SunBear DL165 User manual
PUBLICATION NO. 16500
SEPTEMBER, 2009
N.B. Read and practice your Sunbear Heavy Equipment operating and servicing instructions.
Failure to do this may void the warranty.
SUNBEAR HEAVY EQUIPMENT LIABILTY WARRANTY
THE WARRANTY IS THE ONLY OBLIGATION OF SUNBEAR HEAVY EQUIPMENT OR A
SUNBEAR HEAVY EQUIPMENT DEALER TO THE PURCHASER OR ANYONE ELSE
CONCERNING A PRODUCT. IT'S USE OR PERFORMANCE OR ITS LOSS OF USE OR FAILURE
TO PERFORM. NEITHER SUNBEAR HEAVY EQUIPMENT NOR A IMPLIED REPRESENTATION,
WARRANTY OR AGREEMENT CONCERNING A PRODUCT, NEITHER SUNBEAR HEAVY
EQUIPMENT NOR A SUNBEAR HEAVY EQUIPMENT DEALER HAVE MADE OR WILL MAKE
ANY REPRESENTATION, WARRANTY OR AGREEMENT CONCERNING A PRODUCT'S
MERCHANTABILITY OR OTHER QUALITY, IT'S SUITABILITY FOR PURCHASER'S PURPOSE
(EVEN IF A PURCHASER HAS INFORMED SUNBEAR HEAVY EQUIPMENT OR A SUNBEAR
HEAVY EQUIPMENT DEALER OF THAT PURPOSE), IT'S DURABILITY, PERFORMANCE OR
OTHER CONDITION.
EVEN IF SUNBEAR HEAVY EQUIPMENT OR A SUNBEAR HEAVY EQUIPMENT DEALER WAS
ADVISED OF THE POSSIBILITY OF SUCH LOSS, NEITHER SUNBEAR HEAVY EQUIPMENT
NOR A SUNBEAR HEAVY EQUIPMENT DEALER WILL BE LIABLE TO PURCHASER OR
ANYONE ELSE FOR ANY INDIRECT, INCIDENTAL CONSEQUENTIAL, PUNITIVE, ECONOMIC,
COMMERCIAL, OR SPECIAL LOSS WHICH IN ANY WAY ASSOCIATED WITH A PRODUCT.
THIS INCLUDES ANY LOSS OF USE OR NON-PERFORMANCE OF A PRODUCT, ANY
REPLACEMENT RENTAL OR ACQUISITION COST, ANY LOSS OF REVENUE OR PROFITS,
ANY FAILURE TO REALIZE EXPECTED SAVINGS, ANY INTEREST COSTS, ANY IMPAIRMENT
OF OTHER PERSON.
PURCHASER MAY NOT ATTEMPT TO ENLARGE ITS RIGHTS UNDER THE WARRANTY BY
MAKING CLAIM, FOR INEMNITY, FOR BREACH OF CONTRACT, FOR BREACH OF
COLLATERAL WARRANTY, FOR A TORT (INCLUDING NEGLIGENCE, MISREPRESENTATION
OR STRICT LIABILITY) OR BY CLAIMING ANY OTHER CAUSE OF ACTION.
THE WARRANTY IS A CONDITION OF SALE OF THE PRODUCT TO THE PURCHSER AND WILL
THEREFORE APPLY EVEN IF THE PURCHASER ALLEGES THAT THERE IS A TOTAL FAILURE
OF THE PRODUCT.
WARRANTY DELIVERY: TWO (2) YEARS 1000HOURS (FOR ONLY SAMPLES).
