Superior 10002124 User manual

Microwave
Oven with Grill
INSTRUCTIONS FOR USE
ENGLISH
Article Number 10002124
Power supply 220-240V ~ 50 Hz
Nominal consumption microwave oven 1200 Watt
Nominal consumption grill 1000 Watt
Power output 800 Watt
Electrical protection class I
Capacity 20 Liter
Net weight 11.5 kg
6 Microwave settings
2 Combination settings (grill + microwave)
Grill function
8 Automatic programs & 1 defrost program (with weight indicator)
Digital display
60 Minute timer with end signal
V02a
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 1
10/12/2012 3:06 PM

2
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 03
SAFETY PRECAUTIONS TO PREVENT EXCESSIVE
MICROWAVE RADIATION 06
OVERVIEW OF DEVICE 07
SETTING UP THE DEVICE 08
RADIO INTERFERENCE 08
INFORMATION ON GROUNDING 08
CLEANING BEFORE FIRST USE 09
NOTES ON DISHES 09
COOKING AND GRILLING BASICS 10
CONNECTING DEVICE TO THE MAINS 11
SETTING THE CLOCK 11
MICROWAVE FUNCTION 12
• POWER FUNCTION BUTTON 12
• SETTING THE TIME 12
• ENDING THE MICROWAVE FUNCTION 13
GRILL FUNCTION 13
• GRILL FUNCTION BUTTON 13
• SETTING THE TIME 13
• ENDING THE GRILL FUNCTION 13
COMBINATION MICROWAVE OVEN AND GRILL 13
AUTOMATIC PROGRAMMES 14
CHILD LOCK 16
QUICK COOKING FUNCTION 16
CLEANING AND CARE 16
DISPOSAL 18
SERVICE / WARRANTY 18
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 2
10/12/2012 3:06 PM

3
IMPORTANT SAFETY INSTRUCTIONS
When using electric devices, basic safety precautions must be
observed. To avoid the risk of burns, electric shocks, fire, and/or
personal injury, please read the instruction manual carefully before
using the device, and observe all of the instructions during the
operation of the device.
Store this manual carefully for further use.
Please include this manual when transferring the device to a third
party.
GENERAL INFORMATION
• Electric devices are not toys! Keep children away from this device!
• Use this device for its intended purpose only.
• This device is suitable for use in private households and not for
commercial use.
• Do not leave this device unattended during use or while it is plugged
in.
• Switch the device off and pull the power plug when not in use, in case
of malfunction or when cleaning.
• Do not carry this device by its power cord.
• Keep this device clean and dust-free.
• Do not operate this device outdoors.
• Check the device regularly for visible damages. Do not use the device
under any circumstances if you discover damages, if it has fallen or if it
does not function properly. Do not try to repair the device yourself.
• Repairs may only be done by qualified professionals.
• The power outlet must be located near the device so that it can be
pulled out effortlessly in case of emergency.
RISKS FROM ELECTRICITY:
• The voltage of the device specified on the rating plate must match the
voltage of your electricity network.
• Connect the device to an approved installed outlet. Do not use table
power bars or extension cords.
• Do not operate this device with a timer or remote control.
• Never touch this device, the power cord or the power plug if your
hands are damp or wet or if you are standing on a wet floor.
• Do not pull the power cord over or through a sink.
• Do not immerse in water.
• There is a danger of electric shock from immersion in water or other
fluids!
• Keep the device, power cord and power plug away from hot surfaces,
open flame, direct sunlight and sharp edges. Make sure that the cord
is not clamped during use (e.g. in doors).
• When you pull the plug, always pull by the plug and never the cord.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 3
10/12/2012 3:06 PM

