Stratitec Multistage s3002 User manual

About The Stratitec MultiStage™ Surge Protection Technology

This Stratitec surge suppressor meets the L 1449 Rev 2 specification. The L specification ensures this surge suppressor is safe to use and is effective as a surge

suppressor. Note: Surge suppressors made before Feb 1998 generally do not meet the L 1449 Rev 2 specification and can be a fire hazard. We strongly

recommend you discard any old surge suppressors and replace them with new units.

Accommodates three AC

blocks without blocking any

other outlets.

S3002 Surge Suppressor Instructions for Use

R010506

2 Plug in AC Cords and Power Blocks

Note: In the event of a major surge on the telephone line, the tele-

phone protection circuitry will disconnect your equipment. The pro-

tection circuitry cannot be reset. If you find that your telephone

equipment does not work when plugged into the “O T” port, try

plugging your telephone equipment directly into the wall. If your

equipment then works, then the surge suppressor may have saved

it from destruction.

DSL Filter

Connect to DSL Modem

Connect to Phone(s)

WALL

OUTLET

3 Connect the Telephone Protection with Patent-pending

SurgeAbsorb™ Technology

Connect the “O T” port to your

modem, telephone, fax machine,

answering machine, or any other

telephone device you want to protect.

IMPORTANT! It is very important that

you plug the phone cables in as shown.

If you do not, the telephone protection

will be reduced and the Connected

Equipment Warranty will be void.

Connect the “IN” port to the wall telephone

jack.

Please register your surge suppressor at

http://www stratitec com

1 Plug the S3002 into an AC Outlet

The S3002 package includes:

7-Outlet MultiStage™ S3002

6 Ft. Telephone Cord

If you are missing any items, DO NOT RET RN PROD CT TO

STORE. Instead, please call our support center at 888.336.4418

The power cord can plug directly into an AC

outlet.

The power cord can also be routed through the bottom of the surge

suppressor.

Routing the cable through the bottom shortens the cord for a neat

appearance and allows easier access to the master power switch.

Flip the power switch to the “RESET” position. The red “Protected” light should

turn on.

Red “Protected” light - If this light is off but the devices

plugged into the surge suppressor are working, the AC

outlet the surge suppressor power cord is plugged into

may not be grounded. We highly recommend the use of

a grounded AC outlet.

If you are using a grounded AC outlet, and the red “Protected” light is off,

shut down, disconnect power to the surge suppressor, and contact the

Stratitec support center at 888 336 4418

Green “Grounded” light - When this light is on, it indicates that the surge

suppressor is plugged in to a properly-grounded outlet. If this light does not turn

on, you must move to a grounded outlet or have an electrician wire a proper

ground to your outlet. It is safe to use the surge suppressor with the “grounded”

light off, but the surge protection is greatly reduced and the Connected Equip-

ment Warrantly is void.

IMPORTANT! This surge suppressor must be plugged into a

properly-grounded 3-prong AC outlet. If you plug into a non-

grounded outlet or if you use a 2-prong to 3-prong adapter, the

surge protection will be greatly reduced and the Connected

Equipment Warranty will be void.

Note: The power switch contains an integrated circuit breaker. If the

surge unit becomes overloaded, the power switch will automatically

turn off. If this happens, unplug items from the surge suppressor, flip

the power switch to “Off” and then back to “Reset.”

The Stratitec S3002 incorporates two-stage technology to offer solid surge protection:

Stratitec IsolationFailsafe™ protects you and your equipment. If a massive surge occurs, the SurgeAbsorb™

circuitry signals the IsolationFailsafe™ circuitry to automatically disconnect power and shut off your equipment.

This provides ultimate power protection.

IsolationFailsafe™

Stratitec SurgeAbsorb™ diffuses and redirects surge energy, stopping it from reaching your equipment. Although

we use a powerful array of high quality surge absorbers, the protection decreases as surges are absorbed and your

equipment is protected.

SurgeAbsorb™

DSL Users: Connect the “out“ jack

of the surge suppressor to the DSL

filter’s “Line” or “In” connector. Con-

nect your DSL modem and phones

to the DSL filter.