Courtesy of Machine.Market
INDEX
1. SAFETY PRECAUTIONS
2. CONTROLS
2. 1 Instrument Panel
2. 2 Control Lever Handles
2. 3 Seat and Seat Belt
2. 4 Seat Bar
2. 5 Parking Brake
2. 6 Throttle Control
2. 7 Lift Arm Support
2. 8 Steering Control
2. 9 Auxiliary Controls
2. 10 Liftarm Control
2. 11 Quick - Tach
2. 12 Electrical Panel
3. OPERATION
3. 1 Starting Instructions
3. 2 Operating Procedure
3. 3 Filling From a Pile
3. 4 Digging with a Bucket
3. 5 Leveling and Backfilling
3. 6 Auxiliary Hydraulics
3. 7 Lifting
3. 8 Towing
3. 9 Securing and Transporting
3. 10 Lowering Lift Arms
3. 11 Accumulator
4. MAINTENANCE
4. 1 Preventive Maintenance Service Schedule
4. 2 Service Access
4. 3 Daily Service Checks
4. 4 50 Hour Service Check
4. 5 250 Hour Service Check
4. 6 Final Drive Maintenance
4. 7 Hydraulic / Hydrostatic System Maintenance
4. 8 Engine Maintenance
4. 9 Air Cleaner Maintenance
4. 10 Engine Cooling System
4. 11 Electrical System
4. 12 Tire Maintenance
4. 13 Trouble Shooting
4. 14 Hydraulic / Hydrostatic Circuit
4. 15 Special Tools
5. SPECIFICATIONS
5. 1 Loader Specifications
5. 2 Torque Specifications
5. 3 Decals
6. ATTACHMENTS AND BUCKETS
6. 1 SUNBEAR Approved Buckets and Attachments
Courtesy of Machine.Market
WARNING
This warning indicates
hazards or unsafe
practices which COULD
result in severe personal
injury or death.
This warning indicates an
immediate hazard which
WILL result in severe
personal injury or death.
DANGER
Instructions are necessary
before operating or
servicing this machine.
Read the operators manual
and service decals on the
loader. Follow warnings and
instructions in this manual
when making repairs,
adjustments or servicing.
Check for correct operation
after adjustments and
repairs.
IMPORTANT
This notice shows
important procedures
which must be followed
to prevent damage to the
loader or attachment.
IMPORTANT
This warning indicates
hazards or unsafe
practices which COULD
result in minor personal
injury or product or
property damage.
CAUTION
FOREWORD
This book has been written to give the Owner / Operator necessary operating,
servicing and preventative maintenance instructions on the loader.
Read this manual completely and know the loader before operating or servicing it.
Do not do any service procedures that are not in the Operator•s manual.
Only service personnel that have had training in the service of this loader can do these
service procedures.
Reference Information
Write the correct information for your loaders in the spaces below. Always use these
numbers when referring to your loader.
Model No.
Serial No.
Dealer Name
Address
Phone
Throughout this manual the terms DANGER, WARNING and CAUTION are used to
indicate the degree of hazard in terms of personal safety. These words will be used in
conjunction with the Safety - Alert symbol, a triangle with an exclamation mark.
Throughout this manual, the term IMPORTANT is used
* To indicate that instructions are necessary before operating or servicing the
loader.
* To show important procedures which must be followed to prevent damage to
the loader or attachment.
Courtesy of Machine.Market
5
1. SAFETY PRECAUTIONS
The following precautions are suggested to help prevent accidents.
A careful operator is the best operator. Most accidents can be avoided by observing certain precautions. Read and take the
following precautions before operating this loader to help prevent accidents. Equipment should be operated only by those
who are responsible and instructed to do so.
1. Read this manual carefully before using the loader.
Working with unfamiliar equipment can lead to accidents.
2. Do not allow anyone to ride on the loader with the
operator.
3. Make sure the seat bar is installed and functioning at all
times.
4. Never run the engine in a closed building without
adequate ventilation, as the exhaust fumes can cause
death.
5. Always fasten the seat belt around your waist before
starting the engine. Never fasten the seat belt behind you.
6. Never attempt to start the engine while standing beside
the unit unless as specified in this manual or under
specific service and backhoe operation procedures. Start
the engine only while sitting in the operator•s seat with
the seat belt fastened around you. Always check to make
certain that the seat cushion is secured to the frame.
7 Keep the operator•s area free of debris.
8. Never enter or leave the loader while the engine is
running. Always lower the lift arms down against the
frame, drop the attachment down to contact the ground,
set the parking brake and shut off the engine prior to
leaving the loader.
9. If the unit is equipped with a cab enclosure kit always
close the door prior to operating the loader lift arms.
10. Do not operate the loader unless all safety equipment,
shields, seat belt, seat bar, hydraulic controls, parking
brake, operator guard, and lift arm support are working
properly, as well as all safety and instruction decals are in
place.
