Sub-Zero IC-24FI Guide

Integrated Refrigeration Design Guide

Models IC-18F and IC-30R.
Features and specications are subject to change at any
time without notice. Visit subzero.com/specs for the most
up-to-date information.
IMPORTANT NOTE: Throughout this guide, dimensions may
vary by ± 1/8"(3). Dimensions in parentheses are millimeters
unless otherwise specied.
Contents
3Integrated Refrigeration
4Specications
8Custom Panels
11 Full-Scale Template

subzero.com/specs | 3
INTEGRATED REFRIGERATION
KEY FEATURES
•Custom front panels and hardware allow for innite
design options.
•Point-of-use refrigeration that can be placed anywhere in
the home.
•Dual refrigeration; two compressors preserve food’s
goodness in self-contained compartments.
•Energy efcient; many models are ENERGY STAR®
qualied.
•Star-K certied.
Integrated Refrigeration
With custom front panels and hardware, Sub-Zero invented
integrated columns, tall and drawer models that disappear
into the decor. Integrated units t ush with other cabinets,
making integrated refrigeration as practical and beautiful in
the master suite, bar or theatre room as in the kitchen.
INTEGRATED MODELS
IC-18FI IC-24R,
IC-24FI
IC-30R(ID),
IC-30FI
IC-36R(ID) IT-30R(ID),
IT-30FI, IT-30CI(ID)
ID-24R,
ID-24F(I)
ID-27R ID-30R(P),
ID-30F(I), ID-30C(I)
ID-36R(P),
ID-36C(I)
IT-36R(ID),
IT-36CI(ID)

4 | Sub-Zero Customer Care 800.222.7820
INTEGRATED REFRIGERATION
Overall Dimensions
COLUMN
691/2"
(1765)
W24" (610)
84"*
(2134)
41/2" (114)
35/8" (92)
*831/2"(2121) MIN TO 841/2"(2146) MAX
A
B
13/4" (45)
COLUMN
MODEL W A B
IC-18FI 18" (457) 21/2"(64) 161/2"(419)
IC-24R, IC-24FI 24" (610) 4" (102) 221/2"(572)
IC-30R(ID), IC-30FI 30" (762) 55/8"(143) 281/2"(724)
IC-36R(ID) 36" (914) 71/4"(184) 341/2"(876)
Specications
INTERIOR CAPACITY
COLUMN R CU FT (L) F CU FT (L)
IC-18FI 8.4 (238)
IC-24R 12.9 (365)
IC-24FI 12.3 (348)
IC-30R(ID) 17.3 (490)
IC-30FI 15.3 (433)
IC-36R(ID) 21.4 (606)
TALL R CU FT (L) F CU FT (L)
IT-30R(ID) 16.5 (467)
IT-30FI 15.1 (428)
IT-30CI(ID) 10.6 (300) 5.0 (142)
IT-36R(ID) 20.5 (580)
IT-36CI(ID) 13.3 (377) 6.4 (181)
DRAWER R CU FT (L) F CU FT (L)
ID-24R 4.0 (113)
ID-24F(I) 3.8 (108)
ID-27R 4.6 (130)
ID-30R(P) 5.2 (147)
ID-30F(I) 4.9 (139)
ID-30C(I) 3.0 (85) 2.0 (57)
ID-36R(P) 6.6 (187)
ID-36C(I) 3.4 (96) 2.5 (71)
SHIPPING WEIGHT
COLUMN LB (KG)
IC-18FI 260 (118)
IC-24R, IC-24FI 340 (154)
IC-30R(ID), IC-30FI 400 (181)
IC-36R(ID) 440 (200)
TALL LB (KG)
IT-30R(ID), IT-30FI, IT-30CI(ID) 400 (181)
IT-36R(ID), IT-36CI(ID) 460 (209)
DRAWER LB (KG)
ID-24R, ID-24F(I) 170 (77)
ID-27R 190 (86)
ID-30R(P), ID-30F(I), ID-30C(I) 210 (95)
ID-36R(P), ID-36C(I) 250 (113)
IMPORTANT NOTE: Overall dimensions do not include
panels or handles. Dimensions will vary with panel
thickness.

subzero.com/specs | 5
INTEGRATED REFRIGERATION
Overall Dimensions
TALL DRAWER
173/4"
(451)
W24" (610)
84"*
(2134)
109/16"
(268)
447/8"
(1140)
135/16"
(338)
3/8" (10)
41/2" (114)
35/8" (92)
*831/2"(2121) MIN TO 841/2"(2146) MAX
3/8" (10)
A
B
13/4" (45)
W
173/4"
(451)
24" (610)
1/4" (6)
34
1/2"*
(876) 109/16"
(268)
135/16"
(338)
3/8" (10)
35/8" (92)
*34" (864) MIN TO 35" (889) MAX
TALL
MODEL W A B
IT-30R(ID), IT-30FI 30" (762) 55/8"(143) 281/2"(724)
IT-30CI(ID) 30" (762) 55/8"(143) 281/2"(724)
IT-36R(ID), IT-36CI(ID) 36" (914) 71/4"(184) 341/2"(876)
DRAWER
MODEL W
ID-24R, ID-24F(I) 24" (610)
ID-27R 27" (686)
ID-30R(P), ID-30F(I), ID-30C(I) 30" (762)
ID-36R(P), ID-36C(I) 36" (914)

