Strong Technologies SRT D85W User manual

SRT D85W - Instructions www.strong-technologies.com 1
SRT D85W - INSTRUCTIONS
1. Stand Mounting
1.1. Terrace Mounting
Place the Pipe Mount Fixer on the ground pointing to the
North & South,
Place two 1/4 "*1-2/2" Anchor Bolts into the Pipe
Mount Fixer and screw them.
Place and screw the 45° Pipe into the Pipe Mount Fixer
using one M8*65 hex-head cap screw and a M8 nut,
The top of the 45° Pipe has to point to the North.
Warning:
Do not follow the instruction provided on the below
guide regarding the position of the pipe:
Place and screw the two Side Supporting Rods (R) & (L)
on the 45° Pipe using a M8*65 hex-head cap screw & a
M8 nut.
Warning:
You have to use the first hole, the hole circled in green
on the picture.
Place and screw two 1/4 "*1-2/2" Anchor Bolts into the
two Side Supporting Rods (R) & (L).

SRT D85W - Instructions www.strong-technologies.com 2
1.2. Wall Mounting
Place and screw the Pipe Mount Fixer
slightly down tilted,
Proceed with the same steps as the Terrace
Mounting.
Warning:
Do not follow the instruction provided on
the below guide regarding the position of
the pipe:
Terrace Mounting
Wall Mounting

SRT D85W - Instructions www.strong-technologies.com 3
2. Reflector Mounting
Screw the two M8*25 round-head
screws into the Pole Adapter using
two M8 flange nuts.
Place the Pole Adapter into the Tilting
Az/El Bracket.
Screw the two M8*16 Round flat head
Square screws using two M8 flange
nuts,
Screw the M8*65 hex-head cap screw
w/w/sw using a M8 flange nut.
Place the Pole Adapter & Tilting Az/El
Bracket on the Reflector Bracket,
Screw the three M8*16 Round flat
head Square screws using three M8
flange nuts.
Place the Cap washer into the LNBF
Arm,
Place the four M6*30 Round flat head
Square screws into the LNBF Arm.
Use the four M6 stop washers to fix
the screws.
Place and screw the Reflector Bracket
into the screws of the LNBF Arm using
four M6 flange nuts.

SRT D85W - Instructions www.strong-technologies.com 4
Place and screw the Reflector on the
Reflector Bracket using four M8*16
Round flat head Square screws and
four M8 flange nuts,
Place the Plastic Cover on the top of
the LNBF Arm.
3. Dish assembling
The below steps are the same for a Terrace or a Wall stand configuration
Insert the assembled Reflector into the 45° Pipe,
Screw the M8*65 hex-head cap in order to hold
the Reflector.
Place and screw the Clamp adapter on the LNBF
Arm using two M6*35 round-head screws and
two M6 flange nuts,
The Clamp adapter has to be placed on the side
of the Reflector.
Insert the two M5 Spring Washers into the two
M5*12 hex-cross-head cap screws,
Then insert the two M5*12 hex-cross-head cap
screws into the Clamp adapter,
Insert two M5 Washers into the screws and
screw the M5 Square nuts.

SRT D85W - Instructions www.strong-technologies.com 5
Insert the Spacing Bar into the two M5 Square
nuts,
Screw the Spacing Bar in the middle of the
Clamp adapter.
Insert the Right clamp into the Spacing bar,
Insert a M5 Spring Washer into the Spacing bar,
Place a M5 Washer into the Spacing bar,
Insert and screw a M5*12 hex-cross-head cap
screw into the Right clamp.
Place the five Right clamps on the same way as
the picture in order to maximize the reception of
all satellites.
Place the LNBF's on the Right clamps and place
the Left clamps around the LNBF's,
Screw the Left clamp on the Right clamp using
the five 4*16L self-drilling screws.

SRT D85W - Instructions www.strong-technologies.com 6
4. Satellites Tracking
Amos 5 at 17°
Plug the RG6 cable in the LNBF pointing to Amos
5 & Eutelsat 16A (Focal Point LNBF),
Go to Menu, Installation, enter 0000
Go to Dish Setting and select:
-Satellite: 17.0E Amos5/K
-Frequency: 12.216 GHz
-Symbol Rate: 27.500 MS/s
-Polarization: V
You first have to find the good elevation (up &
down), then tight the screws of the Pole Adapter
& the Tilting Az/El Bracket.
Adjust the LNBF polarization in order to get the
best signal reception, then tight the screw of the
LNBF holder.
NB: As soon as you get the signal, you can rotate
the reflector, you will keep the signal.