4
• If the power cord becomes damaged, it must be replaced by a
qualified professional in order to avoid hazards. The same applies for
the power plug.
HAZARDS TO PERSONS:
• This device is not meant for persons (including children) with reduced
physical, sensory or mental abilities or lack of experience and / or lack
of knowledge to be used, unless they are supervised by a person who
is responsible for their safety or have received instructions on how to
use this device.
• Children must be supervised in order to ensure that they do not play
with this device.
• Children do not recognise the dangers which could occur in dealing
with electric devices. Keep children away from this device. Be especially
careful when using this device if children are in your midst!
• Keep packaging materials such as plastic bags and polystyrene parts
out of reach of children. Danger of suffocation!
• Make sure when laying the power cord that it cannot be tripped over.
• Make sure that the device itself does not become a tripping hazard.
HAZARDS RELATED TO THIS SPECIFIC PRODUCT:
• Use this device only with the accessories included.
• Only this device and its accessory parts can be used together. Do
not use the accessory parts in the oven or in combination with other
devices.
• Always use this device on an even, anti-slip and heat-resistant surface!
• Do not place this device on cooktops!
• The microwave is not suitable for installation into a cupboard or rack.
• In order to ensure sufficient air circulation, there must be a distance
between the device and the physical boundaries (walls, cupboards,
racks, etc.)! Above the microwave, there should be a distance of at
least 20 cm, at least 10 cm at the back and at least 5 cm on the sides.
• The microwave must not be used in damp rooms!
• The microwave must not be used for storage purposes or the like. Do
not store any objects such as paper, cookware or the like in the oven.
• If you should discover smoke while using the microwave, turn the
device off and pull the power plug. Keep the door closed to suffocate
potential flames.
• Please note that the heating element (grill) can become very hot!
Always be careful when removing food and use oven mitts!
• Caution! Hot surfaces.
• The temperature of the surfaces which can be touched can be very
high during operation.
• This device must not be operated without contents.
• Do not cover the device while in use!
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 4
10/12/2012 3:06 PM

5
• All repair or maintenance work which requires opening up the
microwave, removing the cover or replacing parts may only be
carried out by suitably authorized personnel. Danger due to escaping
microwave radiation!
• If the door or door seal is damaged, the cooking device must not be
operated before being repaired by a person who is suitably trained for
such repairs.
• Attention!
Children shall only be allowed to use this device without supervision
once they have received sufficient instruction, are able to use this
device safely and understand the dangers of improper use.
• Warning: If this device is used in combination operating mode,
children may only use this device under adult supervision due to the
temperatures which occur.
• Persons with heart pacemakers should ask their physician or the
manufacturer regarding any safety precautions related to using
microwave ovens.
• This product is an ISM device of Group 2 Class B. Group two includes
all ISM devices (industrial, scientific, medical) in which radio frequency
energy is generated and/or is used in the form electromagnetic
radiation to process materials as well as for electrical discharge
machining equipment. Class B covers devices for household use or
power supply networks which feed residential buildings.
• Do not use this device as a surface for decorative items such as vases
and the like which can be placed on the device.
• When warming or cooking foods which are in flammable materials
such as plastic or paper containers, the microwave oven must be
monitored due to the possibility of ignition.
• Use only microwaveable dishes and food containers.
• Do not use any heat-retaining packaging which could contain
aluminium foil. If you heat foods in plastic or paper containers, first
remove all previously existing seals, tie wires and the like. Make sure
that these containers do not ignite during heating.
• Any meal or food package lids or foils which are suitable for heating
in the oven must be pierced several times so that the steam can escape
and the package will not burst.
• Be aware that the warming or cooking time in the microwave oven is
often much shorter than on the cooktop or in the oven. Cooking times
which are too long could lead to drying out or ignition of the food.
• Liquids and foods must not be heated in sealed containers or glasses
because they could explode.
• Delayed overcooking could occur when heating liquids in the
microwave oven. Handle the containers with the required caution.
• The microwave oven is not suitable for roasting foods. Hot oil can
damage parts of the device and cookware as well as perhaps cause
skin burns.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 5
10/12/2012 3:06 PM

6
• Eggs with shells or hard-cooked eggs must not be heated or cooked in
the microwave oven because they could explode or the egg yolk could
spray out once the microwave heating is complete.
• Foods with a firm skin or shell such as tomatoes, sausages, potatoes
with skins, whole pumpkins or apples must be pierced several times or
nicked before cooking so that the steam build-up can escape and the
food will not explode.
• In order to prevent scalding, the contents of feeding bottles and jars
with baby food must be stirred or shaken before feeding and the
temperature must be checked in all cases.
• The food containers can become very hot due to the heat from the
heated foods. Dish towels or oven mitts should be used to remove
food containers from the oven area. Always open the door and
container in a direction away from the face and body. Danger of burns
from steam and scalding!
• Please clean the door seal, cooking area and their surrounding areas
carefully and regularly.
• Do not wash the device and accessories in the dishwasher.
• Dirt can damage the surfaces and reduce the lifetime of the device or
cause dangerous interference.
• Use this device only for the purposes described in these instructions.
Do not use any harsh chemicals or vapours in this device. This device
is only suitable for heating, boiling and cooking foods in private
households and not for use in laboratories.
SAFETY PRECAUTIONS TO PREVENT EXCESSIVE
MICROWAVE RADIATION
ATTENTION!
• The safety lock of the door must not be dismounted or modified.
• Never use this device if the door is open. Harmful microwaves can escape this
way.
• Do not place any objects between the front side of the device and the door.
Make sure that no dirt or residues from cleaning agents accumulate on the
seals.
• Do not use this device if it is damaged.
• The door of the device must close properly and must not show signs of any
damages or malformations. Make sure that the locking mechanism is in perfect
condition and that the door seals and seal surfaces do not show signs of any
damages or soiling.
• Damages or repairs to this device must be carried out by suitably qualified
professionals.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 6
10/12/2012 3:06 PM

