape
to prevent shorting (shorting can result in injury or fire).
• Place this unit as far away from the battery as cables permit.
• Never allow battery acid to come in contact with this unit.
• Do not operate this unit in a closed area or restrict ventilation in any way.
• This system is designed to be used only on vehicles with a 12 volt DC battery
system. Do not connect to a 6 volt or 24 volt battery system.
• This system is not designed to be used as a replacement for a vehicular battery. Do
not attempt to operate a vehicle that does not have a battery installed.
• Excessive engine cranking can damage a vehicle’s starter motor. If the engine
fails to start after the recommended number of attempts, discontinue jump-start
procedures and look for other problems that may need to be corrected.
• Do not use this Jump-Starter on a watercraft. It is not qualified for marine
applications.
• Although this unit contains a non-spillable battery, it is recommended that unit be
kept upright during storage, use and recharging. To avoid possible damage that
may shorten the unit’s working life, protect it from direct sunlight, direct heat and/
or moisture.
SPECIFIC SAFETY INSTRUCTIONS FOR THE USB PORTS
• Do not insert foreign objects into the USB Ports.
• Do not attach USB hubs or more than one personal electronic device to each USB
Port.
• Do not use this unit to operate appliances that require more than 3.1A (5V) to
operate from each of the USB Ports.
• Some household USB-powered electronics will not operate with this unit.
SPECIFIC SAFETY INSTRUCTIONS FOR COMPRESSORS
CAUTION – To reduce the risk of injury or property damage:
• Never leave the compressor unattended while in use.
• Do not operate compressor continuously for longer than approximately 10
minutes, depending on ambient temperatures, as it may overheat. This could
damage the compressor. Follow the instructions in the “Portable Compressor”
section.
WARNING – Burst hazard: Bursting articles can cause serious injury.
• Carefully follow instructions on articles to be inflated.
• Never exceed the recommended pressure listed in instructions on articles to be
inflated. If no pressure is given, contact article manufacturer before inflating.
• Monitor the pressure at all times on the LCD screen.
PERSONAL SAFETY
When working with lead acid batteries, always make sure immediate assistance is
available in case of accident or emergency.
Remove personal metal items such as rings, bracelets, necklaces and watches when
working with a lead acid battery. A lead acid battery can produce a short circuit
current high enough to weld a ring, or similar metal object, to skin, causing a
severe burn.
Do not wear vinyl clothing when jump-starting a vehicle. Friction can cause
dangerous static-electrical sparks.
Always have protective eyewear when using this product: contact with battery acid
may cause blindness and/or severe burns. Be aware of first aid procedures in case of
accidental contact with battery acid.
Have plenty of fresh water and soap nearby in case battery acid contacts skin.
• SKIN: If battery acid comes in contact with skin, rinse immediately with water,
then wash thoroughly with soap and water. If redness, pain, or irritation occurs,
seek immediate medical attention.
• EYES: If battery acid comes in contact with eyes, flush eyes immediately, for a
minimum of 15 minutes and seek immediate medical attention.
• LCD LIQUID CRYSTAL DISPLAY: If liquid crystal comes in contact with
your skin: Wash area off completely with plenty of water. Remove contaminated
clothing. If liquid crystal gets into your eye: Flush the affected eye with clean
water and then seek medical attention. If liquid crystal is swallowed: Flush
your mouth thoroughly with water. Drink large quantities of water and induce
vomiting. Then seek medical attention.
SAVE THESE
INSTRUCTIONS
INTRODUCTION
Congratulations on purchasing your new Portable Power Station. Read this
Instruction Manual and follow the instructions carefully before using this
unit.
OVERVIEW
Common Actions and Unit Responses
The following actions turn the unit on and activate the LCD screen:
Press the LED Area
Light Power Button.
(Refer to the "LED Area
Light" section.)
A beep will sound and the Area Light will turn on.
The backlight will turn on for 10 seconds (only).
The LCD screen will continue to display the Battery
Status Icon and Battery Voltage Indicator. The unit
remains on until the LED Area Light Power Button
is pressed again to turn it off.
Press the USB Power
Button. (Refer to the
"USB Ports" section.)
A beep will sound and the USB Ports will turn on.
The backlight will turn on for 10 seconds (only).
The LCD screen will display the Battery Status
Icon, Battery Voltage Indicator, and the USB Icon;
indicating the three USB Ports are active. The unit
remains on until the USB Power Button is pressed
again to turn it off.
Press the Compressor
Power Button. (Refer
to the "Portable
Compressor" section.)
A beep will sound and the backlit LCD screen will
display the Battery Status Icon, "XXX" PSI and the
Compressor Icon. If no further actions are taken
after 1 minute, the unit will display the Battery
Status Icon and Battery Voltage Indicator for 10
seconds before automatically turning off.
If the Jump-Starter
Switch has been
turned to the on
position and the
clamps are not
connected to a battery
(refer to the “Jump-
Starting Your Vehicle”
section) ...
... a two-second warning will sound every 10
seconds. The backlit LCD screen will display the
Battery Status Icon, Battery Voltage Indicator, the
Clamp Icons, and the “+” and ”–” signs. The Alarm
Icon and the Jump-Starter Icon will flash. The unit
remains on until the Jump-Starter Power Switch is
switched off and then displays the battery status
icon and the voltage of digital display for 10
seconds before automatic shut down.
If the clamp
connections to the
battery’s positive and
negative terminals
are reversed (refer
to the "Jump-Starter"
section) …
… the backlit LCD screen will display the Battery
Status Icon, Battery Voltage Indicator, and the
Clamp Icons. The Alarm Icon, the “+” and ”–”
signs and the Reverse Polarity Icons will flash and
the unit will sound a warning continuously until
the clamps are disconnected from the battery.
Whenever the
clamps are properly
connected to a battery
(refer to the “Jump-
Starting Your Vehicle”
section) ...
... a beep will sound and the backlit LCD screen
will display the Battery Status Icon, Battery Voltage
Indicator, the Clamp Icons, and the “+” and ”–”
signs. The Jump-Starter Icon will flash. The unit
remains on until the clamps are
disconnected from the battery.
