Sumex 3505150 Operation instructions

1
JUMPSRT &
POWER SION
   
   
   
6000mAh
[ I Lithium I p



-2-
OPERATION GUIDANCE
Indicator
Press the switch to check the storage level of the jump starter. The indicator will ash one
by one during the period of charging.
Different number of solid indicators show different storage level of power. AII indicators light
off when the charging is paused or completed.
Charging instructions
1. Plug the charger cable to any working USB
output port.
2. Connect the Micro USB to the 5V2A Input
port.
JUMP START & POWER STATION
Always follow basic safety precautions when using electrical appliances.
Read all instructions carefully, Please keep this instruction manual for easy
reference.
BOOST
reverse correct
BOOST
reverse correct
Original Manual

-3-
BOOST
reverse correct
BOOST
reverse correct
BOOST
reverse correct
BOOST
reverse correct
Jump start 12V vehicle Instruction
1. Connect the blue plug fully seated into the host, and make sure
the Cable Indicator is off.
2. Connect Red Clamp to the positive (+) battery terminal, Black
Clamp to the negative (-) battery terminal.
3. Operate following the instruction of the Cable Indicator:
4. Start the vehicle.
5. When the vehicle is started, remove the jumper cable from the
vehicle battery. Leave the vehicle’s engine running.
JUMP START & POWER STATION
BOOST
reverse correct
GREEN LIGHT on: Telling
the connection circuit is
working, you can turn on
the engine to jump-start
directly.
RED LIGHT on with
buzzing: Telling the
connection is wrong, and
buzzing to alarm to correct
the clamps as step 2
mentioned above, wait until
the GREEN LIGHT is on to
turn on the engine.
GREEN LIGHT blinking
with buzzing: Saying
the vehicle battery is low,
press the “BOOST” button,
wait until GREEN LIGHT
becomes solid, then turn on
the engine within 30s.
No Lights on, No buzzing:
Saying the vehicle’s
battery may be damaged,
after conrm the clamps
connection is correct,
press the “BOOST” button,
wait until GREEN LIGHT
is on, and then turn on the
engine within 30s.
Charging Cell Phone or Tablet Instructions
1. Plug the switch cable to Quick Charge output port.
2. Select appropriate connector and connect it to your mobile phones or tablet.
3. Touch the switch button, it can recognise electronic products’ suitable parameters, start
to charge for mobile phone/tablet, etc
LED ash light
Press the switch 3 seconds to start the LED ash light, short press to turn off.
BOOST
reverse correct
Original Manual

-4-
JUMP START & POWER STATION
WARNING
1. Read the instruction manual carefully before using this unit.
2. Jump for 12V vehicles only, it would be hazard if for other jumping. It is forbidden to use
for other machines such as aircraft ship and so on.
3. Caution while using this unit.
4. DO NOT use this unit if any cable clamp or cord is damaged.
5. DO NOT use in place of a vehicle battery.
6. DO NOT use as a battery charger.
O: Indicate all homogeneous materials’ hazardous substances content are below the
MCV limit specied in the Standard 2002/95/EC (RoHs).
FAC
Q. How to turn off this appliance?
A. This appliance will power off automatically when no load or charging is complete.
Q. How long time to full charge the jump starter?
A. Approx. 4 hours through the Quick Charge input.
Q. How many times can this appliance charge for my cell phone?
A. Depend on the battery capacity of your cell phone. Take iPhone6 as an example, can
full charging 8 times.
Q. How long will this appliance on a full charge take to supply the Notebook?
A. 4-6 hours.
Q. How many times can this appliance jump start the vehicle if it is in full battery?
A. Approx. 40 times.
Q. What’s the lifetime of the jump starter?
A. Usually 3-5years in normal condition.
Q. How long does the battery last still can jump start the car after fully charged?
A. 6-12 months, however, we suggest to recharge it every 3 months.
TROUBLE SHOOTING
TOXIC AND HARMFUL SUBSTANCES
FINDING
No response when press-
ing the switch button.
Pb Hg Cd Cr (Vi) PBB PBDE
OOOOOO
CAUSE
Low voltage protection of
jump starter is started.
REMEDIES
Plug the adaptor into
the 5V 2A input port to
activate.
Original Manual

