Studebaker SB2000 User manual

E - 1
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
WARNING
The Caution Marking is located at the rear enclosure of the apparatus.
The rating plate is located at bottom enclosure of the apparatus.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Cleaning-Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not place this product on an unstable cart, stand, tripod, bracket, or table.
The product may fall, causing serious injury to a child or adult, and serious
damage to the product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product. Any mounting
of the product should follow the manufacturer’s instructions, and should use
a mounting accessory recommended by the manufacturer. A product and cart combination
should be moved with care-quick stops, excessive force and uneven surfaces may cause
the product and cart combination to overturn.
9. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including ampliers) that product heat.
10. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong is provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
IMPORTANT SAFETY INSTRUCTIONS
The lightning flash and
arrow head within the
triangle is a warning
sign alerting you of
“dangerous voltage”
inside the product.
CAUTION:TO REDUCE THE
RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (ON
BACK), NO USER SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The exclamation
point within the
triangle is a warning
sign alerting you of
important instructions
accompanying the
product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
11. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
12. Only use attachments/accessories specied by the manufacturer.
13. Unplug this apparatus during lightning storms or when unused for a long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
15. This appliance shall not be exposed to dripping or splashing water and that no object lled
with liquids such as vases shall be placed on the apparatus.
16. Do not overload wall outlet. Use only power source as indicated.
17. Use replacement part as specied by the manufacturer.
18. Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks.
19. Power Sources - This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your home, consult
your product dealer or local power company. For products intended to operate from battery
power, or other sources, refer to the operating instruction.
20. Object and Liquid Entry - Never push objects of any kind into this product through openings
as they may touch dangerous voltage points or short-out parts that could result in a re or
electric shock. Never spill liquid of any kind on the product.
21. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to
qualied service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions. Adjust only
those controls that are covered by the operating instructions as an improper adjustment
of other controls may result in damage and will often require extensive work by a qualied
technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way, and
f ) When the product exhibits a distinct change in performance - this indicates a need for service.
22. To be completely disconnected the power input, the mains plug of apparatus shall be
disconnected from the mains.
23. The mains plug is used as disconnect device. The mains plug of apparatus should not be
obstructed OR should be easily accessed during intended use.
E - 2
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio technician for help.
E - 3
WARNING
Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a radio receiver,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
This system is equipped with non-skid rubber ‘feet’ to prevent the product from moving when
you operate the controls. These ‘feet’ are made from non-migrating rubber material specially
formulated to avoid leaving any marks or stains on your furniture. However certain types of oil
based furniture polishes, wood preservatives, or cleaning sprays may cause the rubber ‘feet’
to soften, and leave marks or a rubber residue on the furniture.
To prevent any damage to your furniture we strongly recommend that you purchase small self-
adhesive felt pads, available at hardware stores and home improvement centers everywhere,
and apply these pads to the bottom of the rubber ‘feet’ before you place the product on ne
wooden furniture.
SAVE THESE INSTRUCTIONS
COMPLIANCE WITH FCC REGULATIONS
PROTECT YOUR FURNITURE!!
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT. FULLY INSERT.
This symbol indicates that this product incorporates double insulation between hazardous
mains voltage and user accessible parts.
R-3252 IB STUD 001 REV0 GB.indd 1 2016/3/18 17:06:13

This warranty gives you specic legal rights, and you may also have other rights which vary
from state to state. TO OBTAIN SERVICE please remove all batteries (if any) and pack the unit
carefully and send it freight prepaid to SPECTRA at the address shown below. IF THE UNIT
IS RETURNED WITHIN THE WARRANTY PERIOD shown above, please include a proof of
purchase (dated cash register receipt) so that we may establish your eligibility for warranty
service and repair of the unit without cost. Also include a note with a description explaining how
the unit is defective. A customer service representative may need to contact you regarding the
status of your repair, so please include your name, address, phone number and email address
to expedite the process.
IF THE UNIT IS OUTSIDE THE WARRANTY PERIOD, please include a check for $10.00 to cover
the cost of repair, handling and return postage. All out of warranty returns must be sent prepaid.
It is recommended that you contact SPECTRA rst at 1-800-777-5331 or by email at custserv@
spectraintl.com for updated information on the unit requiring service. In some cases the model
you have may be discontinued, and SPECTRA reserves the right to offer alternative options
for repair or replacement.
SPECTRA MERCHANDISING INTERNATIONAL, INC.
4230 North Normandy Avenue,
Chicago, IL 60634, USA.
1-800-777-5331
Printed in China
0316
To register your product, visit the link on the website below to enter your information.
http://www.spectraintl.com/wform.htm
SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from
defective materials or factory workmanship for a period of 90 days from the date of original
customer purchase and provided the product is utilized within the U.S.A. This warranty is not
assignable or transferable. Our obligation under this warranty is the repair or replacement of
the defective unit or any part thereof, except batteries, when it is returned to the SPECTRA
Service Department, accompanied by proof of the date of original consumer purchase, such as
a duplicate copy of a sales receipt.
You must pay all shipping charges required to ship the product to SPECTRA for warranty service.
If the product is repaired or replaced under warranty, the return charges will be at SPECTRA’s
expense. There are no other express warranties other than those stated herein.
