Stoelting Futura F131 User manual

Futura F144 and F131 w/ Blender
OWNER'S MANUAL
Manual No. 513603-1 March 2005

Need Parts or Service?
We stock the parts you need.

Our Technicians are factory
trained and are certified in the
Stoelting Technicare program.
Model No.: _______________________
Serial No.: _______________________
Purchase Date: ____________________
Start-Up Date:____________________
CALL
Distributor: _________________________
Phone No.: _________________________
(fill in or affix label)

This manual provides basic information about the freezer. Instructions and suggestions are
given covering its operation and care.
The illustrations and specifications are not binding in detail. We reserve the right to make
changes to the freezer without notice, and without incurrring any obligation to modify or pro-
vide new parts for freezers built prior to date of change.
DO NOT ATTEMPT to operate the freezer until instructions and safety precautions in this
manual are read completely and are thoroughly understood. If problems develop or questions
arise in connection with installation, operation, or servicing of the freezer, contact the company
at the following location:
STOELTING, LLC Ph: 920-894-2293
502 Hwy. 67
Kiel, WI 53042 Fax: [phone]
Owner's Manual
For Futura F144/SF144
Stoelting Counter Model Gravity Freezer
Soft Serve/Shake

Safety Alert Symbol:
This symbol Indicates danger, warning or caution.
Attention is required in order to avoid serious personal
injury.Themessagethatfollowsthesymbol contains
importantinformationaboutsafety.
Signal Word:
Signal words are distinctive words used throughout
this manual that alert the reader to the existence
and relative degree of a hazard.
CAUTION
The signal word “CAUTION” indicates a potentially
hazardous situation, which, if not avoided, may result
in minor or moderate injury and equipment/property
damage.
A Few Words About Safety
SafetyInformation
Read and understand the entire manual before
operating or maintaining Stoelting equipment.
ThisOwner'sManualprovidestheoperatorwith
information for the safe operation and maintenance of
Stoelting equipment.As with any machine, there are
hazards associated with their operation. For this
reasonsafetyisemphasizedthroughoutthemanual.
To highlight specific safety information, the following
safety definitions are provided to assist the reader.
The purpose of safety symbols is to attract your
attentiontopossibledangers.The safety symbols, and
theirexplanations,deserveyourcareful attention and
understanding. The safety warnings do not by them-
selveseliminate any danger.Theinstructions or
warnings they give are not substitutes for proper
accidentpreventionmeasures.
If you need to replace a part, use genuine Stoelting
parts with the correct part number or an equivalent
part. We strongly recommend that you do not use
replacement parts of inferior quality.
WARNING
Thesignalword“WARNING” indicatesapotentially
hazardous situation, which, if not avoided, may result
in death or serious injury and equipment/property
damage.
CAUTION
The signal word “CAUTION” not preceded by the
safetyalertsymbolindicates a potentially hazardous
situation, which, if not avoided, may result in equip-
ment/propertydamage.
NOTICE
The signal word “NOTICE” indicates information or
procedures that relate directly or indirectly to the
safety or personnel or equipment/property.

TABLE OF CONTENTS
SECTION 1 - SPECIFICATIONS .................................................................................. 1
1.1 Description ............................................................................................................ 1
1.2 Specifications......................................................................................................... 2
SECTION 2 - INSTALLATION INSTRUCTIONS .......................................................... 3
2.1 SafetyPrecautions................................................................................................. 3
2.2 ShipmentandTransit ............................................................................................. 4
2.3 FreezerInstallation ................................................................................................. 4
2.4 Floor Stand Installation ........................................................................................... 5
2.5 InstallingPermanentWiring .................................................................................... 5
SECTION 3 - INITIAL SET-UP AND OPERATION ....................................................... 7
3.1 Operator'sSafety Precautions................................................................................ 7
3.2 OperatingControlsand Indicators .......................................................................... 7
3.3 Sanitizing ............................................................................................................... 9
3.4 Freeze Down and Operation.................................................................................. 10
3.5 MixInformation ...................................................................................................... 11
3.6 RemovingMixfrom Freezer ................................................................................... 11
3.7 Cleaning theFreezer.............................................................................................. 12
3.8 Disassembly of Freezer Parts ............................................................................... 12
3.9 Cleaning the Freezer Parts .................................................................................... 14
3.10 Sanitize Freezer and Freezer Parts ....................................................................... 14
3.11 Assembly of Freezer.............................................................................................. 14
3.12 RoutineCleaning .................................................................................................... 16
3.13 PreventativeMaintenance...................................................................................... 16
3.14 ExtendedStorage .................................................................................................. 19
SECTION 4 - TROUBLESHOOTING............................................................................ 21
4.1 Troubleshooting Chart............................................................................................ 21
4.2 Error Code System................................................................................................ 23
SECTION 5 - REPLACEMENT PARTS......................................................................... 25
5.1 How to Order Parts ............................................................................................... 25
WARRANTY .................................................................................................................. 27

