Induction Hob Page 1
Portable Touch Control
Induction Hob
Instruction
Manual
Model No. SEA15
Please read this instruction
manual carefully before
use and retain for later
reference.
Unpack your Induction Hob
carefully and remove packing
pieces.
CAUTIONS
Check that the electrical supply ratings of the appliance are correct for your home•
(see specification).
The induction hob must be connected via an earthed socket, which should have an
•
individually rated load of above 10A. The plug must be fully pushed into the socket.
Overheating could occur if a socket is shared and overloaded.
PERSONS WITH PACEMAKERS SHOULD KEEP A MINIMUM DISTANCE OF 60CM
•
FROM INDUCTION HOBS - SEEK THE ADVICE OF A DOCTOR.
Do not insert plug with wet hands.
•
Do not operate this device using a timer/controller, or remote control system.•
Do not place the hob near a hot gas or electric burner, or in a heated oven.•
Do not use the hob in high humidity conditions.•
The hob should be placed on a level stable worktop at least 10cm from walls or other•
solid obstructions.
Do not use the induction hob on a metal table.
•
Do not use the induction hob on a carpet or tablecloth - the air circulation fan ports•
are underneath the hob, and could become blocked with fibres.
Do not move the induction hob whilst in operation.
•
Never move the hob by pulling the power cord.•
Ensure that the power cord does not trail over the edge of the worktop, and that it is•
kept away from any hot object.
Do not operate the appliance if the power cord has been damaged: contact
•
STELLAR at the address given.
This appliance is not intended for use by persons (including children) with reduced
•
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Always keep the appliance out of the reach of children.
•
The Hob Plate may remain hot for a short period after cooking.•
Never use the appliance if it has been dropped, shows damage or does not function•
properly: contact STELLAR at the address given. Do not attempt to repair the
induction hob yourself.
Use the appliance only for its intended purpose.
•
Extreme caution must be used when moving pans containing hot oil or other hot•
liquids.
Do not heat empty pans, as bases may distort and become ineffective for future use.
•
Keep the unit clean and prevent foreign matter from entering the air circulation•
ports.
Do not immerse the appliance in water.
•
Do not place the induction hob close to devices or objects which are sensitive to•
magnetic fields - radios, TVs, recording devices, credit cards etc.
Do not leave ‘out of use’ cookware on the hob plate - this will become hot if the hob
•
is inadvertently switched on.
The hob plate is temperature resistant glass. If it has been damaged in any way,
•
even if the damage is minor, do not operate the unit: contact STELLAR at the
address given.
Do not attempt to insert wires or tools into the air circulation ports, as this could
•
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
lead to electric shock.
Do not heat unopened tins on the induction hob as they could explode.
•
SPECIFICATIONS
Power Supply: 220-240V 50Hz-60Hz•
Wattage: 2000W maximum•
Temperature range: 40°C - 220°C•
AFTER SALES SERVICE
Do not attempt to repair any part of this Hob. Please refer any problem to STELLAR
Customer Services.
WARRANTY
The STELLAR warranty covers the product to be free of defects in materials and
workmanship for period of two years from the date of original retail purchase. During
this period, STELLAR will, at our option, repair or replace defective parts of the
product, or replace the product, providing the Use Care & Safety Instructions have
been followed. The warranty does not cover damage, defect or failure caused by or
resulting from accidents, external damage, alteration, modification, abuse, misuse or
misapplication. The Hob is for Domestic Use only. The warranty does not cover any
damage caused by taking the appliance apart yourself, or attempting to repair the
appliance yourself. Please keep your purchase receipt and contact us directly if you
encounter any problems with your product.
STELLAR CUSTOMER SERVICES
HORWOOD
AVONMOUTH WAY
BRISTOL
BS11 9HX
GREAT BRITAIN
[email protected]
www.stellarcookware.co.uk
Tel: [phone]
HORWOOD SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT (INCLUDING COLOUR
FADING, SCRATCHES OR ACCUMULATED DIRT THROUGH COMMERCIAL USE)
WITHOUT FOLLOWING THE USE, CARE & SAFETY ADVICE.
FOR DOMESTIC USE ONLY
www.stellarcookware.co.uk

Induction HobPage 2 Induction HobPage 3 Induction HobPage 4
Timing
Once Power or Temperature have been set, you may choose to set a cooking time,
after which the hob will switch OFF, up to a maximum of 180 minutes.
Touch the1. control to display the cooking time, which will start at a setting of 0
minutes, shown on the Display 9along with a flashing
TIMER
symbol, which indicates
that the time may be set using the and controls, to decrease or increase the
cooking time. When setting the time, if either of these controls are held, the setting
will count down or up automatically until released.
Once no further adjustments are made to the time, initially
• the Display 9will show
the selected Power or Temperature setting, then alternate with the time remaining
until the hob switches OFF automatically.