OPERATING THE LOADER
1. Always drive the loader at speeds compatible with safety,
especially when operating over rough ground, crossing
ditches or when turning.
2. Avoid jerky turns, starts, stops, or reverses.
3. Use care when operating on steep grades to maintain
proper stability.
4. Do not turn the loader while the lift arms are in the
raised position.
5. Be careful when driving through door openings or under
overhead objects. Always make sure there is sufficient
clearance for the operator•s guard.
6. When travelling on public roads, know the local rules and
regulations and make sure your loader is equipped with
the proper safety equipment.
7. Always be sure of water, gas, sewage and electrical line
locations before you start to dig.
8. Watch out for overhead and underground high-voltage
electrical lines when operating the loader.
9. Park the loader on level ground where possible. If the
loader is to be parked on an incline, always lower the
attachment so it contacts the ground, set the parking brake
and block the wheels.
10. Do not leave the loader when it is in motion.
11. Do not dismount from the loader and leave the loader lift
arms raised, unless following specific service procedures.
Always lower the lift arms down against the frame and
drop the attachment down to contact the ground.
12. Always be watchful of bystanders when operating the
loader.
13. Always carry the attachment low for maximum stability
and visibility.
14. Exercise extreme caution when operating the loader with
a raised attachment.
15. Never attempt to lift loads in excess of loader capacity.
16. Check that control lever functions are locked before
getting out of the operator•s seat.
17. Keep both hands on the control levers while the loader is
in motion.
MAINTENANCE
1. Stop the engine before performing any service on the
loader.
2. Never refuel the loader while smoking or with the engine
hot or running.
3. Replace all missing, illegible or damaged safety and
warning decals. See Section 5.3 for list.
4. Do not modify or alter, or permit anyone to modify or
alter this loader or any of its components or any loader
function.
5. Do not bypass the safety system. Consult your SUNBEAR
Equipment Dealer if your safety controls are
malfunctioning.
6. Do not make mechanical adjustments while the loader is
in motion or when the engine is running. However, if
minor engine adjustments must be made, securely block
the loader with the wheels clear of the ground, and use
extreme caution.
7. Do not attempt to repair or tighten hydraulic hoses when
the system is under pressure, when the engine is running
or when the lift arms are raised.
8. Do not get under the attachment or lift arms or reach
through the lift arms when they are raised.
9. Never attach the chains or ropes to the operator•s guard
for pulling purposes, as the loader can tip over.
10. Whenever servicing or replacing pins in cylinder ends,
buckets,
etc., always use a brass drift and a hammer.
Failure to do so could result in injury from flying metal
fragments.
11. Cooling system operates under pressure which is
controlled by the radiator cap. It is dangerous to remove
the cap while system is hot. Always turn cap slowly to the
first stop and allow the pressure to escape before
removing the cap entirely.
12. Keep the operator area free from debris.
13. For lifting and towing instructions, refer to Sections 3.7
and 3.8 of this manual.
Courtesy of Machine.Market
To prevent personal
injury do not start the
engine unless you are in
the seat with the seat belt
fastened around you.
WARNING
To prevent personal
injury do not operate the
loader without lowering
the safety bar, fastening
the seat belt and keeping
feet on the cab floor.
WARNING
This engine is equipped
with glow plugs. Do not
use ether or any high
energy fuels to assist
starting.
IMPORTANT
C-359
6
1. SAFETY PRECAUTIONS
To avoid personal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the hydraulics to
ensure they are locked.
Then, unlatch the seat belt
and exit the loader. Do not
enter or exit with the engine
running unless as specified
in this manual or under
specific service and backhoe
operating procedures.
WARNING
START SAFELY
1. Sit in the operator's seat and adjust it so you can operate
all of the controls properly.
2. Adjust the seat and fasten the seat belt. Cycle the
controls to make sure they are in the locked or neutral
position. Lower the seat bar.
3. Know the exact starting procedure for your machine.
See Section 3 for the manufacturer•s instructions for
starting.
PARK SAFELY
Select level ground whenever possible. If you must park
on a slope or incline, position the machine at right angles
to the slope. Lower the attachment to the ground, engage
the parking brake and block the wheels (C359).
