Summit SCFF55 SERIES User manual

FELIX STORCH, INC.
SUMMIT APPLIANCE DIVISION®
INSTRUCTION MANUAL FOR MODEL:
SCFF-55
ALL-FREEZER

*Before Putting Into UsE*
Before connecting the appliance to the power supply, leave it standing for
about 2 hours, this will reduce the possibility of malfunctions in the cooling
system due to transport handling.
Clean the appliance thoroughly; especially in the interior (See Cleaning and
Maintenance).
In case the interior accessories are not correctly placed, rearrange them as
described on pages 7-10 (Description of the Appliance).
Instructions for Use
These instructions for use are intended for the user. They describe the appliance and
the correct and safe way to use it. The instructions were prepared for various
types/models of freezers therefore you may find in it descriptions of some
accessories and functions that your appliance may not have.
Mounting Instructions
Integrated appliances are equipped with instructions for mounting the appliance into
the kitchen unit. The appliance should be mounted by qualified technicians and
instructions are for their use only.
We Care for the Environment
Our appliances are distributed in packaging made of environmental friendly
material which could safely be recycled, disposed of or destroyed without any
effects on the environment whatsoever.
Our instruction manuals are printed either on recycled paper or chlorine free
bleached paper.
Tips for Energy Savings
Try not to open the door too often, especially when the weather is hot and
humid. Once you open the door try to close it as soon as possible.
Every now and then check if the appliance is sufficiently ventilated
(adequate air circulation behind the appliance).
Set thermostat from higher to lower settings as soon as possible
(depending on how loaded the appliance is, ambient temperature etc...).
The coils on the rear of the refrigerator should be cleaned and free of dust
or any impurities.
Always consider instructions stated in sections Positioning and Energy
Saving Tips, otherwise the energy consumption is substantially higher.
Instructions for Use

IMPORTANT
If you bought this appliance to replace an old one equipped with a lock
that cannot be opened from inside (lock, bolt), make sure that the lock is
broken. This will make it impossible for children to lock themselves
inside the appliance and suffocate.
The appliance must be correctly connected to the power supply.
If the food has a strange smell or color throw it away because it is very
likely that it is spoiled and therefore dangerous to eat.
Disconnect the appliance from the power supply before repairing (only a
qualified technician should repair it), cleaning and before replacing the
light bulb.
Use only enclosed tools or tools recommended by the manufacturer.
Before throwing away your old freezer please remove the doors and
leave the shelves in place so that children may not easily climb inside.
.The rating plate is inside the appliance or outside on the rear wall.
Disposing of the Worn Out Appliance
When your appliance finally wears out, dispose of it. If the appliance
has a lock, break it to prevent eventual accidents (the danger of
children getting locked inside the appliance).
The freezing system of the appliance is filled with refrigerant and
insulating substances which should be separately treated and processed,
you should call your nearest authorized service agent or specialized
servicing center if they cannot be contacted call your local authorities or
your distributor to remove the freezer. Be careful not to damage the
tubes on the rear wall of the appliance (danger of pollution).
Instructions for Use

PLACING AND INSTALLATION
It is important to make sure the appliance is leveled evenly to prevent falling.
Two spacers attached to the appliance must be fitted onto the upper edge of
the condenser, thus preventing the appliance from being installed too close to
the wall. Spacers are manufactured for all-purpose functions depending on the
distance of the condenser from the wall. Therefore turn spacers correspondingly
and adjust them accordingly to the appliance.
Connection to Power Supply
Connect the appliance with the cable and plug to the power supply socket outlet
with a ground terminal (safety socket).
“DO NOT USE AN EXTENSION CORD.”
Required nominal voltage and frequency are indicated on the rating plate.
The connection to the power supply and grounding has to be made according to
current standards and regulations. The appliance resists temporary voltage
tolerance up to -15 to 10%.
Operation Control
The freezer is controlled with a thermostat knob located in the upper right
hand corner of your refrigerator.
Temperature Selection
Higher settings on the knob (towards 7) mean colder temperatures in
all compartments of the appliance. The temperature in the interior of the
appliance may even drop below 32°F. Use the higher thermostat setting
only when required or recommended. We recommend that you set your
thermostat in the middle for standard temperature.
Changing the thermostat will affect the temperature inside of the
appliance; therefore choose your temperature wisely.
When the thermostat is on the STOP (0) position the appliance does
not operate.
Temperature in the freezer also depends on how often you open the door.
Instructions for Use