For the highest level of continued protection, we suggest that you move surge suppressors that have been in use

for three or more years to protect less valuable equipment.

Block

IMPORTANT: Register on-line at www.stratitec.com, or follow the alternative registration method out-

lined below to activate your Connected Equipment Warranty.

24-hour, free technical support is available via our web site at www.stratitec.com. If you are unable to get a solution

to your problem through our on-line solutions center, a toll-free technical support number will be provided to contact

us for additional assistance.

STRATITEC PRODUCT AND CONNECTED EQUIPMENT WARRANTY

Limited Product Warranty. STRATITEC warrants to the original purchaser of any STRATITEC Surge Suppressor for the life of the product, that the surge

suppressor shall be free of defects in assembly, or workmanship, and will repair, or replace, at its option, any defective product free of charge (the “Limited Product

Warranty”), subject to the conditions, limitations and exclusions set forth herein.

Limited Connected Equipment Warranty. STRATITEC provides a Limited Connected Equipment Warranty, subject to the conditions, limitations

and exclusions set forth herein STRATITEC warrants that it will repair or replace, at its option, equipment that is damaged by transient voltage surge/spike or

lightning strike (an “Occurrence”) while properly connected through the STRATITEC Surge Suppressor to a properly wired AC power line with protective ground and

telephone line properly connected. This warranty applies only to connected equipment purchased prior to the purchase of the STRATITEC Surge Suppressor or

connected equipment purchased within twelve (12) months after the date of purchase of the STRATITEC Surge Suppressor. If STRATITEC determines that you are

entitled to compensation, STRATITEC will, at its option, pay you the present fair market value of the damaged equipment less $100.00, or pay for the cost of the

repair, up to the maximum amount set forth for your Surge Suppressor Model less $100.00, or send you equivalent replacement equipment. The maximum amount

of the warranty for your Surge Suppressor is shown on the product package or can be found on the STRATITEC web site at www.stratitec.com. The fair market

value of the equipment shall be the current value of the equipment specified in the most recent edition of the Orion Blue Book by Orion Research Corporation, Roger

Rohrs Publisher or a valuation as determined by STRATITEC at STRATITEC’s discretion.

Conditions and limitations applicable to both the Limited Product Warranty and the Limited Connected Equipment Warranty are as follows.

STRATITEC reserves the right to review the damaged STRATITEC Surge Suppressor, the damaged equipment, and the site where the damage occurred. All costs

of shipping the STRATITEC Surge Suppressor and the damaged equipment to and from STRATITEC for inspection shall be borne solely by the purchaser.

STRATITEC reserves the right to negotiate the cost and facility at which any repairs will take place, and STRATITEC must be notified and approve of any repair

facility before any connected equipment is serviced. Approval for repairs must be received in writing from an authorized STRATITEC representative prior to repairs

being made. Any repair or modification of the connected equipment or Surge Suppressor by a facility or entity not authorized in writing by STRATITEC voids this

warranty. If STRATITEC determines, in its sole discretion, that it is impractical to ship the damaged equipment to STRATITEC, STRATITEC may designate in its sole

discretion, an equipment repair facility to inspect and estimate the cost to repair such equipment. The cost, if any, of shipping the equipment to and from such repair

facility and of such estimate shall be borne solely by the purchaser. Damaged equipment must remain available for inspection until the claim is finalized. Whenever

claims are settled, STRATITEC reserves the right to be subrogated under any existing insurance policies the claimant may have. Standard STRATITEC surge

protectors are designed to eliminate disrupting and damaging effects of momentary (less than 10ms) voltage spikes or impulses from lightning or other power

transients. If it can be shown that a voltage spike lasting longer than 10ms has occurred, the Occurrence will be deemed outside the rated capabilities of the surge

suppressor and the warranty is void. All above warranties are null and void if the STRATITEC Surge Suppressor in use during the Occurrence: (a) is not provided

to STRATITEC for inspection upon STRATITEC’s request; (b) Stratitec determines that the STRATITEC Surge Suppressor has been improperly installed, was

altered in any way, or was tampered with; (c) STRATITEC determines that the damage did not result from the Occurrence or that no Occurrence in fact took place;