To cancel the Timer at any time, touch the
2.
control to change all settings, or the
control to switch OFF.
When the set cooking time is reached, the hob will switch OFF, a series of “beeps”
•
will sound and the display will flash “----”, to indicate that the hob is in Standby.
Lock
To prevent further operation of the controls during cooking, touch and hold• the
control. The Display 9will show the symbol and all other controls except
the control will be disabled. To switch the Lock OFF, touch and hold the
control again for 1 second, to enable the other controls.
Note: the Lock function cannot be used to prevent operation from Standby. Disconnect
from the mains to prevent unwanted use.
CLEANING
Clean after each use.•
Switch OFF, allow to cool and disconnect from the mains before cleaning.1.
Hob Plate: Clean with a warm damp cloth and washing-up detergent, occasionally a2.
proprietary Hob Cleaner.
Casing: Clean with a warm damp cloth and washing-up detergent.
3.
Air Circulation Ports: Use a vacuum cleaner to suck out dust.4.
DO NOT immerse the Induction Hob in water.•
ERROR MESSAGES
If shown on the Display 9, perform the action described below. If this does not rectify
the problem, or it repeats without obvious cause, or another error message is displayed,
please report the following error messages to STELLAR Customer Services at the
address given in the warranty section:
E0: Cookware not present, unsuitable material, or less than 12cm diameter; hob
•
switches power off and “beeps”
- use correct cookware.
E1, E2 or E3: Overheating problem; hob switches power off and “beeps”
•
- switch off, remove cookware and allow 5 minutes to cool, check the position and
location of the hob, then operate as normal.
Touch Controls & Indicators
Lock control6.
Timer control
7.
Down control
8.
Multifunction display9.
Up control10.
Select control11.
Power control12. and indicator
Add contents for heating to suitable cookware and place within the centre of the2.
heating zone 2.
Touch the
3. control.
A “beep” will sound and the Display
• 9will flash “----”, to indicate that the hob is
in Standby; only the and controls are enabled. If no further action is taken
within 1 minute, the hob will drop out of Standby, with just the Power indicator
illuminated.
Note: if any control is touched when enabled, a “beep” will sound to confirm operation
of the control.
Cooking may be controlled in either Power mode or Temperature mode; each
•
mode is selected in turn using the control. In Temperature mode, the desired
temperature will be reached as quickly as possible and then maintained; this is useful
to prevent food burning. In Power mode, the hob will work in a similar way to a
conventional hob.
Touch the4. control; the hob will begin heating immediately in Power mode,
indicated by the
POWER
symbol on the Display 9, which will also show 1200W, the
default power setting.
Use the
5. and controls to decrease or increase the required power. The
following power settings are available:
Min Default Max
500W 900W 1000W 1100W 1200W 1400W 1500W 1600W 1800W 2000W
To select Temperature mode from Power mode, touch the6.
control once. The
Display 9will show the symbol, as well as 120°C, the default temperature
setting.
Use the
7.
and controls to decrease, or subsequently increase, the required
temperature. The following temperature settings are available:
Min Default Max
40°C 60°C 80°C 100°C 120°C 140°C 160°C 180°C 200°C 220°C
After setting either Temperature or Power, you may subsequently adjust these•
further, using the and controls. If you wish to make alternative settings,
touch the control again, to return to the start point, the default Power setting.
Once cooking has started, you may use the Timing and Lock functions - refer to the
following headings.
When you have finished cooking, touch
8. the control to switch OFF, wait until you
hear the cooling fan stop, then disconnect from the mains.
HOW INDUCTION HOBS WORK
An induction hob heats in a unique way. A very strong magnetic field is created by
electricity running through an electrical coil positioned under a ceramic plate. The
‘induction current’, created by the magnetic field, generates heat in any cookware
capable of being magnetised, while standing on the ceramic plate. Only the pan is
heated - the ceramic plate remains relatively cool. As a result, spilt food will not burn on
to the surface, and can be simply wiped off at the end of cooking.
CHOOSING COOKWARE FOR INDUCTION HOB USE
Only pans that can be magnetised can be used on induction hobs. Most recent Judge,
Stellar, and Horwood cookware is induction-ready, and is described as ‘suitable for all
hob types’. Some cookware, although made of non-magnetic material, has a special
base which allows efficient working on induction hobs. A simple way to check - if a
fridge magnet will stick to the base of the pans, then the pan will heat on an induction
hob. Pans with a base diameter of less than 120mm may not work on this hob.
Ensure all cookware used on the hob is clean before use.
HOW TO USE
Main Cooking Functions
Insert the Mains Plug1. 3into a mains socket and switch on at the socket. A “beep”
will sound and the indicator above the control will illuminate, to indicate that
power is applied.
2
5
5
5
IDENTIFYING THE PARTS
1
678910 11 12
Hob plate1.
Heating zone2.
Mains plug3.
Mains lead4.
Air circulation ports5.
3
4