When the unit is
charging or recharging
using the built-in
120 Volt AC Charger
(refer to the "Charging/
Recharging" section) …
… the backlight will turn on for 10 seconds (only).
The LCD screen will continue to display the Battery
Status Icon and Battery Voltage Indicator. The bars
on the Battery Status Icon will change from empty
to solid (bottom to top) repeatedly.
Note: The unit will automatically power off once ALL the functions are turned off.
VIEWING BATTERY STATUS
The Battery Status Icon and Battery Voltage Indicator indicate the battery charge
level as follows.
• If the battery charge level is at full capacity, four solid bars will display.
• If the battery is partially charged, two or three solid bars will display.
• If the battery is nearly empty, one solid bar will display. The unit should be
charged at this time.
• If the battery is completely empty, four blank bars will display. The unit MUST be
charged at this time or the unit’s built-in low voltage protection will activate. The
empty Battery Status Icon will flash for a short period of time before automatic
shut down. The unit will not operate until the battery is recharged.
CHARGING/RECHARGING
This unit is delivered in a partially charged state – you must fully charge it before
using it for the first time. Initial AC charge should be for 40 hours or until the Battery
Status Icon shows 4 solid bars.
Lead-acid batteries require routine maintenance to ensure a full charge and long
battery life. All batteries lose energy from self-discharge over time and more
rapidly at higher temperatures. Therefore, batteries need periodic charging to
replace energy lost through self-discharge. When the unit is not in frequent use,
manufacturer recommends the battery should be recharged at least every 30 days
and after each use.
Failure to keep the battery charged will cause permanent damage and result in
poor Jump-Starting performance.
IMPORTANT NOTES:
• Recharging the battery after each use will prolong battery life; frequent heavy
discharges between recharges and/or overcharging will reduce battery life.
• Make sure all other unit functions are turned off during recharging, as this can
slow the recharging process.
• If you know the unit is discharged, but the battery icon displays four solid bars as
if the unit is fully charged when connected to a charging power source, this may
be due to the internal battery having high impedance. The manufacturer suggests
leaving the unit charging for a period of 40 hours using the built-in AC charger
before use.
Charging/Recharging Using the Built-In 120 Volt AC
Charger and AC Extension Cord (not included)
1. Lift the protective cover of the built-in 120 Volt AC Charger (refer to the
“Features section to locate). Connect an extension cord to the unit. Plug the
other end of the cord into a standard 120-volt AC wall outlet. When the unit
is properly connected to an AC power source, the LCD screen will display the
following:
The bars on the Battery Status Icon represent the charge level of the unit’s
internal battery. The bars on the Battery Status Icon will change from empty to
solid (bottom to top) repeatedly to indicate the unit is charging. The backlight
will turn on for 10 seconds (only).
2. Charge for approximately 40 hours or until the Battery Status Icon shows 4
solid bars.
3. When charging is complete, unplug the AC extension cord from the AC outlet
and then disconnect it from the unit.
12 VOLT DC CHARGING METHOD
Charging the unit from an external 12 volt DC power source requires the use of the
optional 12 Volt DC adapter (not included).
1. Lift the protective cover of the Built-in 120 V AC Charger located on the back
of the unit. Make sure the AC extension cord is disconnected from the 120 V
AC Charger.
2. Insert the barrel tip of the 12 V DC Charging Adaptor into the 12 V DC
Charging Port on the back of the unit.
3. Insert the grooved tip of the 12 V DC Charging Adaptor into the vehicle’s 12
V DC accessory outlet or other functioning 12 V DC power source. The 12V
DC Charging Adapter LED Indicator will light to indicate the unit is properly
plugged into the 12V DC power source and is in charging.
4. Charge the unit until the Battery Status Icon shows 4 solid bars when either
the Area Light, USB or Compressor Power Button is pressed (with the adapter
unplugged from the unit).
5. When charging is complete, remove the DC Charging Adaptor from the unit
and the 12 V DC power source when not in use and store in a safe place.
Notes: Some vehicles require that the ignition be switched to the accessory outlet position in order to power
the accessory outlet. Do not leave the unit unattended when charging using the this method.
JUMP-STARTER
This Jump-Starter is equipped with an On/Off Power Switch. Once the connections
are properly made, turn the switch on to jump-start the vehicle.
IMPORTANT: Make sure the Compressor Power Button has been turned off before
attempting to use the unit as a Jump-Starter.
1. Turn off vehicle ignition and all accessories (radio, A/C, lights, connected cell
phone chargers, etc.). Place vehicle in “park” and set the emergency brake.
2. Make sure the Jump-Starter Power Switch is turned to off.
3. Remove jumper clamps from clamp tabs. Connect the red clamp first, then the
black clamp.
4. Procedure for jump-starting a NEGATIVE GROUNDED SYSTEM (negative
battery terminal is connected to chassis) (MOST COMMON)
4a. Connect positive (+) red clamp to vehicle battery’s positive terminal.
4b. Connect negative (–) black clamp to chassis or a solid, non-moving, metal
vehicle component or body part. Never clamp directly to negative battery
terminal or moving part. Refer to the automobile owner’s manual.
5. Procedure for jump-starting POSITIVE GROUND SYSTEMS
Notes: In the rare event that the vehicle to be started has a Positive Grounded System (positive battery
terminal is connected to chassis), replace steps 4a and 4b above with steps 5a and 5b, then
proceed to step 6.
5a. Connect negative (–) black clamp to vehicle battery’s negative terminal.
5b. Connect positive (+) red clamp to vehicle chassis or a solid, non-moving,
metal vehicle component or body part. Never clamp directly to positive
battery terminal or moving part. Refer to the automobile owner’s
manual.
6. When clamps are connected properly, turn the Jump-Starter Power Switch to
ON. The backlit LCD screen will display the following:
J7C09D_ManualENSP_060921.indd 6-7J7C09D_ManualENSP_060921.indd 6-7 6/9/2021 1:56:29 PM6/9/2021 1:56:29 PM

8 9
The Battery Status icon, Battery Voltage Indicator, Clamp Icons and the “+” and
“–” signs light solid. The Jump-Starter icon will flash to indicate the clamps are
properly connected.