6 | Sub-Zero Customer Care 800.222.7820
INTEGRATED REFRIGERATION
Opening Dimensions
INTEGRATED MODELS
25" (635)
OPENING
DEPTH
W
OPENING WIDTH
H
OPENING
HEIGHT
NOTE: Shaded areas will be visib
le and should be finished to match cabinetry.
SIDE
VIEW
TOP VIEW
FRONT VIEW
3/4" (19)
TYPICAL
31/2"
(89)
TYPICAL
OPENING DIMENSIONS
COLUMN W H
IC-18FI 18" (457) 84" (2134)
IC-24R, IC-24FI 24" (610) 84" (2134)
IC-30R(ID), IC-30FI 30" (762) 84" (2134)
IC-36R(ID) 36" (914) 84" (2134)
TALL W H
IT-30R(ID), IT-30FI, IT-30CI(ID) 30" (762) 84" (2134)
IT-36R(ID), IT-36CI(ID) 36" (914) 84" (2134)
DRAWER W H
ID-24R, ID-24F(I) 24" (610) 341/2"(876)
ID-27R 27" (686) 341/2"(876)
ID-30R(P), ID-30F(I), ID-30C(I) 30" (762) 341/2"(876)
ID-36R(P), ID-36C(I) 36" (914) 341/2"(876)
The depth of each integrated model is 24" (610). Allow for
panel thickness when planning the nished opening depth.
Approximately 31/2"(89) of the opening depth may be visible
when the door/drawers are open and should be nished to
match cabinetry. Refer to the illustration below.
DUAL INSTALLATION
When installing two units side by side in a dual installa-
tion, the opening width is the width of the two units added
together. A dual installation kit will be required for this instal-
lation. If a dual installation kit is not specied, a minimum
2" (51) ller strip is required between units.
Dual installation kits are available through an authorized
Sub-Zero dealer. For local dealer information, visit the nd a
showroom section of our website, subzero.com. For ques-
tions regarding the installation, call Sub-Zero customer care
at 800-222-7820.
25" (635)
OPENING
DEPTH
W
OPENING WIDTH
H
OPENING
HEIGHT
NOTE: Shaded areas will be visible and should be finished to match cabinetry.
SIDE VIEW
TOP VIEW
FRONT VIEW
3/4" (19)
TYPICAL
31/2"
(89)
TYPICAL

subzero.com/specs | 7
INTEGRATED REFRIGERATION
Electrical
The electrical supply must be located within the shaded
area shown in the illustration and chart below. A separate
circuit, servicing only this appliance is required. A ground
fault circuit interrupter (GFCI) is not recommended and may
cause interruption of operation.
The electrical outlet must be positioned with the grounding
prong to the right of the thinner blades.
Installation must comply with all applicable electrical codes.
ELECTRICAL REQUIREMENTS
Electrical Supply 115 VAC, 60 Hz
Service 15 amp
Receptacle 3-prong grounding-type
ELECTRICAL SUPPLY LOCATION
MODEL A
18" Model 6" (152)
24" Model 91/2"(241)
27" Model 11" (279)
30" Model 121/2"(318)
36" Model 151/2"(394)
A
1/4" (6)
1/4" (6)
41/4"
(108)
41/2"
(114)
FLOOR
LEFT SIDE
OF OPENING
Electrical supply location.
Plumbing
The water supply line should be located within the shaded
area shown in the illustration below. The water supply line
should be connected to the house supply with an easily
accessible shut-off valve. Do not use self-piercing valves.
The water supply line must not interfere with installation of
the anti-tip bracket.
A reverse osmosis system can be used provided there is
constant water pressure of 35–120 psi (2.4–8.3 bar) supplied
to the unit at all times. A copper line is not recommended
for this application.
Installation must comply with all applicable plumbing codes.
PLUMBING REQUIREMENTS
Water Supply 1/4" OD copper, braided
stainless steel or PEX tubing
Pressure 35–120 psi (2.4–8.3 bar)
Excess Line for Connection 36" (914)
WATER SUPPLY LOCATION
MODEL A
18" Model 3" (76)
24" Model 51/2"(140)
30" Model 6" (152)
36" Model 9" (229)
3" (76)
6" (152)
RIGHT SIDE
OF OPENING
AREA EXTENDS 1/2"(13)
FORWARD ON FLOOR
A
Water supply location.

