SuperMax SMW 3200 GR User manual

MODEL: SMW 3200 GR
Microwave Oven Owner's Manual
Please read these instructions carefully before installing and operating the oven.
Record in the space below the SERIAL NO. found on the nameplate on your oven and
retain this information for future reference.
SERIAL NO.


1. Do not attempt to operate this oven with the door open since open door operation
can result in harmful exposure to microwave energy. It is important not to defeat or
tamper with the safety interlocks.
2. Do not place any object between the oven front face and the door or allow soil or
cleaner residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is particularly important that the oven
door close properly and that there is no damage to the
a. Door (bent),
b. Hinges and latches (broken or loosened),
c. Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except properly qualified
service personnel.
CONTENTS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY ------------------------------------------------------------------------------------------- 1
IMPORTANT SAFETY INSTRUCTIONS -------------------------------------------------------- 2
SPECIFICATIONS* ------------------------------------------------------------------------------ 3
BEFORE YOU CALL FOR SERVICE ----------------------------------------------------------- 3
INSTALLATION------------------------------------------------------------------------------------ 3
GROUNDING INSTRUCTIONS ---------------------------------------------------------------- 4
RADIO INTERFERENCE------------------------------------------------------------------------- 4
MICROWAVE COOKING PRINCIPLES ------------------------------------------------------ 4
UTENSILS GUIDE--------------------------------------------------------------------------------- 5
PART NAMES------------------------------------------------------------------------------------- 5
CONTROL PANEL ------------------------------------------------------------------------------- 6
HOW TO SET THE OVEN CONTROLS ------------------------------------------------------- 7
Setting the clock --------------------------------------------------------------------------------------- 7
Microwave cooking ------------------------------------------------------------------------------------ 7
Grill cooking --------------------------------------------------------------------------------------------- 7
Combination cooking --------------------------------------------------------------------------------- 7
Auto Cook ----------------------------------------------------------------------------------------------- 8
Defrost by weight -------------------------------------------------------------------------------------- 8
Jet Defrost ----------------------------------------------------------------------------------------------- 8
Multi-stage Cooking ----------------------------------------------------------------------------------- 9
Delay start ----------------------------------------------------------------------------------------------- 9
Quick start ----------------------------------------------------------------------------------------------- 9
Child Lock ----------------------------------------------------------------------------------------------- 9
CLEANING AND CARE------------------------------------------------------------------------10
P
PR RE EC CA AU UT TI IO ON NS ST TO OA AV VO OI ID DP PO OS SS SI IB BL LE EE EX XP PO OS SU UR RE E
T
TO OE EX XC CE ES SS SI IV VE EM MI IC CR RO OW WA AV VE EE EN NE ER RG GY Y

When using electrical appliance basic safety
precautions should be followed, including the
following:
WARNING: To reduce the risk of burns,
electric shock, fire, injury to persons or
exposure to excessive microwave energy:
1. Read all instructions before using the
appliance.
2. Use this appliance only for its intended
use as described in this manual. Do not
use corrosive chemicals or vapors in this
appliance. This type of oven is specifically
designed to heat, cook or dry food. It is not
designed for industrial or laboratory use.
3. Do not operate the oven when empty.
4. Do not operate this appliance if it has a
damaged cord or plug, if it is not working
properly or if it has been damaged or
dropped. If the supply cord is damaged, it
must be replaced by the manufacturer or
its service agent or a similarly qualified
person in order to avoid a hazard.
5. Warning: When the appliance is operated
in the combination mode, children should
only use the oven under adult supervision
due to the temperatures generated.
6. WARNING: Only allow children to use the
oven without supervision when adequate
instructions have been given so that the
child is able to use the oven in a safe way
and understands the hazards of improper
use.
7. To reduce the risk of fire in the oven cavity:
a. When heating food in plastic or paper
container, keep an eye on the oven due to
the possibility of ignition.
b. Remove wire twist-ties from paper or
plastic bags before placing bag in oven.
c. If smoke is observed, switch off or
unplug the appliance and keep the door
closed in order to stifle any flames.
d. Do not use the cavity for storage
purposes. Do not leave paper products,
cooking utensils or food in the cavity when
not in use.
8. WARNING: Liquid or other food must not
be heated in sealed containers since they
are liable to explode.
9. Microwave heating of beverage can result
in delayed eruptive boiling, therefore care
has to be taken when handling the
container.
10. Do not fry food in the oven. Hot oil can
damage oven parts and utensils and even
result in skin burns.
11. Eggs in their shell and whole hard-boiled
eggs should not be heated in microwave
ovens since they may explode even after
microwave heating has ended.
12. Pierce foods with heavy skins such as
potatoes, whole squashes, apples and
chestnuts before cooking.
13. The contents of feeding bottles and baby
jars should be stirred or shaken and the
temperature should be checked before
serving in order to avoid burns.
14. Cooking utensils may become hot
because of heat transferred from the
heated food. Potholders may be needed to
handle the utensil.
15. Utensils should be checked to ensure that
they are suitable for use in microwave
oven.
16. WARNING: It is hazardous for anyone
other than a trained person to carry out
any service or repair operation which
involves the removal of any cover which
gives protection against exposure to
microwave energy.
17. This product is a Group 2 Class B ISM
equipment. The definition of Group 2
which contains all ISM (Industrial,
Scientific and Medical) equipment in which
radio-frequency energy is intentionally
generated and/or used in the form of
electromagnetic radiation for the treatment
of material, and spark erosion equipment.
For Class B equipment is equipment
suitable for use in domestic
establishments and in establishments
directly connected to a low voltage power
supply network which supplies buildings
used for domestic purpose.
18. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
I
IM MP PO OR RT TA AN NT TS SA AF FE ET TY YI IN NS ST TR RU UC CT TI IO ON NS S


