sunjoe Sharper Blade SB600E User manual

A Division of Snow Joe, LLC
Model No. SB600E
Stringless Electric Trimmer/Edger
Stringless Electric Trimmer/Edger
Form No. SJ-SB600E-880E
© 2010 by Snow Joe, LLC
All rights reserved. Original instructions.
1
SAVE THESE INSTRUCTIONS
OPERATOR’S MANUAL
mCAUTION!
Before using this electric tool, carefully read and observe the
safety rules and instructions listed below. Before starting work,
make sure that you know how to stop the machine in case of
an emergency, The incorrect use of this machine could cause
serious injury. Keep these instructions in a safe place and on
hand so that they can be consulted when required.
mCAUTION!
The grass trimmer should only be used for cutting lawns and
along the borders of ower beds. Other uses of the trimmer,
not in these instructions, could damage the trimmer or
seriously injure the operator.
GENERAL Safety Rules
• The grass trimmer must not be used by anyone under the
age of 16.
• Always check the good working order of the trimmer which,
if not adequate, could endanger the user.
• Before connecting the trimmer to the mains, make sure that
the rotating parts are not damaged.
• Do not use the trimmer if the cutting device is not secured
properly or is damaged.
• Before starting the trimmer, make sure that the blade is not
touching stones or debris.
• Always wear suitable clothing when using the trimmer to
prevent head, hand, or feet injuries. Use a helmet, glasses
(or visor). High boots (or sturdy shoes and trousers) and
work gloves.
• When the trimmer is in operation, keep the cutting section
away from all parts of the body.
• Do not start the trimmer when it is upside down or when not
in working position.
• Turn the trimmer off and disconnect the plug when: the
trimmer is not being used; it is left unattended; it is being
examined because it is not working correctly; the power
supply cable is damaged; the blade is being removed or
changed or when the trimmer is being moved from one
place to another.
• Keep children, other people, and pets away from the
trimmer; the grass which is cut and dispersed may contain
stones and debris.
• Do not let other people or animals come within 5 meters of
the trimmer when in use.
• Remain in a stable and secure position while operating the
trimmer.
• Keep the area being cut free from wires, stones, and debris.
• Do not cut against hard objects. This could cause injury or
damage the trimmer.
• Use the edge of the guard to keep the trimmer away from
walls, surfaces, miscellaneous things, and delicate objects.
• Never use the trimmer without the guard.
mCAUTION!
The guard is critical to the safety of the operator and people
near the trimmer. The guard keeps the trimmer in good working
order and must always be in place during operation. Failure to
have the guard in place during operation is dangerous and will
void the warranty.
• Be careful of the blade, which can give deep cuts.
• Do not try to stop the cutting device with your hands.
Always let it come to a stop by itself.
mCAUTION!
The blade will continue to rotate after turning the trimmer OFF.
Wait until the blade has completely stopped before making
contact.
• Only use the type of blade originally provided with the
trimmer.
• Do not use the trimmer to cut grass which is not in contact
with the ground.
• Do not switch the grass trimmer on in enclosed or poorly
ventilated spaces or in the presence of inammable and/or
explosive substances such as liquids, gas, and powders.
• The user of the grass trimmer is responsible for any damage
sustained by third parties which has been caused by the
grass trimmer within the working area.
• Only cut during broad daylight or with corresponding
articial light.
• Do not cross roads or gravel paths with the trimmer still
running.
• When the trimmer is not in use, store it in a dry place and
out of the reach of children.
• The trimmer must be operated vertical, perpendicular to the
ground.
• Check regularly that the screws are properly secured.
Electrical Safety Rules
• The voltage must correspond to the one marked on the
technical data plate (120V~60Hz). Do not use other sources
of power.

2
• The power line should have a circuit-breaker no lower than
10A. Consult an electrician.
• Never pass the grass trimmer over the extension cable
when the grass trimmer is working as this could cut the
cable. Mark sure you always know where the cable is.
• Use the special cable holder for the connection of the
extension cable.
• Never use the trimmer when it is raining, avoid moisture and
humidity. Do not leave the trimmer outside overnight or cut
damp, wet grass.
• The power supply cable should be checked regularly and
not damaged. If the cable is not in good condition, do not
use the trimmer.
• Only use an extension cable which is rated for outdoor use.
Keep the extension cable away from the cutting area, sharp
edges, heat, fuels and damp, wet, oily surfaces.
• The mobile socket of the extension cable should be splash
proof in compliance with DIN 57282 and DIN VDE 0282
regulations; the cross-section of the wire (max. length: 75m)
should be at least 1.5mm². Use H07RN-F harmonied cable.
• This grass trimmer has been built with dual insulation in
compliance with EEC 20 regulations. Dual insulation is
electrically safer and therefore the trimmer does not need
additional grounding.