Fig. Description Page
1 ModelEndura/Futura131G Freezer ................................................................... 1
2 Specifications .................................................................................................... 1
3 Warning LabelLocations .................................................................................... 3
4 Spaceand Ventilation Requirements.................................................................. 4
5 InstallingTrayandInsert ...................................................................................... 4
6 Power Cord........................................................................................................ 4
7 FloorStand ........................................................................................................ 5
8 PowerCord Connection ..................................................................................... 5
9 Controls ............................................................................................................. 7
10 MixInletRegulator .............................................................................................. 9
11 SanitizingProcedure .......................................................................................... 9
12 CleanControl ..................................................................................................... 9
13 SanitizingHopper ...............................................................................................10
14 SpigotOpened andSolution Draining.................................................................10
15 SanitizingAgitatorShaft .....................................................................................10
16 DispensingProduct ............................................................................................11
17 RemovingMixInlet Regulator.............................................................................11
18 DrainingMix .......................................................................................................12
19 CleaningAgitatorShaft ......................................................................................12
20 Auger Flight Wear and FrontAuger Support Wear.............................................13
21 RemovingFront Door .........................................................................................13
22 Front Door Disassembly ....................................................................................13
23 RemovingAgitator From Shaft ...........................................................................13
24 RemovingAugerSupport ...................................................................................13
25 RemovingO-ring ................................................................................................14
26 Exploded View ofAuger.....................................................................................15
27 Exploded View of Front Door .............................................................................15
28 Install Mix Inlet Regulators .................................................................................15
29 CondenserandFilter..........................................................................................18
30 Cleaning Condenser ...........................................................................................18
31 Spigot, Front Door andAugerAssembly ............................................................26
LIST OF ILLUSTRATIONS

1
1.1DESCRIPTION
TheStoeltingFuturaF144andF131w/Blendercountertop
combinationshake/softservefreezersaregravityfed.The
freezers are equipped with fully automatic controls to
provide uniform product. The freezer is designed to
operatewithalmostanytypeofcommercialsoftserveand
shake mixes available, including ice milk, ice cream,
yogurt, and frozen dietary desserts.
The F144 series freezers allow the operator to dispense
outstandingsoftservefromtheleftpigot,andthickcreamy
shakesfromtherightspigot,withtheconvenienceandcost
of one unit. The freezer is designed to be used with both
barrels in operation. If you desire to use one barrel only,
thefreezermustbecleaned,sanitizedandfilledwithfresh
mixdaily.The F131 freezer includes ablenderformixing
fruitandberriesintothedairyproductformakingsmoothies.
For more information call your authorized Stoelting
Serviceperson.
SECTION 1
SPECIFICATIONS
Figure 2. Specifications
Thismanualisdesignedtoassistqualifiedserviceperson-
neland operators in the installation,operation and main-
tenanceoftheStoeltingModelFutura144gravityfreezer. Figure 1. Model Futura 144/F131 Freezer
(F131 w/ blender shown mounted on
the optional floor stand.)