8 | Sub-Zero Customer Care 800.222.7820
INTEGRATED REFRIGERATION
Custom Panels
For integrated models, custom door panels and handle
hardware must be provided. Refer to the panel requirements
chart and typical panel dimensions.
The thickness of the custom panel can vary. A minimum
5/8"(16) thick panel is required, but the thickness can be
increased provided it does not exceed the weight limit. The
depth of each integrated model is 24" (610). Allow for panel
thickness when planning the nished opening depth. Refer
to the full-scale template on page 11.
CAUTION
As reveals between cabinetry and the unit decrease,
severe nger pinching can occur while door is closing.
Finish all sides of custom panels. They will be visible when
the door/drawer is open.
D-style handles are recommended. Door handles must be
located near the edge of the panel opposite the hinge and
should be centered top to bottom. Drawer handles must
be located near the top edge of each panel. Stainless steel
tubular and pro handles are available through an authorized
Sub-Zero dealer. For local dealer information, visit the nd a
showroom section of our website, subzero.com.
PANEL REQUIREMENTS
PANEL WEIGHT MAX
18" Column 45 lb (20 kg)
24" Column 60 lb (27 kg)
30" Column 75 lb (34 kg)
36" Column 75 lb (34 kg)
PANEL WEIGHT MAX
30" Tall (door) 50 lb (22 kg)
36" Tall (door) 60 lb (27 kg)
Drawer 15 lb (7 kg)
PANEL THICKNESS MIN
All Panels 5/8"(16)
TYPICAL PANEL DIMENSIONS
Typical panel dimensions are based on an 84" (2134) nished
height for column and tall models and 341/2"(876) for drawer
models, with a 4" (102) toe kick and 1/8"(3) reveals. Panel
dimensions must be adjusted accordingly for all other instal-
lations. Refer to the illustration for panel heights and the
chart below for panel widths.
PANEL WIDTH
MODEL W
18" Model 173/4"(451)
24" Model 233/4"(603)
27" Model 263/4"(679)
30" Model 293/4"(756)
36" Model 353/4"(908)
DUAL INSTALLATION
For dual installations, refer to the illustration for panel
heights and the chart below for panel widths.
PANEL WIDTH
MODEL W
18" Model 1713/16"(452)
24" Model 2313/16"(605)
27" Model 2613/16"(681)
30" Model 2913/16"(757)
36" Model 3513/16"(910)
W
493/8"
(1254)
139/16"
(345)
1611/16"
(424)
WW
797/8"
(2029)
Column Tall Drawer

subzero.com/specs | 9
INTEGRATED REFRIGERATION
Custom Panels
DOOR PANEL HEIGHT
The height of the custom door panel can extend beyond the
typical panel height, provided it does not exceed the weight
limit. Refer to the illustration below.
TOE KICK CLEARANCE
The height of the toe kick area can extend beyond the
typical toe kick height, provided it does not exceed the
dimensions in the illustration below.
24" (610)
TO BACK OF UNIT
VENTED
LOUVERS
HINGE
DOOR
PANEL
11/8" (29)
MAX
TOE KICK
ADJUSTMENT
A DECORATIVE TOE KICK
CANNOT EXTEND
BEYOND THIS PLANE
4" (102)
TO
6" (152)
FROM FLOOR
Toe kick—side view.
13/4"
(45)
A DECORATIVE VALANCE
CANNOT EXTEND
BEYOND THIS PLANE
DOOR
PANEL
HINGE
24" (610)
TO BACK OF UNIT
84"
(2134)
1/8" (3)
Upper valance (column and tall)—side view.

10 | Sub-Zero Customer Care 800.222.7820
INTEGRATED REFRIGERATION
Handle Hardware
Optional stainless steel tubular and pro handles are avail-
able through an authorized Sub-Zero dealer. For local dealer
information, visit the nd a showroom section of our
website, subzero.com.
Refer to the chart below for the length and stud spacing of
standard handles for integrated models.
STANDARD HANDLES
COLUMN LENGTH STUD SPACING
Tubular 501/8"(1273) 471/8"(1197)
Pro 483/8"(1229) 471/8"(1197)
TALL (DOOR) / 36" DRAWER LENGTH STUD SPACING
Tubular 331/4"(845) 301/4"(768)
Pro 311/2"(851) 301/4"(768)
30" DRAWER LENGTH STUD SPACING
Tubular 271/4"(692) 241/4"(616)
Pro 251/2"(648) 241/4"(616)
27" DRAWER LENGTH STUD SPACING
Tubular 241/4"(616) 211/4"(540)
Pro 221/2"(572) 211/4"(540)
24" DRAWER LENGTH STUD SPACING
Tubular 211/4"(540) 181/4"(464)
Pro 191/2"(495) 181/4"(464)