This warranty is valid only in accordance with the conditions set forth below:
1. The warranty applies to the SPECTRA product only while:
a. It remains in the possession of the original purchaser and proof of purchase is demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service, usage outside
the descriptions and warnings covered within the user manual or non-SPECTRA approved
modications.
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by electrical wiring not in
compliance with electrical codes or SPECTRA user manual specications, or failure to provide
reasonable care and necessary maintenance as outlined in the user manual.
3. Warranty of all SPECTRA products applies to residential use only and is void when products
are used in a nonresidential environment or installed outside the United States.
E - 5
E - 6
LOCATION AND DESCRIPTION OF CONTROLS
POWER SUPPLY
CAUTION:
Danger of explosion if batteries are incorrectly replaced. Replace only with the same or
equivalent type.
Note:
When the unit is plugged into an AC outlet, it automatically switches to AC power source even
if batteries are installed.
TURNING UNIT ON AND OFF
1. Rotate the On/Off Volume Control clockwise to turn on the unit, you will hear a “click” sound.
2. Rotate the On/Off Volume Control counter-clockwise to turn off the unit, a “click” sound is heard.
The SB2000 can be operated from the following power sources:
AC: 120V 60 Hz
DC: 4 x 1.5V , battery type R14/ UM-2/ “C” size (not provided)
CONNECTING TO AC POWER AND INSTALLING BATTERIES
1. Insert the plug of Power Cord into a standard wall outlet with a constant AC power supply.
2. Install 4 fresh alkaline batteries into the Battery Compartment following the polarity diagram
inside. Use only the specied size and type of batteries.
IMPORTANT:
• Be sure that the battery is installed correctly. Wrong polarity may cause permanent damage
to the unit.
• For best performance and longer operating time, we recommend the use of alkaline batteries.
• If the unit is not to be used for an extended period of time, remove all the batteries. Old or
leaking battery can cause damage to the unit and will also void the warranty.
• Do not dispose of battery in re. Battery may leak or explode.
• Battery shall not be exposed to excessive heat, such as sunshine, re or the like.
E - 4
1. Dial scale
2. Tuning Knob
3. FM/AM Band Selector
4. AUX IN Jack
5. On/Off Volume Control
6. Speaker
7. Foldable Carrying Handle
8. AC Power Cord
9. Battery & AC Cord Compartment
10. Swivel FM Telescopic Antenna
LISTENING TO THE RADIO
1. Use the Band Selector to choose the AM or FM band.
2. Turn on the radio by rotating the On/Off Volume Control clockwise.
3. Use the tuning knob to tune to your desired radio station.
4. Adjust the volume level.
HINTS FOR BEST RECEPTION:
AM - The AM antenna is located inside the cabinet of the unit. If AM reception is weak, change
the position of unit until the internal antenna picks up the strongest signal.
FM - To insure maximum FM tuner reception, fully extend the FM telescopic antenna and rotate
it for the best FM radio reception.
LISTENING TO AN AUXILIARY AUDIO SOURCE
This unit provides an auxiliary audio signal input jack for connecting external audio devices like
MP3 players, CD players, smart phones and iPods (except iPod shufe 3rd generation) to listen
to your external source through the speakers of this system.
1. You need an audio cable (not included) with one 3.5 mm stereo plug on each end of the cable.
2. Plug one end of the cable into the AUX-IN jack located on the right hand side of the unit and the
other end of the cable into the Line-out Jack or Headphone Jack of your external audio device.
3. Turn on the external audio device.
4. Turn on your unit and it will switch to AUX mode automatically.
5. The volume level can now be controlled through the volume control of your radio. Operate
all other functions on the auxiliary device as usual.
Note:
(1) If you connected the Line-out Jack of your external device then you only need to adjust the
volume control of this system. If you connected the Headphone Jack of your external device
then you may need to adjust both the volume control of your external device and the volume
control of this system to nd the most desirable volume setting.
(2) Remove the audio cable from AUX IN jack when you nish listening. Don’t forget to switch
off the power on your external device as well.
E - 7
SPECIFICATIONS
POWER SUPPLY
FREQUENCY RANGE
AC - 120V 60Hz, 4W
DC - 4 x1.5V type R14/ UM-2/ “C” size batteries (not provided)
FM 88 -108 MHz
AM 535 -1705 kHz
TROUBLESHOOTING GUIDE
90 DAY LIMITED WARRANTY AND SERVICE
VALID IN THE U.S.A. ONLY
If you experience difculties in the use of this music system, please check the following or call
1-800-777-5331 for Customer Service.
Symptom Possible Cause Solution
Noise or sound
distorted on AM or
FM broadcast.
- Station not tuned properly for AM
or FM.
- FM: Telescopic antenna is not
extended.
- AM: The bar antenna is not positioned
correctly.
- Retune the AM or FM broadcast
station.
- Fully extend the FM telescopic
antenna.
- Reposition the unit until the best
reception is obtained.
AM or FM no
sound.
- Unit not set to AM or FM band.
- Volume at minimum.
- Slide the band selector to AM or FM
position.
- Increase Volume.
R-3252 IB STUD 001 REV0 GB.indd 2 2016/3/18 17:06:13