2
1.2SPECIFICATIONS
MODELFUTURA 144
COUNTERTOPCOMBINATIONSHAKE/SOFTSERVE
GRAVITYFREEZER
Dimensions:
Freezer: 22" (56 cm) wide x 28" (72 cm) deep x 34.75" (88 cm) high
Crated: 28" (71 cm) wide x 35 1/2" (89.4 cm) deep x 40.3" (102.4 cm) high
Weight:
Freezer: 385 lbs. (174.6 kg) Crated: 470 lbs. (213.2 kg)
Electrical:
Approximately11totalrunningAmps,20Amp.maximumfuseorcircuitbreakers.NEMA6-20Ppowercordprovided.
Automaticsafeguardcircuit built into electronic control - protects majorfreezercomponents under normal operating
conditions.
Refrigerant:
R404a
Compressor:
12,000 B.T.U.H./hr.
Drive Motor:
(2) 3/4 H.P.
Cooling
Air cooled requires minimum 3" air clearance on right and left hand side and rear. Minimum 10" top clearance
FreezingCylinderVolume
Two cylinders, .85 gallon, 3.4 Quarts (3,22 liters)
Hopper
2 each, 3 Gallons (11.35 liters) each refrigerated and insulated.

3
SECTION 2
INSTALLATION INSTRUCTIONS
2.1SAFETY PRECAUTIONS
Do not attempt to operate the freezer until the safety
precautionsandoperatinginstructionsin this manual are
readcompletelyand are thoroughly understood.
Takenoticeof all warning labels on the freezer (Fig. 3).
Thelabelshavebeenputtheretohelpmaintainasafe
workingenvironment. The labelshavebeen designed to
withstand washing and cleaning. All labels must remain
legibleforthelifeofthefreezer.
Fig. 3. Warning Label Locations
Labels should be checked periodically to be sure they
canberecognizedaswarninglabels.
Ifdanger, warning or caution labels areneeded,indicate
the part number, type of label, location of label, and
quantityrequiredalong with your address and mail to:
STOELTING, INC.
ATTENTION: Customer Service
502 HWY 67
Kiel, Wisconsin 53042-1600

4
Fig. 4. Space and Ventilation Requirements
2.2 SHIPMENTAND TRANSIT
Thefreezerhas been assembled, operated andin-
spectedat the factory. Upon arrival at the final destina-
tion, the complete freezer must be checked for any
damagewhichmayhave occurred during transit.
Withthe method of packaging used, the freezer should
arriveinexcellentcondition. THE CARRIER IS RE-
SPONSIBLEFORALLDAMAGE INTRANSIT,
WHETHERVISIBLEORCONCEALED.Donotpaythe
freightbilluntilthe freezer has been checked for dam-
age.Havethecarriernoteanyvisible damage on the
freightbill.
Ifconcealeddamaged and/or shortageisfound later,
advisethecarrierwithin10 days and request inspection.
Thecustomermustplace claim for damages and/or
shortages in shipment with the carrier. Stoelting, Inc.
cannot make any claims against the carrier.
2.3FREEZER INSTALLATION
Installationof the freezerinvolvesmoving thefreezer
close to its permanent location, removing all crating,
setting in place, assembling parts, and cleaning.
A. Uncrate the freezer.
B. Accurate leveling is necessary for correct drainage
offreezerbarreland to insure correct overrun. Place
a spirit level on top of the freezer at each corner to
check for level condition. If adjustment is necessary,
levelthefreezerbyturning the bottom part of each
leginorout. Then separate freezer base gasket and
install with the seam to the back and the flat to the
bottom.
C. Aircooled freezers requirecorrectventilation.The
right side of the freezer is the air intake and must
have a 3" (7.5cm) clearance. Air discharges out of the
left side of the unit and must have 3" (7.5cm) clear-
ance. Do not obstruct the intake or discharge
(Fig. 4).
CAUTION
Failuretoprovideadequateventalationwillvoid
Warranty.
D. Place the OFF-ON switch in the OFF position. See
Figure8.
E. Install the drip trays, drain trays, covers and other
miscellaneous parts on the freezer. (Fig. 5)
F. Connect the power cord. The plug is designed for
208 or 230 volt/20 amp duty. Check the nameplate
on your freezer for proper supply. The unit must be
connected to a properly grounded receptacle. The
electrical cord furnished as part of the freezer has a
threepronggroundingtypeplug(Fig.6).Theuseof
an extension cord is not recommended. If one must
be used, use one with a wire size 12 gauge or heavier
with a ground wire. Do not use an adaptor to get
aroundgroundingrequirement.
WARNING
Do not alter or deform electrical plug in any way.
Altering the plug to fit into an outlet of different
configuration may cause fire, risk of electrical
shock, product damage and will void the warranty.
Figure 5. Installing Trays and Inserts
(F131 w/ blender shown)
Figure 6. Power Cord