7. Turn ON the ignition and crank the engine in 5-6 second bursts until engine
starts. The backlit LCD screen will display the following:
The Battery Status Icon, the Battery Voltage Indicator, Jump-Starter Icon, Clamp
Icons and the “+” and”–” signs light solid to indicate the unit is jump-starting.
8. Turn the Jump-Starter Power Switch back to the off position.
9. Disconnect the negative (–) engine or chassis clamp first, then disconnect the
positive (+) battery clamp.
IMPORTANT: Always turn the unit off when not in use. Recharge this unit fully
after each use.
WARNING – To reduce the risk of serious injury or property damage:
• Follow all safety instructions found in the “Specific Safety Instructions for Jump-
Starters” section of this instruction manual.
• Never touch red and black clamps together. This can cause dangerous sparks,
power arcing, and/or explosion.
• If the clamps are connected incorrectly with regard to polarity, the unit will sound
a continuous alarm until the clamps are disconnected. The backlit LCD Screen will
display the Battery Status Icon, the Battery Voltage Indicator and the Clamp Icons.
The “+” and”–” signs above the Clamp Icons, the Arrow Icons and the Alarm Icon
will flash. The backlit LCD screen will display the following:
CAUTION – This unit will suffer permanent damage if the Jump-Starter Power
Switch is turned on while the clamps are connected with reverse polarity. Disconnect
the clamps and reconnect to battery with correct polarity before operating the unit.
• Always disconnect the negative (black) jumper cable first, followed by the positive
(red) jumper cable, except for positive grounded systems.
CAUTION – To reduce the risk of property damage:
• Vehicles that have on-board computerized systems may be damaged if vehicle
battery is jump-started. Before jump-starting this type of vehicle, read the vehicle
manual to confirm that external-starting assistance is advised.
• Excessive engine cranking can damage the vehicle‘s starter motor. If the engine
fails to start after the recommended number of attempts, discontinue jump-start
procedure and look for other problems that need to be corrected.
• If vehicle fails to start, turn off the ignition, turn off the Jump-Starter Power
Button, disconnect the jump-start system’s leads and contact a qualified technician
to investigate why the engine did not start.
AREA LIGHT
The area light is controlled by the Area Light Power Button on the Control Panel
(refer to the “Features” section to locate).
1. Press the Area Light Power Button once to turn the light on.
2. Press the Area Light Power Button again to turn the area light off.
When the Area Light Power Button is pressed to turn it on, a beep will sound. The
backlit LCD screen will turn on for 10 seconds (only) and will then continuously
display the Battery Status Icon and the Battery Voltage Indicator.
Periodically check the unit’s battery status on the backlit LCD screen. Four solid bars
in the battery icon indicates a full battery. When the battery level is nearly empty
with only one solid bar or completely empty with four empty bars, the unit must
be recharged at this time or the unit’s built-in low voltage protection will activate.
The empty Battery Status Icon will flash for a short period of time before automatic
shut down.
IMPORTANT: Make sure the Area Light is turned off when the unit is being
recharged or stored.
USB PORTS
The USB power button and the three USB ports are located on the front of the unit
(see the “Features” section to locate).
IMPORTANT NOTES:
1. The three USB ports provide 3.1A (5V) each.
2. When the USB Ports are in use, the unit will monitor for the following USB
fault conditions on all the USB Ports: low battery voltage fault, overload and
short circuit. In any of these cases, the backlit LCD screen will continuously
display the following:
The Fault Icon will flash. The USB Ports will automatically shut down. Should
this occur:
2a. Disconnect the USB-powered device and press the USB Power Button
again to turn off the USB Ports immediately.
2b. Make sure the unit does not need to be recharged.
2c. Allow the unit to cool down for several minutes before attempting to
use the USB Ports again.
2d. If a fault occurs again, make sure that the total draw of the USB device
plugged into the USB Port does not exceed 3.1A (5V).
2e. If an individual USB device is within specifications and the fault occurs,
have the USB device checked for malfunction and do not continue to use
it with these USB Ports.
3. This unit’s USB Ports do not support data communication. They only provide
power to external USB-powered devices. The USB Ports provide 3.1A (5V) each.
4. Some household USB-powered electronics will not operate with this unit.
Using the USB Ports
1. Press the USB Power Button to turn on all of the USB Ports. A beep will sound.
The backlight will turn on for 10 seconds (only). The backlit LCD screen will
continuously display the following:
The Battery Status Icon and Battery Voltage Indicator will light solid, as well as
the USB Icon, indicating the USB ports are ready to use.
2. Plug the USB-powered device into the USB power port(s) and operate normally.
3. Press the USB Power Button again to turn off the USB Ports.
Periodically check the unit’s battery status on the backlit LCD screen. Four solid bars
in the battery icon indicates a full battery. When the battery level is nearly empty
with only one solid bar or completely empty with 4 empty bars, the unit must be
recharged at this time or the unit’s built-in low voltage protection will activate. The
empty Battery Status Icon will flash for a short period of time before automatic
shut down.
IMPORTANT: Make sure the USB Ports are turned off when the unit is being
recharged or stored.
PORTABLE COMPRESSOR
The built-in 12 volt DC compressor is the ultimate compressor for all vehicle tires,
trailer tires and recreational inflatables. A nozzle adaptor is supplied that screws
onto the end of the Sure Fit®nozzle at the free end of the compressor hose.
The compressor hose with tire fitting is stored in the compressor hose storage
compartment. Refer to the “Features” illustration for locations of compressor
hose. The Compressor Power Button and Increase (+) and Decrease (–) Compressor
Pressure Control Buttons are located on the control panel on the front of the unit.
Before proceeding, check the unit’s battery status on the LCD screen. Four solid bars
in the battery icon indicates a full battery. When the battery level is nearly empty
with only one solid bar, the unit MUST be recharged before use or the unit’s built-in
low voltage protection will activate. The empty Battery Status Icon will flash for a
short period of time before automatic shut down.