instruction concerning use of the appliance
by a person responsible for their safety.
19. Children should be supervised to ensure
that they do not play with the appliance.
Power Consumption 230V~50Hz, 1400W(Microwave)
1100W(Grill)
Rated Microwave Power Output 900W
Operation Frequency 2450MHz
Outside Dimensions 300mm(H)×539mm(W)×446mm(D)
Oven Cavity Dimensions 240mm(H)×354mm(W)×358mm(D)
Oven Capacity 30Litres
Cooking Uniformity Turntable System
Net Weight Approx.16.4kg
If the oven fails to operate:
1. Check to ensure that the oven is plugged
in securely. If it is not, remove the plug
from the outlet, wait 10 seconds, and plug
it in again securely.
2. Check for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be
operating properly, test the outlet with
another appliance.
3. Check to ensure that the control panel is
programmed correctly and the timer is set.
4. Check to ensure that the door is securely
closed engaging the door safety lock
system. Otherwise, the microwave energy
will not flow into the oven.
IF NONE OF THE ABOVE RECTIFY THE
SITUATION, THEN CONTACT A QUALIFIED
TECHNICIAN. DO NOT TRY TO ADJUST
OR REPAIR THE OVEN YOURSELF.
1. Make sure that all the packing materials
are removed from the inside of the door.
2. WARNING: Check the oven for any
damage, such as misaligned or bent door,
damaged door seals and sealing surface,
broken or loose door hinges and latches
and dents inside the cavity or on the door.
If there is any damage, do not operate the
oven and contact qualified service
personnel.
3. This microwave oven must be placed on a
flat, stable surface to hold its weight and
the heaviest food likely to be cooked in the
oven.
4. Do not place the oven where heat,
moisture, or high humidity are generated,
or near combustible materials.
5. For correct operation, the oven must have
sufficient airflow. Allow 20cm of space
above the oven, 10cm at back and 5cm at
both sides. Do not cover or block any
openings on the appliance. Do not remove
feet.
6. Do not operate the oven without glass tray,
roller support, and shaft in their proper
positions.
7. Make sure that the power supply cord is
undamaged and does not run under the
oven or over any hot or sharp surface.
8. The socket must be readily accessible so
that it can be easily unplugged in an
emergency.
9. Do not use the oven outdoors.
S
SP PE EC CI IF FI IC CA AT TI IO ON NS S* *
B
BE EF FO OR RE EY YO OU UC CA AL LL LF FO OR RS SE ER RV VI IC CE E
I
IN NS ST TA AL LL LA AT TI IO ON N