5
Fig. 7. Floor Stand
2.4 FLOOR STAND INSTALLATION
To install the F144 on the floor stand, follow the steps
outlinedbelow.
1. Uncratethefloor stand and place in an upright posi
tion.
NOTE
Detailedinstructionsareincluded with each floor stand.
2. Place a spirit level across the top of the stand to
check for level condition, side to side and front to
back. If adjustment is necessary, level the stand by
turning the bottom part of each caster in or out, then
tighten the lock nut, and lock caster.
3. Removethe four legsfromthefreezer and replace
withthefourlegadaptersprovided.Adaptersmustbe
fullytightenedtothefreezer.
4. Place the F144 freezer on the floor stand with the
front of the freezer to the door end of the stand.
Secure the freezer to the stand with the nuts and lock
washersprovided.Thenseparatefreezerbasegasket
and install the seam to the back and the flat to the
bottom (Fig. 7).
2.5 INSTALLING PERMANENT WIRING
WARNING
High voltage will shock, burn or cause death. Turn
off and lock out main power disconnect before
proceeding with installation. Do not operate
machinewith cabinet panels removed.
Electrical materials, arrangement and grounding must
conformwithnationalandlocalelectricalcodes.Ifperma-
nent wiring is required by local codes, the following
procedure must be performed:
A. Removethebackpanel.
B. Disconnect the wires from the terminal block. Discon-
nect the green ground wire from the grounding stud.
C. Removethepowercord.
D. Install permanent wiring according to local code.
E. Replace the backpanel.
Figure 8. Power Cord Connection

6

7
3.1 OPERATOR'S SAFETY PRECAUTIONS
SAFEOPERATIONISNOTANACCIDENT; Observe
theserules:
A. Know the freezer. Read and understand the
OperatingInstructions.
B. Notice all warning labels on the freezer.
C. Wear proper clothing.Avoid loose fitting garments,
and remove watches, rings or jewelry which could
cause a serious accident.
D. Maintain a clean work area.Avoid accidents by
cleaning up the area and keeping it clean.
E. Stay alert at all times. Know which switch, push
button or control you are about to use and what
effect it is going to have.
F. Disconnect electrical cord for maintenance.
Never attempt to repair or perform maintenance on
the freezer until the main electrical power has been
disconnected.
SECTION 3
INITIALSET-UPANDOPERATION
G. Do not operate under unsafe operating condi
tions. Never operate the freezer if unusual or exces
sive noise or vibration occurs.
3.2 OPERATION CONTROLSAND INDICATORS
Before operating the freezer, it is required that the
operator know the function of each operating control.
Refer to Figure 9 for the location of the operating
controls on the freezer.
A. SPIGOT SWITCH
TheSPIGOTswitch will automatically actuate the
auger drive and refrigeration systems when the
spigot is opened to dispense product. When the
spigot is closed, the drive motor and compressor will
remain "on" until the product in the barrel reaches
the proper consistency.
Figure 9. Controls
DispenseRate Adjuster
Push To Freeze Switch
CleanSwitch
Green Light
Mix Low Light
Off-OnSwitch
HoldReady
Switch
Off-OnSwitch

