Summit CF04 User manual

Write the Serial Number here:
_________________________
CHEST FREEZER
Model CF04
Owner's Manual
BEFORE USE, PLEASE READ AND FOLLOW
ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
FELIX STORCH, INC.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com

1
IMPORTANT SAFEGUARDS
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read
and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the words” DANGER”, “WARNING” or “CAUTION”.
DANGER means that failure to heed this safety
statement may result in severe personal injury or
death.
WARNING means that failure to heed this safety
statement may result in extensive product
damage, serious personal injury, or death.
CAUTION means that failure to heed this safety
statement may result in minor or moderate
personal injury, or property or equipment
damage.
Safety messages will alert you to what the potential hazard is, tell you how to reduce the chance of injury,
and let you know what can happen if the instructions are not followed.
Before the chest freezer is used, it must be properly positioned and installed as
described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the chest freezer, follow basic precautions,
including the following:
Plug into a grounded 3-prong outlet. Do not remove grounding prong, do not use an adapter, and do
not use an extension cord.
Replace all panels before operating.
It is recommended that a separate circuit, serving only your chest freezer, be provided. Use
receptacles that cannot be turned off by a switch or pull chain.
Never clean chest freezer parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance. The fumes can create a fire hazard or explosion.

2
Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is
disconnected.
Do not connect or disconnect the electric plug when your hands are wet.
Unplug the chest freezer or disconnect the power before cleaning or servicing. Failure to do so can
result in electrical shock or death.
Do not attempt to repair or replace any part of your chest freezer unless it is specifically recommended
in this material. All other servicing should be referred to a qualified technician.
Use two or more people to move and install the chest freezer. Failure to do so can result in back or
other injury.
To ensure proper ventilation for your chest freezer, the front of the unit must be completely
unobstructed. Choose a well-ventilated area with temperatures above 55°F (13°C) and below 90°F
(32°C). This unit must be installed in an area protected from the elements, such as wind, rain, water
spray or sunlight.
The chest freezer should not be located next to ovens, grills or other sources of high heat.
The chest freezer must be installed with all electrical connections in accordance with state and local
codes. A standard electrical supply (115V AC, 60 Hz), properly grounded in accordance with the
National Electrical Code and local codes and ordinances, is required.
Do not kink or pinch the power supply cord of the chest freezer.
The fuse (or circuit breaker) size should be 15 amperes.
It is important for the chest freezer to be leveled in order to work properly. You may need to make
several adjustments to level it.
Never allow children to operate, play with or crawl inside the chest freezer
Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may damage or
discolor the interior.
Do not use this apparatus for other than its intended purpose.
Risk of child entrapment
Child entrapment and suffocation are not problems of the past. Junked or abandoned
freezers are still dangerous, even if they will “just sit in the garage a few days.”
Before you throw away your old freezer: Take off the doors. Leave the shelves in place
so that children may not easily climb inside.
Never allow children to operate, play with, or crawl inside the freezer.
Never clean freezer parts with flammable fluids. The fumes can create a fire hazard or
explosion.
Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this
or any other freezer. The fumes can create a fire hazard or explosion.
- SAVE THESE INSTRUCTIONS -

3
Table of Contents
Important Safeguards ............................................................................................1 - 2
Location of Parts ........................................................................................................4
Technical Information .................................................................................................5
Installation Instructions ..........................................................................................5 - 6
Before Using Your Freezer ..............................................................................5
Installing Your Freezer ...............................................................................5 - 6
Electrical Connection .......................................................................................6
Operating Your Freezer .........................................................................................6 - 8
Temperature Control ..................................................................................6 - 7
The Fast Freeze Switch ...................................................................................7
Defrosting Your Freezer .............................................................................7 - 8
The Freezer Compartment ..............................................................................8
Care and Maintenance ..........................................................................................8 - 9
Cleaning Your Freezer ...............................................................................8 - 9
Vacation Time ..................................................................................................9
Moving Your Freezer .......................................................................................9
Energy Saving Tips .........................................................................................9
Problems with Your Freezer (Troubleshooting) ........................................................10
Limited Warranty ......................................................................................................11

4
Location of Parts
Control Panel
1 COUNTER BALANCED LID
2 RECESSED HANDLE
3 ROLLERS
4 THERMOSTAT CONTROL
5 FAST FREEZE SWITCH
6 POWER INDICATOR LIGHT
amber
red