The compressor is capable of inflating up to 120 pounds per square inch (psi)
pressure. Return hose to the storage compartment after use.
IMPORTANT NOTES:
• Make sure the Jump-Starter Power Button has been turned off before attempting
to use the unit as a Compressor.
• The Compressor will not operate if the unit’s battery falls below 12V. This is to
protect the Compressor and the battery. If the Battery Voltage Indicator reads
lower than 12V, recharge the unit before using the Compressor.
WARNING – To reduce the risk of serious injury or property damage:
Follow all safety instructions found in the “Specific Safety Instructions for
Compressors” section of this instruction manual.
CAUTION – To reduce the risk of serious injury or property damage:
When the compressor is operated at a low PSI, the unit may start in low and
gradually rev up. When the compressor is operated at higher PSIs, the unit may
operate normally for several minutes, then rev down for a few minutes before
returning to normal operation. This feature protects the unit from overheating
during normal use. In any event, do not operate compressor continuously for longer
than 10 minutes, as it may overheat. This could damage the compressor. If the
compressor must be operated for longer periods: every 10 minutes press the
Compressor Power Button to turn the compressor off, then restart after a cooling
down period of approximately 30 minutes.
Inflating Tires or Products With Valve Stems
1. Screw the Sure Fit®nozzle onto the valve stem. Do not overtighten.
2. Press the Compressor Power Button. A beep will sound and the backlit LCD
screen will display the following:
The Compressor Icon will light and the digital display will alternately show the
flashing pre-set psi value (that was last set by the compressor pressure control
buttons) and the current pressure of the item being inflated (which will light
solid).
3. Press the “+” and “–” Pressure Control Buttons to set the desired pressure from
a range pre-set values (between 1 and 120), which will display on the backlit
LCD screen. The unit will sound a beep with each press of the buttons (holding
the button speeds up the upward or downward value selection). Once the
desired pressure has been entered, release the button and the flashing digital
display will show the new selected pressure, as follows:
The new selected value is now stored in the unit’s memory until it is manually
reset.
4. Press the Compressor Power Button once more to begin inflating. The
Compressor Icon will flash and the digital display will only show the current
pressure value (which will light solid) to indicate the compressor is activated.
Monitor the pressure on the LCD screen.
IMPORTANT NOTE: To interrupt during inflation, press the Compressor Power
Button again.
5. When desired pre-set pressure is reached, the compressor will automatically stop.
6. Press the Compressor Power Button again to turn off the unit.
7. Unscrew and remove the Sure Fit®nozzle from the valve stem.
8. Allow the unit to cool, then recharge before storing away.
9. Store the compressor hose and Sure Fit®nozzle in storage compartment.
Inflating Other Inflatables Without Valve Stems
Inflation of other items requires use of the nozzle adapter.
1. Screw the nozzle adapter into the Sure Fit®nozzle. Do not overtighten.
2. Insert the nozzle adapter into item to be inflated.
3. Follow steps 2 through 4 of the “Inflating Tires or Products With Valve
Stems” section.
IMPORTANT: Small items such as volleyballs, footballs, etc. inflate very rapidly.
Keep this in mind when setting pressure. Take extra care not to over-inflate.
4. When the desired pressure is reached, the compressor will automatically stop.
Press the Compressor Power Button again to turn off the unit.
5. Disconnect the adapter from the inflated item.
6. Unscrew and remove the nozzle adapter from the Sure Fit®nozzle.
7. Allow the unit to cool, then recharge before storing away.
8. Store the compressor hose, Sure Fit®nozzle and nozzle adapter in the storage
compartment when not in use.
CARE AND MAINTENANCE
All batteries lose energy from self-discharge over time and more rapidly at higher
temperatures. When the unit is not in use, we recommend that the battery is
charged at least every 30 days.
Never submerge the unit in water. If the unit gets dirty, gently clean the outer
surfaces of the unit with a soft cloth.
There are no user-replaceable parts. Periodically inspect the condition of adapters,
connectors and wires. Contact manufacturer to replace any components that have
become worn or broken.
Battery
Please be advised that the battery is designed to last the service life of
the unit and is not replaceable, removable or serviceable. Service life is
dependent on a number of factors including but not limited to the number of
recharge cycles, and proper care and maintenance of the battery by the end user.
Contact manufacturer for any information you may need.
SAFE BATTERY DISPOSAL
Contains a maintenance-free, sealed, non-spillable, lead acid
battery, which must be disposed of properly. Recycling is
required. Failure to comply with local, state and federal
regulations can result in fines, or imprisonment.
Please recycle.
WARNINGS:
• Do not dispose of the battery in fire as this may result in an explosion.
• Before disposing of the battery, protect exposed terminals with heavy-duty
electrical tape to prevent shorting (shorting can result in injury or fire).
• Do not expose battery to fire or intense heat as it may explode.
TROUBLESHOOTING
Unit will not charge
• Make sure all of the unit’s functions are turned off.
• Make sure a suitable gauge extension cord is properly connected to both the unit
and a functioning AC outlet.
Unit fails to jump-start
• Make sure the unit is not being operated in the Compressor mode.
• Make sure a proper polarity cable connection has been established.
• Make sure unit’s Jump-Starter Power Switch is in the on position.
• Check that unit has a full charge. Recharge unit if necessary.
USB power port will not power appliance
• Make sure the USB Power Button has been pressed to turn the USB Ports on.
• If a fault condition exists in any of the USB Ports, the Fault Icon on the LCD screen
will flash. Refer to the Important Notes in the “USB Ports” section to remedy any
faults.
• Make sure that the total draw the USB device plugged into the USB Port does not
exceed 3.1A (5V).
• Some USB-powered household electronics will not operate with this USB charging/
power port. Check the manual of the corresponding electronic device to confirm
that it can be used with this type of USB charging/power port.
• Check that unit has a full charge. Recharge unit if necessary.
LED area light does not come on
• Make sure the area light power button has been pressed to turn the area light on.
• Check that unit has a full charge. Recharge unit if necessary.
Portable compressor will not inflate
• Make sure the unit is not being operated in the Jump-Starter mode.