C - 360
Courtesy of Machine.Market
12. Coolant Temperature Indicator Light: This light
will illuminate if there is a rise in engine temperature. If
this occurs, shut of
the cause. f the engine immediately and determine
1. Left Signal Indicator Light: This light will
illuminate when the operator uses the optional left signal.
(Optional)
2. Auxiliary Front Indicator Light: This light will
illuminate when the loader auxiliary hydraulic front switch
is turned on. Light does not operate when lever switch is
depressed.
3. Hi-Flow Hydraulics Indicator: This light will
illuminate when the loader hi-flow hydraulics are in use.
(Optional)
4. Work Lights (Up) Indicator: The light will
illuminate when the loader work lights are turned on.
This will serve as a reminder to turn them OFF when the
loader is not in use.
5. Right Signal Indicator Light: This light will
illuminate when the operator uses the optional right signal.
(Optional)
6. Hydraulic Oil Temperature Indicator: This light
will illuminate when the oil temperature has exceeded
recommended levels. Shut off the engine immediately and
determine the cause.
7. Brake Light Indicator: The brake light will
illuminate when the parking brake is engaged.
8. Seat Belt Indicator Light: This light will illuminate
when the seat belt is unfastened.
9. Work Lights (Down) Indicator:
10. This light will
11.
The light will
illuminate when the loader work lights are turned on.
This will serve as a reminder to turn them OFF when the
loader is not in use.
14. Air Cleaner Indicator Light: This light will
illuminate when there is an obstruction in the intake or
when the air filter needs servicing. If this light illuminates,
stop the engine and service the cleaner.
8
2. CONTROLS
2.1 INSTRUMENT PANEL
K5250A
To prevent personal
injury do not start the
engine unless you are in
the seat with the seat belt
fastened around you.
WARNING
This engine is equipped
with glow plugs. Do not
use ether or any high
energy fuels to assist
starting.
IMPORTANT
1 2 3 4 5
6 7 8 9 10
11 12 13 14 15
1 2 3 4 5
6 7 8 9 10
11 12 13 14 15
16 17
18 19 20
0FULL
½
HOUR METER
000032 H
1/10
21 22
23
Work Lights (Back) Indicator:
illuminate when the loader Back light are turned on. This
will serve as a reminer to turn them OFF when the loader is
not in use.
Engine Oil Pressure Indicator: This light will
illuminate when the engine loses lubrication pressure. Shut
off the engine immediately and determine the cause.
13. Alternator Indicator Light: This light will
illuminate when the alternator is not producing sufficient
current.
15. Pre-heat Indicator Light: This light will illuminate
when the ignition key is turned counter clockwise to
activate the engine glow plugs.
16. Headlight Switch: This is a toggle switch. Push up
to turn the dipped beam lights on. These lights are located
on the front of the loader.
17. Auxiliary Hydraulics Front Switch: This switch
is a toggle switch. Push up to provide a continous flow of
oil to the quick couplers when using an attachment.
Courtesy of Machine.Market
9
This switch is a toggle switch
Push up to turn the dipped beam lights on. This light are
located on the rear of the loader.
2.2 CONTROL LEVER HANDLES
1. Spare
2. Spare
3, 4. Right / Left Direction Indicator (optional)
5. Horn
6. Spare
8. Auxiliary Hydraulic Switch
The left hand control lever is for moving the loader
forward and reverse. Pushing the lever forward will cause
the loader to move forward, and pulling the lever back
towards the operator will cause the loader to move in
reverse. This lever also operates hydraulic functions (refer
to section 2.8 for instructions).
The right hand control lever controls the lift arms and
bucket tilt. Pushing the lever forward will cause the lift
arms to raise, while pulling the lever back towards the
operator will cause the lift arms to lower. Moving the
control lever to the left and right will tilt and untilt the
bucket. Refer to section 2.10 for detailed operating
instructions of this lever.
Ensure liftarm brace is
properly stowed before
raising or lowering lift
arms
IMPORTANT
2. CONTROLS
LH Control Handle RH Control Handle
1
32
4
5
6
8
7
Fig. 2.2A C3933
19. Door Window Wiper Switch: This switch is a toggle
switch. Push up to turn the wiper on.
