Stingray SB-3 User manual

SB-3 MEDIA PLAYER
Installation Guide

2SAFETY INSTRUCTIONS
• The SB-3 is designed to be placed horizontally and right
side up. Other positions may cause problems with air
 owandshortenthelifespanofthecomponents.
• The SB-3 should be placed in a clean, well-ventilated
area. Do not stack items on or against it.
• Ensureallcablingisroutedproperlyandsafely.
• Ensure your SB-3 is plugged into a properly grounded,
always-on AC electrical outlet.
WARNING
Device should remain powered at all times.
Toreducetheriskofreorelectricshock,do
notexposethisunittorainorotherformsof
moisture.
To prevent electric shock due to exposure
ofblades,donotconnectthepolarizedplug
oftheexternalpowersupplytoanextension
cord, receptacle or other outlet unless the
bladescanbefullyinserted.
Toreducetheriskofanyproblemswithyour
SB player, never place the unit on an operating
electronicorasurfacethatmaygenerateheat.

3
WELCOME
ALL GOOD VIBES
StingrayBusinessisthrilledtoofferyouitsnewestmedia
player, the SB-3 (Stingray Box); the little box with a big
sound.Affordable,user-friendlyandbuilttolast,theSB-3’s
impeccable sound and image quality will allow you to connect
with your customers through your very own musical and
digitalsignagesignature.Thebestmusicforeverymoment,
placeandmoodinyourlife.

4YOUR DEVICE AT A GLANCE
Installation
Not a techie? Not a
problem! Setting up the
SB-3 is a walk in the park.
Turn to page 5 to learn
how to get rolling in no
time.Can’tndwhat
youarelookingfor?Our
resourcefulsupportteamis
at your service at all times.
Content
Choosefromourpreprogrammed
collectionofchannelsorcraft
atotallyuniqueambiancefor
your store without ever having
toworryaboutcopyrightfees.
Integrate on-hold music and
custom messaging seamlessly into
your schedule to maximize every
momentyouhaveacustomer’s
attention.
Content
updates
The SB-3 will arrive
at your doorstep
preloaded with all
thegoodstuffyou
requested. Subsequent
updates will be made
available through the
web.
Features and
functionalities
•Adapt music, messaging and digital
signagetospecicspaceswiththe
zoning option.
•Multiplefeaturesandoptionsavailable
through a remote based control site:
Block songs, schedule messages, select
programs and more.
•LCDfrontpaneldisplayssongtitle,
artist name, message name, network
informationandmenuoptions.
•OurbreakthroughOntheGofeature
allows you to manage your account
fromyourmobiledevice.

5
UNPACKING
Checkyourproductboxforthefollowingitems.Ifthere
are any missing accessories, call 1.888.685.2486 or contact
[email protected] . Please keep all packaging
materialforlateruseincaseyourSB-3mustbere-shipped.
Internet I n
ower 5.0 v 2.
P
A) SB-3 player
B) Power Module
C) Network Cable*
D) Audio Cable
E) HDMI Cable**
C.
D.
A.
B.
NOTES
• The items supplied with your product may vary
dependingonthedevicemodelandyouramplication
system.
• Donotuseanyunapproveditemstoensurethesafety
andproductlifespan.
• Damages or injuries caused by using unapproved items
are not covered by the warranty.
B.
E.
* Only available to clients with an internet connection
** Only included with SB-3s delivering digital signage or music
videos.

6SETTING UP
Setting up the network connection
Skipsteps1and2ifyoudon’thaveaninternetconnection.
1. Connect the network cable to an active network connection.
2.Connecttheotherendofthenetworkcabletotheethernet
port on the SB-3.
Setting up audio
3.Attachbothheadsatoneendofyouraudiocabletotheaudio
outputs “1” and “2” on your SB-3.
4.Attachtheotherendsofyouraudiocabletotheamplier
inputs.Ifyouonlyhaveoneamplierinput,plugonlyone
cable head in and leave the other one dangling. You will not be
needing it.
Settingupon-holdmusicandmessagesfor
phones (Optional)
Tocompletethecircuittothetelephonesystem,followsteps1
to4,butmakesureyouattachoneheadoftheaudiocableto
theamplierinputlinkedtomusicon-hold.
Setting up digital signage or music videos
ToconnectyourSB-3toascreen,plugoneendoftheHDMI
cabletotheHDMIoutputofyourSB-3andattachtheotherend
to your TV HDMI source.
Internet I n
5.0
P
1.
2.
3.
4.
5.
TV HDMI Source
Internet Source Amplifier Power Source
1 - AUDIO - 2 DC 5V
HDMI

7
THIS IS YOUR 9 DIGIT INITIALIZATION
CODE
Important information for clients receiving
internet updates
An active network connection must be maintained to receive
updates. Content updates will be downloaded onto your
device during the download window period you preselected.
Congratulations your music should start playing in no time!
Remember, your device should remain powered at all times.
Please refer to page 7
in french instructions
Back Select
SUPPORT 1-888-685-2486
5.0v 2.
6.
SETTING UP
Setting up power
5. Attach the power module to the power port on the SB-3.
6. The LCD screen on your device will light up to indicate that
the device has been plugged in properly.
Activate
7. Activate your device by calling 1.888.571.9040. and entering
the 9 digital initialization code on your telephone dial.
8.Adjustvolumefromyouramplier,deviceorphonesystem..
USB Update

8
Online Control
Start exploring your new musical universe by logging into the
remoteSB-3ManagementInterface.Toaccessthepage,visit
http://cs.business.stingray.com/login and enter your email
address.
Frequently Asked Questions
Viewouranswerstofrequentlyaskedquestionsbyvisiting
http://business.stingray.com/customer-support and clicking on
SB Media Player Setup and User Guide.
Contact us
Email [email protected]
Phone [phone]
MORE
Environmental operation conditions and
physicalspecications
Use
Unit packing (LxWxH)
Dimensions
Power Supply Voltage Input
Power Consumption
Supported Connector
Indoor
L9’’xW9’’xH4’’
L3.75’’xW73/4’’xH2’’
100-240 VAC, 50/60 hz
5V, 2A
2 RCA outputs (2 mono
zones or one stereo zone)
and one HDMI output.