-5-
JUMP START & POWER STATION
7. Never remain the unit on car battery after cranking the car success.
8. Use the jumper cable provided with this unit only.
9. Make sure the BLUE plug of the jumper Cable is plugged fully into jumping socket,
Otherwise, the blue plug would be melted.
10. Make sure to check all the battery connections are CLEAN before Jump Starting! Make
sure the battery clamps are well connected! If the battery terminals on the vehicle are dirty
or corroded, the power of the unit will be lessened.
11. Do NOT Jump Start more than 3 times in a row. It could damage the unit by overheating.
Give two minutes between attempts. The jumping cable can become overheated and
detach as a safety measure.
12. Remove the product from the vehicle battery within 30 seconds of Jump Starting. If not,
it could lead to damage.
13. Do NOT connect the two clamps together.
14. Only jump start when 3 to 4 indicator lights are illuminated.
15. Do NOT use by young or inrm persons without supervision.
16. Do NOT use as a toy.
17. Do NOT allow the product to become wet.
18. Do NOT immerse the product in water.
19. Do NOT operate the product in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust.
20. Do NOT modify or disassemble the jump starter. Only a repair technician may repair this
unit.
21. Do NOT expose product to extreme heat or re.
22. Make sure someone should be within range of your voice or close enough to come to your
aid when working with batteries.
23. Remove personal metal items like rings, bracelets, necklaces, etc. When using the
products.
24. Do NOT drop unit. If unit receives a sharp blow or is otherwise damaged in any way have
it checked by a qualied battery technician.
25. Do NOT store in locations where the temperature may exceed 70ºC
26. Charge only at ambient temperature between 0ºC and 60ºC.
27. Charge only using the charger provided with this unit.
28. Do NOT use the unit to jump start a vehicle while charging the internal battery.
29. If this unit is leaking liquid dispose of at proper recycle facility immediately.
30. Under extreme conditions, battery leakage can occur. If a liquid is noticed coming from
product do not handle with bare hands. In case of skin contact wash with soap and water
immediately. If liquid comes in contact with eyes rinse eyes with cold running water for at
least 10 minutes and get medical attention immediately.
31. Product contains lithium based battery, at end of product life dispose of product according
to local regulation.
Original Manual

-6-
JUMP START & POWER STATION
WARRANTY INFORMATION
1. We offer a limited warranty for this product against any defects in material and
workmanship for a period of 6 months from the date of purchase by the end user/
consumer. The conditions of the warranty are as follows:
2. The warranty is only valid upon presentation of the original receipt (from dealer/retailer)
by the original purchaser with the product to be repaired or replaced.
3. The warranty is void if the serial number, date of purchase and label has been removed.
4. The warranty does not cover damage or product failure resulting from normal wear
and tear, physical abuse, improper installation, misuse, modication or repairs by
unauthorized third parties.
5. We do not assume responsibility for any loss or damage incurred during shipment or
as a result of a force majeure.
6. We are not liable for any incidental or consequential damages arising from the use or
misuse of this product.
7. All warranty claims are limited to repair or replacement of the defective product and at
the sole discretion of us.
8. If we repair or replace the product, the product will be covered for the remaining
time of the original warranty period. Repair or replacement may involve the use of
reconditioned units which are equivalent in function. Replaced part or product
becomes the property of us.
9. Consumable components such as batteries are not covered by the warranty.
CAUTION
1. Do not jump start the vehicle if lees than 3 indicators are lighting. Do not connect the
positive and negative poles to the opposite poles, or connect the two clamps together,
otherwise may occur accident.
2. If the engine does not start within 3 seconds, stop cranking and wait at least 30
seconds before attempting to start the vehicle again.
3. Do not disassemble the host or use it as car battery, otherwise may occur accident.
4. Do not crush the product or put it into re, otherwise may occur accident.
5. Keep away from children to avoid any accident.
Original Manual

-7-
JUMP START & POWER STATION
EU Declaration of Conformity in accordance with the EU Machinery Directive
2006/42/EC
The declaration hereunder solely concerns the original machinery and composition, any
additional parts or modications made by the end user are not covered and this declaration
will not be valid should the product be modied in any way without our authorization.
Mr. Angel CAÑARDO, CEO of Suministros Exteriores, S.A., hereby declares under his
responsibility that our Jump Start & Power Station (reference code 3505150) fully conforms
to all relevant provisions of the EU Machinery Directive 2006/42/EC.
The applicable regulation is NF EN 1494: 2000+A1: 2009.
This declaration covers machinery with series numbers from SG17100 through to SG18999.
Sant Joan Despí, Spain. 21/11/2017
Angel Cañardo Aranguren
Director General Suministros Exteriores SA.
