Sunsystem 1000 de boss Manual

READ THESE INSTRUCTIONS BEFORE FIRING UP YOUR BALLAST

®

Sun System®1 Ballasts are controller-compatible

with signal ports for on /oﬀ /dimming functions

(Etelligent

™

controller sold separately. Part # 902245 )

ETELLIGENT

CONTROLLER

compatible

Product # 906612 Sun System®1000 Watt DE Boss®Commercial Fixture 277 Volt

600W 750W 1000W Turbo

750W

660W

600W

SIG A

INPUT

SIG B

www.HawthorneGC.com

RC

825W

1000W

1150W

Includes hard-wired 277 volt

power cord with a L7-15p 277

volt twist lock power plug.

1000 DE BOSS®

COMMERCIAL FIXTURE

Installation &Operating Instructions

KEEP ORIGINAL PACKAGING: All returns need to be in the original packaging in order to

avoid product damage during shipping. Any damage to products not in their original packaging

will not be covered under warranty.

SAFETY FIRST!

Failure to observe the following safety warnings may result in serious injury. In addition, failure to

observe these safety warnings will result in a waiver of all liabilities and will void all warranties.

WARNING:

 If the exterior of the lamp is damaged, replace lamp immediately.

 When relamping, make sure lamp has time to cool before touching.

 Make sure power cord is connected properly.

 Disconnect power before relamping.

 DO NOT hang by power or lamp cord.

 DO NOT make contact with the interior of the socket while power is on.

 DO NOT operate light systems in wet locations.

  DO NOT plug system into supply voltage other than what is designated on ballast.

  DO NOT attempt to rewire or recongure your system, it will void warranty and could cause

serious safety hazards (i.e. power cord, lamp cord, lamp socket or ballast).

Keep away from children.

Full warranty detail within.

SUN SYSTEM®1000 WATT DE BOSS®COMMERCIAL

FIXTURE SETUP:

1. Remove the system from the box along with all additional parts.

2. These systems do not require much setup.

3. Insert a DE lamp into a DE reflector. (FIG. 1) Insert each lamp wire of the double-ended

lamp into both socket slots. Make sure the wires are straight. Push both ends of lamp

rmly down into the metal clips. Slide each socket slider lock over both ends of the

lamp to secure the lamp into place.

4. Hang the xture using V-hangers provided (FIG. 3). Use an eye bolt or some other means

of securely hanging from the ceiling. Sun Grip®Push Button Light Hangers (#710122,

#710114, #710116 & #710123), (FIG. 2), Sky Hook™ Light Hangers (#710119) or jack

chain (#350205) may be used to adjust the hanging height.

5. Plug the unit into the proper NEMA congured receptacle or hardwire unit depending

on model voltage.

FIG. 3

Push both ends of lamp rmly

down into the metal clips.

Slide both sockets in the locked

position for a secure lamp.

SLIDE THIS WAY

SLIDE SOCKET

LOCK ALL THE WAY

UNTIL IT STOPS HERE

FIG. 1 FIG. 2

NOTES

   This Sun System® 1000 WATT DE BOSS® COM Commercial Etelligent™ Electronic

Ballast is designed to operate 1000 Watt double-ended H.I.D. lamps.

  This unit offers short-circuit and power fluctuation protection.

  Features internal built-in circuit breaker.

WIRING - VERY IMPORTANT! All digital ballasts may malfunction if the circuit has

a neutral. The input for the ballast is 2 HOT WIRES and 1 GROUND WIRE. If you are using a

light controller ONLY bring a ground wire and two hot leads from your electrical panels.

HOT RESTRIKE - The 1000 Watt DE Boss®COM features a hot restrike function to

protect the lamp and ballast. This function allows the ballast to reignite the lamp once it has

cooled. In the event of a power interruption or failed ignition, the ballast will wait one minute

and attempt to restart the lamp. If the lamp does not ignite at that time, it will make four

more attempts in ve minute intervals. If the ballast has ran though the complete sequence

(1 minute -5 minutes -5 minutes -5 minutes -5 minutes), the ballast will go into a locked

mode. The ballast will not begin the ignition sequence again until it has been disconnected

from power. This can be achieved by unplugging the ballast and plugging it back in or

waiting until the next set timer cycle. Do not unplug the ballast until it has completed the full

twenty-six minute sequence.

This 906612 Sun System® 1 DE BOSS® COM 1000 Watt 277 Volt xture has a

hard-wired 6 foot 277 Volt power cord with a L7-15p 277 Volt twist lock plug.

