Summary
The SUMO Deep Tillage Seeder (DTS) drill is based on a concept known as ‘strip till drilling’, a method
of only loosening and preparing a band of soil where the seed is to be placed and leaving the soil in-
between rows undisturbed, and therefore not working ground unnecessarily.
The DTS, a uniquely versatile drill capable of direct drilling, min-till drilling and conventional plough
based drilling. Designed and manufactured in Britain, the DTS features an auger (Sumo patent name
“Orga”) metering unit capable of dispensing wide range of seeds and fertilisers and widely varying rates.
DTS features:
•Based on 33.3cm row spacing.
•Individually mounted seeding units that articulate with ground contours and are governed by a
constant flow pressured hydraulic system.
•Leading opener disc for cutting through trash
•Single tungsten edged deep loosening auto-reset leg capable of a maximum working depth of
250mm
•Wide band (approx. 150mm) or narrow (approx. 25mm) row seed opener boots place seed in the
loosened strip
•Covering discs channel loosened soil over the seed
•Gel filled press wheels firm the soil around the seed and also govern the sowing depth of the
coulters
Before using the Sumo DTS it is absolutely necessary that you read this Operators manual and Safety
Instructions attentively.
Specifications, descriptions and illustrations in this manual are accurate, as known, at the time of
publication but may be subject to change.

3
To activate your SUMO Warranty, you must complete this page and send it
back to us at: Sumo UK Ltd
Redgates
Melbourne
York
YO42 4RG
Tel. [phone]
Fax. [phone]
(NO REGISTRATION = NO WARRANTY)
SUMO SERIAL No:
For your own records.
Sumo DTS customer Registration Document
NAME:
ADDRESS:
Telephone Number:
SUMO SERIAL No.
DEALERSHIP
NAME AND
BRANCH:
COMMENTS:
Postcode:
DATE:

4
Contents
1.0 Quick start..............................................................................................................................................6
1.1 Dealer PDI check list............................................................................................................................6
1.2 Quick start Guide for coupling up the DTS drill..................................................................................7
1.3 DTS technical data ...............................................................................................................................8
1.4 Operator Check List .............................................................................................................................9
1.5 Warranty.............................................................................................................................................10
2.0 Safety.....................................................................................................................................................11
2.1 Qualification and Training .................................................................................................................11
2.2 General safety.....................................................................................................................................12
2.3 Special safety instructions..................................................................................................................12
3.0 RDS Control system overview............................................................................................................13
3.1 The Artemis system (single motor kit)...............................................................................................13
3.2 Main functions....................................................................................................................................14
3.3 Control Modes and Data Logging......................................................................................................15
3.4 Menu keys ..........................................................................................................................................15
4.0 RDS Control Unit Operation..............................................................................................................16
4.1 Status Indicators .................................................................................................................................16
4.2 ‘MAIN’ screen ...................................................................................................................................16
4.2.1 Forward speed display and alarm functions ...............................................................................17
4.2.2 Tramlining status/functions ........................................................................................................18
4.2.3 Advancing the bout number........................................................................................................18
4.2.4 Holding the bout number............................................................................................................18
4.3 ‘RATE’ screen....................................................................................................................................19
4.3.1 Setting /overriding the target rate...............................................................................................19
4.4 ‘INFO’ screen.....................................................................................................................................20
4.5 Tramlining..........................................................................................................................................20
4.6 Metering motor –manual override/Half-Width Shut off (HWSO) drilling.......................................22
4.7 Product calibration .............................................................................................................................23
4.7.1 Initial product calibration ...........................................................................................................23
4.7.2 ‘CALIBRATION NUDGE’ - Adjusting the calibration factor..................................................25
4.8 Set Fan Speed and Hopper Level alarm thresholds............................................................................25
4.9 Speed simulation ................................................................................................................................26
4.10 Select units / Rate step%..................................................................................................................26
4.11 Speed Auto-cal. routine...................................................................................................................27
5.0 GPS Configuration .............................................................................................................................28
5.1 Port cable configuration ....................................................................................................................28
5.2 Head Unit Configuration - Port Settings............................................................................................30
5.3 Internal Data Card Module.................................................................................................................31
5.4 GPS Receiver .....................................................................................................................................31
5.4.1 ‘GPS 16’ GPS Receiver..............................................................................................................31
5.4.2 Third-party GPS Receivers.........................................................................................................32
5.5 GPS Baud Rate...................................................................................................................................32
5.6 GPS Configuration .............................................................................................................................32
5.6.1 To enable the GPS to be used.....................................................................................................32
6.0 Data Logging and Variable Rate Treatment.....................................................................................33
7.0 Overview and operation......................................................................................................................34
7.1 Grain and Fertiliser Overview............................................................................................................34
7.2 Drill Settings –Coulter overview.......................................................................................................36
7.2.1 Disc Depth ..................................................................................................................................36
7.2.2 Leg Depth ...................................................................................................................................36