8
WARNING
High voltage will shock, burn or cause death. The
OFF-ON switch must be placed in the OFF position
prior to disassembling for cleaning or servicing. Do
notoperate machine with cabinet panels removed.
B. OFF-ON SWITCH
TheOFF-ONswitchisatwoposition toggle switch
used to supply power to the control circuit. When the
switch is in the OFF position, nothing will turn. When
the switch is in the ON position, the freezer can be
run in the freezing mode or cleaning mode. The
freezer will be in the idle mode until a switch is
activated.
C. PUSH TO FREEZE SWITCH
ThePUSHTOFREEZEswitch is a "snap" switch
used to start the freezing cycle. During initial freeze
down, the OFF-ON switch is placed in the ON
position.ThenthePUSHTOFREEZEswitchis
pressed until the drive motor and compressor come
"ON".
NOTE
After the auger drive motor starts, there is a 3
second delay before the compressor starts.
Duringthenormaloperation,the red PUSH TO FREEZE
switch light will illuminate after the freezer has been idle
for the preset cycles. Before drawing product, press the
red PUSH TO FREEZE switch if it is illuminated. Wait
until the green light is illuminated before dispensing.
NOTE
If the freezer shuts off and the PUSH TO
FREEZE light flashes, you have an error
condition.Turnthe OFF-ON switch to theOFF
position, correct the problem and turn the
freezer back on. (See Troubleshooting.)
D. GREEN LIGHT
The green light is used to indicate that the product
has reached the proper consistency and is ready to
be dispensed. The light begins to flash at 98% of
consistency.
NOTE
IfthePUSHTO FREEZE red light is illuminated,
pushthePUSHTOFREEZE switch and wait
untilthegreenlightilluminates before dispens-
ing.
E. CLEAN SWITCH
TheCLEANswitchisa"snap"switch.Whentheswitch
ispushedtherefrigerationsystemwillbeOFFandthe
auger will rotate for cleaning. When the switch is
pushedagain,theaugerwillstopandtheCLEANlight
willflashindicatingthefreezer is in the CLEAN mode.
ToexittheCLEANmodeturn the OFF-ON switch to
the OFF position. If the freezer is left in CLEAN for
more than 30 minutes or is pushed three times in ten
seconds, it will go in error.
F. DRIVE MOTOR OVERLOAD
The internal drive motor overload will trip if the drive
motorisoverloaded.Itwillresetafterapproximately
10-12 minutes. If the drive motor continues to trip,
refertoSection4-Troubleshooting.
G. RED MIX LOW LENS
The red MIX LOW light is designed to alert the
operatorto a low mix condition. The lens will illumi-
natewithapproximatelyonegallonofmix in the
hopper. When the MIX LOW lens is lit, refill hopper
immediately.
NOTE
Failure to immediately refill hopper may result in opera-
tionalproblems.
H. HOLD READY SWITCH
The HOLD READY switch is a push button switch.
Whenpushedinandheldfor5seconds,theholdready
mode will be activated. The product will remain ready
toserveandthefreezerwill not go to idle. To return to
normal operation push and hold for 5 seconds.
I. HIGH PRESSURE CUTOUT
TheHIGHPRESSURECUTOUTswitchisasafety
switchdesigned to protect the compressor from dam-
age due to excessive head pressure. When tripped,
the lever will be out, push in to reset.
J. DISPENSERATE ADJUSTER
TheDISPENSERATEADJUSTERlimitstheopening
of the spigot.
Toadjustproductdispenserate,turn the adjusting
knobclockwise for slower flow and counterclockwise
for faster flow.
K. DOOR INTERLOCK SWITCH
When the door is securely fastened, the freezer will
operate normally. When the door is removed, the
drive and compressor will not run.

