SunFounder Pironman User manual
SunFounder Pironman
www.sunfounder.com
Jan 31, 2024
CONTENTS
1 1. What Else Should We Prepare? 3
2 2. Assembly Instructions 5
3 3. Installing the OS 7
4 4. Setting Up Your Raspberry Pi 15
4.1 Setting Up with a Screen ......................................... 15
4.2 Setting Up Without a Screen ....................................... 16
5 5. Quick User Guide 25
5.1 1. Download and Install SPC ...................................... 25
5.2 2. View Data from SPC Dashboard ................................... 26
5.3 3. Modify Configuration from Terminal ................................. 35
6 6. About Hardware 37
6.1 Features .................................................. 37
6.2 Main Board ................................................ 39
6.3 Pi5 NVMe PIP .............................................. 48
6.4 18650 Battery .............................................. 57
6.5 Fan .................................................... 58
6.6 Power Button ............................................... 58
7 Home Assistant(Pi 4) 61
7.1 1. Install the Home Assistant OS .................................... 61
7.2 2. Configuring Your Home Assistant .................................. 67
7.3 3. Home Assistant Addon ........................................ 73
7.4 4. View Data from SPC Dashboard ................................... 80
7.5 5. Home Assistant MQTT Integration .................................. 89
8 7. Appendix 99
8.1 Get the IP address ............................................ 99
8.2 Install OpenSSH via Powershell ..................................... 99
8.3 PuTTY .................................................. 101
i
ii
SunFounder Pironman
Thanks for choosing our Pironman U1.
img/pironman_u1.jpg
Meet the Pironman U1, the essential UPS case for Raspberry Pi, designed for seamless performance and sophisticated
style. It features Advanced Hardware Power Path Switching for stable power, Triple Current Sensors for efficient power
management, and Intelligent Charging to enhance battery life. Enjoy real-time battery monitoring via I2C Communi-
cation, extensive storage options with NVMe SSD Compatibility, and easy multimedia control with an IR Receiver.
The case also boasts a retro-style Metal Power Button, an Extended 40-pin GPIO with labeled pins for easy access,
and a robust, aesthetically pleasing build. With an efficient cooling fan and direct access to the microSD card slot, the
Pironman U1 is the perfect blend of functionality and elegance for your Raspberry Pi.
If you have any questions, please send an email to service@sunfounder.com and we will respond as soon as possible.
CONTENTS 1
SunFounder Pironman
2 CONTENTS
CHAPTER
ONE
1. WHAT ELSE SHOULD WE PREPARE?
Essential Components
•Raspberry Pi 5/4 Model B
The Pironman U1 is fully compatible with the Raspberry Pi 5/4 Model B.
•5V/5A USB Type C Power Adapter
It is recommended to use the official 27W power supply of Raspberry Pi or other Pi5 dedicated USB PD protocol
5V/5A power sources.
•Micro SD Card
It is recommended to use an SD card with a minimum of 16GB of storage for Raspberry Pi OS. For Raspberry
Pi OS Lite, a minimum of 4GB is advised.
Optional Components
•M.2 NVMe SSD
The Pironman U1 features an NVMe PIP with an M.2 SSD connector, accommodating four NVMe M.2 SSD
sizes: 2230, 2242, 2260, and 2280. It supports both PCIE2.0 and PCIE 3.0 NVMe M.2 SSDs.
•Screen
To access the Raspberry Pi’s desktop environment, a screen such as a TV or a computer monitor is required.
•Micro HDMI Cable
A Micro HDMI cable is required when you want to connect the Raspberry Pi to a screen.
•Mouse & Keyboard
Any USB port on the Raspberry Pi can be used to connect a wired keyboard and mouse, or a USB Bluetooth
receiver for wireless peripherals.
3
SunFounder Pironman
4 Chapter 1. 1. What Else Should We Prepare?
CHAPTER
TWO
2. ASSEMBLY INSTRUCTIONS
Before assembling the Pironman, please first verify that all parts and components have been included. If there are any
missing or damaged components, please contact SunFounder immediately at service@sunfounder.com to resolve the
issue as soon as possible.
Tips
•It is recommended to follow the paper installation instructions step by step.
•Before installation, sort and stack the components to find them more quickly.
•Repeatedly check the connections of FFC and FPC cables to avoid poor contact.