5
Technical Information
Model: CF04
Capacity: 3.5 cubic feet
Electrical Input: 115V AC / 60Hz
Rated Current: 1.45A
Power Input: 90W
Refrigerant: R134a, 95g
Installation: Free standing
Unit Weight: 68 lbs
Unit Dimensions: 22.6"W x 26.0"D x 34.8"H
Installation Instructions
Before Using Your Freezer
Remove the exterior and interior packing.
Check to be sure you have all of the following parts:
1 storage basket
1 divider
1 instruction manual
1 plastic scraper
Before connecting the freezer to the power source, let it stand upright for
approximately 2 hours. This will reduce the possibility of a malfunction in the cooling
system from handling during transportation.
Clean the interior surface with lukewarm water using a soft cloth.
Installing Your Freezer
This appliance is designed to be free standing only, and should not be recessed or
built-in.
Place your freezer on a floor that is strong enough to support the freezer when it is
fully loaded.
Allow 5 inches of space between the back and sides of the freezer, which allows
proper air circulation.
Locate the freezer away from direct sunlight and sources of heat (stove, heater,
radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources may
increase electrical consumption. Extremely cold ambient temperatures may also
cause the freezer not to perform properly.
Avoid locating the freezer in moist areas.

6
Plug the freezer into an exclusive, properly installed, grounded wall outlet. Do not
under any circumstances cut or remove the third (ground) prong from the power cord.
Any questions concerning power and/or grounding should be directed toward a
certified electrician or an authorized service center.
After plugging the appliance into a wall outlet, allow the unit to cool down for 2 to 3
hours before placing food in the freezer compartment.
Electrical Connection
This freezer should be properly grounded for your safety. The power cord of this
freezer is equipped with a three-prong plug which mates with standard three-prong wall
outlets to minimize the possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the power
cord supplied.
This freezer requires a standard 115Volt / 60Hz electrical outlet with three-prong ground.
The cord should be secured behind the freezer and not left exposed or dangling to
prevent accidental injury.
Never unplug the freezer by pulling the power cord. Always grip the plug firmly and pull
straight out from the receptacle.
Do not use an extension cord with this appliance. If the power cord is too short, have a
qualified electrician or service technician install an outlet near the appliance.
The RED Power On light indicates that the freezer is properly connected to the electrical
power. The light indicates that power is supplied, and will glow even if the temperature
control dial is turned to “OFF”, or the compressor has failed to work and the compart-
ment is not being cooled.
Operating Your Freezer
Temperature Control
Your freezer has one control for regulating the temperature. The temperature
control is located on the lower right hand corner of the front panel.
The first time you turn the unit on, switch on the Fast Freeze switch (amber) and run
the unit for at least 2 hours before putting frozen foods inside. This will ensure the
cabinet is thoroughly chilled before food is put in.
Warning
Improper use of the grounded plug can result in the risk of electrical shock. If the power
cord is damaged, have it replaced by an authorized service center.

7
Turn off the Fast Freeze switch.
The range of the temperature control is from position “1” (least cold) to "5" (coldest).
Adjust the temperature control to the setting that best suits your needs. The setting
“3” should be appropriate for home or office freezer use.
To turn the freezer off, turn the power switch to "OFF".
NOTES:
If the unit is unplugged, has lost power or is turned off, you must wait 3 to 5
minutes before restarting the unit. If you attempt to restart before this time delay,
the freezer will not start.
Large amounts of food will lower the cooling efficiency of the appliance.
If you choose to change the thermostat setting, adjust thermostat control by one
numerical increment at a time. Allow several hours for temperature to stabilize
between adjustments.
The Fast Freeze Switch (Amber)
The light glows while the Fast Freeze switch is in the "ON" position.
The switch overrides the thermostat and will make the compressor operate
continuously, lowering the cabinet temperature still further than the thermostat
setting.
This switch is used to freeze unfrozen food in appreciable quantities.
When loading the freezer, freeze only three pounds of fresh food per cubic foot of
freezer space at one time.
Distribute packages to be frozen evenly throughout the freezer.
It is not necessary to adjust the thermostat setting when using the Fast Freeze
switch.
Defrosting Your Freezer
For the most efficient operation and minimum energy consumption, defrost the
freezer when the frost on the freezer walls is excessive or ¼ to ½ inch thick.
Choose a time when the stock of frozen food is low.
CAUTION
Do not use boiling water because it may damage the plastic parts. In addition, never
use a sharp or metallic instrument to remove frost as it may damage the cooling coils
and will void the warranty. We recommend using the plastic scraper provided with
your unit.
To defrost,
1. Remove the frozen food from the freezer and place it in a cooler to protect the
food.
2. Turn the thermostat knob to “OFF”.
3. Unplug the freezer. The Power Supply light should go off (red light out).