7
OVERVIEW OF DEVICE
1. Door safety lock
2. Door with viewing window
3. Rotating device / rolling ring
4. Door opener
5. Operating element
5a) Display
5b) Power
5c) Time
5d) Combi 2
5e) Combi 1
5f) Start / Quick Start
5g) Stop / Cancel
5h) Time/ Menu
5i) Grill
5j) Weight
6. Outlet opening of the microwave oven with cover
7. Glass plate
8. Heating element
9. Grill rack
NOT SHOWN: Power cord and power plug
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 7
10/12/2012 3:06 PM

8
SETTING UP THE DEVICE
• Remove all stains and packing materials as well as all liners from the device.
• ATTENTION! Check the device for any possible damages such as a poorly-
mounted or crooked door, damaged door seals and sealing surfaces, defects or
loose hinges and latches, dents on the inside or on the door. Also check for any
damages to the power cord / power plug. Do not use this device if damages are
present.
• The microwave may only be placed on an even, stable and heat-resistant
surface which is suitable for bearing the weight of the device.
• Do not place this device near sources of heat, near flammable or combustible
materials or in places where wetness or high humidity occurs.
• The device must be adequately ventilated for proper operation. Make sure that
there is a distance of 20 cm from above, 10 cm from the back and 5 cm on each
of both sides. The openings of the device must not be covered or obstructed.
The legs of the device must not be removed.
• Make sure that the power cord is undamaged and does not run under the
device or over hot or sharp-edged surfaces.
• The power outlet must be easily accessible so that the power plug can be pulled
out without effort in case of emergency.
• Do not use this device outdoors.
• Do not use this device without its approved, properly inserted
glass plate (7)
and
rolling ring (3) .
RADIO INTERFERENCE
Operating this microwave device can lead to interference to your radio, television
or similar devices. These disturbances can be minimised or eliminated using the
following measures:
• Clean the door and sealing surfaces of the microwave device.
• Reorient the reception antenna of the device which has been disturbed by the
microwave.
• Change the location of the microwave device or the device which is being
disturbed by the microwave.
• Connect the microwave device to another power outlet so that the microwave
device and the device being disturbed by the microwave are connected to
different power circuits.
INFORMATION ON GROUNDING
• This device must be grounded.
• This device must be connected only to an approved, properly installed,
grounded isolated receptacle power outlet. The power supply voltage must
correspond to the voltage specified on the name plate.
• Setting up a separate power circuit only for this device is recommended.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 8
10/12/2012 3:06 PM

9
• Using high voltage is dangerous and can lead to fires, accidents resulting in
injuries or damage.
• Improper use can cause electric shock or fire.
Notes:
If you have any questions regarding the grounding instructions or electricity, please
contact and electrician.
Liability for damages caused by failure to comply with this information is excluded.
CLEANING BEFORE FIRST USE
In order to remove any potential residues from manufacturing, you should clean the
device before using it for the first time.
• Wipe the interior of the device carefully with a damp cloth.
• The
glass plate (7) the rolling ring (3) and the grill rack (9) can be washed.
• Then dry off all of the parts thoroughly.
• Insert the
rolling ring (3) back into the depression in the oven floor.
• Place the
glass plate (7) with the grooved side down on the rotating device /
rolling ring (3)
.
• Position the
glass plate (7) so that the lower centre of the plate fits perfectly on
the actuator.
• The
heating element (8) must not be rinsed off. When using the grill for the first
time, a slight smoke development or odour development could occur which
would be caused by burning of production residues on the heating element.
These are normal processes and not defects.
NOTES ON DISHES
• Microwave dishes are microwave permeable and enable the energy of the
microwaves to penetrate through the container and heat the food.
• ATTENTION! Microwaves cannot penetrate metal. Therefore, no dishes with
metal or gold edges can be used when operating a microwave. Sparks or fire
can occur.
• When boiling or cooking in the microwave oven, do not use any products
from recycled paper because they could contain small metal pieces
which could spark or start a fire.
• You should use round or oval cookware instead of square or long cookware
which overcooks food in the corners.
• In addition to its microwave function, this device also has a grill function and a
combination grill and microwave function.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 9
10/12/2012 3:06 PM