18. Back Light Switch:
23. Ignition Switch: The ignition switch is a three (3)
position switch: 'OFF', 'ON', 'RUN' and 'START'. Turn the
22. Fuel Gauge: The fuel gauge indicates the quantity of
fuel remaining in the fuel tank.
20. Hi-Flow Hydraulic Switch: This switch is a toggle
switch. Push up to turn the Hi-Flow hydraulics on. (Not
available on all models)
21. Hour Meter: The hour meter records the number of
engine operating hours and has a total of 99999.9 hours.
Turn the key counter clockwise to engage engine 'PRE-
HEAT'. Turn the key clockwise to the 'START' position,
this engages the starter The key will be in the 'RUN' position
when released. Turn the key to 'OFF' to shut off the engine
and remove the key.
C3015 Fig. 2.2B
Courtesy of Machine.Market
2. CONTROLS
2.3 SEAT AND SEAT BELT
The seat can be adjusted forward or back for operator
comfort (Fig. 2.3A)
For your safety the loader is equipped with a seat belt.
Before starting the loader adjust and fasten the seat belt
(Fig. 2.3B) around you. The seat and seat belt also have
integrated safety lock switches whereby the operator must
be seated in the seat with the seat belt securely fastened
and seat bar lowered before the loader hydraulics can be
operated.
To prevent personal
injury do not start the
engine unless you are in
the seat with the seat belt
fastened around you.
WARNING
Fig. 2.3B
C2698
Fig. 2. 3A
C2699
Release
10
Courtesy of Machine.Market
11
2. 4 SEAT BAR
For operator protection the loader is equipped with a seat
bar.
The loader must be started with the operator seated in the
loader and the seat bar in the up position. To raise the seat
bar, lift up on the bar (Fig. 2.4A). In the up position, the
seat bar activates the parking brake and locks out the
functions of the control levers including the auxiliary
hydraulics.
When down (Fig. 2.4B), the seat bar releases the park
brake and the hydraulic controls of the lift, tilt and
auxiliary hydraulic circuits.
Before exiting the loader always check the controls by
cycling them to ensure that they are in the neutral position.
2. CONTROLS
To avoid personal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the hydraulics to
ensure they are locked. Then,
unlatch the seat belt and exit
the loader. Do not enter or
exit with the engine running
unless as specified in this
manual or under specific
service and backhoe
operating procedures.
WARNING
Seat Bar Up
C5295
Seat Bar Down
C5288
Fig. 2. 4A
Fig. 2. 4B
Courtesy of Machine.Market
12
2. 5 PARKING BRAKE
The loader is equipped with park brakes, located inside the
torque motor. The brakes are activated and de-activated
by the seat bar, via charge pressure. When the seat bar is
in the up position, the brake is activated (Fig. 2.5A). When
the seat bar is in the down position, the brake is off (Fig.
2.5B).
The loader has a parking brake indication light to warn that
the brake is engaged. When the seat bar is in the down
position, activation of the emergency break can be carried
out by pushing on the button, located on the ROPS, in
front of the left hand control lever handle.
2. 6 THROTTLE CONTROL
The diesel engine throttle control is located on the left
hand side of the loader behind the control lever (Fig. 2.6).
Engine start and stop are controlled electrically by the
ignition key.
Before shutting off the engine, return the throttle control
to idle position and allow the engine to cool at least 2
minutes.
Pushing the lever full forward increases the engine speed
to maximum high idle. Pulling the lever back decreases
the engine RPM.
The engine should always be operated at full speed and
the loader travel speed controlled with the steering
control lever (See Section 2.8).
To avoid personal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the hydraulics to
ensure they are locked.
Then, unlatch the seat belt
and exit the loader. Do not
enter or exit with the engine
running unless as specified
in this manual or under
specific service and backhoe
operating procedures.
WARNING
2. CONTROLS
Seat Bar Up
(Parking Brake on)
C5295 Fig. 2.5A
Seat Bar Down
(Parking Brake off)
C3776 Fig. 2.5B
High
Speed
Low
Speed
Throttle
Control
Fig. 2.6
C5297
Courtesy of Machine.Market
13
2. 7 LIFT ARM SUPPORT
For safety while performing regular service or
maintenance work the loader is equipped with a liftarm
support.
