Summit FF1116W series User manual

Write the Model and Serial Numbers here:
_________________________
_________________________
FROST-FREE REFRIGERATOR-FREEZER
Models CM405
CM411L
CM421BL
Owner's Manual
BEFORE USE, PLEASE READ AND FOLLOW
ALL SAFETY RULES AND OPERATING INSTRUCTIONS
FELIX STORCH, INC.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
FF1116W series
FF1158SS series

1
IMPORTANT SAFEGUARDS
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential
hazards that can kill or injure you and others. All safety messages will
follow the Safety Alert Symbol and either the words ”DANGER” or
“WARNING”.
DANGER means that failure to heed this
safety statement may result in severe
personal injury or death.
WARNING means that failure to heed
this safety statement may result in
extensive product damage, serious
personal injury, or death.
Safety messages will alert you to what the potential hazard is, tell you how to reduce the chance
of injury, and let you know what can happen if the instructions are not followed.
Before the refrigerator is used, it must be properly positioned and installed
as described in this manual, so read the manual carefully. To reduce the
risk of fire, electrical shock or injury when using the refrigerator, follow
basic precautions, including the following:
•Plug into a grounded 3-prong outlet. Do not remove grounding prong, do not use an adapter,
and do not use an extension cord.
•It is recommended that a separate circuit, serving only your refrigerator, be provided. Use
receptacles that cannot be turned off by a switch or pull chain.
•Never clean refrigerator parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.
•Do not connect or disconnect the electric plug when your hands are wet.
•Unplug the refrigerator or disconnect the power before cleaning or servicing. Failure to do so
can result in electrical shock or death.
•Do not attempt to repair or replace any part of your refrigerator unless it is specifically
recommended in this material. All other servicing should be referred to a qualified technician.

2
•This unit is not designed to operate in enclosed spaces. When placing your
unit, make sure you allow adequate airflow on all sides.
•Use two or more people to move and install the refrigerator. Failure to do so can result in back
or other injury.
•To ensure proper ventilation for your refrigerator, the front of the unit must be completely
unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below
90°F (32°C). This unit must be installed in an area protected from the elements, such as wind,
rain, water spray or drips.
•The refrigerator should not be located next to ovens, grills or other sources of high heat.
•The refrigerator must be installed with all electrical connections in accordance with state and
local codes. A standard electrical supply (115V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances, is required.
•Do not kink or pinch the power supply cord of the refrigerator.
•The fuse (or circuit breaker) size should be 15 amperes.
•It is important for the refrigerator to be leveled in order to work properly. You may need to
make several adjustments to level it.
•Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may
damage or discolor the interior.
•Do not use this apparatus for other than its intended purpose.
Risk of child entrapment
Child entrapment and suffocation are not problems of the past. Junked or abandoned
refrigerators are still dangerous, even if they will “just sit in the garage a few days.”
•Before you throw away your old refrigerator: Take off the doors. Leave the shelves
in place so that children may not easily climb inside.
•Never allow children to operate, play with, or crawl inside the refrigerator.
- SAVE THESE INSTRUCTIONS -

3
Table of Contents
Important Safeguards ....................................................................................................1 - 2
Location of Parts .................................................................................................................3
Technical Information .........................................................................................................4
Installation Instructions .................................................................................................4 - 7
Before Using Your Appliance .....................................................................................4
Installing the Appliance .........................................................................................4 - 5
Electrical Connection / Extension Cord ......................................................................5
Reversing the Door Swing ....................................................................................6 - 7
Operating Your Refrigerator ..........................................................................................8 - 9
Setting the Temperature Controls ..............................................................................8
Frost-Free Defrost System ....................................................................................8 - 9
Making Ice Cubes / Hot-Line ......................................................................................9
Care and Maintenance ...............................................................................................10 - 11
Cleaning Your Refrigerator / Evaporation Tray / Power Failure / Vacation Time ......10
Moving your Unit / Energy-Saving Tips ....................................................................11
Troubleshooting ................................................................................................................12
Limited Warranty ...............................................................................................................13
Location of Parts
Freezer door
with 2 racks
Refrigerator
door with 4
racks
Crisper cover
Crisper
Leveling legs
Plastic-coated
shelves
Freezer
compartment
Temperature
control
Interior light
Magnetic
door gasket
3

4
Technical Information
Models: FF1116W (white)
FF1158SS (black cabinet
with stainless steel door)
Capacity: 10.3 cubic feet
Electrical Input: 115V AC / 60Hz
Rated Current: 1.6A
Energy Consumption: 313 kWh/yr
Energy Star approved: Yes
Refrigerant: R134a, 5.3 oz
Installation: Free-standing
Shipping Weight: 166 lbs
Unit Dimensions: 23.63"W x 26.0"D x 58.88"H
Installation Instructions
Before Using Your Appliance
•Remove the exterior and interior packing.
:
•Check to be sure you have all of the following parts:
2 wire shelves
1 crisper drawer with clear cover
1 ice cube tray
•Before connecting the unit to the power source, let it stand for approximately 2
hours. This will reduce the possibility of a malfunction in the cooling system
from handling during transportation.
•Clean the interior surface with lukewarm water using a soft cloth.
Installing the Appliance
•This appliance is designed to be free-standing only, and should not be
recessed or built in.
:
•Place your unit on a floor that is strong enough to support it when it is fully
loaded. To level your unit, adjust the leveling legs at the bottom.
•Allow 5 inches of space between the back and sides of the unit, which will
allow the proper air circulation to cool the compressor and condenser.
•Locate the unit away from direct sunlight and sources of heat (stove, heater,
radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources
may increase electrical consumption. Extremely cold ambient temperatures
may also affect the unit's performance.