5
7.2.3 Seed depth...................................................................................................................................37
7.2.4 Covering disc adjustment ...........................................................................................................37
7.2.5 Chassis adjustment......................................................................................................................37
7.2.6 Hydraulic Coulter adjustment.....................................................................................................38
7.2.7 Markers.......................................................................................................................................39
7.3 Trailed DTS Calibration Procedure....................................................................................................40
7.4 ORGA Metering Setup.......................................................................................................................42
7.5 ORGA Metering Setup Overview......................................................................................................43
8.0 Maintenance.........................................................................................................................................44
8.1 Greasing..............................................................................................................................................44
8.2 Spares .................................................................................................................................................44
8.3 Winter storage ....................................................................................................................................44
9.0 Hydraulic Systems ...............................................................................................................................45
9.1 On/Off FCV balancing.......................................................................................................................45
9.2 Fan Return Pressure............................................................................................................................45
9.3 Coulters ..............................................................................................................................................45
9.4 Axle Lift/Shut-off System..................................................................................................................45
9.5 Coulter system....................................................................................................................................46
9.6 Fan Motor system...............................................................................................................................46
9.7 Wings/Markers system.......................................................................................................................47
10.0 Parts Assembly Overview .................................................................................................................48
10.1 Coulter Overview.............................................................................................................................49
10.2 Parallel Linkage and Rams...............................................................................................................50
10.3 Depth Pins ........................................................................................................................................51
10.4 Leading Disc Unit ............................................................................................................................52
10.5 Seed Leg Assembly..........................................................................................................................53
10.6 Loosening Tine Assembly................................................................................................................54
10.7 Covering Discs .................................................................................................................................55
10.8 Press Wheels.....................................................................................................................................56
10.9 Distribution System..........................................................................................................................57
10.10 Drill Switching System ..................................................................................................................58
10.11 Fan Assembly.................................................................................................................................59
10.12 Hydraulic Fan Assembly................................................................................................................60
10.13 Lifting and Folding.........................................................................................................................61
11.0 RDS Kit list and Part Numbers........................................................................................................62
12.0 Trailed Drill Settings.........................................................................................................................67
13.0 3m Drill Settings ................................................................................................................................68
14.0 3m DTS Specific points to note.........................................................................................................69
14.1 Fan adjustment .................................................................................................................................69
14.2 3m tramline system ..........................................................................................................................69
14.3 Finger Switch ...................................................................................................................................69

6
1.0 Quick start
1.1 Dealer PDI check list
Check transport tyre pressures (see data table in first section)
Check wheel nuts, (270N/m 8 stud) (450n/m 10 stud)
Check bout marker measurements
Set fan speed (start with low fan speed and raise slowly, check back pressure)
Check for oil leaks with warm oil
Check seed on/off system sensitivity i.e. either hydraulic ram & sensor or finger
switch responds accurately and quickly?
Set up to match tractor, drawbar height and length extension
Fit electric power lead direct to tractor battery
Set working depth according to seed type and ground conditions
Ensure tractor is correctly balanced and ballasted
Check forward speed reading is correctly calibrated
Train customer to use machine
oSafe coupling and uncoupling to tractor
oFree flow return in particular
oSet coulter pressure
oSetup machine to suit different crops
oCoulter settings
oCalibrate drill
oChange seed rate