8
4. Remove the drain plug on the floor of the freezer by pulling straight out. During
defrosting, the ice melts into the cabinet.
5. Place a shallow pan outside the drain outlet. The defrost water will drain out.
6. Check the pan occasionally so the water does not overflow.
7. Clean and dry the interior of the freezer.
8. Replace the plug on the inside floor.
9. Reset the thermostat to the desired setting.
10.Allow the cabinet to cool for one hour.
11.Switch on Fast Freeze for a minimum of 2 hours.
12.Return food to the freezer.
HELPFUL HINTS:
Defrosting usually takes a few hours. Leaving the door open will help speed the
process. Also, pouring warm water (not boiling) on the ice/frost will help speed
melting. If you must use a scraper, please use caution. It is very easy to damage
the freezer compartment and void your warranty.
The Freezer Compartment
This compartment is designed for the long-term storage of frozen food. Storage time
is up to three months.
The storage life of frozen foods varies and the recommended storage time should not
be exceeded. The instructions regarding the care of frozen foods should be followed
when defrosting the freezer.
Pre-packed commercially frozen food should be stored in accordance with the frozen
food manufacturer’s instructions for a three star frozen food storage compartment or
home freezer.
Place frozen food into the freezer as quickly as possible after purchase. If there are
instructions on the packet, carefully follow these instructions regarding storage times.
The freezer door is susceptible to breaking due to excessive ice build up. Be sure to
defrost when the ice reaches ¼ to ½ inch thickness.
A storage basket is provided for the organization of odd-shaped items. To reach
other packages in the freezer, just slide the basket to one side, or lift it out.
Care and Maintenance
Cleaning Your Freezer
Upon installation of your new appliance, we recommend that it be cleaned
thoroughly.
Turn the thermostat knob to "OFF", unplug the freezer, remove the food and storage
basket.

9
Wash the inside with a damp warm cloth containing a water and baking soda
solution. (Dissolve 2 tablespoons of baking soda in a quart of water.)
Wash the storage basket with a mild detergent solution.
To keep the unit running efficiently, be sure to keep the door gasket (seal) clean.
The outside of the freezer should be cleaned with mild detergent and warm water.
Dry the interior and exterior with a soft cloth.
The condenser coils should be vacuumed when they are dusty or dirty.
It is recommended that the unit be cleaned each time it is defrosted to help keep the
unit odor-free and running efficiently.
Vacation Time
Short vacations: Leave the freezer operating during vacations of less than three
weeks.
Long vacations: If the appliance will not be used for several months, remove all food
and unplug the power cord. Clean and dry the interior thoroughly. To prevent odor
and mold growth, leave the door open slightly, blocking it open if necessary, or have
the door removed. Use extreme caution in the case of children. The unit should not
be accessible to children at play.
Moving Your Freezer
Remove all the food.
Securely tape down all loose items inside your freezer.
Remove the rollers to prevent damage.
Tape the doors shut.
Be sure the freezer stays in the upright position during transportation.
Energy Saving Tips
The freezer should be located in the coolest area of the room, away from heat-
producing appliances or heating ducts, and out of direct sunlight.
Let hot foods cool to room temperature before placing in the freezer. Overloading the
freezer forces the compressor to run longer. Foods that freeze too slowly may lose
quality, or spoil.
Be sure to wrap foods properly, and wipe containers dry before placing them in the
freezer. This cuts down on frost build-up inside the freezer.
The freezer's storage bin should not be lined with aluminum foil, wax paper or paper
toweling. Liners interfere with cold air circulation, making the freezer less efficient.
Organize and label food to reduce door openings and extended searches. Remove
as many items as needed at one time, and close the door as soon as possible.

