Supera SSUD18-1 User manual

SSUD18-1
DISHWASHER
INSTRUCTION MANUAL
This manual contains important information regarding your Supera® unit. Please read this manual thoroughly prior to equipment set-up, operation and mainte-
nance. Failure to comply with regular maintenance guidelines outlined in this manual may void the warranty.

INSTRUCTION
MANUAL
©SUPERA V.1.0 | October 2014
OPERATION GUIDELINES
WARNING: Pay attention to the following before operating for safe usage.
•Only wash dishes with applicable chemicals.
•Never put an inflammable liquid into the tank. This can cause an explosive
accident.
•Never open the door while operating. This is dangerous and you can get
burned by hot water.
•Contact Supera Service if you encounter any technical problems. Only
authorized technicians are approved for maintenance.
•Make sure to ground the electrical wire. Failure to do so can cause electrical
leakage and shock.
•Do not store anything on top of the dishwasher. This may cause mechanical
defects.
•Do not wash exterior electrical components with water. This may cause
electrical leakage.
•Make sure to place and install this unit where there is good ventilation and no
flammable agents.
•Only use low foaming detergent in this unit. High foaming detergent and other
soaps will prevent a thorough wash.
•When exchanging chemicals, do not get the detergent on your skin, clothes,
and eyes. This chemical is severely corrosive to skin, eyes, and clothes.
•Wear chemically impervious gloves and apron while cleaning and moving this
unit.
•If there are defects in the ignition of the gas booster, call a Supera Service
representative immediately. Be sure to also close the gas valve and check for
gas leakage.
•Keep chemical agents away from children.
•If you consume detergent, do not vomit. Drink two glasses of water and
immediately go see a doctor.
•Avoid materials that are reactive with acids, alkalis, etc.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using your dishwasher, follow basic precautions, including the
following:
SAFETY AND CAUTION
•Please read this manual carefully before using the dishwasher for the first time.
•This manual contains very important information regarding the installation, use
and maintenance of your dishwasher.

©SUPERA V.1.0 | October 2014
INSTRUCTION
MANUAL
•The manufacturer cannot be responsible for problems caused by ignoring
these safety and caution instructions.
•This dishwasher is designed for commercial and industrial use.
•Do not use the dishwasher for domestic use, or other purpose.
•The appliance is not intended for use by young children or infirm persons
without supervisions.
During Installation
•Electrical connection must be in accordance with the rating label.
•Electrical safety isonly guaranteed when the ground systemof your house is
in accordance with the related local regulations. (Do not use an extension or
cable cord.)
•If power supply cord is damaged, it must be replaced by the manufacturer, a
service agent, or a similar qualified person in order to avoid a hazard.
•The appliance is to be connected to the water main using new hose-sets and
old hose-sets should not be re-used.
During Use
•Do not use any kind of solvent in your dishwasher. This may cause an
explosion or fire.
•Do not spray water on the appliance. It may cause failure of electric parts or
an electric shock.
•Do not use the detergent for hand washing. The detergent for the dishwasher
should only be used for normal operation.
•Dishwasher detergents are strongly alkaline. They can be extremely
dangerous if swallowed. Avoid contact with skin and eyes.
After Use
•Pull down circuit breaker when dishwasher is not in use anymore.
PREVENT ELECTRICAL LEAKAGE AND SHOCK
Make sure to ground the wire to electrode to avoid electrical accidents.
Grounding – All exposed dead-metal parts are connected to the grounding lead of
the power supply cord or the equipment grounding terminal.

©SUPERA V.1.0 | October 2014
INSTRUCTION
MANUAL
DIMENSIONS

INSTRUCTION
MANUAL
©SUPERA V.1.0 | October 2014
SPECFICIATIONS
Model: SSUD18-1
Operating Specification (Hot Water Sanitation Specification)
Wash Temp: Minimum 165°F
Rinse Temp: Minimum 180°F
Wash Cycle: 60S (60~160, 8 Step)
Rinse Cycle: 10S (6~13, 8 Step)
Wash Tank: 10.6 Gallons
Rinse Tank: 7.1 Gallons
Water Inlet: ½” (15A)
Drain Connection: 1-1/2”
Electrical Specification
Phase: 3PH
Volts: 208V
Hertz: 60 Hz.
Wash Motor: 1.75kW 4.0A
Rinse Motor: 94W 1.47A
Heater: 8kW(4kWx2) 10.5A
Washing Cycle: 4.0A
Rinsing Cycle: 0.6A
Dimension: 25.6” (W) x 25.6” (D) x 64.8” (H)
Net Weight: 198 lbs