• Make sure the Sure Fit®nozzle connector is securely screwed on to the valve stem
when attempting to inflate tires; or that the nozzle adapter is securely screwed
into the Sure Fit®nozzle connector and is inserted properly into the item to be
inflated on all other inflatables.
• Make sure the compressor power button has been pressed to turn the compressor on.
• The compressor may be overheated. Press the compressor power button to turn the
compressor off. Restart after a cooling down period of approximately 30 minutes.
• Check that unit has a full charge. Recharge unit if necessary.
ACCESSORIES
Recommended accessories for use with your tool may be available from the
manufacturer. If you need assistance regarding accessories, please contact the
manufacturer at 1-877-571-2391.
The use of any accessory not recommended for use with this appliance could be
hazardous.
SERVICE INFORMATION
Whether you need technical advice, repair, or genuine factory replacement parts,
contact the manufacturer at 1-877-571-2391.
J7C09D_ManualENSP_060921.indd 8-9J7C09D_ManualENSP_060921.indd 8-9 6/9/2021 1:56:29 PM6/9/2021 1:56:29 PM

8 9
The Battery Status icon, Battery Voltage Indicator, Clamp Icons and the “+” and
“–” signs light solid. The Jump-Starter icon will flash to indicate the clamps are
properly connected.
7. Turn ON the ignition and crank the engine in 5-6 second bursts until engine
starts. The backlit LCD screen will display the following:
The Battery Status Icon, the Battery Voltage Indicator, Jump-Starter Icon, Clamp
Icons and the “+” and”–” signs light solid to indicate the unit is jump-starting.
8. Turn the Jump-Starter Power Switch back to the off position.
9. Disconnect the negative (–) engine or chassis clamp first, then disconnect the
positive (+) battery clamp.
IMPORTANT: Always turn the unit off when not in use. Recharge this unit fully
after each use.
WARNING – To reduce the risk of serious injury or property damage:
• Follow all safety instructions found in the “Specific Safety Instructions for Jump-
Starters” section of this instruction manual.
• Never touch red and black clamps together. This can cause dangerous sparks,
power arcing, and/or explosion.
• If the clamps are connected incorrectly with regard to polarity, the unit will sound
a continuous alarm until the clamps are disconnected. The backlit LCD Screen will
display the Battery Status Icon, the Battery Voltage Indicator and the Clamp Icons.
The “+” and”–” signs above the Clamp Icons, the Arrow Icons and the Alarm Icon
will flash. The backlit LCD screen will display the following:
CAUTION – This unit will suffer permanent damage if the Jump-Starter Power
Switch is turned on while the clamps are connected with reverse polarity. Disconnect
the clamps and reconnect to battery with correct polarity before operating the unit.
• Always disconnect the negative (black) jumper cable first, followed by the positive
(red) jumper cable, except for positive grounded systems.
CAUTION – To reduce the risk of property damage:
• Vehicles that have on-board computerized systems may be damaged if vehicle
battery is jump-started. Before jump-starting this type of vehicle, read the vehicle
manual to confirm that external-starting assistance is advised.
• Excessive engine cranking can damage the vehicle‘s starter motor. If the engine
fails to start after the recommended number of attempts, discontinue jump-start
procedure and look for other problems that need to be corrected.
• If vehicle fails to start, turn off the ignition, turn off the Jump-Starter Power
Button, disconnect the jump-start system’s leads and contact a qualified technician
to investigate why the engine did not start.
AREA LIGHT
The area light is controlled by the Area Light Power Button on the Control Panel
(refer to the “Features” section to locate).
1. Press the Area Light Power Button once to turn the light on.
2. Press the Area Light Power Button again to turn the area light off.
When the Area Light Power Button is pressed to turn it on, a beep will sound. The
backlit LCD screen will turn on for 10 seconds (only) and will then continuously
display the Battery Status Icon and the Battery Voltage Indicator.
Periodically check the unit’s battery status on the backlit LCD screen. Four solid bars
in the battery icon indicates a full battery. When the battery level is nearly empty
with only one solid bar or completely empty with four empty bars, the unit must
be recharged at this time or the unit’s built-in low voltage protection will activate.
The empty Battery Status Icon will flash for a short period of time before automatic
shut down.
IMPORTANT: Make sure the Area Light is turned off when the unit is being
recharged or stored.
USB PORTS
The USB power button and the three USB ports are located on the front of the unit
(see the “Features” section to locate).
IMPORTANT NOTES:
1. The three USB ports provide 3.1A (5V) each.
2. When the USB Ports are in use, the unit will monitor for the following USB
fault conditions on all the USB Ports: low battery voltage fault, overload and
short circuit. In any of these cases, the backlit LCD screen will continuously
display the following:
The Fault Icon will flash. The USB Ports will automatically shut down. Should
this occur:
2a. Disconnect the USB-powered device and press the USB Power Button
again to turn off the USB Ports immediately.
2b. Make sure the unit does not need to be recharged.
2c. Allow the unit to cool down for several minutes before attempting to
use the USB Ports again.
2d. If a fault occurs again, make sure that the total draw of the USB device
plugged into the USB Port does not exceed 3.1A (5V).
2e. If an individual USB device is within specifications and the fault occurs,
have the USB device checked for malfunction and do not continue to use
it with these USB Ports.
3. This unit’s USB Ports do not support data communication. They only provide
power to external USB-powered devices. The USB Ports provide 3.1A (5V) each.
4. Some household USB-powered electronics will not operate with this unit.
Using the USB Ports
1. Press the USB Power Button to turn on all of the USB Ports. A beep will sound.
The backlight will turn on for 10 seconds (only). The backlit LCD screen will
continuously display the following:
The Battery Status Icon and Battery Voltage Indicator will light solid, as well as
the USB Icon, indicating the USB ports are ready to use.
2. Plug the USB-powered device into the USB power port(s) and operate normally.
3. Press the USB Power Button again to turn off the USB Ports.
Periodically check the unit’s battery status on the backlit LCD screen. Four solid bars
in the battery icon indicates a full battery. When the battery level is nearly empty
with only one solid bar or completely empty with 4 empty bars, the unit must be
recharged at this time or the unit’s built-in low voltage protection will activate. The
empty Battery Status Icon will flash for a short period of time before automatic
shut down.