7
1.2 Quick start Guide for coupling up the DTS drill
Yellow- Axle Pressure
Yellow- Axle Return
Red- Wings/Markers Pressure
Red- Wings/Markers Return
Blue- Coulter Pressure
Blue- Coulter Return
Orange/Brown- Fan Pressure
Orange/Brown- Fan Free flow return & coulter dump
Two cable ties represent –Pressure
One cable tie represents –Return
When removing pipes from the tractor make sure all hydraulics are fully open or fully closed before
applying float on the tractor.
The wings are fitted with check valves on the rams which allows them to be depressurised without
letting the wings unfold.
The changeover tap for the wings and bout markers (4m, 4.8m and 6m versions only) is located on the
front of the chassis beneath the hopper access steps.
FREE-FLOW RETURN
Damage will occur to either the fan motor seal or the oil cooler (oil coolers are only fitted to seed &
fertilizer machines) if the free-flow return hydraulic line is not connected to the tractor first.
Any movement of the fan or the coulters immediately pressurizes the free-flow return line. This includes
just lowering the machine to the floor to allow the coulters to “take some weight”. Doing this will
displace oil from the coulter rams and pressurize the free-flow line, which may result in component
damage.
When connecting the free-flow line it is necessary to observe the back pressure present. A gauge for this
reason is provided, mounted on the fan. The maximum return pressure is 15bar. Running with a pressure
higher than this will result in damage so it is then necessary to take steps to reduce the restrictions in the
free-flow line, usually at the point where it enters the tractor.

8
1.3 DTS technical data
DTS 3m
DTS 4m
DTS 4.8m
DTS 6m
DTS 8m
DTS 9m
Transport width
3m
3m
3m
3m
3m
3m
Transport height
2.5m
(in work)
3.7m
(wheels in
transport)
4.1m
(wheels up)
3.7m
(wheels in
transport)
4.1m
(wheels up)
3.7m
(wheels in
transport)
4.1m
(wheels up)
3.7m
(wheels in
transport)
4.1m
(wheels up)
3.7m
(wheels in
transport)
4.1m
(wheels up)
Transport Length
3.1m
6.4m
6.4m
7.4m
7.9m
8.3m
Working width
3m
4m
4.8m
6m
8m
9m
Tank capacity
1600litres
3000litres
3000litres
3600litres
3600litres
3600litres
Coulters
9
12
15
18
24
26
Coulter spacing
33cm
33cm
32cm
33cm
33cm
34.6cm
Approx.Weight
2840kg
6000kg
6400kg
7800kg
9000kg
9800kg
Max fan speed
3800 RPM
4200 RPM
4200 RPM
4200 RPM
4200 RPM
4200 RPM
Max oil flow
required
30 l/min
30 l/min
30 l/min
30 l/min
30 l/min
30 l/min
Max free flow
return back
pressure
15 Bar
15 Bar
15 Bar
15 Bar
15 Bar
15 Bar
Tyre pressure
15 PSI
15 PSI
18PSI
20 PSI
20 PSI
20 PSI
Wheel Nuts
450N/m
450N/m
450N/m
450N/m
450N/m
450N/m

9
1.4 Operator Check List
It is the owner / drill operator’s responsibility to set up the drill for:
1. Sowing depth according to conditions in each soil type and pre worked condition
2. Tramline bout number to suit tramlines
3. Tramline track width
4. Marker width setting to allow matching of bouts (3-6m)
5. Operation of half width shut off (standard on 6m and above via RDS Unit)
6. Folding the machine in and out of work without damage
7. Correct calibration procedure
It is also the owner / operator’s responsibility to check the operation of the various functions of the
machine between each hopper fill, or at least once every hour to check the machine is operating
correctly.