3
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
READ THE OPERATOR’S MANUAL(S) Read, understand and
follow all instructions in the manual(s) before attempting to
assemble and operate.
WARNING! Keep out of rain and away from wet areas.
DANGER! Rotating objects may spin off and cause personal
injury. Keep people away from hazard area.
WARNING! Always turn the machine OFF and disconnect the
electrical power before conducting inspection, cleaning and
maintenance.
DANGER! Keep electrical extension cable away from tines.
DANGER! Rotating parts may cause serious injury. Allow the
blade to completely stop before moving the machine,
inspection, cleaning and maintenance.
SAFETY ALERT
DOUBLE INSULATION
Symbol Description

4
Know Your Sharper Blade
Electric Trimmer/Edger
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Technical Data
Power supply voltage – 120V~60Hz
Power consumption – 450W
Cutting diameter – 12 inch
Idle Speed – 10000min-1
Noise power level LWA – 95dB(A)
A. Adjustable Handle
B. Telescopic Shaft Button
C. Motor Cover
D. Flower Guard
E. Sharper Blade
F. Telescopic Shaft
G. Twist-N-Groom Shaft
H. Adjustable Handle knob
I. Plug Inlet
J. Power Switch
K. Cord Hook
L. Handle
M. Shield
N. Plastic Flower Guard
Attachment

5
SECRETS to a Long Lasting
Sharper Blade™
CONGRATULATIONS! YOU ARE ABOUT TO
EXPERIENCE A FASTER, EASIER, WAY OF
GROMMING YOUR LAWNS EDGE AND MANAGING
WEEDS.
First, you will notice that there are obvious differences between
your Sharper Blade and string line, among which are size and
shape. These differences require you to operate your trimmer
slightly differently:
1. Use MINIMAL pressure when edging against concrete,
brick, or stone. Since the Sharper Blade is more ridged
than string, you may feel the need to put pressure on the
blade while edging. The more pressure you apply, the
FASTER the blade will wear. In contrast, the less pressure
you apply against hard surfaces, the LONGER the blade
will last! The SECRET is to keep the blade just off the hard
surface.
2. NEVER FORCE your Sharper Blade. High speed along with
an impact against any hard surface may cause the blade
to buckle near the center hub and tear. The SECRET is to
allow the Sharper Blade to do ALL the work without extra
effort.
Pressure = LONG
LASTING
We sincerely hope you feel the Sharper Blade has helped you
nish your work faster.
Warm regards,
Customer Service Staff
Sharper Blade™
Assembly
Before using the Sharper Blade Electric Trimmer/Edger, follow
these instructions to assemble:
1) Remove the trimmer and parts from the box.
2) Assemble the assist handle by xing the knob (Figure 1).
3) Insert the steel ower guard into the lower motor cover and
lock in place (Figure 2).
Figure 1
Figure 2

6
4) Place the Shield over the blade shaft and snap into place
(Fig. 3).
5) Assemble the plastic ower guard attachment to the steel
ower guard. There are 3 positions to meet different blade
lengths. First insert the slot of the plastic plate into the
steel bar (Figure 4).
6) Rotate the plastic ower guard attachment away from you
till the plastic is close to the steel bar and the two bottom
corner slots of the plastic feet snap in place to the steel bar
(Figure 5). This is position 1, the diameter of the protection
area is 12 inches.
7) Turn the plastic ower guard attachment towards you till
the plastic is close to the steel bar and the two bottom
corner slots of the plastic feet snap to the steel bar (Figure
6). This is position 2, now the diameter of the protection
area is 11 inches.
8) Remove the plastic ower guard attachment. (Figure 7).
Now in position 3, the diameter of the protection area is 9.5
inches.
9) Ultimately you can remove the ower guard from the motor
cover. This will allow you maximum use of the Sharper
Blade.
NOTE: Be careful when operating the machine while steel
ower guard is removed.
Click slot to
the steel bar
slot 2
slot 1
slot 4
slot 3
Figure 3
Figure 4
Figure 5
Figure 6
Figure 7