10
Problems with Your Freezer
You can solve many common freezer problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before
calling the servicer.
TROUBLESHOOTING GUIDE
Problem Possible Causes
Freezer does not operate. Not plugged in.
Circuit breaker tripped or fuse blown.
The thermostat knob is at "OFF".
Compressor turns on and off
frequently. The room temperature is hotter than normal.
A large amount of food has been added to the freezer.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The freezer does not have the correct clearances.
The freezer has recently been disconnected for a period of time.
Four hours are required for the freezer to cool down completely.
Temperature inside the freezer
is too warm. Temperature control is set too warm. Turn the control to a cooler
setting and allow several hours for the temperature to stabilize.
Door is kept open too long or is opened too frequently. Warm air
enters the freezer every time the door is opened. Open the door
less often.
The door is not closed completely.
The door gasket does not seal properly.
A large amount of warm or hot food might have been stored
recently. Wait until the freezer has had a chance to reach its
selected temperature.
The freezer has recently been disconnected for a period of time.
Four hours are required for the freezer to cool down completely.
Temperature inside the freezer
is too cold. Temperature control is set too cold. Turn the control to a warmer
setting and allow several hours for the temperature to stabilize.
Fast Freeze switch is turned on. This causes continuous running
of the compressor and bypasses the temperature control.
Temperature of external freezer
surface is warm. The exterior freezer walls can be as much as 30F warmer than
room temperature. This is normal while the compressor works to
transfer heat from inside the freezer cabinet.
Vibrations Check to be sure the freezer is on a level surface.
Floor is uneven or weak. Freezer rocks on the floor when it is
moved slightly. Be sure floor can adequately support freezer.
Level the freezer by putting wood or metal shims under part of the
freezer.
The freezer is touching the wall. Re-level the freezer and move it
from the wall.
See Installation Instructions.
The door will not close properly. The freezer is not on a level surface.
The gasket is dirty.
The storage basket is out of position.

11
For parts and accessory ordering,
troubleshooting and helpful hints, visit:
www.summitapplianceparts.com
Limited Warranty
ONE YEAR LIMITED WARRANTY
Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is
operated and maintained according to instructions attached to or furnished with the product, warrantor will
pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service
must be provided by a designated service company. Outside the 48 states, all parts are warranted for one
year from manufacturing defects. Plastic parts, shelves and cabinets are warranted to be manufactured to
commercially acceptable standards, and are not covered from damage during handling or breakage.
5 YEAR COMPRESSOR WARRANTY
1. The compressor is covered for 5 years.
2. Replacement does not include labor.
ITEMS WARRANTOR WILL NOT PAY FOR:
1. Service calls to correct the installation of your appliance, to instruct you how to use your appliance,
to replace or repair fuses or to correct wiring or plumbing.
2. Service calls to repair or replace appliance light bulbs or broken shelves. Consumable parts (such
as filters) are excluded from warranty coverage.
3. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper
installation, installation not in accordance with electrical or plumbing codes, or use of products not
approved by warrantor.
4. Replacement parts or repair labor costs for units operated outside the United States.
5. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
6. Expenses for travel and transportation for product service in remote locations.
7. The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not
installed in accordance with published installation instructions.
DISCLAIMER OF IMPLIED WARRANTIES –LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE
PRODUCT REPAIR AS PROVIDED HEREIN. IMPLIED WARRANTIES, INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR.
WARRANTOR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME
STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS, SO THESE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO
YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM STATE TO STATE.
FELIX STORCH, INC.
770 Garrison Avenue
Bronx, NY 10474
Phone: (718) 893-3900
Fax: (718) 842-3093
www.summitappliance.com
Table of contents
Other Summit Freezer manuals

Summit
Summit UF850L User manual

Summit
Summit CF11ES User manual

Summit
Summit SPRF26 User manual

Summit
Summit FS603FROST User manual

Summit
Summit SCFF1842KS User manual

Summit
Summit VT65M User manual

Summit
Summit FS605 User manual

Summit
Summit SCFU1375 User manual

Summit
Summit FS407L User manual

Summit
Summit FS21L User manual

Summit
Summit accucold ACR45L User manual

Summit
Summit SWC3066 User manual

Summit
Summit FS22L User manual

Summit
Summit CF11ES User manual

Summit
Summit FS60SSVH User manual

Summit
Summit SCFF55 SERIES User manual

Summit
Summit Accucold ALF620 User manual

Summit
Summit WCH07W User manual

Summit
Summit FS60-FROST User manual

Summit
Summit FS62 Series User manual
