Stealthbox SB-F-150/10W3v3 User manual

INSTALLATION
DIFFICULTY:
INSTALLATION GUIDE
for the
SB-F-150/10W3v3
SB-F-150/10W3v3
2004 - Up
2004 - Up
Ford F-150
Ford F-150
SuperCab & SuperCrew
SuperCab & SuperCrew
&
&
2006-Up Lincoln Mark LT
2006-Up Lincoln Mark LT
Thank you for choosing a JL Audio Stealthbox®for your automotive sound system. With proper
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox®installed by your authorized JL Audio
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage
extends to 1 year if your system is installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this installation guide completely
before beginning the process.
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox®be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
STEP 1
Remove all contents from the rear seating area.
Fold the rear seating up.
Continued on Next Page
STEP 2
Place the supplied wax square onto the transmission hump.
The middle of the wax square should measure, 5-inches
from the rear seat forward and along the driver’s side edge
of the transmission hump, as seen in the picture at left.
STEP 3
Thread in a supplied socket cup screw into the bottom insert
of the Stealthbox®, leaving 1-inch exposed.
SB-F-150/10W3v3_INSTR_SKU#011227
SB-F-150/10W3v3_INSTR_SKU#011227
2
5
OUT
OF
5INCHES

Continued on Next Page
SB-F-150/10W3v3_INSTR_SKU#011227
SB-F-150/10W3v3_INSTR_SKU#011227
STEP 6
Lower the Stealthbox®onto the floor and firmly press
down.
Remove the Stealthbox®out of the vehicle carefully, leav-
ing the wax square in place. The socket cup set screws will
leave an impression in the wax. The socket cup set screw
will leave an impression onto the wax.
STEP 5
Position the Stealthbox®into the mounting location.
Guide the side socket cup set screw through the existing
hole in the rear seat bracket. The Stealthbox®needs to fit up
against this seat bracket.
STEP 4
Thread in a supplied socket cup screw into the side insert of
the Stealthbox®, leaving 1 1/2-inches exposed.
Page 2 • JL Audio, Inc 2006
STEP 8
Back out the bottom socket cup set screw installed in
Step 3, leaving 1 1/2-inches of thread exposed.
STEP 9
Cut enough speaker wire to allow the run from the
Stealthbox®location to the amplifier location.
Attach the speaker wire to the wire terminal on the
Stealthbox®. Check the woofer for proper operation.
STEP 7
Note: Before drilling, make sure that you are not going
to be drilling into any gas lines, brake lines, transmission
lines, electrical wiring, transfer case (4x4 vehicles)
or anything else that might cause a reduction in your
weekly pay. Always wear eye protection when drilling!
With a drill and a 1/2-inch drill bit, drill through the
impression made in the wax square and into the vehicle’s
transmission hump. Once the drill bit breaks through the
metal floor, do not force it any more. A cross-member runs
on the outside under the floor. Remove the wax square and
cut the carpet from the area around the drilled hole.