  277 Volt

Frequency: 50/60Hz

  Power Factor: > 0.99%

Max Ambient Temp: 104˚F

 Total Harmonic Distortion:

(THD): < 10.0%

277 Volt Fixture:

Includes 6 ft. hard-wired

power cord with a L7-15p

twist lock plug.

SAFETY FIRST!

  DO NOT alter or modify this unit in any way. Unit may cause bodily injury

or death as this is a high power electrical device.

 DO NOT submerse in water or splash water on the unit.

 DO NOT plug or unplug the lamp cord while the ballast is energized.

These high performance, ultra high frequency electronic ballasts are extremely efcient.

They have a high power factor and high luminous efcacy. Their stable performance creates

constant power output even when power fluctuates (power surge). Short circuit protection

technology prevents damage to the lamp and other ballasts connected to the same circuit.

LAMP REPLACEMENT - Be sure to disconnect the power source before changing lamps.

Always use the specied wattage lamp. (ie: A 400 Watt halide lamp should NOT be used in a

600 Watt ballast).

TIMER BOX - If you are connecting a 277 volt ballast to a timer box, please make sure that it

cuts off both legs when timer is switched off. If you continue to supply voltage to your ballast when

the timer is switched off, it may damage your ballast.

LAMP RECOMMENDATIONS - The ballasts are designed to provide superior performance

with several lamps manufactured to American specications. There are several brands of lamps

available for the U.S. market that were made according to European specications. We do not

recommend using these types of lamps, since they will provide inconsistent performance with your

ballast.

ERROR CODES - If the ballast encounters any abnormal conditions the built-in

self-diagnostic feature will display easily identiable error codes. Error codes can be

identied by the number of flashes made by the green LED marked “turbo”.

1 Flash = Ballast Protection: This code means that the ballast has gone into a

locked mode to protect itself. This may be followed by another code to help

troubleshoot the cause.

2 Flash = Bad Lamp/Short Circuit: This code means that the ballast has a bad

connection somewhere between the ballast and lamp. Reasons can include

a bad lamp, loose lamp, loose lamp cord, a short in the cord or reflector, or a

short in the ballast receptacle.

3 Flash = Low Voltage: This code means the power coming from the outlet to your

ballast is not sufcient to power the unit.

4 Flash = Over Temperature: This code means the ballast has shut itself off due to

overheating (>140° F).

5 Flash = Over Voltage: This code means the power from the outlet to your ballast

has exceeded the maximum allowed voltage.

6 Flash = Lamp Fault: Incorrect/non compatible lamp will not work with ballast.

The Sun System® 1 Etelligent™ digital lighting controller enables the grower to control up to 400

xtures. Features an industry rst, the ability to control any Sun System® Etelligent™ compatible

xture or ballast with the same controller, operating on separate channels. This two channel

controller allows daisy-chaining up to 200 xtures per zone. Enabling complete control of your

growing environment with timed on/off switching, sunrise/sunset, accurate temperature readings

with dual thermal probes and thermal-threshold auto dim-shutdown for additional protection.

Sun System® 1 Etelligent™ Controller Kit #902245 (sold separately) allows wired control of the on/off/dimming

capabilities. Complete kit includes: 1 Etelligent™ Controller, 1 universal power adapter 5 ft/1.5 m cable, 2 each 16

ft/5 m signal wires with ferrites for connection from controller to ballast and 2 each 16 ft/5 m temperature probes.

CONTROL UP TO 400 SUN SYSTEM DOUBLE-ENDED

COMMERCIAL FIXTURES OR OTHER COMPATIBLE

MODELS WITH ONE ETELLIGENT™ CONTROLLER!

ZONE A (up to 200 xtures) ZONE B (up to 200 xtures)

This product contains delicate electronic components. This means that if it is placed near an object that transmits

radio signals, it could cause interference. This could be, for example, mobile telephones, walkie talkies, CB radios,

remote controls and microwaves. If interference occurs, move such objects away from the appliance.

Sun System

®

1000 Watt DE Boss

®

Commercial Fixture:

Compliant with FCC Part 18 Class A (governs commercial use) and FCC Part 18 Class B (governs residential

use) as tested by an independent US testing lab in a true as used conguration. In our case, Northwest EMC

or ElectroMagnetic Investigations, Hillsboro OR.

This installation guide does not supersede national, state, or local regulations for electrical installations.

TROUBLESHOOTING… IF YOUR FIXTURE DOES NOT WORK:

1. CHECK YOUR ELECTRICAL SOURCE: Make sure the unit is plugged in properly and that the

breaker is not tripped or fuse blown.