This appliance must be grounded. This oven
is equipped with a cord having a grounding
wire with a grounding plug. It must be plugged
into a wall receptacle that is properly installed
and grounded. In the event of an electrical
short circuit, grounding reduces risk of electric
shock by providing an escape wire for the
electric current. It is recommended that a
separate circuit serving only the oven be
provided. Using a high voltage is dangerous
and may result in a fire or other accident
causing oven damage.
WARNING Improper use of the grounding
plug can result in a risk of electric shock.
Note
1. If you have any questions about the
grounding or electrical instructions, consult
a qualified electrician or service person.
2. Neither the manufacturer nor the dealer
can accept any liability for damage to the
oven or personal injury resulting from
failure to observe the electrical connection
procedures.
The wires in this cable main are colored in
accordance with the following code:
Green and Yellow = EARTH
Blue = NEUTRAL
Brown = LIVE
Operation of the microwave oven can cause
interference to your radio, TV, or similar
equipment.
When there is interference, it may be
reduced or eliminated by taking the following
measures:
1. Clean door and sealing surface of the
oven.
2. Reorient the receiving antenna of radio or
television.
3. Relocate the microwave oven with respect
to the receiver.
4. Move the microwave oven away from the
receiver.
5. Plug the microwave oven into a different
outlet so that microwave oven and receiver
are on different branch circuits.
1. Arrange food carefully. Place thickest areas
towards outside of dish.
2. Watch cooking time. Cook for the shortest
amount of time indicated and add more as
needed. Food severely overcooked can
smoke or ignite.
3. Cover foods while cooking. Covers prevent
spattering and help foods to cook evenly.
4. Turn foods over once during microwaving
to speed cooking of such foods as chicken
and hamburgers. Large items like roasts
must be turned over at least once.
5. Rearrange foods such as meatballs
halfway through cooking both from top to
bottom and from the center of the dish to
the outside.
G
GR RO OU UN ND DI IN NG GI IN NS ST TR RU UC CT TI IO ON NS S
R
RA AD DI IO OI IN NT TE ER RF FE ER RE EN NC CE E
M
MI IC CR RO OW WA AV VE EC CO OO OK KI IN NG GP PR RI IN NC CI IP PL LE ES S


1. The ideal material for a microwave utensil
is transparent to microwave, it allows
energy to pass through the container and
heat the food.
2. Microwave cannot penetrate metal, so
metal utensils or dishes with metallic trim
should not be used.
3. Do not use recycled paper products when
microwave cooking, as they may contain
small metal fragments which may cause
sparks and/or fires.
4. Round /oval dishes rather than
square/oblong ones are recommend, as
food in corners tends to overcook.
5. Narrow strips of aluminum foil may be
used to prevent overcooking of exposed
areas. But be careful don’t use too much
and keep a distance of 1 inch (2.54cm)
between foil and cavity.
The list below is a general guide to help you select the correct utensils.
COOKWARE MICROWAVE GRILL COMBINATION
Heat–Resistant Glass Yes Yes Yes
Non Heat–Resistant Glass No No No
Heat–Resistant Ceramics Yes Yes Yes
Microwave–Safe Plastic Dish Yes No No
Kitchen Paper Yes No No
Metal Tray No Yes No
Metal Rack No Yes No
Aluminum Foil & Foil Containers No Yes No
1. Door Safety Lock System
2. Oven Window
3. Roller Ring
4. Shaft
5. Control Panel
6. Wave Guide
7. Glass tray
8. Grill Heater
9. Metal Rack
U
UT TE EN NS SI IL LS SG GU UI ID DE E
P
PA AR RT TN NA AM ME ES S


QMENU ACTION SCREEN
Cooking time, power, action indicators, and clock time
are displayed.
QQUICK COOK BUTTONS
Instant settings to cook popular foods.
QCLOCK
Touch to set the digital clock.
QPOWER LEVEL
Touch once or repeatedly to set microwave cooking
power.
QNUMBER PADS
10 Min. 1000g=10gh100 1 Min. 100g=1gh100
10Sec. 10g 1Sec. 1g
Touch to set clock, cooking time or enter food weight.
QGRILL/COMBI.
Press up to three times to choose a cooking mode.
QMEMORY
Used for setting a multistage cooking program.
QPRESET
Delay start control allows you to put food into the oven
and program it to start cooking at a later time.
QJET DEFROST
Quick defrost function that alternates defrost and stand
times to quickly and effectively defrost foods.
QWEIGHT DEFROST
Programmed defrosting based on the weight of the
foods to be defrosted.
QQUICK START
Touch to start the oven quickly at full microwave
power.
QSTOP/CANCEL
Touch to clear entry before setting a cooking program
Touch once to temporarily stop cooking or twice to
cancel cooking.
QSTART
Touch to start cooking.
Touch and hold to set child lock.
C
CO ON NT TR RO OL LP PA AN NE EL L