10
Please use the below table as a guide to help you select suitable cookware.
ATTENTION! Please note that certain cookware materials must not be used
in the preparation of foods in the microwave oven!
COOKWARE
MICROWAVE
OVEN
GRILL COMBINATION
MICROVEN + GRILL
Heat-resistant glass
Yes Yes Yes
Non-heat-resistant glass No No No
Microwaveable ceramic
Yes Yes Yes
Microwaveable plastic cookware
Yes No No
Paper towels Yes No No
Metal insert No Yes No
Metal grill No Yes No
Aluminium foil & foil containers No Yes No
Grill rack No Yes No
COOKING AND GRILLING BASICS
• ATTENTION! Never operate this device when it is empty or without the glass
plate (7)
on the rolling ring (3) .
• The oven area must be clean when being used for the first time. The
glass plate
(7)
and the rotating device / rolling ring (3) must be able to turn freely during
operation.
• Make sure that no food or vessels project out over the edge of the
glass plate
(7)
.
• Distribute the food evenly. Lay the thickest pieces on the outer edge of the
plate.
• Pay attention to boiling and cooking time. Choose the shortest boiling or
cooking time specified and then increase it as required. Foods which are heavily
overcooked can cause smoke or catch fire.
• Cover the food while it is cooking or boiling.
A microwaveable cover prevents spills, and avoids potential messes or damages
to the device. It also allows more even cooking. Furthermore, the moisture
remains in the foods which are being cooked.
• The microwaves do not heat the food evenly. Therefore, turn foods such as
meat pieces over once to speed up cooking. Larger pieces of meat such as
roasts should be turned over several times.
• Once half of the cooking time is over, re-distribute any foods which are placed
on top of one another, e.g. meatballs. Do this by moving the foods on the top
to the bottom and the foods on the bottom to the top.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 10
10/12/2012 3:06 PM

11
• Do not leave the device unattended during operation.
If you notice an unusual noise, overcooking of the food or smoke, stop the
cooking cycle immediately.
• Let the food stay in the oven area at the end of the cooking time. This way, the
heat distributes better into the food.
• NOTE: When removing cooked foods, you should wear oven mitts in order to
prevent burns.
• Make sure not to come into contact with the
heating element (8) in the upper
oven chamber after using the grill!
• WARNING: When using the grill function and the combination of grill/
microwave, all parts of the device including the
door (2) and the top become
very hot. Therefore, you should not touch the device housing and use only the
handles and buttons.
• Microwave function: Put the food on the glass plate (7) and close the door (2) .
Grill: Put the food on the grill rack (9) , and then put it on the glass plate (7) and
shut the
door (2) .
Combi functions: Put the food on the
glass plate (7) and close the door (2) .
ATTENTION:
1) The
grill rack (9) must be removed when using the microwave function
(also in combination mode)!
2) Make sure when grilling that the food does not come into contact with
the upper mounted
heating element (8).
CONNECTING DEVICE TO THE MAINS
As soon as the device is connected to the mains, a signal tone sounds and the
display 1:01 with a clock symbol occurs in the
display (5a) .
SETTING THE CLOCK MODE
You can set the time in the 24 or 12-hour mode.
• Press the time (5c) button. A signal tone sounds and the display for the 24-
hour mode (24h) appears with a blinking clock symbol in the
display (5a) .
• Press the
time (5c) button again briefly in order to access the 12-hour mode. A
signal tone sounds and the display for the 12-hour mode (12h) appears with a
blinking clock symbol in the
display (5a) .
SETTING THE CLOCK
Once you have selected the clock mode, you can set the clock.
ATTENTION: The clock can be set as long as the clock symbol is blinking in the
display (5a).
• Turn the Time/Menu control (5h) in order to set the hour. The hour display
blinks. Once the current hour has been set, press the
time button (5c) to
confirm the setting and to be able to set the minutes.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 11
10/12/2012 3:06 PM