SB-F-150/10W3v3_INSTR_SKU#011227
SB-F-150/10W3v3_INSTR_SKU#011227
STEALTHBOX WALL
REAR SEAT BRACKET
THREADED INSERT
LOCK WASHER
FLAT WASHER
SOCKET CUP SET SCREW
HEX NUT
STEALTHBOX WALL
THREADED INSERT
VEHICLE SHEET METAL
FENDER WASHER
SOCKET CUP SET SCREW
LOCK WASHER
FLAT WASHER
HEX NUT
SILCONE SEALANT
CONGRATULATIONS
You have completed the installation for this model!
Please refer to the Power Recommendation section for an
amplifier recommendation and basic set-up help.
STEP 12
The socket cup set screw is not viewable from under the
vehicle. You will have to reach up and over the gas tank and
the cross-member, feel for the socket cup set screw.
From under the vehicle, place a supplied fender washer,
flat washer, lock washer and then hex nut onto the socket
cup set screw and secure.
Note: For added protection it is recommended that
you apply a bead of silicone between the vehicle and
the fender washer. After the bolt assembly is tightly
secured, it is also recommended that vehicle under-
coating material is applied to the exposed assembly
STEP 11
Place a supplied flat washer, lock washers and then hex nut
onto the side socket cup set screw and secure.
STEP 10
Position the Stealthbox®back into the mounting location.
Guide the side socket cup set screw through the existing
hole in the rear seat bracket. Guide the bottom socket cup
set screw through the drilled hole.
Page 3 • JL Audio, Inc 2006
All specifications are subject to change without notice. “JL Audio®” and the JL Audio logo, “Stealthbox” and the Stealthbox logo are registered
trademarks of JL Audio, Inc.“Ahead of the Curve”and its respective logo is a trademark of JL Audio, Inc.
JLA-SKU#011227-12-19-200
JLA-SKU#011227-12-19-200
6
6
• Printed in USA • ©2005 JL Audio, Inc. • U.S. PATENTS: #5,734,734 #5,949,898 #6,118,884 #6,229,902
#6,243,479 #6,294,959 #6,501,844 #6,496,590 #6,441,685 #5,687,247 #6,219,431 #6,625,292 #D472,891 #D480,709 Other U.S. & Foreign
patents pending. For more detailed information please visit us online at www.jlaudio.com.
[phone]
www.jlaudio.com
10369 NORTH COMMERCE PARKWAY • MIRAMAR, FLORIDA • 33025 • USA
INCLUDED HARDWARE
(2)
(2)
3/8-inch -16 x 2-1/4-inches Socket Cup Set Screws
3/8-inch -16 x 2-1/4-inches Socket Cup Set Screws
(1)
(1)
1-1/2-inches Fender Washer
1-1/2-inches Fender Washer
(2)
(2)
3/8-inch Flat Washers
3/8-inch Flat Washers
(1)
(1)
3-inches x 3-inches Wax Square
3-inches x 3-inches Wax Square
(2)
(2)
3/8-inch Split lock Washers
3/8-inch Split lock Washers
(2)
(2)
3/8-inch -16 Hex Nut
3/8-inch -16 Hex Nut
SPECIFICATIONS
Enclosure Type:
Acoustic Suspension (sealed)
Acoustic Suspension (sealed)
Driver Type:
10W3v3-4
10W3v3-4
Nominal Impedance:
4 ohm mono
4 ohm mono
Continuous Power Handling:
300 Watts
300 Watts
POWER RECOMMENDATION
JL Audio recommends using a high quality amplifier such as the JL Audio 250/1.
The diagram below shows the recommended crossover, infrasonic filter and equalizer settings for the 250/1 when
being used to power your Stealthbox®.
JL AUDIO 250/1
monoblock subwoofer amplifier
Amplifier Input Section
Input Sens.
Input Voltage
Low/High
Left Ch. Right Ch.
Signal Sensing
Off/On
Output Mode
Full-Range/Low-Pass/High-Pass
Left Ch. Right Ch.
Amp LP Filter
Mode/Slope
Off/12dB/24dB
Filter Freq. (Hz)
Bass Control
LF Boost (dB)
Off/30Hz
Infrasonic Filter
+1 +13
+3 +7 +10
Preamp Output Section
+12VDC Ground Remote
The JL Audio 250/1 is a very versatile audio component. Please consult the owner’s manual for even more
detailed information about installing and tuning this amplifier.
MID/HIGH FREQUENCY DRIVER FITMENT
A variety of JL Audio coaxial and component systems will fit in the factory speaker locations of you vehicle.
Front Speaker Size / Location:
5-inches x 7-inches / Front Doors
5-inches x 7-inches / Front Doors
Fits JL Audio Models:
TR570-CXi, XR570-CSi, XR570-CXi & ZR570-CSi
TR570-CXi, XR570-CSi, XR570-CXi & ZR570-CSi
Rear Speaker Size / Location:
5-inches x 7-inches / Rear Doors
5-inches x 7-inches / Rear Doors
Fits JL Audio Models:
TR570-CXi & XR570-CXi
TR570-CXi & XR570-CXi