10
1.5 Warranty
In this section Sumo UK Ltd. is referred to as the Company.
1. Subject to the provisions of this warranty the Company warrants each new machine sold by it to be
sold free from any defect in material or workmanship.
2. If the machine or part there of supplied by the Company is not in accordance with the warranty given
in clause 1 the Company will at its option;-
(a) Make good the machine at the Company’s expense, or
(b) Make an allowance to the purchaser against the purchase price, or replace the machine as soon as
is reasonably practical.
3. This warranty shall not oblige the Company to make any repayment in respect of loss of profit or
other consequential loss or contingent liability of the purchaser alleged to arise from any defect in the
machine or impose any liability on the company other than that contained in clause 2.
4. Any claim under this warranty must be notified to the company in writing specifying the matters
complained of within 12 months from the date of receipt by the purchaser or his/her nominee of the
machine.
5. Any claim under this warranty must be made by the original purchaser of the machine and is not
assignable to any third party.
6. If the purchaser hires out the machine to any third party the warranty shall apply only to matters
notified to the Company within 90 days of the date of delivery and clause 4 shall be read as if the
period of 90 days were substituted for the period of 12 months.
7. The warranty will cease to apply if:-
I. Any parts not made, supplied or approved in writing by the Company are fitted to the machine.
II. Any repair is carried out to the machine other than by or with the written approval of the
Company.
III. Any alterations not expressly authorised by the Company in writing are made to the machine.
IV. The machine is damaged by accident.
V. The machine is abused or overloaded or used for a purpose or load beyond its design capabilities.
8. Any dispute as to whether the goods are sold free from any defect in workmanship or materials shall
be referred to a single arbitrator to be agreed between the company and the buyer.

11
2.0 Safety
This manual contains basic advice, which should be observed during setting-up, operation and
maintenance. Therefore, this operating manual must be read by the personnel concerned prior to starting
up and using the machine and be accessible at all times.
If safety instructions are not complied with, then this can lead to the risk of injury to yourself and others
as well as damage to the environment or the machine. Non-compliance to the safety instructions can also
lead to any warranty claims becoming invalid.
2.1 Qualification and Training
Reliable personnel only may perform any work on, or, with the machine. Statutory minimum age
limits must be observed.
Employ only trained or instructed staff; the individual responsibilities of the personnel concerning
operation, setting up, maintenance and repair must be clearly established.
Make sure that only authorized personnel work on or with the machine.
Define the machine operators’ responsibilities – also with regard to observing traffic regulations.
The operator must have the authority to refuse any instructions issued by third parties, which
contravene safety.
Persons undergoing training or instruction or taking part in a general training course should not be
allowed to work on or with the machine unless they are under the constant supervision of an
experienced person.
The use of spare parts, accessories and ancillary equipment not supplied and/or not approved by
SUMO could have detrimental effects to the construction of the SUMO machine or on its
functions and hence impair the active and/or passive driving and/or operational safety (accident
prevention).
SUMO shall not be responsible for any damage caused by the use of spare parts, accessories and
ancillary equipment not supplied and/or approved by SUMO.
Conversions of or modifications to the machine may only be carried out after consultation with
SUMO.

12
2.2 General safety
Warning signs and other notices on the machine provide important information for the safe
operation. Observing them will serve your safety.
Before starting work, make yourself familiar with all the equipment and controls as well as their
functions.
The user should wear close-fitting clothing.
Keep the machine and in particular the bearings clean to avoid risk of fire.
Check around the machine before moving off or starting up (watch out for children!). Make sure
you have adequate all-round visibility.
Always match your speed to the local conditions. Avoid sudden turning manoeuvres when driving
uphill or downhill or when travelling across a slope.
Observe the respective regulations when using public roads.
Take into account the length, the wide overhang, the folded height and the sideways force acting
on the machine when turning or negotiating curves.
2.3 Special safety instructions
Take extreme care when hitching up or unhitching machine to/from the tractor.
Never allow persons to stand between the tractor and the SUMO machine unless the tractor is
secured against rolling away by means of parking brake and/or wheel chocks.
It is forbidden to allow persons to ride on the machine at any time. A safe distance should be
maintained from the machine by observers when in work.
Ensure all persons are stood clear of the machine when folding or unfolding.
When making adjustments to the machine the tractor engine should be switched off to prevent the
hydraulics from operating.
When making adjustments to the machines care should be taken not to trap any body parts in
moving or pivoting parts.
When working on the coulters, extra consideration should be placed on the safety of personnel.
Ideally the DTS should be folded up with the wings positioned in their transport support carriers.
If this is not possible and there is no other way than to work beneath the coulters then the DTS
must be reversed up to a suitably strong wall to protect against crushing in the unlikely event that
the hydraulics should fail. Also the front end should be hitched up to a tractor, with the parking
brake applied on the tractor.