12
• The minute display blinks. Turn the Time/Menu (5h) to set the minutes. Once
the current minutes have been set, press the
time button (5c) to confirm.
• The time is now shown in the
display (5a) with a blinking colon.
MICROWAVE FUNCTION
POWER FUNCTION BUTTON
At first choose the desired power level.
The microwave oven has 6 power levels which heat foods at varying speeds and to
various degrees of heating.
• These levels are set by pressing the power button (5b) and shown in the display (5a) :
Press Power / On Display Description Symbol
1 x 100%(P-HI)
Full power for heating very
quickly
2 x 80%(P-80) High power for heating quickly
3 x 60%(P-60) Medium power for heating
4 x 40%(P-40) Low power for slow heating
5 x 20%(P-20) Defrost
6 x 00%(P-00) Can be used to cool off the
microwave oven
SETTING THE TIME
After selecting the power level, set the preparation time. Set the cooking time using
the time setting. Press the
Time/Menu (5h) control. The set minutes are shown in the
display (5a) .
• The shortest time setting: 10 seconds.
• The longest time setting: 60 minutes.
• The time setting from 10 seconds to 5 minutes in divided into 10-second
increments.
• For time settings from 5 minutes to 10 minutes, 30-second increments can be
set.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 12
10/12/2012 3:06 PM

13
• For 10 minutes to 30 minutes, one-minute increments can be set.
• From 30 minutes, 5-minute increments up to a maximum time of 60
minutes can be set.
• To start, press the button
Start/Quick Start (5f).
• The device starts and the set time counts down.
ENDING THE MICROWAVE FUNCTION
• When the set preparation time expires, the device shuts off. END appears
in the
display (5a) and a signal tone sounds. Press the Stop/Cancel (5g)
button in the
display (5a) and the time is shown.
• To interrupt preparation of foods in the microwave, press the
Stop/Cancel
(5g)
button once. The device shuts off temporarily. The time at which the
programme was interrupted blinks in the display.
• To stop preparation before the time has expired and to cancel the
programme, press the
Stop /Cancel (5g) button twice. The hour will then
be shown in the
display (5a) .
GRILL FUNCTION
GRILL FUNCTION BUTTON
Only the
heating element (8) in the upper cooking chamber is supplied with
power. This provides a golden brown crust but it is possible in cases of thicker
cooked foods for the surface to be burnt and to have a completely uncooked
centre. This setting is ideal for cooking sausage, chicken legs, pork chops, meat
pieces, sandwiches, and much more.
• Press the
Grill (5i) button. In the display (5a) the number 10 and the grill
symbol appear.
SETTING THE TIME
• Set the time.
• Set the preparation time in grill mode as described under “SETTING THE
TIME” in the “MICROWAVE FUNCTION” section.
• Press the
Start/Quick Start (5f) button to start.
ENDING THE GRILL FUNCTION
• End the grill mode as described in “ENDING THE MICROWAVE FUNCTION”
in the “MICROWAVE FUNCTION” section.
COMBINATION MICROWAVE OVEN AND GRILL
In this case, the magnetron (microwave) and the heating element (8) are
supplied alternately with power. Depending on the characteristic of the food,
this combination of grill and microwave can achieve excellent cooking results.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 13
10/12/2012 3:06 PM

14
1. COMBI 1:
30% of the operating time is microwave and 70% is grill. This is suitable for the
preparation of fish, sandwiches, and gratins.
• Press the
Combi 1 (5e) button once. In the display (5a) the number 10 and the
Combi 1 symbol appear.
• Choose the desired preparation time using the
Time/Menu (5h) control in
accordance with the time setting of the functions described above.
• Once you enter the desired time, press the
Start/Quick Start (5f) button.
• The time specified counts down.
• Once the time has expired, a signal tone sounds and END appears in the
display (5a) . The device then shuts off.
• Press the
Stop /Cancel (5g) button.
2. COMBI 2:
55% of the operating time is microwave and 45% is grill. This is suitable for
cooking chicken and fish, for example.
• Proceed as described in COMBI 1 but be sure to press the
Combi 2 (5d) symbol.
• On the
display (5a) the Combi 2 symbol appears.
AUTOMATIC PROGRAMMES
Select the appropriate automatic programme for your food. The device
automatically controls the functions and the power levels as well as the duration of
cooking. In this case, you do not need to set any power levels or preparation times.
Select the automatic programme as described here and press the
Start/Quick Start
(5f)
button to start the programme.
Note:
The foods should be checked once half of the preparation time has been reached
because the automatic programmes are based on average preparation times only
(duration and power levels).
Interrupt the preparation by pressing the Stop/Cancel (5g) button and re-align
the foods (from inside to out and from above to below. See: “COOKING AND
GRILLING BASICS”)
Note:
The setting A-09 stands for the defrost programme!
1. Press the
Time/Menu (5h) control counterclockwise.
2. In the
display (5a) the automatic programme with the abbreviation A-01 –
A-09 appears.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 14
10/12/2012 3:06 PM