The liftarm support, when engaged, prevents the liftarms
from dropping if hydraulic pressure is relieved or the right
hand control lever is accidentally cycled.
To operate the liftarm support, remove attachment and
park on level ground. Lower the liftarms to the ground and
stop the engine. Exit the machine and remove pin that
holds the liftarm support in stored positon(Fig. 2.7A).
Lower the liftarm support to rest on the lift cylinder(Fig.
2.7B). Re-enter the machine and re-assume proper
operating positon with the seat belt fastened and start the
engine. Slowly raise the liftarms until the support falls
onto the cylinder rod. Slowly lower the liftarms until
support restricts movement. Stop the engine.
To remove the liftarm support, enter the loader and assume
proper operating position with the seat belt fastened and
start the engine, slowly raise the liftarms until the support
is free, have a helper pin the support into its stored positon,
lower the liftarms to the ground and shut off the engine
before exiting the loader.
2. 8 STEERING CONTROL LEVER
The left control lever controls speed, direction and turning
of the loader. Loader speed is controlled by the amount the
lever is moved from the centre or neutral position. (Fig.
2.8A) The further away from neutral, the faster the travel
speed. For maximum power and slow travel speed move
the control lever only a small amount.
To drive the loader forward in a straight line, move the left
control lever forward from the neutral position (Fig.
2.8A).
To drive the loader in reverse in a straight line, move the
left control lever back from the neutral position (Fig.
2.8A).
The loader is turned by moving the left control lever to the
side. To turn right while in forward or reverse travel, ease
the control lever to the right. To stop turning, return the
lever to a center position. To turn left while in forward or
reverse travel, ease the lever to the left from the neutral
position. To stop turning, return the lever to a center
position (Fig. 2.8A).
For the loader to turn or "skid-steer" within its own length,
move the lever to the left or the right from the neutral
position. This causes the wheels on one side to turn
forward and the wheels on the other side to reverse turning
the loader (Fig. 2.8A).
2. CONTROLS
C5298 Fig. 2.7A
C5416
Fig. 2.8A
Liftarm Support,
Stored Position Pin
Fig. 2. 7B
C 5299
Liftarm Support
Resting On Cylinder
Forward
Right
Turn
Left
Turn
Reverse
C5415
Ensure liftarm brace is
properly stowed before
raising or lowering lift
arms
IMPORTANT
Forward Reverse
Left Turn Right Turn
N
Courtesy of Machine.Market
14
2. CONTROLS
C5254 Fig. 2.9B
C5416 Fig. 2.9A
C5255 Fig. 2.9C
2.9 ELECTRIC SOLENOID
AUXILIARY CONTROLS
Auxiliary hydraulics (solenoid operated - standard) will
only operate with the seat bar down.
A switch located on the R.H. steering control lever (Fig.
2.8A) is used to engage the loader's auxiliary hydraulic
circuit to power attachments such as post hole augers,
sweepers, etc. Pressing and holding the switch in position
1 (fig. 2.8A) provides hydraulic flow to the female quick
connect coupling located at the front of the lift arms (fig.
2.8C). Releasing the switch returns the auxiliary hydraulic
circuit to neutral, stopping the hydraulic flow.
Pressing and holding the switch in position 2 (fig. 2.8A)
provides hydraulic flow to the male quick connect
coupling located at the front of the lift arms (fig. 2.8C).
releasing the switch returns the auxiliary hydraulic circuit
to neutral, stopping hydraulic flow.
For continuous flow to the auxiliary hydraulic circuit, a
toggle switch is located on the L.H. instrument panel (fig.
2.8B). Placing the switch in the "ON" position provides
continuous hydraulic flow to the female quick connect
coupling located at the front of the lift arms (fig. 2.8C). To
stop hydraulic flow to the auxiliary hydraulic circuit,
return the switch to the "OFF" position (fig. 2.8B). When
the switch on the instrument panel is in the "ON" position,
the switch located in the L.H. control lever is not operable.
NOTE: See Section 2.2 for information on the control
handles.
