Supero SuperWorkstation 5035G-T User manual

®
SUPER
SUPERWORKSTATION 5035G-T
USER’S MANUAL
Revision 1.0

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of
this manual, please see our web site at www.supermicro.com.
SUPERMICRO COMPUTER reserves the right to make changes to the product described in this
manual at any time and without notice. This product, including software, if any, and documenta-
tion may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any
medium or machine without prior written consent.
IN NO EVENT WILL SUPERMICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE VENDOR SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING
OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between
manufacturer and customer shall be governed by the laws of Santa Clara County in the State of
California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the
resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price
paid for the hardware product.
Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2005 by SUPER MICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America

Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SuperWorkstation 5035G-
T. Installation and maintainance should be performed by experienced technicians
only.
The 5035G-T is a high-end, single processor mid-tower workstation based on the
SC733T-450 mid-tower workstation chassis and the Super PDSGE motherboard.
The PDSGE supports a single Intel®Pentium®D or Pentium 4 processor and up
to 8 GB of unbuffered ECC DDR2-667/533/400 SDRAM.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
system and describes the main features of the Super PDSGE motherboard and
the SC733T-450 chassis.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperWorkstation 5035G-T
into a rack and check out the server configuration prior to powering up the system. If
your server was ordered without the processor and memory components, this chap-
ter will refer you to the appropriate sections of the manual for their installation.
Chapter 3: System Interface
Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
iii
Preface

SUPERWORKSTATION 5035G-T User's Manual
iv
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperWorkstation 5035G-T.
Chapter 5: Advanced Motherboard Setup
Chapter 5 provides detailed information on the PDSGE motherboard, including the
locations and functions of connectors, headers and jumpers. Refer to this chapter
when adding or removing processors or main memory and when reconfiguring the
motherboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC733T-450 workstation chassis.
You should follow the procedures given in this chapter when installing, removing
or reconfiguring Serial ATA or peripheral drives and when replacing system power
supply units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: BIOS POST Messages
Appendix B: BIOS POST Codes
Appendix C: Software Installation
Appendix D: System Specifications

v
Preface
Notes

vi
Table of Contents
Preface
About This Manual ...................................................................................................... iii
Manual Organization ................................................................................................... iii
Chapter 1: Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Motherboard Features .................................................................................... 1-2
1-3 Chassis Features ............................................................................................ 1-5
1-4 Contacting Supermicro ................................................................................... 1-7
Chapter 2: System Installation
2-1 Overview ......................................................................................................... 2-1
2-2 Unpacking the System ................................................................................... 2-1
2-3 Setting up the System .................................................................................... 2-2
Checking the Motherboard Setup ........................................................... 2-2
Checking the Drive Bay Setup ............................................................... 2-4
Chapter 3: System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons .................................................................................... 3-1
Reset ....................................................................................................... 3-1
Power ...................................................................................................... 3-1
3-3 Control Panel LEDs ........................................................................................ 3-2
Power ..................................................................................................... 3-2
HDD ........................................................................................................ 3-2
NIC .......................................................................................................... 3-2
Overheat/Fan Fail ................................................................................... 3-2
3-4 Serial ATA Drive Carrier LEDs......................................................................... 3-3
Chapter 4: System Safety
4-1 Electrical Safety Precautions........................................................................... 4-1
4-2 General Safety Precautions............................................................................. 4-2
4-3 ESD Precautions ............................................................................................ 4-3
4-4 Operating Precautions .................................................................................... 4-4
SUPERWORKSTATION 5035G-T User's Manual