15
PROGRAMME FOOD BUTTON WEIGHT COMMENTS
A-01 Liquids (e.g.
soup, coffee)
1x = 1min 30sec
2x = 2min 40sec
3x = 3min 50sec
For a maximum of 200ml
of liquid
A-02 e.g. rice 1x = 150g
2x = 300g
3x = 450g
4x = 600g
150g = 21min
300g = 24min
450g = 27min
600g = 30min
A-03 e.g. noodles 1x = 100g
2x = 200g
3x = 300g
100g = 25min
200g = 30min
300g = 35min
A-04 e.g. potatoes
(sliced)
1x = 4min
2x = 8min
3x = 12min
For a maximum of 230g
of potatoes
A-05 Warming 1x = 200g
2x = 300g
3x = 400g
4x = 500g
5x = 600g
6x = 700g
7x = 800g
200g = 1min 40sec
300g = 2min 20sec
400g = 3min 00sec
500g = 3min 40sec
600g = 4min 20sec
700g = 5min 00sec
800g = 5min 40sec
A-06 e.g. fish 1x = 200g
2x = 300g
3x = 400g
4x = 500g
5x = 600g
200g = 4min 30sec
300g = 5min 30sec
400g = 6min 30sec
500g = 7min 30sec
600g = 8min 30sec
A-07 e.g. poultry 1x = 800g
2x = 1000g
3x = 1200g
4x = 1400g
800g = 33min 00sec
1000g = 36min 00sec
1200g = 39min 00sec
1400g = 42min 00sec
A-08 e.g. meat 1x = 200g
2x = 300g
3x = 400g
4x = 500g
5x = 600g
200g = 12min 00sec
300g = 15min 00sec
400g = 18min 00sec
500g = 21min 00sec
600g = 24min 00sec
A-09 Defrost
function
With the defrost function, you have the
option of setting in 100-g increments the
weight of the food to be defrosted using
the
weight (5j) button. The minimum weight
is 100g and the maximum weight is 1800g.
The time which results from this is between
5 and 39 minutes, depending on the weight
selected. Furthermore, in the
display (5a ), the
defrost symbol appears.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 15
10/12/2012 3:06 PM

16
3. The automatic programme selected is shown by turning the control.
4. Press the
weight button (5j) to enter the weight of the food. The weight
increases every time the button is pressed. For programmes A-01 and
A-04 the numbers 1, 2 or 3 will be displayed instead of the weight. These
numbers stand for the preset times (see chart above).
5. Press the
Start/Quick Start (5f) button to start the selected automatic
programme.
6. The time counts down. For the automatic programmes A-07 and A-08 a
signal tone sounds after half of the preparation time as a reminder to turn
re-align the foods as necessary.
7. Once the time has expired, a signal tone sounds and END appears in the
Display (5a) .
8. Press the
Stop/Cancel (5g) button.
CHILD LOCK
• To activate the child lock, press the Stop/Cancel (5g) button for 3 seconds. A
signal sounds and a padlock symbol appears in the
display (5a) .
• The control buttons are locked and only the
door (2) can be opened.
• To deactivate the child lock, press the
Stop/Cancel (5g) button again for 3
seconds. Another signal sounds, the symbol is cancelled and the control
buttons can be used again.
QUICK COOKING FUNCTION
The microwave power is always at 100% when this function is used. In quick
cooking function, the times are preset and are called up and displayed
by pressing the
Start/Quick Start (5f) button. The selected setting starts
automatically after the last rapid pressing of the Start/Quick Start (5f) key.The
times increase in 30-second increments beginning at 30 seconds to a maximum
of 12 minutes.
Example:
You want to cook for 2 minutes using 100% microwave power.
• Press the
Start/Quick Start (5f) button quickly 4 times in a row.
• The cooking cycle will begin.
CLEANING AND CARE
ATTENTION! Before beginning cleaning, switch the device off and pull the power
plug from the wall socket.
• Keep the device clean. If sprinkles from food or shaken liquids stick to the
walls of the device, wipe them with a damp cloth. If the device is very dirty, a
mild detergent can be used. Avoid the use of spray or other harsh detergents
which could corrode, scratch or dull the surface of the
door (2) .
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 16
10/12/2012 3:06 PM