INSTRUCTION
MANUAL
©SUPERA V.1.0| October 2014
INSTALLATION INSTRUCTIONS
LEVEL THE DISHWASHER
The dishwashing machine is designed to operate while being level. This is important
to prevent any damage to the machine during operation and to ensure the best
results when washing ware. The unit comes with adjustable feet, which can be turned
using a pair of channel locks or by hard if the unit can be raised safely. Ensure that
the unit is level from side to side and from front to back before making any
connections.

INSTRUCTION
MANUAL
©SUPERA V.1.0 | October 2014
PLUMBING CONNECTIONS
DRAIN
ELECTRICAL CONNECTIONS
WARNING: Electrical and grounding connections must comply with the applicable
portions of the National Electrical Code and/or other local electrical codes.
WARNING: Disconnect the electrical power to the machine (both dishwasher and
booster if applicable) and follow lockout/tagout procedures.

INSTRUCTION
MANUAL
©SUPERA V.1.0 | October 2014
Check Rotation (Three Phase Machines Only)
Three-phase motors must rotate in the direction of the arrow on the motor housing.
In order to check rotation, close the machine doors and press the power switch to
ON.
When the machine is completely filled, open and close machine doors to verify that
the motor impeller rotates in the clockwise direction.
If the rotation is incorrect, DISCONNECT ELECTRICAL POWER SUPPLY and
interchange any two of the incoming power supply leads. Reconnect the power
supply and verify correct rotation.
OPERATING INSTRUCTIONS
Available to hook on left or right hand of dishwasher

INSTRUCTION
MANUAL
©SUPERA V.1.0 | October 2014
©SUPERA V.1.0 | October 2014
SETTING AND CHANGING MODES
A. SWITCH
A1. POWER S/W
To turn on/off electric power on main board.
If power is on, the ready lamp will be flickering, and it will display the whole
washing time (wash, stand by, rinse) by digits.
A2. READY S/W
To prepare for operation, set time, wash, rinse, chemical agent supply, delayed
time and temp, etc. and to lock system
a. To prepare for the operation system if press ready, ready flickering
and then press again ready lamp on; all preoperational courses (water
supply, chemical agent supply, heating, etc.) to be ready.
b. To set and change modes; wash time, rinse time, chemical agent
supply time, wash temp, rinse temp, delayed time, initial
detergent supply time, etc. When changing the existing modes,
press ready button with functional sw 1,2,3 in three holes as
shown below.
c. To lock washing system temporarily, press ready and close the door.
To unlock washing system press ready again.
B. HOW TO CHANGE AND SET MODE
1. Power ON
2. Press MODE button (adjustment for step) Wash Time – Rinse Time –
Booster Temp. –
Detergent Supply Time – Delay Time – Wash Tank Temp – Initial Detergent
Supply Time
3. Change step by MODE bottom (digit flickering, then adjust by UP/DOWN)
4. Change next step by pressing MODE button
5. Press READY when setting is finished
EX) Wash time 50sec to 60sec/rinse time 8sec to 9sec
1. Power ON
2. Press MODE (wash time shows 50 sec)
3. Press UP (50 sec, flickering)

INSTRUCTION
MANUAL
©SUPERA V.1.0 | October 2014
4. Press UP again (50 is changed to 60, and flickering)
5. Press MODE (rinse time shows 8sec)
6. Press UP (8 is changed to 9, and flickering)
7. Press READY (setting finished and stand-by)
C. LAMP DISPLAY
1. WATER LAMP ON/OFF
ON: to supply water to wash & booster tank
OFF: to finish watering tank
2. STAND BY LAMP ON/OFF
ON: to be ready to start the system
3. WASH LAMP ON/OFF
ON: to wash dishes by system
4. RINSE LAMP ON/OFF
ON: to rinse dishes by system
5. DETERGENT LAMP ON/OFF
ON: to supply detergent to tank while washing
6. RINSE AID LAMP ON/OFF
ON: to supply rinse aid to tank while rinsing
OPERATION
1. Place drain pipe and strainer in the right place
2. Turn on the main switch
3. Controller
Check the flickering light after pushing the ready button