SRT D85W - Instructions www.strong-technologies.com 7
Eutelsat 36A at 36°
Plug the RG6 cable in the LNBF pointing to
Eutelsat 36A.
Go to Menu, Installation, enter 0000
Go to Dish Setting and select:
-Satellite: 36.0E EUTELSAT 36A/36
-Frequency: 12.245 GHz
-Symbol Rate: 27.500 MS/s
-Polarization: H
Track the signal by:
-adjusting the LNBF holder on the
Spacing Bar
-Rotating the reflector
NB: We recommend you to adjust the LNBF on
EBRU channel (frequency: 12323/H/23436)
Eutelsat 16A at 16°
Plug back the RG6 cable on the LNBF pointing to
Eutelsat 16A & Amos 5,
Go to Menu, Installation, enter 0000
Go to Dish Setting and select:
-Satellite: 16.0E EUTELSAT 16A
-Frequency: 10.803 GHz
-Symbol Rate: 30.000 MS/s
-Polarization: H
You can adjust the polarization of the LNBF in
order to optimize the signal level,
Make sure you still have the signal on Amos 5 as
well.
Astra 4A / SES 5 at 4.9° or Eutelsat 7A at 7°
Choose which Satellites you prefer to receive
between Astra 4A/SES 5 and Eutelsat 7A.
Plug the RG6 cable on the last LNBF,
Go to Menu, Installation, enter 0000
Go to Dish Setting and select:
-Satellite: 4.9° ASTRA4A/SES5
-Frequency: 12.0543 GHz
-Symbol Rate: 29.950 MS/s
-Polarization: V
Or
-Satellite: 7.0 EUTELSAT 7A
-Frequency: 12.728 GHz
-Symbol Rate: 30.000 MS/s
-Polarization: H

SRT D85W - Instructions www.strong-technologies.com 8
Track the signal by:
-adjusting the LNBF holder on the Spacing Bar.
If the signal is not coming you have to rotate the
reflector; in this case you will have to confirm
that Eutelsat 36A has still a good signal quality.
In order to track Astra 2F & Badr 5, you only have
to adjust the LNBF holders on the Spacing Bar.
Astra 2F at 28,2°
Plug the RG6 cable on the second LNBF pointing
to Astra 2F,
Go to Menu, Installation, enter 0000
Go to Dish Setting and select:
-Satellite: 28,2E ASTRA 1N/2A/2F
-Frequency: 12.525 GHz
-Symbol Rate: 27.000 MS/s
-Polarization: V
Badr 5 at 26°
Plug the RG6 cable on the third LNBF pointing to
Bard 5,
Go to Menu, Installation, enter 0000
Go to Dish Setting and select:
-Satellite: 26.0E BARD 4,5,6
-Frequency: 12.303 GHz
-Symbol Rate: 27.500 MS/s
-Polarization: H
NB: As the two LNBFs are close from each others,
you need to adjust them in order to optimize the
signal reception of both satellites.

SRT D85W - Instructions www.strong-technologies.com 9
5. DiSEqC Setting
Crimp five RG6 cables of 1.5 meters long each,
Crimp one RG6 cable (distance between the DiSEqC
switch and the receiver),
Plug the RG6 cables on the LNBFs,
Place a self-locking plastic around the LNBF Arm,
Place all the RG6 cables into the self-locking plastic.
Use one DiSEqC switch SRT 8X1 to connect the 5
LNBFs to the receiver
-Input LNB1 - Eutelsat 36A
-Input LNB2 - Astra 2F
-Output RECIEVER - Plug the RG6 cable (from the
DiSEqC to the receiver)
Place the DiSEqC switch into the Reflector Bracket,
Plug the 3 remaining RG6 cables to the DiSEqC switch,
-Input LNB3 - Bard 5
-Input LNB4 - Eutelsat 16A & Amos 5
-Input LNB5 - Astra 4A/SES 5 or
Eutelsat 7A
Place back the DiSEqC switch into the Reflector
bracket.
DiSEqC Setting
Go to Installation, Enter as password 0000, Go to Dish Setting:
Select the below information for each Satellite.
Satellite
36.0E Eutelsat
36A/36
28.2E ASTRA
1N/2A/2F
26.0E BADR
4,5,6
16.0
EUTELSAT
16A
17.0E
AMOS
5/K
4.9E
ASTRA4A
/SES5
7.0E
EUTELSAT 7A
Frequency
12.245 Ghz (H)
12.526 Ghz
(H)
12.303 GHz
(H)
10.803 Ghz
(H)
12.216
GHz (V)
12.054 Ghz
(V)
12.728 GHz
(H)
DiSEqC 1.0
OFF
OFF
OFF
OFF
OFF
OFF
OFF
DiSEqC 1.1
1 of 16
2 of 16
3 of 16
4 of 16
4 of 16
5 of 16
5 of 16
