Sunyash MapOut Plus User manual

1 | P a g e
Sunyash Multi Trading Pvt. Ltd.
MapOut Plus Vehicle Tracker
User Manual
(Version V1.0.1)

2 | P a g e
Sunyash Multi Trading Pvt. Ltd.
Index
Sr.No.
Chapter
Page No
1
Start Guide
1.1 Accessories
1.2 Main Function
1.3 Technical Specification
1.4 Hardware Specification
3
2
Device
2.1 Appearance
2.2 LED Indication
4
3
Connection & Installation
3.1 Wire Connection
3.2 Device Installation
6
4
Operation of Device
6
5
Main Functions
7
6
Platform Operation
6.1 APN & Server Setting
6.2 Login Service on Platform
6.3 Login Service on Application
8
7
Command List
9
8
Trouble Shooting
9
A
Warranty Instruction & Service
10
B
Service Report
10

3 | P a g e
Sunyash Multi Trading Pvt. Ltd.
1. Start Guide
1.1 Accessories:
Main Device
OBD Cable
SOS Button (As Per Requirement)
1.2 Main Functions:
Real time GPS Tracking
SOS Alert, Ignition ON/OFF Alert
Enter or Exit Geo-Fence Alert
Tow Alert
Multiple analog & Digital Input/output
FOTA
Fuel Monitoring
Track by Time Interval
Easy to Install
No Need External Antenna
Built-in battery with large capacity 1100mA
1.3 Technical Specifications:
External Power
12V to 36V DC
Internal Battery
3.7V /1100mA or 3.7V /2000mA
Charging Time/ Battery Backup
120 minutes/ 300 minutes
Operating Temp.
- 30°C to +85°C (0°F to +85°C)
CPU
ARM7 LPC2148
CPU internal Flash+ Memory
512KB Flash + 40KB SRAM
External Memory
512KB EEPROM
Wired Communication
2 Serial (GSM/GPRS + GPS )
GSM/GPRS Modem
SIM800C
Navigation GPS Receiver
L80-M39
Device Input (Digital + Analog)
2+2
Device Output
2
Power/SIM/Battery Removal Alert
Yes
Battery Charging Indication
Yes
Geo Address
----
GPS antenna
Inbuilt
GPRS antenna
Inbuilt
GPS dark zone
LBS & GSM Triangulation
Smart Polling
Time, Distance ,Angle & IO Events

4 | P a g e
Sunyash Multi Trading Pvt. Ltd.
1.4 Hardware Specifications:
Warranty: 6 Months Seller Warranty.
Color: Translucent Black.
Material: Polycarbonate casing.
Brand: MapOut.
Quality: As per Automobile Standard.
Condition: A brand-new, unused and undamaged item.
2 Device
2.1 Appearance:
Front & Back View of Hardware

5 | P a g e
Sunyash Multi Trading Pvt. Ltd.
2.2 LED Indicators:
A. Power Indicators
Power Supply (PWRLED)- Red
ON
Input Power Supply is ON
OFF
Input Power Supply is OFF
B. Charging Indication:
Charging (Green and Orange)
Both ON
Battery Removed
Green ON
Battery connected and Charging
Both OFF
Charging Disconnected
C. Device Status Indication:
Memory (S_OK1)- Blue
1 Sec Blink
Save Data into Memory
OFF
No Data Stored into Memory
Server Data (S_OK)- Red
1 Sec Blink
Send Data to Server
OFF
No Data Stored into Memory
Connect (C_OK)- Green
Steady ON
Device Connected to Server
OFF
Device Not Connected to Server
GPS (GPS)- Blue
1 Sec Blink
GPS is Fixed
OFF
No GPS is fixed or Initializing
GPS (GPS)- Orange
1 Sec Blink
GPS is Fixed
OFF
No GPS is fixed or Initializing
GSM (GSM)- Blue
64ms On/ 800ms OFF
Not Registered with Network
64ms On/ 3000ms OFF
Registered with Network
64ms On/ 300ms OFF
GPRS Connection Established
OFF
Power OFF

6 | P a g e
Sunyash Multi Trading Pvt. Ltd.
Restart (S_OK1, S_OK, C_OK)- Blue --> Red -->Green
Flash In a Loop
Device Restart
3. Connection & Installation:
3.1 Wire Connection:
Line
Colour
Description
Definition
1
Red
VCC
12V/24V Car Battery Positive
2
Black
GND
12V/24V Car Battery Negative
3
Green
IGN
ACC Ignition
4
Yellow
FUEL
Fuel gauge of Fuel Sensor
3.2 Device Installation:
Fig. OBD-II Port Location
The OBD-II connector directly plug into vehicles OBD-II Female connector then
immediately POWER Led(Red) is ON.
The POWER Led is the status of device is connected to vehicle and supply is OK.
Device Should be fitted tightly.
Metal thermal barrier or heating Layer of the windshield affects the signal. So Please
change installation places to receive the Better signal.
4. Operation of Device:
Power ON/OFF:
Plug the OBD-II connector to the vehicles OBD-II female connector the POWER LED goes ON
and same time the device starts charging. Until battery was not discharge the device still ON. After
battery fully discharged the device goes into Power OFF Stage.
Server Connection:
After Successful registration of Network, the GPRS will activated then the device connected to
server and starts the Green LED.
GPS Signal & Data Send to Server:

7 | P a g e
Sunyash Multi Trading Pvt. Ltd.
After fixing the position of GPS the Orange Led starts the blinking. Then the device starts the
sending data to server after every 5 sec.
5. Main Functions
5.1 Advance Tracking:
This feature enables our customers to be see their current vehicle status in different regions of
country and can track single vehicle. In Advance tracking you can see the real-time location of your vehicle
and also status whether currently parked or moving. You can view which road your vehicle is on map and
all details of vehicle.
5.2 Detail Dashboard:
You can overcome on fuel theft as it is major problem in transport industry with below mentioned
alerts,
Fuel Pilferage/ Theft Alert
Live Fuel Status
5.3 SOS Button:
It helps the customer to transmit signals when they are in critical situation like accident or other
dangers. As soon as the driver/any other person presses the panic button, it triggers a message to
owner/manager as selected by the user in its preference.
5.4 Anti-Theft:
It helps to against to vehicle theft when you park your vehicle outside your home at night or in busy
market place.
5.5 Point of interest:
It is specific point location that someone may find useful for his vehicle to frequent place visit. For
instance, Home, Office, Delivery location etc.
5.6 Playback:
It enables to review the vehicle past trip with dates including running, stoppage, idling, parking
details with every location on map.
5.7 Geo-Fence:
It allows you too quickly and easily setup geographic boundaries around specific areas and then
receive automated alerts whenever a vehicle enters or exits those boundaries.
5.8 Power Disconnect Alert:
When the device will remove from the OBD-II port then immediately Power Disconnect Alert
activated.
5.9 Restart Device
If GPRS service is abnormal (OFFLINE), then user can send SMS command RESTART to restart
the device. Device will RESTART device after 20 secs after receiving the command.

8 | P a g e
Sunyash Multi Trading Pvt. Ltd.
5.10 Analog Signal:
The analog port is currently used to measure the Fuel Reading which will be uploaded to
platform/APP in fixed time of interval. Yellow wire of device receives Analog signal.
5.11 FOTA:
Using simple command easy to update the firmware through Air. (Check Command List).
6. Platform Operation:
MapOut24 platform is used to checking all data. Also our application is available on both Google
Play Store and Apple App Store
Link of Platform:
http://mapout24.com/
Google Play Store:
https://play.google.com/store/apps/details?id=com.vts.mapout.vts&hl=en
6.1 APN and Server Setting:
To ensure normal network operation please check server setting and APN of your network before
login. In most countries APN could be automatically adapted to local mobile operators. If not, then need
to update APN manually using SMS (Check Command List).
For Server setting, confirm the server address and setting with distributors. If server is incorrect
please send SMS to update (Check Command List).
6.2 Login Service on Platform:
Open the Home page using the platform link and go to the Login and then click on server login.
Then enter provided username and Password. For demo login use following details
Username: mapout_demo
Password: 123456
6.3 Login Service on Application:
Download the app using app store link and install it. After successful installation enter the server
name and login using provided username and Password. For demo login use following details
Server Name: indiansilicon
Username: mapout_demo
Password: 123456

9 | P a g e
Sunyash Multi Trading Pvt. Ltd.
7. Command List:
Sr. No.
Command
Description
1.
UPDATEFIRM
Update firmware to Latest Version
e.g. UPDATEFIRM
2.
SET:APN[apnname];
To Update APN
e.g. SAPNinternet;
3.
SIP[ip],[port];
To update IP address and PORT
e.g. SIP134.34.154.42,5142;
4.
SINGTH[TH. Value];
To SET threshold value for ADC
SINGTH0234; //Threshold value is 2.34V
5.
SVEHNO[Vehicle
No.]
To set vehicle Number
e.g. SVEHNOMH12AA0000;
6.
SDSF[Seconds]
To set Data Sending Frequency
e.g. SDSF0234; // Time is 234Sec.
7.
RESTART
To Restart Device
e.g. RESTART
8.
RESTORE
To Restore All data of Memory
e.g. RESTORE
9.
GSMRESET
To reset only GSM
e.g. GSMRESET
10.
GVEHNO;
To get Vehicle Number
e.g. GVEHNO
11.
GHEALTH;
TO get Health Parameter Firmware Version, IMEI Number,
GSM Range, Digital I/O, Analog.
e.g. GHELTH
8. Trouble Shooting:
If any problem found with hardware, try following troubleshooting procedure,
Problems
Causes
Solutions
Offline
Abnormal Power supply/GPRS not
Activated/ GMS Network not
registered
Check Power Supply/ Check GSM
network
No Update Vehicle
Location
No GPS Positioning
Test the device again/ Change the
location of installed device
Unable to Locate
Poor Signal/ No GPS signal
Change the location of installed
device
Unable to Boot
Low Battery
Charge the Device Battery
Unable to Connect
Network
Poor Signal
Using the GPS tracker in the places
that have good signal condition
Power Disconnect
Loose Connection of OBD-II
Connector
Remove and plug connector again.

10 | P a g e
Sunyash Multi Trading Pvt. Ltd.
Warranty Instruction and Service:
Warranty of Device is 6 Months
The warranty is not applicable to causes other than defects in material, design & workmanship.
Replacement or Repairing device under the terms of this warranty does not provide right to
extension or renewal of the warranty period.
Our free service is limited to repair of the defect or replacement the defective part. For replace of
any part, extra cost is added to the service.
Warranty repairs must be carried out by our Authorized service Centre. If warranty period is over,
then also repair has been attempted by any Authorized service Centre (Repairing Charges is
Added Extra).
Service Record
Model
Service By
IMEI Number
Date
……./…../20….
Service Type
Paid Service / Free Service
Fault Descriptions
Replace Part
Remark
Sign. of Customer
Sign. of Technician