INSTRUCTION
MANUAL
©SUPERA V.1.0 | October 2014
4. Wait for watering after closing the door
a. Automatically fill up the water to the tank
b. After finished filling up the watering, turn water lamp, detergent feeding
and detergent lamp off, then turn stand by lamp on
5. Wash
a. Put the dishes into the rack
b. Put the rack into the machine
c. The door actuation system will close the door automatically
6. Rinse the dishes and rinse aid feeding
a. After finishing the wash cycle, automatically operate as programmed
7. Finish
a. Buzz for the finish and finish & standby lamp on
MAINTENANCE
Tips for Washing
•Scrap the dishes to remove large particles of food and debris (prewash)
•Arrange the dishes in the rack. Don’t stack dishes one on top of another as
water must have free access to all sides of every dish
•After filling a rack, open the door, slide rack into the dishwasher and close the
door
Tip for Cleaning Dishwasher
1. Period for cleaning
a. The machine must be thoroughly cleaned at the end of each working
shift
b. Never use steel wool to clean the dishwasher
2. Clean
a. Push off the power button
b. Drain wash water by taking out the drain pipe and strainer
c. Clean off the strainer
d. Cleanse and flush inside of the dishwasher and remove a remaining soil
with soft cloth or brush
e. Replace all removed parts and leave the machine door open for drying

INSTRUCTION
MANUAL
©SUPERA V.1.0 | October 2014
No use of dishwasher detergent Use of dishwasher detergent
Low temperature of wash water Check wash water temperature
Closed gas valve Open valve
Closed water valve Open valve
Battery out for ignition Exchange batteries
Dripped water by low pressure Close another valve
Debris on the nozzles of wash arm Remove debris
Run out of detergent Refill detergent
No rinse aid Refill rinse aid
Low temperature of rinse water Use the dishwasher at the proper
temperature
Debris on nozzle of rinse arm Remove debris
Weak wash blade or drip Food or debris on the filter of wash
pump Remove debris
Wash defets
Dry defects
Take out the drain pipe Put it on wash tank
Trouble Possible Cause Solution
Higher foaming than
usual
No ignition of gas
booster
Continual gas booster
work
TROUBLESHOOTING

