Strategic Vista VQ1530R User manual

VQ1530R -WEATHER PROOF COLOR
BULLET CAMERA WITH SUNSHADE
Overview
§Weatherproof Design
§Equipped with Removable Sunshade
§Auto Back Light Compensation
§1/4" Color CCD imaging device
§Resolution: 330 TV Lines
§Mounting bracket and power supply
included
Package Contents:
§Check the package for the following
contents listed below.
Installation Instructions:
§Install bracket in the desired camera.
location using the three mounting screws
provided.
§Mount camera onto the bracket.
§Apply power to the camera (using supplied
12V DC Adapter).
§Connect the video cable to the BNC
connector (provided) if connecting to a
TV/Monitor or DVR with a BNC input.
§Adjust the camera direction for the desired
picture view.
Note:If you are using the RCA video cable to
connect the camera to a TV you must tune
your television to an auxiliary (AUX), A/V or
video mode to view the camera(Note:
Consult the TV’s Owner’s Manual for setting
the TV to an auxiliary, A/V or video mode.)
VQ1530R -WEATHER PROOF COLOR
BULLET CAMERA SUNSHADE
Specifications
As our products are subject to continuous
improvement, SVII and its subsidiaries reserve the
right to modify product design, specifications and
prices, without notice and without incurring any
obligation. E&OE.
Sensor 1/4" Interline transfer type
Col CCD
Effective
Pixels 510H x 492V (250K)
Scanning
System 525 Lines 2:1 Interlace
Scanning
Frequency 15.734KHz (H), 59.94Hz (V)
Resolution 330 TV-Lines
Shutter
Speed 1/60 ~ 1/100,000 sec.
S/N Ratio More than 48dB (AGC off)
Sync.
System Internal
Min.
Illumination <1 LUX (F2.0)
White
Balance AWB
Video Output
1.0 Vp-p (75? load)
Lens Fixed (3.6mm)
Power
Supply DC12V ± 10%
Power
Consumption100mA (DC12V)
Operating
Temp -10 to +45 C / 14 to 113F
Operating
Humidity 90% RH Max.
Camera
and Stand
Manual
Power
Supply

VQ1530R
WEATHERPROOF
COLOR BULLET
CAMERA WITH
SUNSHADE
Distributed By:
STRATEGIC VISTA
300 Alden Road, Markham,
Ontario Canada L3R 4C1
For more information, visit:
www.strategicvista.com