(d) the repair or replacement of the damaged equipment is covered under another manufacturer’s warranty; (e) the repair or replacement of the damaged equipment

is covered under any insurance policy; or (f) STRATITEC determines that the connected equipment was not used under normal operating conditions or in accordance

with any labels or instructions. All STRATITEC Surge Suppressors must be plugged directly into a properly grounded 120VAC utility power source and must not be

“daisy-chained” together in serial fashion with other power strips, uninterruptible power supplies, grounding adapters, other surge protectors, or extension cords

except a single Stratitec GoldGround extension cord if included with the STRATITEC Surge Suppressor at the time of purchase. Any such installation voids all

warranties. The STRATITEC Limited Connected Equipment Warranty only applies to equipment that is listed by nderwriters’ Laboratories ( L listed) and has all

electrically conductive cords, cables or wires connected through the STRATITEC Surge Suppressor. The STRATITEC Limited Connected Equipment Warranty only

protects against damage to properly connected equipment where STRATITEC has determined, in its sole discretion, that the Surge Suppressor did not function

properly because it had defects in assembly, materials, or workmanship, causing it to operate outside design specifications, and the surge suppressor shows clear

signs of damage, and the damage resulted from the Occurrence. The Limited Connected Equipment Warranty does not protect against acts of God (other than

lightning) such as floods, earthquake, war, vandalism, theft, normal-use wear and tear, erosion, depletion, obsolescence, abuse, damage due to low voltage

disturbances (i.e. brownouts, sags, or power outages), non-authorized program, or system equipment modification or alteration.

Disclaimer of other Warranties and Limitation of Remedies The Limited Product Warranty and the Limited Connected Equipment Warranty are

the only warranties made by STRATITEC EXCEPT AS SPECIFICALLY REQUIRED BY APPLICABLE LAW, THERE ARE NO OTHER WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED WARRANTY OR CONDITION OF QUALITY, MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE, and such implied warranties, if any, are limited in duration to twenty-four (24) months from the date of original purchase IN NO EVENT

SHALL STRATITEC BE LIABLE FOR INCIDENTAL, SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH AS, BUT NOT

LIMITED TO, LOST BUSINESS OR PROFITS ARISING OUT OF SALE OR USE OF ANY STRATITEC SURGE SUPPRESSOR, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES

Sales within the United States and Canada

The Limited Product Warranty and the Limited Connected Equipment Warranty are made only to purchasers who accept delivery of the Stratitec Surge Protector

within the nited States or Canada. SOME STATES IN THE UNITED STATES AND SOME JURISDICTIONS IN CANADA DO NOT ALLOW LIMITATIONS ON

HOW LONG AN IMPLIED WARRANTY LASTS, THE EXCLUSION OF IMPLIED WARRANTIES AND/OR THE LIMITATION OF REMEDIES, INCLUDING

EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES, IN CONSUMER TRANSACTIONS, IN WHICH CASE THE DISCLAIMER OF OTHER

WARRANTIES AND LIMITATION OF REMEDIES STATED IN THE PRECEDING PARAGRAPH DO NOT APPLY TO YOU For example, if you are an individual

and purchased the STRATITEC Surge Protector in the State of Kansas, you have rights based on implied warranties and none of the limitations and disclaimers set

forth in the preceding paragraph apply to you.

Registration requirements and warranty claim procedures. The Limited Product Warranty and Limited Connected Equipment Warranty are valid for

and are made only to the original purchaser of the product. The original purchaser must complete an on-line registration at http://www.stratitec.com or fax name,

address, phone number and purchase/receipt information to 801-760-1988 within 14 days of the date of purchase or else the Limited Connected Equipment

Warranty is void. All damage claims arising from use of the Surge Protector must be made within ten (10) days from the date of the Occurrence and must be

accompanied by the surge protector, damaged equipment, the original receipt for the Surge Suppressor and receipts for all damaged equipment or the Limited