AUXILIARY HYDRAULIC CONTROL
1
2
NEUTRAL
TOGGLE
SWITCH
To avoid personal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the controls to
ensure they are locked.
Then, unlatch the seat belt
and exit the loader. Do not
enter or exit with the engine
running unless as specified
in this manual or under
specific service and backhoe
operating procedures.
WARNING
Female Quick Coupling
Male Quick Coupling
ROPS SIDESEAT SIDE
Courtesy of Machine.Market
15
2. 10 LIFTARM CONTROLS
The right hand control lever (Fig. 2.10) operates the
loader•s liftarm and bucket hydraulic system. Refer to
section 2.8 for instructions on steering control.
When the control lever is in the neutral position, the lift
and tilt functions are static, the work attachment position
should not change unless the control lever is moved. If the
work attachment does move, service to hydraulic controls
is required.
Having the control lever in the neutral position does not
affect auxiliary hydraulics. Auxiliary hydraulics are
controlled separately and will continue to operate with the
control lever in the neutral position.
FLOAT (A)- Pushing the control lever all the way forward
will lock the lever in liftarm float detent. This float
position allows the work attachment to follow the contour
of the ground. Lever will remain locked in float position
until it is pulled out of float position.
LOWER (B)- To lower the liftarm, push the control lever
straight forward from the neutral position, the control lever
will return to the neutral position when released.
NEUTRAL (N)- Neutral (hold) position, lift and tilt
functions are static. Liftarms should hold their position.
RAISE(D)- Pulling the control lever back from the neutral
position will raise the liftarms, releasing the control lever
will allow it to return to the neutral position.
TILT BACK (E)- Moving the control lever to the left will
tilt the work attachment back (roll back bucket), releasing
the control lever will allow it to return to a neutral position.
TILT FORWARD (F)- Moving the control lever to the
right will tilt the work attachment forward (dump bucket),
releasing the control lever will allow it to return to a
neutral position.
By moving the control lever between two positons, both
functions can be done at the same time.
- Move the lever diagonally between lower and tilt forward
(B-F) to do both at the same time (lower and roll the work
attachment forward).
-Move the lever diagonally between raise and tilt back (D-
E) to do both at the same time (raise and roll the work
attachment back).
-Move the lever diagonally between raise and tilt forward
(D-F) to do both at the same time (raise and tilt the work
attachment forward).
-Move the lever diagonally between lower and tilt back
(B-E) to do both at the same time (lower and tilt the work
attachment back).
2. CONTROLS
To prevent personal
injury do not operate the
loader without lowering
the safety bar, fastening
the seat belt and keeping
feet on the cab floor.
WARNING
To avoid personal injury,
lower the lift arms, shut
off the engine, raise the
seat bar and cycle the
hydraulics to ensure they
are locked. Then unlatch
the seat belt and exit the
loader. Do not enter or
exit with the engine
running unless as
specified in this manual
or under specific service
and backhoe operating
procedures.
WARNING
C5413 Fig. 2.10
C5325
N
A
F
B
E
D
C5414
Courtesy of Machine.Market
16
2.11 QUICK - TACH
The quick-tach, which is standard equipment, allows
changing from one attachment to another quickly without
having to remove bolt or pins.
To operate, (Fig. 2.11A), lift the locking lever (1) up to
completely retract the locking pins (2). Tilt the quick - tach
frame forward (Fig. 2.11B) with the bucket tilt cylinders and
drive into the attachment. Retract the bucket tilt cylinders
(Fig. 2.11C) which will line up the bottom of the attachment
with the quick - tach lock pins. Shut off the engine.
Push the locking lever (1) fully down (Fig. 2.11D) extending
the lock pins (Fig. 2.11E item 2) through the attachment and
securing the attachment.
Before operating the attachment check that the locking pins
are correctly engaged.
After hooking up the
attachment check to be
sure pins and locking
levers are correctly
engaged.
WARNING
C5359 C5410 Fig. 2.11B
Fig. 2.11A
C5412 C 5357 Fig. 2.11E
11
2
Fig. 2.11D
1
C5411 Fig. 2.11C
1
1
11
2
1
2. CONTROLS
Courtesy of Machine.Market