IMPORTANT: Make sure the USB Ports are turned off when the unit is being
recharged or stored.
PORTABLE COMPRESSOR
The built-in 12 volt DC compressor is the ultimate compressor for all vehicle tires,
trailer tires and recreational inflatables. A nozzle adaptor is supplied that screws
onto the end of the Sure Fit®nozzle at the free end of the compressor hose.
The compressor hose with tire fitting is stored in the compressor hose storage
compartment. Refer to the “Features” illustration for locations of compressor
hose. The Compressor Power Button and Increase (+) and Decrease (–) Compressor
Pressure Control Buttons are located on the control panel on the front of the unit.
Before proceeding, check the unit’s battery status on the LCD screen. Four solid bars
in the battery icon indicates a full battery. When the battery level is nearly empty
with only one solid bar, the unit MUST be recharged before use or the unit’s built-in
low voltage protection will activate. The empty Battery Status Icon will flash for a
short period of time before automatic shut down.
The compressor is capable of inflating up to 120 pounds per square inch (psi)
pressure. Return hose to the storage compartment after use.
IMPORTANT NOTES:
• Make sure the Jump-Starter Power Button has been turned off before attempting
to use the unit as a Compressor.
• The Compressor will not operate if the unit’s battery falls below 12V. This is to
protect the Compressor and the battery. If the Battery Voltage Indicator reads
lower than 12V, recharge the unit before using the Compressor.
WARNING – To reduce the risk of serious injury or property damage:
Follow all safety instructions found in the “Specific Safety Instructions for
Compressors” section of this instruction manual.
CAUTION – To reduce the risk of serious injury or property damage:
When the compressor is operated at a low PSI, the unit may start in low and
gradually rev up. When the compressor is operated at higher PSIs, the unit may
operate normally for several minutes, then rev down for a few minutes before
returning to normal operation. This feature protects the unit from overheating
during normal use. In any event, do not operate compressor continuously for longer
than 10 minutes, as it may overheat. This could damage the compressor. If the
compressor must be operated for longer periods: every 10 minutes press the
Compressor Power Button to turn the compressor off, then restart after a cooling
down period of approximately 30 minutes.
Inflating Tires or Products With Valve Stems
1. Screw the Sure Fit®nozzle onto the valve stem. Do not overtighten.
2. Press the Compressor Power Button. A beep will sound and the backlit LCD
screen will display the following:
The Compressor Icon will light and the digital display will alternately show the
flashing pre-set psi value (that was last set by the compressor pressure control
buttons) and the current pressure of the item being inflated (which will light
solid).
3. Press the “+” and “–” Pressure Control Buttons to set the desired pressure from
a range pre-set values (between 1 and 120), which will display on the backlit
LCD screen. The unit will sound a beep with each press of the buttons (holding
the button speeds up the upward or downward value selection). Once the
desired pressure has been entered, release the button and the flashing digital
display will show the new selected pressure, as follows:
The new selected value is now stored in the unit’s memory until it is manually
reset.
4. Press the Compressor Power Button once more to begin inflating. The
Compressor Icon will flash and the digital display will only show the current
pressure value (which will light solid) to indicate the compressor is activated.
Monitor the pressure on the LCD screen.
IMPORTANT NOTE: To interrupt during inflation, press the Compressor Power
Button again.
5. When desired pre-set pressure is reached, the compressor will automatically stop.
6. Press the Compressor Power Button again to turn off the unit.
7. Unscrew and remove the Sure Fit®nozzle from the valve stem.
8. Allow the unit to cool, then recharge before storing away.
9. Store the compressor hose and Sure Fit®nozzle in storage compartment.
Inflating Other Inflatables Without Valve Stems
Inflation of other items requires use of the nozzle adapter.
1. Screw the nozzle adapter into the Sure Fit®nozzle. Do not overtighten.
2. Insert the nozzle adapter into item to be inflated.
3. Follow steps 2 through 4 of the “Inflating Tires or Products With Valve
Stems” section.
IMPORTANT: Small items such as volleyballs, footballs, etc. inflate very rapidly.
Keep this in mind when setting pressure. Take extra care not to over-inflate.
4. When the desired pressure is reached, the compressor will automatically stop.
Press the Compressor Power Button again to turn off the unit.
5. Disconnect the adapter from the inflated item.
6. Unscrew and remove the nozzle adapter from the Sure Fit®nozzle.
7. Allow the unit to cool, then recharge before storing away.
8. Store the compressor hose, Sure Fit®nozzle and nozzle adapter in the storage
compartment when not in use.
CARE AND MAINTENANCE
All batteries lose energy from self-discharge over time and more rapidly at higher
temperatures. When the unit is not in use, we recommend that the battery is
charged at least every 30 days.
Never submerge the unit in water. If the unit gets dirty, gently clean the outer
surfaces of the unit with a soft cloth.
There are no user-replaceable parts. Periodically inspect the condition of adapters,
connectors and wires. Contact manufacturer to replace any components that have
become worn or broken.
Battery
Please be advised that the battery is designed to last the service life of
the unit and is not replaceable, removable or serviceable. Service life is
dependent on a number of factors including but not limited to the number of
recharge cycles, and proper care and maintenance of the battery by the end user.
Contact manufacturer for any information you may need.
SAFE BATTERY DISPOSAL
Contains a maintenance-free, sealed, non-spillable, lead acid
battery, which must be disposed of properly. Recycling is
required. Failure to comply with local, state and federal
regulations can result in fines, or imprisonment.
Please recycle.
WARNINGS:
• Do not dispose of the battery in fire as this may result in an explosion.
• Before disposing of the battery, protect exposed terminals with heavy-duty
electrical tape to prevent shorting (shorting can result in injury or fire).
• Do not expose battery to fire or intense heat as it may explode.
TROUBLESHOOTING
Unit will not charge
• Make sure all of the unit’s functions are turned off.
• Make sure a suitable gauge extension cord is properly connected to both the unit
and a functioning AC outlet.