7
Installing or Changing Blade
1) Remove screw knob (Figure 8).
2) Remove the washer (Figure 9).
3) Assemble the Sharper Blade to the Electric Trimmer/Edger
(Figure 10).
4) Place the washer on the Blade (Figure 11).
5) Tighten the screw knob ( Figure 12).
screw knob
washer
Sharper Blade
Sharper Blade
washer
Sharper Blade
screw knob
Figure 10
Figure 9
Figure 11
Figure 12
Figure 8

8
Operation
mWARNING:
Rocks or debris may ricochet or be thrown into eyes and face,
cause blindness, or other serious injury. Never lean over the
trimmer head and always wear eye protection.
When operating unit, stand as shown and check for the
following:
• Wear eye protection and heavy clothing.
• Hold the trigger handle with one hand and adjustable
handle with the other hand.
• Keep the trimmer below waist level.
• Cut only from your right to your left to ensure debris is
thrown away from you. Without bending over, keep the
trimmer near and parallel to the ground.
mWARNING:
Use only Sharper Blade Electric Trimmer/Edger™ replacement
blade. Other products will not work properly and will result in
improper cutting head function or can cause serious injury. Do
not use other materials such as steel blades, wire, string, rope,
etc. Other materials can break off during cutting and become a
dangerous missile that can cause serious injury.
TRIMMING
Hold the bottom of the trimmer head above the ground and at
an angle if desired. Allow only the blade to make contact. Do
not force blade into work area.
Trimming
Blade above the ground
SCALPING
The scalping technique removes unwanted vegetation down
to the ground. Hold the bottom of the trimmer head about
3 inches (8 cm) above the ground and at an angle. Allow
the tip of the line to strike the ground around trees, posts,
monuments, etc. This technique increases line wear.
Scalping
MOWING
Your trimmer is ideal for mowing in places conventional lawn
mowers cannot reach. In the mowing position, keep the line
parallel to the ground. Avoid pressing the head into the ground
as this can scalp the ground and damage the tool.
Mowing

SWEEPING
Fanning action can be used for quick and easy clean up. Keep
the line parallel to and above the surfaces being swept and
move the tool from side to side.
Sweeping
EDGING
To change your Sharper Blade Trimmer into an edger, you
must slide down the Twist-N-Groom Shaft (balck ring) ½”, and
twist to rotate the black ring 180° in a clockwise direction.
To convert from edger back to trimmer, hold the green handle,
slide the Twist-N-Groom Shaft (black ring) down ½”, and twist
to rotate the black ring 180° anti-clockwise direction.
Maintenance
Before carrying out any maintenance operations, cut off the
electric power supply by disconnecting the plug from the
extension cable.
• Regular cleaning and maintenance of you grass trimmer will
ensure efciency and prolong the life of your machine.
• After each cutting operation, take apart and clean out the
grass and soil from; the whole trimmer and guard.
• During operation, keep the air slots clean and free from
grass.
• Only use a cloth soaked with hot water and a soft brush to
clean the grass trimmer.
• Do not spray or wet the appliance with water.
• Do not use detergents or solvents as these could ruin the
trimmer. The parts in plastic can easily be damaged by
chemical agents.
• If cutting blade no longer cuts or breaks, have this replaced
by contacting an authorized service center.
mCAUTION!
The blade can give deep cuts.
• For repairs which have not been explained in these
instructions, contact an authorized service center.
Trouble-Shooting
mCAUTION!
Always disconnect the electric power supply before
conducting maintenance or troubleshooting.
• If the grass trimmer vibrates: remove the spool and clean
the slots, carefully remove any grass and weeds and so
forth. If vibration persists after reassembly, replace the
blade with a new one. In the evert of the problem not
disappearing, have the trimmer checked at an authorized
service center.
• If the trimmer does not start: check all the electrical
connections; make sure the safety circuit-breaker has not
been activated; check that a fuse has blown in your
electrical system. Take the trimmer to an authorized service
center if the trimmer does not start after completing the
checks.
Storage
Follow these recommendations for storing the grass trimmer.
• Carry out general cleaning of the grass trimmer and its
ancillary parts (see maintenance paragraph), this prevents
9