17
• The outer surfaces should be cleaned with a damp cloth. In order to avoid
damages to the operating parts in the interior of the device, water must not
reach the ventilation openings.
• Wipe the door with the
viewing window (2) from both sides. Clean the door
(2)
and the adjacent parts regularly with a damp cloth in order to remove any
residues or splashes. Do not use any abrasives.
• Make sure that no moisture reaches the interior of the device when cleaning
the
operating element (5) . Clean it with a soft, damp cloth.
• Clean the
glass plate (7) regularly with warm water and a commercial
detergent.
• The
rotating device (3) and the inner floor of the device should be cleaned
regularly in order to avoid function problems and excessive noise. Rinse off the
floor of the device with a mild detergent. The
rolling ring (3) can be washed
with a mild detergent and warm water. Be sure to install the
rolling ring (3)
properly after cleaning.
• To remove odours from your device, put a cup of water with the juice and
grated skin of a lemon in a deep, microwaveable container and heat it for 5
minutes in the microwave oven. Then wipe out the device thoroughly with a
damp cloth and dry with a soft cloth.
• If the device’s lamp needs to be replaced, please refer to a retailer for the
proper lamp.
• Clean this device regularly and thoroughly remove all food residues. Stains like
burned-on fat can corrode the surfaces, impact the functions, have a negative
effect of the lifetime of the device and cause potential risks.
DISPOSAL
USED ELECTRIC HOUSEHOLD DEVICES
• If you do not want to use your electrical appliance any longer,
return it free of charge to a recycling depot for used electric
appliances.
• Used electric devices do not belong in the household garbage (see
symbol)
FURTHER DISPOSAL INSTRUCTIONS
• Return the electrical appliance in such a condition that its later
re-use or recycling is not adversely affected. Batteries must be
removed in advance and the destruction of parts which contain
fluids must be avoided.
• Electrical appliances can contain harmful substances. Improper
handling or damage to the appliance can lead to health problems
or water or ground contamination, when the appliance is recycled
later.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 17
10/12/2012 3:06 PM

18
SERVICE / WARRANTY
The warranty period covers 3 years and begins with the purchase date. For proof of
the purchase date please retain the receipt.
The warranty covers defects and malfunctions occurring with normal use during the
warranty period.
Warranty repairs are carried out free of charge.
The warranty is void in case of damages, alterations or improper use of the device,
where these are not the responsibility of the warranty provider. This applies
especially to the following cases:
• Interference with the device by unauthorized persons.
• Alterations on or in the device, removing or effacing the serial number, removal
or alteration of the device seal.
• Damages due to impact, dropping or external influence.
• Damages due to incorrect handling or improper use.
• Damages due to external causes, e.g. voltage overload, lightning strike.
• Commercial utilization of the device.
Your legal rights in the case of a defective device (replacement, return, reduction,
compensation) are not restricted by this warranty.
Please keep the original packaging in case of a return for repair.
Repaired or exchanged components are generally covered for the remaining
warranty period of the device.
Should you have any questions relating to this product or to the manual or in case
you should find any deficiencies with this product, please contact our service hotline
directly to discuss further steps.
IMPORTANT NOTE:
Please do not send your device to our address without having been requested to.
Always contact our service hotline first.
SERVICE HOTLINE: Phone: [phone]
E-Mail: [email protected]
ARTICLE NO.: 10002124
PRODUCED FOR:
ZENTRALE HANDELSGESELLSCHAFT - ZHG - MBH,
HANNS-MARTIN-SCHLEYER STRASSE 2,
D-77656 OFFENBURG,
www.zhg-online.com
MADE IN CHINA
All images serve as illustrations only and do not always show exact representations
of the device.
All rights reserved.
10002124_D80D20EP_IM_V02_A120625_ktk_10-12-2012_GB.indd 18
10/12/2012 3:06 PM