2. CHECK THE LAMP COLOR: Make sure the lamp is fully seated in the socket.

POSSIBLE CAUSES CORRECTIVE MAINTENANCE

LAMP LOOSE

IN SOCKETS

Make sure that the lamp is fully inserted into the socket and that the

socket is in the closed position.

INCORRECT

VOLTAGE

Make sure you are using the correct input voltage with xture. If

using incorrect voltage, disconnect the xture from the power source

immediately.

DEFECTIVE OR

IMPROPER WIRING

Examine wiring to ensure it agrees with wiring diagrams on xture label.

Check connections to see that they are secure. If wiring a 240 volt xture,

DO NOT use a neutral. The correct wiring is two hot wires and a ground.

POOR ELECTRICAL

CONNECTIONS

Check wiring and lamp contact with socket. Make sure the lamp cord is

rmly seated in output receptacle.

INCORRECT

LAMP Verify that you are using a 1000 Watt double-ended lamp.

LAMP

DAMAGE

Investigate possibility of outer bulb damage.

Look for broken tubes or loose metal parts. Replace lamp.

TROUBLESHOOTING GUIDE

Follow the troubleshooting tips below. If troubleshooting techniques fail, bring ballast back to

your place of purchase to request warranty service.

FCC compliance This device complies with Part 18 of the FCC Rules.

Advisory statement

This product may cause interference to radio equipment

and should not be installed near maritime safety

communications equipment or other critical navigation

or communication equipment operating between

0.45-30 MHz.

The interference potential

of the device or system

The interference potential of the device or system is the

operating frequency; 110 kHz.

Maintenance of the system Unplug the unit, wait 30 seconds, and plug the unit

back in.

Simple measures that can be taken

by the user to correct interference Move the unit away from any radio device.

WARRANTY SERVICE:

PLEASE READ WARRANTY INFORMATION FIRST

If the light does not work after troubleshooting, please return the light to the dealer where it

was purchased. The dealer will evaluate and test the light and its components. The dealer may

be able to repair the light on site. If the dealer is unable to repair the light, they will return it to

us for factory repair. Many dealers will provide loaner xtures for use during the repair period

(usually not more than 7-10 days).

To locate dealers within the United States: www.HawthorneGC.com. To locate dealers within

Canada: www.HawthorneGC.ca. and click “AUTHORIZED DEALERS”. If there are no dealers in

your area, please contact us directly for technical support. If we cannot help you resolve the

problem over the phone and if the unit is still in warranty, we will issue you an

RMA # (return merchandise authorization number) authorizing you to return the system to

us for factory reconditioning. You will be asked to provide an email address or fax number

to receive the RMA form. The completed RMA form must be included in the packaging when

returning your Sun System®unit. Also please write the RMA # on the outside of the box.

Please package the light carefully in its original packaging. We are not

responsible for xtures damaged during shipment.

The light will be repaired within 48 hours of receipt and returned via UPS Ground. If the unit

cannot be repaired, a replacement will be sent. If there are no identical units available, a

comparable xture will be substituted.

IMPORTANT:

PROOF OF PURCHASE REQUIRED FOR RETURNS

SUN SYSTEM®1000 WATT DE BOSS®COMMERCIAL FIXTURE:

3 Year Warranty Returning Units: Please contact your retail store for returns.

WARRANTY INFORMATION: The Hawthorne Gardening Company warrants to the

original purchaser of this product against defects in material and workmanship under normal

use for 3 year on SUN SYSTEM® 1000 WATT DE BOSS® COMMERCIAL FIXTURE. During the

warranty period, The Hawthorne Gardening Company will, at our option, and without charge,

repair or replace this product if the unit or any of its components fail or malfunction. This

warranty is expressly in lieu of all other warranties, expressed or implied, including the

warranties of merchantability and tness for use and of all other obligations or liabilities

on the part of the seller. This warranty shall not apply to this product or any part thereof

which has been damaged by accident, abuse, misuse, modication, negligence, alteration

or misapplication. The Hawthorne Gardening Company makes no warranty whatsoever in

respect to accessories or parts not supplied by The Hawthorne Gardening Company. This

warranty shall apply only to the United States, including Alaska, Hawaii, territories of the

United States and Canada.

NOTES

_________________________________________________________________________

NOTES

_________________________________________________________________________

Manufactured for Hawthorne Hydroponics LCC,

a subsidiary of The Hawthorne Gardening Company

3204 NW 38th Circle, Vancouver, WA 98660

|

HawthorneGC.com

|

HawthorneGC.ca

111858

Sunsystem 1000 DE Boss Manual

Popular Light Fixture manuals by other brands