ELECTRIC WIRING

www.SuperaCo.com
© Supera 2014 Version 1 | November 2014
LIMITED WARRANTY
SUPERA DISHWASHER EQUIPMENT MODELS:
Dishwashers: [SSUD18-1]
One-Year Parts & Labor Warranty: SUPERA, LLC warrants to the original purchaser of new equipment that said equipment, when
installed in accordance with our instructions within North America and subjected to normal use, is free from defects in material or
workmanship for one year from the date of original purchase. Warranty includes onsite service calls within 60 miles of an authorized
service company. End user is responsible for all extra travel and mileage at prevailing rates and for original call to SUPERA, LLC
expressing need for warranty service. Any service provided without authorization from SUPERA, LLC will not be covered by SUPERA,
LLC.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED. SUPERA, LLC EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTABILITY OR EXPRESSED OR IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE. SUPERA, LLC HAS FINAL DESCRETION ON ALL WARRANTY REQUESTS.
SUPERA, LLC’S OBLIGATION AND LIABILITY UNDER THIS WARRANTY IS EXPRESSLY LIMITED TO REPAIRING AND
REPLACING EQUIPMENT WHICH PROVES TO BE DEFECTIVE IN MATERIAL OR WORKMANSHIP WITHIN THE APPLICABLE
WARRANTY PERIOD. All repairs pursuant to this Warranty will be performed by an Authorized Designated SUPERA, LLC Service
Location during normal working hours. This warranty does not cover services performed at overtime or premium labor rates. End user is
responsible for the difference between normal service rates and premium service rates. This warranty does not cover any service
technician errors. IN NO EVENT SHALL SUPERA, LLC BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES TO BUYER
OR ANY THIRD PARTY, INCLUDING, WITHOUT LIMITATION, LOSS OF PROPERTY, PERSONAL INJURY, LOSS OF BUSINESS
OR PROFITS OR OTHER ECONOMIC LOSSES, OR STATUTORY OR EXEMPLARY DAMAGES, WHETHER IN NEGLIGENCE,
WARRANTY, STRICT LIABILITY, OR OTHERWISE.
This warranty is given only to the first purchaser from a retail dealer. No warranty is given to subsequent transferees. Installation in a
residential application will void all warranties.
Warranty does not cover product failures caused by: failure to maintain, neglect, abuse, damage due to excess water, fire, normal
wear, improper set up and use. Periodic maintenance is not covered. SUPERA, LLC is not responsible or liable for any conditions of
erosion or corrosion caused by corrosive detergents, acids, lye or other chemicals used in the washing and/or cleaning process.
Warranty does not cover service requests for free replacement and/or recall parts.
THE FOREGOING WARRANTY PROVISIONS ARE A COMPLETE AND EXCLUSIVE STATEMENT BETWEEN THE BUYER AND
SELLER. SUPERA, LLC NEITHER ASSUMES NOR AUTHORIZES ANY PERSONS TO ASSUME FOR IT ANY OTHER OBLIGATION
OR LIABILITY IN CONNECTION WITH SAID EQUIPMENT.
Example of items not covered under warranty, but not limited to only these items:
1. Acts of God, fire, water damage, burglary, accident, theft.
2. Freight damage.
3. Improper installation or alteration of equipment.
4. Use of generic or after market parts.
5. Repairs made by anyone other than a SUPERA, LLC designated servicer.
6. Lubrication.
7. Expendable wear parts, adjustable feet, blown fuses, lamps, etc.
8. Cleaning of equipment.
9. Misuse or abuse.
Not Covered Under This Warranty: SUPERA, LLCʼs sole obligation under this warranty is limited to either repair or replacement of parts, subject to the
additional limitations below. This warranty neither assumes nor authorizes any person to assume obligations other than those expressly covered by this
warranty. Warranty does not cover service requests for free replacement and/or recall parts.
SUPERA, LLC HAS FINAL DESCRETION ON ALL WARRANTY REQUESTS. NO CONSEQUENTIAL DAMAGES. SUPERA, LLC IS NOT RESPONSIBLE FOR ECONOMIC
LOSS; PROFIT LOSS; OR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION, LOSSES, SERVICE TECHNICAN ERRORS, OR
DAMAGES ARISING FROM FOOD OR PRODUCT SPOILAGE REGARDLESS OF WHETHER OR NOT THEY RESULT FROM REFRIGERATION FAILURE. WARRANTY IS
NOT TRANSFERABLE, This warranty is not assignable and applies only in favor of the original purchaser/user to whom delivered. ANY SUCH ASSIGNMENT OR TRANSFER
SHALL VOID THE WARRANNTIES HEREIN AND SHALL VOID ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR
LABOR COVERAGE FOR COMPONENT FAILURE OR OTHER THE WARRANTY PACKET PROVIDED WITH THE UNIT. ALTERATION, NEGLECT, ABUSE, MISUSE,
ACCIDENT, DAMAGE DURING TRANSIT OR INSTALLATION, FIRE, FOOD, ACTS OF GOD. SUPERA, LLC is not responsible for the repair or replacement of any parts that
SUPERA, LLC determines have been subjected after the date of manufacture to alteration, neglect, abuse, misuse, accident, damage during transit or installation, fire, flood, or
act of GOD. IMPROPER ELECTRICAL CONNECTIONS. SUPERA, LLC IS NOT RESPONSIBLE FOR THE REPAIR OR REPLACEMENT OF FAILED OR DAMAGED
COMPONENTS RESULTING FROM ELECTRICAL POWER FAILURE, THE USE OF EXTENSION CORDS, LOW VOLTAGE, OR VOLTAGE DROPS TO THE UNIT. NO
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE; THERE ARE NO OTHER WARRANTIES, EXPRESSED, IMPLIED OR
STATUTORY, EXCEPT THE ONE (1) YEAR PARTS & LABOR WARRANTY AS DESCRIBED ABOVE. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES, INCLUDING IMPLIED WARRANTY AND MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. THERE ARE NO WARRANTIES, WHICH
EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. Outside U.S. and Canada; this warranty does not apply, and SUPERA, LLC is not responsible for, any
warranty claims made on products sold or used outside the continent of the United States and Canada. Installation in a residential application will void all warranties.

Supera Customer Care Toll-Free Service Line:
1-866-953-3288
For additional product and warranty information,
please visit our website at:
www.SuperaCo.com