5
SunFounder Pironman
6 Chapter 2. 2. Assembly Instructions
CHAPTER
THREE
3. INSTALLING THE OS
Required Components
•Raspberry Pi 5B
•A Personal Computer
•A Micro SD card
Installation Steps
1. Visit the Raspberry Pi software download page at Raspberry Pi Imager. Choose the Imager version compatible
with your operating system. Download and open the file to initiate installation.
2. A security prompt may appear during installation, depending on your operating system. For example, Windows
might display a warning message. In such cases, select More info and then Run anyway. Follow the on-screen
guidance to complete the installation of the Raspberry Pi Imager.
3. Insert your SD card into your computer or laptop’s SD card slot.
4. Launch the Raspberry Pi Imager application by clicking its icon or typing rpi-imager in your terminal.
7
SunFounder Pironman
5. Within the Imager, click CHOOSE DEVICE and select the Raspberry Pi 5 model from the dropdown list.
6. Select CHOOSE OS and opt for the recommended operating system version.
8 Chapter 3. 3. Installing the OS
SunFounder Pironman
7. Click Choose Storage and select the appropriate storage device for the installation.
Note: Ensure you select the correct storage device. To avoid confusion, disconnect any additional
storage devices if multiple ones are connected.
9
SunFounder Pironman
8. Click NEXT and then EDIT SETTINGS to tailor your OS settings. If you have a monitor for your Raspberry
Pi, you can skip the next steps and click ‘Yes’ to begin the installation. Adjust other settings later on the monitor.
9. Define a hostname for your Raspberry Pi.
Note: The hostname is your Raspberry Pi’s network identifier. You can access your Pi using
<hostname>.local or <hostname>.lan.
10. Create a Username and Password for the Raspberry Pi’s administrator account.
Note: Establishing a unique username and password is vital for securing your Raspberry Pi, which
10 Chapter 3. 3. Installing the OS
SunFounder Pironman
lacks a default password.
11. Configure the wireless LAN by providing your network’s SSID and Password.
Note: Set the Wireless LAN country to the two-letter ISO/IEC alpha2 code corresponding to
your location.
12. Click SERVICES and activate SSH for secure, password-based remote access. Remember to save your settings.
11
SunFounder Pironman
13. Confirm your selected settings by clicking Yes.
12 Chapter 3. 3. Installing the OS
SunFounder Pironman
14. If the SD card contains existing data, ensure you back it up to prevent data loss. Proceed by clicking Yes if no
backup is needed.
15. The OS installation process will commence on the SD card. A confirmation dialog will appear upon completion.
13
SunFounder Pironman
14 Chapter 3. 3. Installing the OS
CHAPTER
FOUR
4. SETTING UP YOUR RASPBERRY PI
4.1 Setting Up with a Screen
Having a screen simplifies the process of working with your Raspberry Pi.
Required Components
•Raspberry Pi 5/4 Model B
•Power Adapter
•Micro SD card
•Screen Power Adapter
•HDMI cable
•Screen
•Mouse
•Keyboard
Steps:
1. Insert the Micro SD card with Raspberry Pi OS installed into the Pironman U1.
2. Connect the Mouse and Keyboard to the Pironman U1.
3. Use the HDMI cable to connect the screen to the Pironman U1’s HDMI port. Ensure the screen is plugged into
a power source and turned on.
4. Power the Pironman U1 using the power adapter. The Raspberry Pi OS desktop should appear on the screen after
a few seconds.
15
SunFounder Pironman
4.2 Setting Up Without a Screen
If you don’t have a monitor, remote login is a viable option.
Required Components
•Raspberry Pi 5/4 Model B
•Power Adapter
•Micro SD card
Using SSH, you can access the Raspberry Pi’s Bash shell, which is the default Linux shell. Bash offers a command-line
interface for performing various tasks.
For those preferring a graphical user interface (GUI), the remote desktop feature is a convenient alternative for managing
files and operations.
For detailed setup tutorials based on your operating system, refer to the following sections:
4.2.1 For Mac OS X Users
For Mac OS X users, SSH (Secure Shell) offers a secure and convenient method to remotely access and control a
Raspberry Pi. This is particularly handy for working with the Raspberry Pi remotely or when it’s not connected to
a monitor. Using the Terminal application on a Mac, you can establish this secure connection. The process involves
an SSH command incorporating the Raspberry Pi’s username and hostname. During the initial connection, a security
prompt will ask for confirmation of the Raspberry Pi’s authenticity.
1. To connect to the Raspberry Pi, type the following SSH command:
ssh pi@raspberrypi.local
16 Chapter 4. 4. Setting Up Your Raspberry Pi
