Suhyoon PA-30R User manual

PA MIXER AMPIFIER
RECEIVER PA-30/60R
Features
■AMPLIFIER SECTION
P i f d li bili
*
P
rotect
i
on
f
or pro
d
uct re
li
a
bili
ty
Over current limiter circuit
Over heating protection
* Selectable Impedance : 25V,35V,50V,70V and 100V
* Soft start circuit for AC power on
* Output LED indicator
* Tone control
*
Input
:
2 mic (XLR), 1 aux (RCA) and tel.paging
Input
2
mic
(XLR),
1
aux
(RCA)
and
tel.paging
* Telephone paging
* Music –on hold tape, tuner
* Vox microphone 1 (muting for priority)
* Master volume control
■TUNER SECTION
* Tuner LCD Display
LED B k li h
*
LED
B
ac
k
li
g
h
t
* Up/Down Switch
* Band Selector FM 1,2,3, AM 1,2
* Memory Switch 1,2,3,4,5,6

Technical Specifications
Architects and Engineers Specifications
PA-30/60R
AMPLIFIER PA-30R PA-60R
Rated Output (RMS) 30W 60W
In
p
ut
Mic -50dBm (2.45mV) 2Kohm Balanced
Line -10dBm (245mV) 200Kohm Balanced
Tel
10dBm (245mV) 5Kohm Balanced
p
Sensitivity
Impedance
Tel
-
10dBm (245mV) 5Kohm Balanced
Rec/Line (pre)
Output 0dBm (1000mV) 600 ohm Unbalanced
Music-on hold 0dBm (1000mV) 600 ohm Balanced
Frequency Response
Mic : Less than -3dB (200Hz ~ 20KHz)
Line : Less than -3dB (35Hz ~ 20KHz)
Signal to Noise Ratio
Mic : More then 70dB (“A” weight)
Line : More then 80dB (“A” weight)
T.H.D (at 1KHz Output ) Less than 0.5%
Tone Controls Bass : +/- 10dB at 100Hz & Treble : +/-10dB at 10kHz
Low IMP 8 Ohm/31V 8 Ohm/44V
Output /
Impedance
High IMP
Europe (Ohm) America (Ohm)
100V 70V
PA-30R 333.3 Ohm 163.3 Ohm
PA-60R 166.6 Ohm 81.6 Ohm
TUNER SECTION
Tuning Range FM : 87.5 ~ 108MHz & AM : 522~1620K㎐
Usable Sensitivity & SN Ratio FM : 2uV, AM : 4.5uV & FM : 60db, AM : 45dB
Antenna Impedance FM : 75 Ohm Coaxial Cable & AM : Loop Antenna &
Lead Antenna
Memory Back-up Time For 15days (After AC Power Off)
GENERAL
Power Consumption 80W 120W
Power Source 110-240VAC 50/60㎐
Weight (kg/lbs) 5.5/12 7.5/16.5
Dimensions (W x H x D) mm/inch 420 x 88 x 320 & 17″x 3.5″x 13 ″
Copyright ⓒ1985-2007, SUHYOON CORPORATION. All right reserved.
OFFICE & FACTORY : 1115-34 Hwagok-Dong, Kangseo-ku, Seoul, Korea.
www.suhyoon.co.kr E-MAIL:[email protected].kr