10
mould from forming.
• Store it out of the reach of children, in a stable and safe
position and in a dry place where the temperature is not too
hot or too cold.
• Store the trimmer in a location with minimal light, away from
direct sunlight.
• Do not store the grass trimmer resting on the oor. Hang it
by the upper handgrip instead, so that the guard does not
touch anything. The resting of the guard on a surface could
alter its shape and therefore its dimensions and safety
characteristics would be modied.
Service and Support
If your Sharper Blade Electric Trimmer/Edger requires service
or maintenance, an Authorized Sun Joe Dealer will best assist
you. Please call 1-866-766-9563 for assistance.
Model and Serial Numbers
When contacting the company or reordering parts, you will
need to provide the model and serial numbers of your product.
These are found on the decal afxed to the housing or guard
of your Sharper Blade Electric Trimmer/Edger. Copy these
numbers into the space provided below.
Record the following numbers from the housing or handle of your
new product:
S B 6 0 0 E
Model #:
Serial #:

11
NOTES

12
A Two-Year Full Warranty
for residential use
in the United States and Canada
General Conditions:
Snow Joe, LLC warrants this product to the original purchaser for two years against defects in material or workmanship when used for
normal residential purposes. Snow Joe, LLC will repair any defect in material or workmanship, and repair or replace any defective part,
subject to the conditions, limitations, and exclusions set forth herein. Such repair or parts replacement will be free from charge to the
original purchaser except noted below.
The duration of the warranty applies only if the product is put to personal use around the household or residence. If the product is put
to any business use, commercial or industrial, then the duration of this warranty is 90 days from the date of original purchase. If any
product is rented or leased, the duration of the warranty is 90 days from the date of original purchase.
It is the owner’s responsibility to perform correctly all maintenance, and minor adjustments explained in the owner’s manual.
Electric Products:
To obtain a replacement electric powered unit or repair the existing electric powered unit, you must return the complete unit and
postage prepaid to: Snow Joe Return Center, 86 Executive Avenue, Edison, NJ 08817.
Gasoline / Battery Products:
Limitations
• Batteries are warranted only for the period of 12 months after the date of purchase on a prorated basis. Rechargeable batteries
will be replaced free from charge during the rst 90 days. After the initial 90 days, batteries will be replaced at prorated cost to
the customer
• Idlers, cables, and electrical components are warranted to the original purchaser for use at household or residence for a period
of two years
Exclusions
• Snow Joe brand engines are covered under this warranty. All other engines and engine accessories are covered only by the
engine manufacturer’s warranty and are not covered by this warranty
• Parts used that are not genuine Snow Joe parts are not covered by this warranty
• Damages resulting from misuse, alteration, improper assembly, improper adjustment, neglect, or accident which requires repair
is not covered under this warranty
• Belts and augers are not covered under warranty – belts and augers wear out and can be purchased at the Snow Joe Center.
Snow Joe, LLC may from time to time change the design of its products. Nothing contained in this warranty shall be construed as
obligating Snow Joe, LLC to incorporate such design changes into previously manufactured products, nor shall such changes be
construed as an admission that previous designs were defective.
This warranty is intended to cover product defects only. Snow Joe, LLC is not liable for indirect, incidental, or consequential damages
in connection with the use of the Snow Joe Products covered by this warranty. This warranty does not cover any cost or expense
incurred by the purchaser in providing substitute equipment or service during reasonable periods of malfunction or non-use of this
product, while waiting for completion of repairs under this warranty. Some states do not allow exclusions of incidental or consequential
damages, so the above exclusions may not apply in all states. This warranty may gives you specic legal rights in your state.
If you wish to contact Snow Joe, please direct inquiries to the:
Customer Service Department
Snow Joe Center
86 Executive Avenue
Edison, NJ 08817
Customers who have purchased Snow Joe products exported from the United States and Canada should contact their Snow Joe
Distributor (Dealer) to obtain information applicable for your country, province, or state. If for any reason, you are not satised with the
distributor’s service, or if you have difculty obtaining warranty information, contact your Snow Joe seller. If in the event your efforts
are unsatisfactory, please write to the Snow Joe Center at the above address.
If you have any questions about your product warranty, please call 1-866-SNOW-JOE or visit us online at www.snowjoe.com.