9
L. BLENDER POWER SWITCH (F131 Models Only)
Theblender power switch is atwo position toggle
switch used to supply power to the blender. When the
switch is in the OFF position, the agitator will not turn.
When the switch is in the ON position, the agitator
willbeactivatedeverytimetheblenderactivation
switch is pressed.
M. BLENDER ACTIVATION SWITCH
(F131 Models Only)
Theblenderactivationswitchis a two speed, momen
tary contact switch that will actuate the agitator to
blend product when pressed in and held in either the
HIGHorLOW speed position. The HIGH speed
position is used to blend fruit into dairy mix when
makingsmoothies. The LOW speed position is used
during cleaning procedures.
3.3SANITIZING
Sanitizing must be done after the freezer is clean and
just before the hopper is filled with mix. Sanitizing the
night before is not effective. However, youshould
always clean the freezer and parts after using it.
THE UNITED STATES DEPARTMENT OF AGRICUL-
TUREAND THEFOODAND DRUGADMINISTRATION
REQUIRETHATALLCLEANINGANDSANITIZINGSO-
LUTIONS USED WITH FOOD PROCESSING EQUIP-
MENT BE CERTIFIED FOR THIS USE.
When sanitizing the freezer, refer to local sanitary
regulationsforapplicable codes and recommended
sanitizing products and procedures. The frequency of
sanitizing must comply with local health regulations.
Mix sanitizer according to manufacturer’s instructions to
providea100 parts per million strength solution. Mix
sanitizer in quantities of no less than 2 gallons (7.5
liters) of 120°F of water.Allow sanitizer to contact the
surfaces to be sanitized for 5 minutes.Any sanitizer
must be used only in accordance with the
manufacturer’s instructions.
CAUTION
Do not allow sanitizer to remain in contact with
stainlesssteel freezer parts for prolonged
periods. Prolonged contact of sanitizer with freezer
may cause corrosion of stainless steel parts.
In general, sanitizing may be conducted as follows:
A. Push the mix inlet regulator into hopper with air inlet
(long) tube toward the front of the freezer.
(Fig. 10).
Figure 10. Mix Inlet Regulator
B. Prepare 2 gallons (7.5 liters) of sanitizing solution
following manufacturer’s instructions. Pour into
hopper with mix inlet regulator in place (Fig. 11).
Figure 11. Sanitizing Procedure
Figure 12. Clean Control
C. Place the OFF-ON toggle switch in the ON position
while pressing the CLEAN switch. Check for leaks.
(Fig. 12)

10
Figure 13. Sanitizing Hopper
Figure 14. Spigot Opened and Solution Draining
D. Clean sides of hopper, mix inlet regulator and under-
side of hopper cover using a sanitized soft bristle
brush dipped in the sanitizing solution (Fig. 13).
3.4 FREEZE DOWN AND OPERATION
This section covers the recommended operating proce-
dures to be followed for the safe operation of the
freezer.
A. Sanitize just prior to use.
B. Place the OFF-ON switch in the OFF position.
C. With spigots open, pour approximately 1 gallon (3.8
liters) of mix into the hopper.Allow the mix to flush
out about 8 ounces (0.23 liters) of sanitizing solution
and liquid mix. Close the spigot.
D. Fill hopper with approximately 3 gallons (11.4 liters)
of prechilled (40°F or 4°C) mix.
NOTE
Donotoverfillthehopper.Mixlevelmustnotbehigher
than2inches(5cm)fromthetopoftheairinlettubeon
themixinletregulator.
E. The freezer barrel will automatically fill until it is
about 1/2 full. If freezer barrel does not fill, check for
obstruction in the mix inlet regulator. If freezer barrel
fills over 1/2 full, indicated by low overrun, check for
leaks at the mix inlet regulator O-ring or check if
themix inlet regulator was installed correctly or that
the freezer is level.
F. Place the OFF-ON switch in the ON position, then
pressthePUSHTOFREEZE swtich until the freezer
starts.
NOTE
After the auger drive motor starts, there is a 3
second delay before the compressor starts.
E. After five minutes, place a bucket under the spigot
and open spigot to drain sanitizing solution. When
solution has drained, press the CLEAN snap switch
to stop the auger.Allow the freezer barrel to drain
completely (Fig. 14).
F. Filla tall cup withsanitizingsolution.Completely
immerse the blender's agitator shaft in the sanitizer
solution. Do not wipe dry (Fig. 15).
Figure 15. Sanitizing Agitator Shaft