Each time a button is touched, a beep will
sound to acknowledge the touch.
SETTING THE CLOCK
To enter the digital clock time, touch the
CLOCK button once (or twice to set the clock
time in 24 hours cycle by some models) and
then press the number pads to set the time of
day.
For example: to set the time of 6: 35.
1. Touch CLOCK button, the screen shows
12 H.
2. Touch 1-MIN. button until the screen
shows 6:00
3. Touch 10-SEC button 3 times and then
touch 1-SEC button 5 times.
4. Touch CLOCK button again to confirm.
NOTE: You can check the clock time when
cooking is in progress by touching the CLOCK
button.
MICROWAVE COOKING
To cook with microwave, time and power level
should be set. The longest cooking time to be
set by touching the number pads is 99 min. 99
sec.
Suppose you want to cook for 5 minutes at
60% of microwave power.
1. Touch POWER LEVEL button to set 60%.
2. Touch 1-MIN. button to set cooking time.
3. Touch START button.
Note: during cooking, press POWER LEVEL to
show the cooking power level for 3 sec.
----------POWER LEVEL BUTTON----------
By pressing the power button a number of
times, you are selecting one of the following
microwave power levels:
Press Power Level Description
Once 100% of total High
Twice 80% M. High
Thrice 60% Medium
4 times 40% M. Low
5 times 20% Low
6 times 0% zero
GRILL COOKING
Grill cooking is particularly useful for thin slices
of meat, steaks, chops, kebabs, sausages of
piece of chicken. It is also suitable for hot
sandwiches and au gratin dishes.
Suppose you want to broil for 12 minutes.
1. Touch GRILL/COMBI. button once.
2. Touch 10-MIN. and 1-MIN.to set cooking
time.
3. Touch START button.
COMBINATION COOKING
Combination 1:
35% time for microwave cooking, 65% for grill
cooking. Recommended for fish, potatoes or au
gratin.
Combination 2:
55% time for microwave cooking, 45% for grill
cooking. Use for puddings omelets, baked
potatoes and poultry.
Suppose you want to set the oven to
COMBINATION cooking for 25 minutes.
1. Touch GRILL/COMBI. button twice or 3
times.
2. Touch 10-MIN. and 1-MIN. button to set
cooking time.
3. Touch START button.
H
HO OW WT TO OS SE ET TT TH HE EO OV VE EN NC CO ON NT TR RO OL LS S

AUTO COOK
For food or the following cooking mode, it is not necessary to program the duration and the cooking
power. It is sufficient to indicate the type of food that you wish to cook as well as the weight of this
food. In order to do this, press the individual icon pad of the food you are going to cook, the first of a
number of preset weight parameters will appear, choose the one that’s equivalent to the weight of food
you have placed into the oven. The oven begins cooking once the START button is engaged.
For example, to cook 400g of fish.
1. Press FISH button a number of times to select food weight.
2. Press START button.
Auto Cook Menu
Food Press to indicate weight of food
Beverage (250ml per cup)
Dinner entree (300~400g/amount)
Reheat (g)
Potato (g)
Pizza (g)
Fish (g)
Chicken (g)
Vegetable (g)
Beef/Mutton (g)
Sausage (g)
Weight parameters are used to determine the
time needed to do the job.
As you press the icon pads once or
repeatedly, a number of preset weight (for
beverage and dinner entree, number of
servings) parameters display, when it comes
up of the right figure which matches the weight
of the food you have placed into the oven,
push START button.
Please note:
For some food, at the middle of cooking time, you may need to open the door to check its doneness
and turn food over to obtain uniform cooking; but be careful to handle with care of very hot food in the
oven. To resume cooking, just close the door, the oven will cook for the remaining time.
DEFROST BY WEIGHT
The oven allows the defrosting of meat,
poultry, and seafood. The time and the
defrosting power are adjusted automatically
once the weight of food is programmed.
The maximum allowable weight for each
category is shown below.
FOOD
CATEGORY
MAXIMUM
WEIGHT DISPLAY
Meat 2300g d1
Poultry 3000g d2
Seafood 1000g d3
FOR EXAMPLE: Suppose you want to
defrost 600g of shrimp.
1. Place the shrimp to be defrosted into
the oven.
2. Press WEI. DEF. button 3 times.
3. Press 0.1 Kg (1g×100) button to enter
weight.
4. Press START button.
NOTE: Turn food over when oven signals.
Touch START pad to resume defrosting.
JET DEFROST
With JET DEFROST, you need to input
defrosting time,
Suppose you want to set the oven to JET
DEFROST for 5 minutes.
1. Touch JET DEFROST button.
2. Touch 1-MIN. button to set cooking
time.
3. Touch START button.

