avertX HD828 User manual

This guide is a quick reference that offers users basic information regarding
installation and operation of the HD828 Night Vision Indoor / Outdoor Ultra High
Definition IP Cameras. For further details on installation and operation, please
refer to the User Manual at avertx.com.
Before proceeding, please conrm that the box contains the items listed here. If
any item is missing or has defects, DO NOT install or operate the product and
contact AvertX for assistance.
About this Guide
CONTENTS OF CAMERA BOX
HD828 QUICK START GUIDE
The HD828 camera can be installed directly onto
a wall or the ceiling. Be sure that the structure is
strong enough to support the camera.
1. Remove the camera dome cover by
removing 3 dome screws and lifting.
2. Use the included mounting template to
pre-drill holes for the mounting screws and,
if passing the cable through the ceiling or
wall, drill a 7/8” hole.
3. If surface mounting the cable, unscrew and
remove the cable knockout on the side of
the dome.
4. Connect the camera cable from the ceiling
or wall to the dongle on the camera. If using
the waterproof cable connector, attach it
now. See instructions below.
5. A󰀩x the base of the camera to the wall with
the included self-tapping screws and wall
anchors. If wall mounting, orient camera so
cable knockout faces downward.
6. Adjust the camera to the desired angle.
• The HD828 features 3-axis camera
positioning: Tilt, Camera Rotation, and
Lens Rotation.
• For best IR performance, rotate the
lens so the IR lights are positioned
directly below the lens and on the
horizontal plane.
7. Replace the dome cover. To install, align
screws to the holes. Tighten dome cover
screws just enough for a good seal.
INSTALLATION
Align Holes on Wall
Remove Cover
Adjust Aim
35539AB
4K IP DOME CAMERA
Screws
Paintable
Dome Cover
Waterproof Cable
Connector
Documents &
Desiccant
HD828 Dome Camera
Anchors
Note: If mounting outside, seal the opening at the wall and the base of the
camera with silicone caulking.
Improper installation may cause damage to your camera and void the warranty.
Wall mount bracket and other mounting accessories are available at avertx.com.

Copyright © 2018 AvertX. All rights reserved. Information contained in this document is subject to
change without prior notice. AvertX does its best to provide accurate information, but cannot be held
responsible for typos or mistakes.
NETWORK CABLE INSTALLATION
A 100’ Cat5e non-plenum UTP camera cable is included with your camera. It is
important to consider how the network cable is attached to the camera.
• If passing the cord through a wall or ceiling, drill a 7/8” hole.
• For outdoor installations, ensure the connection between your network cable
and the camera jack is housed within a wall or indoors or use the waterproof
cable connector.
• For outdoor installations, use silicone caulking to seal any holes in the wall or
ceiling to protect against leaks.
• If your installation is in a commercial building, consult local re codes. Plenum
rated cable may be required.
WATERPROOF CABLE
CONNECTOR
This camera features an IP66-rated waterproof cable connector for unprotected
outdoor connections. You do not need to re-terminate the cable to use the
waterproof cable connector.
• Slide all pieces of the waterproof cable connector over the cable plug in this order:
1. Small plastic ring
2. Flexible silicone seal ring. You will need to stretch the silicone seal over
the RJ-45 plug.
3. Large plastic ring
• Slide the rubber “O” ring over the camera plug screw and connect the camera
cable to the plug on the dongle. Screw the large plastic ring into the dongle.
• Insert the exible silicone seal into the “crown” section of the large plastic ring
• Screw the small plastic ring into the large plastic ring
AUTOFOCUS ZOOM LENS
The HD828 Dome Camera is equipped with an Auto Focus Zoom lens. Do not try
to manually focus this camera. Access focus and zoom functions through the +, -
and AF buttons on your recorder.
1-855-2AVERTX (1-855-228-3789)
www.avertx.com
CONNECTING TO THE CAMERA
If you are using this camera with an AvertX recorder, follow the instructions in
the recorder user manual to connect to your camera. You can also set up your
camera using your PC.
1. Type the IP address 192.168.0.250 in the address bar of your browser
2. Enter username and password. The username and password are case sensitive.
AvertX strongly recommends changing the password after the initial setup to
prevent unauthorized access to the camera.
Username – admin
Password – 1234
3. Viewer software may need to be installed on your PC the rst time you connect
to the camera. Download and install the viewer software when prompted.
4. Supported browsers: Chrome, Firefox, Edge, Internet Explorer. Please consult
the user manual for additional browser support.
MICRO SD CARD
AND RESET BUTTON
Your HD828 camera is equipped with a slot for a Micro SD card and a Reset
button. To access these, you must remove the cover of the HD828 camera.
If you have purchased a microSD card to be used for video backup, insert the
formatted card into the slot. Refer to manual for compatible cards and how to
properly format your microSD Card.
The reset button will return the camera to factory default settings, if necessary. To
reset your camera, power cycle the camera then push and hold the reset button
for 15 seconds. This has to be performed within 10 min after the camera has
been powered on or the reset will fail.
For more information on installing your AvertX camera, see the user manual
or view instructional videos at avertx.com/videos.
For Further Instruction
Reset button
microSD Slot
35539AB