13
3.0 RDS Control system overview
3.1 The Artemis system (single motor kit)
Figure1. RDS Circuit diagram
Head Unit
Speed
Sensor
(Radar)
Motor
2
‘HBM’
CAN Module
Power
supply
‘MCM’
CAN Module
Priming
Switch
Shaft
Speed
Sensors
Land wheel Sensor
(optional)
Fan Speed
Sensor
Tramline
actuators
Hopper level
sensors
Tramline
Advance
switch

14
3.2 Main functions
The Artemis is designed to allow automatic, variable rate control of any drill. You can at any time,
also manually override the predetermined rate as field conditions require.
The basic functions are:
Variable Rate Control
Tramline Control
Forward Speed Alarms
Hopper Level alarm
Fan Speed & alarm
Information totals
The instrument has a special software routine that makes calibration of the metering unit(s) very easy. In
the calibration mode each metering unit is controlled via a ‘priming switch’ to dispense the product.
During normal operation the control system is started and stopped automatically via a magnetic sensor as
the drill is put into and taken out of work. Depending on the particular installation, this sensor is
triggered either by the operation of the lift/lower action or by the markers.

15
3.3 Control Modes and Data Logging
Automatic Control Mode
The application rate is automatically regulated as forward speed varies, to ensure that the actual
application rate constantly matches a preset target rate. The application rate can be manually
nudged up and down from the target rate as required.
Field data ("job summaries") can be logged and are stored in the instrument memory. Up to 75
summaries can be stored. With a GPS receiver and SD data card, as well as creating a job
summary, you can also log the vehicle route and application data to a "dynamic log" file on the
SD card. The job summary data is also appended to this file.
VRT (Variable-rate treatment) Control Mode
This enables the system to be controlled via treatment instructions prepared using Precision
Farming software in conjunction with DGPS position data. To enable fully automatic variable-rate
treatment for Precision Farming applications, the PS 8000i requires a suitable DGPS receiver and
a formatted SD data card to implement treatment plans generated in the Precision Farming
software.
A work record file is automatically created on the card to log data confirming the actual treatment.
The job summary data is also appended to this file, which can be viewed in the Precision Farming
software
3.4 Menu keys
All instrument functions are accessed by nine menu keys adjacent to the LCD display.
Figure 2. Artemis control box
The four menu keys to the right of the screen access the primary screen pages (those viewed
during normal operation). There are three primary screens MAIN, RATE and INFO for normal
operating functions, and a SETUP screen for calibration functions.
The five sub-menu keys below the screen control the various display functions and settings for
each of the primary screen pages. Text or icons are displayed adjacent to the sub-menu keys to
denote their function.
Enter
Backspace
SD Card reader
(optional)
Power On-
Off
Menu
keys
Sub-menu keys (“Soft keys”)

16
4.0 RDS Control Unit Operation
4.1 Status Indicators
All the operating screens have a status bar at the top of screen displaying the time as well as a
number of different icons. These icons indicate the following:
Figure 3. Status symbols
NOTE: The Data Card and GPS icons are only displayed when these functions are enabled via the SETUP menu.
4.2 ‘MAIN’ screen
The instrument will always default to the MAIN screen on startup. The MAIN screen is divided
into 5 sections displaying the following functions,
Figure 4. MAIN screen (single product / single metering)
NOTE: The Metering motor status part of the display will appear differently depending on the drill configuration
Forward Speed
(Section 2.2.1)
Current
Application
Rate
(Section 2.3)
Metering
motor status
(Section 2.7)
Area cutout
In work
Out of Work
Data Card
Inserted
Not inserted
DGPS Signal
No signal
Signal - no differential.
Signal –full differential.
Tramlining status (Section 2.5)
Fan Speed (Section 2.9)
Tramline -
manual advance
Stop tramline automatic
advance
(Manual override)
‘Pre-start’
function
(Section 2.6)
Metering On-
Off
(Manual
override)