Veal (g)

MULTI-STAGE COOKING
The oven can be programmed to do several
consecutive functions.
Suppose you want to set the following
cooking program:
ķJET DEFROST;
ĸMicrowave cooking;
ĹGrill cooking.
Step:
1. If necessary, touch STOP/CANCEL pad
once to reset the oven.
2. Input jet defrost program.
3. Touch MEMORY pad.
4. Input microwave and power level
cooking program.
5. Touch MEMORY pad.
6. Input grill cooking program.
7. Touch START pad.
NOTE: JET DEFROST or WEIGHT
DEFROST should be included only when it is
set foremost in a multistage cooking
program.
The respective lights will come on to indicate
which stage the oven is operating in. After
total time has elapsed, 3 beeps sound.
DELAY START
Delay start function allows the oven to start
up in a later time. Suppose now the clock
running at 11:10 and you want the oven to
start cooking at 11:30.
Step:
1. Set a cooking program.
2. Touch PRESET pad.
3. Use the number pads to enter the time
11:30 when it should start.
4. Touch START pad.
NOTE: Make sure that the food is placed into
the oven in advance before any cooking
starts.
QUICK START
This feature allows you to start the oven
quickly.
Press the QUICK START button once or
repeatedly to set cooking time, the oven
starts work at full power level immediately.
For example, to set the oven to cook for 2
minutes using this feature:
Press QUICK START button repeatedly until
the screen shows the correct cooking times,
the oven starts working immediately at full
microwave power. You can add to cooking
time by pressing this pad while the oven is
already started.
CHILD LOCK
Use to prevent unsupervised operation of the
oven by little children. The CHILD LOCK
indicator will show up on display screen, and
the oven cannot be operated while the
CHILD LOCK is set.
To set the CHILD LOCK: Press and hold the
STOP/CANCEL button for 3 seconds, a beep
sounds and LOCK indicator lights.
To cancel the CHILD LOCK: Press and hold
the STOP/CANCEL button for 3 seconds
until lock indicator on display goes off.


1. Turn off the oven and remove the power plug from the wall socket before cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls,
wipe with a damp cloth. Mild detergent may be used if the oven gets very dirty. Avoid the use of
spray and other harsh cleaners as they may stain, streak or dull the door surface.
3. The outside surfaces should be cleaned with a damp cloth. To prevent damage to the operating
parts inside the oven, water should not be allowed to seep into the ventilation openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a
damp cloth to remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the
control panel, leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This
may occur when the microwave oven is operated under high humidity condition. And it is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy
water or in a dishwasher.
8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe
the bottom surface of the oven with mild detergent. The roller ring may be washed in mild sudsy
water or dishwasher. When removing the roller ring from cavity floor for cleaning, be sure to
replace in the proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon
in a deep microwaveable bowl, microwave for 5 minutes. Wipe thoroughly and dry with a soft
cloth.
10. When it becomes necessary to replace the oven light, please consult a dealer to have it replaced.
11. The oven should be cleaned regularly and any food deposits removed. Failure to maintain the
oven in a clean condition could lead to deterioration of the surface that could adversely affect the
life of the appliance and possibly result in a hazardous situation.
12. Please do not dispose this appliance into the domestic rubbish bin, it should be disposed to the
particular disposal center provided by the municipalities.
13. When the microwave ovens have grill function is first used, it may produce slight smoke and
smell. This is a normal phenomenon, because the oven is made of a steel plate coated with
lubricating oil, and the new oven will produce fumes and odor generated by burning the
lubricating oil. This phenomenon will disappear after a period of using.
C
CL LE EA AN NI IN NG GA AN ND DC CA AR RE E