Storing Fresh Foods
Food to be stored in the freezer should be properly packed as to
prevent mixing various moisture degrees and odors (in
polyethylene bags or sheet, aluminum foil, wax paper, covered
containers or bottles).
Never store any inflammable, volatile or explosive
substances.
Food should not touch the rear wall of the freezer.
Some organic solutions like volatile oils in lemon and orange
peel, acid in butter etc. can cause damages when in contact with
plastic surfaces or gaskets for a long period of time.
An unpleasant odor inside the freezer is a sign that something is
wrong with the food or that your freezer needs cleaning. Odors
may be eliminated or reduced by washing the interior of the
freezer with a mild solution of water and vinegar. We also
recommend using activated carbon filters to clean the air or to
neutralize odors.
If you plan on taking a long trip make sure you remove all
perishable food before you leave to prevent any odors.
Instructions for Use

Self-defrosting
There is no need to defrost the freezer, because this appliance is
self-defrosting.
Cleaning the Appliance
Disconnect the power supply before cleaning the appliance. Do not use
coarse or aggressive cleaning agents as you can damage the surface.
Clean the exterior with water and a mild detergent. Varnished surfaces
are cleaned with soft cloth and a non-abrasive cleaning agent (for example
glass cleaners). You may also use stainless steel cleaner if you have a
stainless steel model.
Remove the detachable accessories in the interior of the appliance and
clean it with water and liquid detergent. Plastic parts cannot be washed in
a washing machine.
Wash the interior of the appliance with lukewarm water, in which you
add one or two spoonfuls of vinegar.
Switch Off the Appliance When Not in Use
If you do not intend to use the appliance for an extensive period of time set
the thermostat knob to the STOP (0) position and disconnect the power
supply. Then take out the food and clean the appliance. Leave the door
slightly open.
Instructions for Use

Trouble-Shooting Guide
During the service of your appliance, you can come across some trouble that in
most cases result from improper handling of the appliance that can easily be
eliminated.
Appliance Fails to Operate After Connecting to the Power Supply:
Check the supply in the outlet socket and make sure the appliance is switched on
(thermostat in the operating position).
. Water is Leaking from the freezer:
In case the discharged water outlet is clogged, the defrost water drips over the
channel or water leaks from the freezer, just clean the clogged opening with a
plastic straw. Manually defrost the increased ice layer. See “Ice Formation
on the Inner Back Wall”.
Instructions for Use

Door swing reversal
(Stainless steel models with towel bar handles do not have reversible doors.)
If you find the direction of opening the door on your appliance inconvenient, you can
change it. Holes on the opposite side have already been prepared at the factory
1. Remove the top hinge cover and hinge (on models with a tabletop, remove the
bottom hinge instead).
2. Next remove the door and remove the bottom hinge.
3. Then remove the kick plate, slide it over to the opposite side and secure in place.
4. Place the lower hinge on the opposite side of the unit and reattach the door,
5. Reattach the top hinge on the opposite side of the unit, it should be aligned with
the bottom hinge
6. Remove handle by unscrewing, place on the opposite side and secure in place.
7. Insert plugs into the holes where the door was initially attached.
8. Check to make sure the door seals properly.
(If it does not, use a hair dryer set on medium to expand the gasket.)
1. Upper hinge cover 4. Kick plate
2. Upper hinge 5. Handle
3. Lower hinge 6 Hole Plugs
Instructions for Use

Noise
During the operation of the compressor, a liquid noise is heard and when
the compressor is not operating a refrigerant flow is heard. This is a
normal condition and it has no influence whatsoever on the lifetime of the
appliance.
After starting the appliance, the operation of the compressor and the
refrigerant flow may be louder and this does not mean something is
wrong with the appliance. The noise will reduce gradually, this will
not affect the lifetime of the appliance.
Sometimes unusual and strong noises occur which is rather unusual for the
appliance. This noise is often a consequence of inadequate placing. To
avoid the noise make sure the appliance is placed and leveled firmly on a
solid base. Make sure the appliance is not touching the wall or kitchen
units standing next to it. And always make sure you check the
accessories in the interior of the appliance; they should be placed correctly
in their positions. Check the bottles, tins and other vessels that might touch
each other and rattle.
Before Calling for Service
Check the plug and fuse.
Test the outlet with a lamp
Be sure the control is not set to OFF
Read the manual, especially the items under the Use and Care sections.
You may find the answer to your questions.
If you don’t find the answer to your questions in this manual, find the
unit model number (on the upper back of the refrigerator) and
contact your Summit Appliance Dealer.
Specifications are Subject to Change Without
Notice.