Unit fails to jump-start
• Make sure the unit is not being operated in the Compressor mode.
• Make sure a proper polarity cable connection has been established.
• Make sure unit’s Jump-Starter Power Switch is in the on position.
• Check that unit has a full charge. Recharge unit if necessary.
USB power port will not power appliance
• Make sure the USB Power Button has been pressed to turn the USB Ports on.
• If a fault condition exists in any of the USB Ports, the Fault Icon on the LCD screen
will flash. Refer to the Important Notes in the “USB Ports” section to remedy any
faults.
• Make sure that the total draw the USB device plugged into the USB Port does not
exceed 3.1A (5V).
• Some USB-powered household electronics will not operate with this USB charging/
power port. Check the manual of the corresponding electronic device to confirm
that it can be used with this type of USB charging/power port.
• Check that unit has a full charge. Recharge unit if necessary.
LED area light does not come on
• Make sure the area light power button has been pressed to turn the area light on.
• Check that unit has a full charge. Recharge unit if necessary.
Portable compressor will not inflate
• Make sure the unit is not being operated in the Jump-Starter mode.
• Make sure the Sure Fit®nozzle connector is securely screwed on to the valve stem
when attempting to inflate tires; or that the nozzle adapter is securely screwed
into the Sure Fit®nozzle connector and is inserted properly into the item to be
inflated on all other inflatables.
• Make sure the compressor power button has been pressed to turn the compressor on.
• The compressor may be overheated. Press the compressor power button to turn the
compressor off. Restart after a cooling down period of approximately 30 minutes.
• Check that unit has a full charge. Recharge unit if necessary.
ACCESSORIES
Recommended accessories for use with your tool may be available from the
manufacturer. If you need assistance regarding accessories, please contact the
manufacturer at 1-877-571-2391.
The use of any accessory not recommended for use with this appliance could be
hazardous.
SERVICE INFORMATION
Whether you need technical advice, repair, or genuine factory replacement parts,
contact the manufacturer at 1-877-571-2391.
J7C09D_ManualENSP_060921.indd 8-9J7C09D_ManualENSP_060921.indd 8-9 6/9/2021 1:56:29 PM6/9/2021 1:56:29 PM

1110
FULL ONE-YEAR HOME USE WARRANTY
The manufacturer warrants this product against defects in materials and
workmanship for a period of ONE (1) YEAR from the date of retail purchase by the
original end-user purchaser (“Warranty Period”).
If there is a defect and a valid claim is received within the Warranty Period, the
defective product can be replaced or repaired in the following ways: (1) Return the
product to the manufacturer for repair or replacement at manufacturer’s option.
Proof of purchase may be required by manufacturer. (2) Return the product to the
retailer where product was purchased for an exchange (provided that the store is a
participating retailer). Returns to retailer should be made within the time period of
the retailer’s return policy for exchanges only (usually 30 to 90 days after the sale).
Proof of purchase may be required. Please check with the retailer for their specific
return policy regarding returns that are beyond the time set for exchanges.
This warranty does not apply to accessories, bulbs, fuses and batteries; defects
resulting from normal wear and tear, accidents; damages sustained during shipping;
alterations; unauthorized use or repair; neglect, misuse, abuse; and failure to follow
instructions for care and maintenance for the product.
This warranty gives you, the original retail purchaser, specific legal rights and you
may have other rights which vary from state to state or province to province. This
product is not intended for commercial use.
Be sure to register your product at https://www.baccusglobal.com/registration to
receive important product information, special promotions and offers, and more.
SPECIFICATIONS
Boost Ampere: 12V DC, 700A instantaneous
Battery Type: Maintenance-free, sealed lead acid, 12V DC
AC Input: 120V AC, 60Hz, 13W
Area Light: 1 white LED
USB Ports: 3.1A max., 5V DC
Compressor Maximum Pressure: 120 PSI
Sure Fit®is a registered U.S. trademarks owned or licensed by Baccus Global, LLC.
STANLEY®AND THE STANLEY®LOGO ARE REGISTERED
TRADEMARKS OF STANLEY BLACK + DECKER INC.
OR ONE OF ITS AFFILIATES, AND ARE
USED UNDER LICENSE.
Imported by Baccus Global LLC,
621 NW 53rd St., Suite 450, Boca Raton, FL 33487
www.baccusglobal.com 1-877-571-2391
RD060921
NORMAS DE
SEGURIDAD /
DEFINICIONES
PELIGRO: Indica una situación de peligro inminente que, si no se evita,
provocará la muerte o lesiones graves.
ADVERTENCIA: Indica una situación de peligro inminente que, si no se evita,
puede provocar la muerte o lesiones graves.
PRECAUCIÓN: Indica una situación de peligro potencial que, si no se evita,
puede provocar lesiones leves o moderadas.
Usado sin la palabra, indica un mensaje relacionado con la seguridad.
AVISO: Indica una práctica no relacionada con lesiones personales que, si no
se evita, puede resultar en daños a la propiedad.
RIESGO DE OPERACIÓN INSEGURA. Cuando se utilizan herramientas o
equipos, siempre se deben respetar las precauciones de seguridad para reducir el
riesgo de lesiones personales. La operación, el mantenimiento o la modificación
incorrectos de herramientas o equipos pueden provocar lesiones graves y daños a la
propiedad. Las herramientas y los equipos están diseñados para usos determinados.
Fabricante recomienda encarecidamente que NO se modifique este producto y
que NO se utilice para ningún otro uso que aquél para el que fue diseñado. Lea
y comprenda todas las instrucciones operativas y las advertencias antes de utilizar
cualquier herramienta o equipo.
LEA TODAS LAS
INSTRUCCIONES
ADVERTENCIA: Lea y comprenda este manual de instrucciones antes
de utilizar esta unidad. El incumplimiento de todas las instrucciones
enumeradas a continuación puede provocar una descarga eléctrica, un
incendio o lesiones graves.
INSTRUCCIONES
IMPORTANTES DE
SEGURIDAD
ADVERTENCIAS E INSTRUCCIONES DE SEGURIDAD
GENERALES
• Esta unidad fue diseñada para el uso domestico.