17
Figure 5. MAIN screen (dual product / single metering)
Figure 6. MAIN screen (single product / dual metering)
4.2.1 Forward speed display and alarm functions
Display smoothing
Except for sudden changes in speed, the forward speed displayed at any moment will be the
average speed calculated over 3 seconds.
Speed alarms on MAIN screen
The instrument is programmed with low and high forward speed alarms.
Display as Fig.4 except as shown
If the drill is in work and
the speed is less than 0.5
km/h then this section of
the MAIN display will
flash the following
warning and the audible
alarm will beep.
If the drill is in work and
the speed is above the
maximum that
proportional control can
achieve (indicated on the
RATE screen), then this
section of the MAIN
display will flash the
following warning and
the audible alarm will
beep.
Display as Fig.4 except as shown

18
When setting a new target rate on the RATE screen, the instrument re-calculates and displays the
maximum forward speed at which that rate can be maintained (Fig.7). It is calculated from the
rate set, drill working width, current calibration factor, gearbox ratio and maximum motor speed.
Figure 7. Maximum speed reminder
Simply press the key to return to the RATE screen.
NOTE: If the speed is too low, the operator must open the metering unit and re-calibrate to increase the calibration factor (ref.
the‘Calibration’ manual).
4.2.2 Tramlining status/functions
The MAIN screen shows the current status of tramlining.
Tramline rhythm:- Symmetrical Assymmetrical left Assymetrical Right
4.2.3 Advancing the bout number
On starting up the instrument the tramline sequence always starts at ‘1’.
If necessary, press the key to select the correct current bout number, e.g. if entering work
on a bout other than bout 1 of the tramline sequence.
4.2.4 Holding the bout number
Press the key to hold the current bout number (e.g. to prevent the bout no. advancing if it
is necessary to take the drill out of work, or depending on the drill setup - lift a marker, to
negotiate a field feature).
The icon indicates that the bout no. is held. Press the key to resume normal
bout advance.
NOTE: The tramlining sequence is set up via the SETUP page (ref. section 2.5).
Output status
( = ON)
Current bout
Target no. of
bouts

19
4.3 ‘RATE’ screen
This screen allows the drilling rate to be adjusted. Either kg/ha or seeds/m2 units can be set via the
SETUP menu.
Figure 8. RATE screen - single product
Figure 9. RATE screen - dual product
NOTE: The maximum forward speed shown is the lowest for the 2 products.
4.3.1 Setting /overriding the target rate
To set the target rate, simply enter the value and press the ENTER key to confirm.
To set the target rate or manually adjust the rate for either product, first press the ENTER key to
select SEED or FERT.
The application rate on the MAIN screen is the same as that shown on the RATE screen above. If
however on the rate screen, the current rate is manually adjusted above or below the target rate, then
this number will flash (on for 1 second, off for 0.5 second).
When operating from a treatment plan, then this number should only flash if the instructed rate has
been changed using the ‘+’ or ‘–‘ percentage buttons on the rate screen.
To override the target rate, use the keys. The % step is configured from the SETUP
menu.
To return to the target rate, press the key.
Both products are reset to their respective target rates
Current drilling rate
% off target
Target rate manual override by % steps
(% step size set in SETUP menu)
Reset to target
rate
Rate step size
Maximum forward speed at
which the current drilling
rate can be maintained
Target rate

20
4.4 ‘INFO’ screen
There is a ‘PART’ and a ‘NORMAL’
total for each product
Figure 10. Info screen graphics and functions
4.5 Tramlining
To set the desired tramline rhythm, select the SETUP screen and press the key.
Figure 11. Tramline set up screen
Select Part Total /
Normal Total display
Reset selected
total
Seed total
Select Grand total display
Fertiliser total
Area total
(No function)
No func.
Increase/decrease
target no. of bouts
Select rhythm
Sprayer width is
based on the
drill width,
target no. of
bouts and
tramline
rhythm.