ADVERTENCIA – Riesgo de incendios, descargas eléctricas, peligro de
explosión o lesiones a personas o propiedades:
• Evite las condiciones ambientales peligrosas. No utilice artefactos en zonas
húmedas o mojadas. No utilice artefactos bajo la lluvia.
• Mantenga a los niños alejados. Los visitantes deben mantenerse a cierta
distancia del área de trabajo.
• Use la vestimenta adecuada. No use ropas holgadas o joyas. Pueden atascarse
en las piezas en movimiento. Se recomienda utilizar guantes de goma y calzado
antideslizante considerable al trabajar al aire libre. Recójase y cubra el cabello
largo.
• Guarde los artefactos que no utilice en el interior. Cuando no los utilice, los
artefactos deben guardarse bajo techo, en un lugar seco, alto o bajo llave, lejos
del alcance de los niños.
• No tire del cable. Nunca transporte el aparato por el cable ni lo jale para
desconectarlo del tomacorriente. Mantenga el cable alejado del calor, el aceite y
los bordes afilados.
• Desconecte los aparatos. Desconecte el aparato de la fuente de energía cuando
no lo utilice, antes de realizar un mantenimiento y al cambiar accesorios como
hojas y elementos semejantes.
• La protección del interruptor de corte por falla a tierra (GFCI) debe
aplicarse a los circuitos o los tomacorrientes que se utilizarán. Hay tomacorrientes
con protección GFCI incorporada que pueden utilizarse para tomar esta medida
de seguridad.
• Uso de accesorios y suplementos. El uso de accesorios o dispositivos no
recomendados para utilizar con este aparato puede resultar peligroso. Consulte la
sección “Accesorios” de este manual para obtener detalles adicionales.
• Manténgase alerta. Use el sentido común. No opere este equipo si está cansado o
con impedimentos.
• Compruebe para saber si hay piezas dañadas. Cualquier parte que esté
dañada debe ser reemplazado por el fabricante antes de su uso posterior. No
utilice la herramienta si el interruptor no le da vuelta por intervalos. Contacto con
el fabricante en 1-877-571-2391 para más información.
• No funcione el aparato cerca de líquidos inflamables o en atmósferas
gaseosas o explosivas. Los motores de estas herramientas normalmente
chispean, y las chispas pueden encender los vapores.
• Nunca sumerja esta unidad en agua; no la exponga a la lluvia, la nieve, ni la
use cuando esté mojada.
• Para reducir el riesgo de descarga eléctrica, desconecte la unidad de cualquier
fuente de energía antes de intentar limpiarla o realizarle un mantenimiento.
Apagar los controles sin desenchufar la unidad no reducirá este riesgo.
• Este equipo emplea piezas (interruptores y relés) que producen arcos o
chispas. Por lo tanto, si utiliza la unidad en una cochera o un área cerrada, DEBE
colocarla a no menos de 457 mm (18 pulgadas) por encima del piso.
• No inserte los objetos extranjeros en los puertos USB o los tomacorrientes
de 120V CA.
INSTRUCCIONES DE SEGURIDAD ESPECÍFICAS PARA
CARGAR ESTA UNIDAD
• IMPORTANTE: Esta unidad se entrega en un estado parcialmente cargado. Cargue
por completo la unidad con un cable de extensión doméstico durante 40 horas
o hasta que el icono de estado de la batería muestre 4 barras sólidas antes de
usarlo por primera vez. No se puede exceso de carga la unidad con el método de
carga de CA.
• Para recargar esta unidad, utilice sólo el cargador incorporado CA.
• Todas las funciones deben apagarse cuando la unidad se está cargando o no está
en uso. Asegúrese de que todos los interruptores estén en la posición de apagado
(OFF) antes de realizar la conexión a una fuente de energía o carga.
CABLES DE EXTENSIÓN:
ADVERTENCIA: El uso de un cable de extensión incorrecta podría dar lugar
a un riesgo de fuego y descarga eléctrica. Al usar un cable de extensión, cerciórese
de que los pernos del cable de extensión son el mismo número, tamaño y forma
que ésos en el cargador; y esté seguro de utilizar uno bastante pesado para llevar
la corriente que su producto dibujará. Un cable de menor capacidad provocará una
disminución en el voltaje de la línea, lo cual producirá una pérdida de potencia y
sobrecalentamiento. La siguiente tabla muestra la medida correcta que debe utilizar
según la longitud del cable y la capacidad nominal en amperios indicada en la
placa. En caso de duda, utilice el calibre inmediatamente superior. Cuanto menor es
el número de calibre, más grueso es el cable.
CALIBRE MÍNIMO PARA LOS JUEGOS
DE CABLES
Voltios Largo total del cable en pies (metros)
120V 0-25 26-50 51-100 101-150
(0-7.6m) (7.6-15.2m) (15.2-30.4m) (30.4-45.7m)
240V 0-50 51-100 101-200 201-300
(0-15.2m) (15.2-30.4m) (30.4-60.9m) (60.9-91.4m)
Grado del amperio Longitud de la cable de extensión
Más No más 0’-25’ 26’-50’ 51’-100’ 101’ -150’
que que Calibrador de alambre Americano (AWG)
0 - 6 18 16 16 14
6 - 10 18 16 14 12
10 - 12 16 16 14 12
12 - 16 14 12 No recomendado
• Cuando se utiliza un cable prolongador, asegúrese de que:
– as patas del cable prolongador sean del mismo número, el mismo tamaño y la
misma forma que las del cargador,
– el cable prolongador posea los conductores correctos y esté en buenas
condiciones eléctricas,
– la medida del conductor sea suficientemente grande para la capacidad nominal
en amperios.
PRECAUCIÓN – Para reducir el riesgo de lesiones o daño a la
propiedad: Cuando desconecte el cable de extensión desde el cargador de CA
de 120 voltios incorporado o la toma de CA, tire por el conectador y no por el cable.
J7C09D_ManualENSP_060921.indd 10-11J7C09D_ManualENSP_060921.indd 10-11 6/9/2021 1:56:29 PM6/9/2021 1:56:29 PM