Chapter 5: Advanced Motherboard Setup
5-1 Handling the Motherboard ............................................................................... 5-1
5-2 Motherboard Installation .................................................................................. 5-2
5-3 Connecting Cables .......................................................................................... 5-3
Connecting Data Cables ........................................................................... 5-3
Connecting Power Cables......................................................................... 5-3
Connecting the Control Panel ................................................................... 5-3
5-4 I/O Ports........................................................................................................... 5-4
5-5 Installing the Processor and Heatsink............................................................. 5-5
5-6 Installing Memory............................................................................................. 5-8
5-7 Adding PCI Add-On Cards .............................................................................. 5-9
5-8 Motherboard Details ...................................................................................... 5-10
PDSGE Layout ........................................................................................ 5-10
PDSGE Quick Reference........................................................................ 5-11
5-9 Connector Definitions .................................................................................... 5-12
Power Supply Connectors .................................................................... 5-12
PW_ON Connector.................................................................................. 5-12
Reset Connector ................................................................................... 5-12
Overheat LED (OH)................................................................................. 5-13
NIC1 (JLAN1) LED.................................................................................. 5-13
IDE/SATA LED......................................................................................... 5-13
Power On LED ........................................................................................ 5-13
NMI Button .............................................................................................. 5-14
Fan Headers............................................................................................ 5-14
ATX PS/2 Keyboard and PS/2 Mouse Ports........................................... 5-14
Chassis Intrusion..................................................................................... 5-14
Universal Serial Bus................................................................................ 5-15
Wake-On-LAN ......................................................................................... 5-15
Wake-On-Ring ......................................................................................... 5-15
LAN (Ethernet Port)................................................................................. 5-15
CD Header/Auxilliary Audio Header ....................................................... 5-16
Power LED ............................................................................................. 5-16
Serial Ports ............................................................................................. 5-16
5-10 Jumper Settings............................................................................................. 5-17
Explanation of Jumpers........................................................................... 5-17
Speaker Connector ................................................................................ 5-17
CMOS Clear ............................................................................................ 5-17
USB Wake-Up ......................................................................................... 5-18
Keyboard Wake-Up ................................................................................ 5-18
vii
Table of Contents

viii
System Power Force On ........................................................................ 5-18
Watch Dog Enable/Disable ..................................................................... 5-19
LAN Enable/Disable ................................................................................ 5-19
SMBus to PCI Enable/Disable ............................................................... 5-19
5-11 Onboard Indicators ........................................................................................ 5-20
LAN LEDs................................................................................................ 5-20
5-12 Parallel Port, Floppy and IDE Drive Connections ......................................... 5-21
Parallel Port Connector ........................................................................... 5-21
Floppy Connector .................................................................................... 5-22
IDE Connectors ....................................................................................... 5-23
Chapter 6: Advanced Chassis Setup
6-1 Static-Sensitive Devices .................................................................................. 6-1
6-2 Front Control Panel ......................................................................................... 6-2
6-3 System Fans.................................................................................................... 6-5
Fan Failure ................................................................................................ 6-5
Replacing System Fans ............................................................................ 6-5
6-4 Drive Bay Installation....................................................................................... 6-7
Serial ATA Drives....................................................................................... 6-7
Installing Components in the 5.25" Drive Bays ...................................... 6-10
6-5 Power Supply................................................................................................. 6-11
Replacing the Power Supply................................................................... 6-11
Chapter 7: BIOS
7-1 Introduction ...................................................................................................... 7-1
7-2 Running Setup ................................................................................................. 7-2
7-3 Main BIOS Setup ............................................................................................ 7-2
7-4 Advanced BIOS Setup ................................................................................... 7-4
7-5 Security .......................................................................................................... 7-12
7-6 Boot .............................................................................................................. 7-13
7-7 Exit ................................................................................................................ 7-14
Appendices:
Appendix A: Beep Codes and POST Messages ...................................................... A-1
Appendix B: Award BIOS POST Codes.................................................................... B-1
Appendix C: Software Installation ............................................................................ C-1
Appendix D: System Specifications ......................................................................... D-1
SUPERWORKSTATION 5035G-T User's Manual

Chapter 1
Introduction
1-1 Overview
Supermicro's 5035G-T is a high-end single processor workstation. The 5035G-T
is comprised of two main subsystems: the SC733T-450 chassis and the PDSGE
motherboard. The PDSGE supports a single Intel Pentium D or Pentium 4 LGA775
processor at up to 3.80 GHz and up to 8 GB of unbuffered ECC DDR2-667/533/400
SDRAM memory. Please refer to our web site for information on operating systems
that have been certified for use with the 5035G-T (www.supermicro.com) and for
regular updates on supported processor speeds.
In addition to the motherboard and chassis, various hardware components may
have been included with the 5035G-T, as listed below.
 One (1) floppy drive [FPD-Teac(B)]
 Serial ATA (SATA) Accessories:
One (1) internal SATA backplane (CSE-SATA-733)
Four (4) SATA cables (CBL-0061)
One (1) SATA LED cable (CBL-0056)
Four (4) SATA drive carriers [(CSE-PT39(B)]
 One (1) 12-cm exhaust fan (FAN-0055)
 One (1) 9-cm cooling fan with air shroud (FAN-0060)
 One (1) CD containing drivers and utilities
 SuperWorkstation 5035G-T User's Manual
Note: a "B" in the part number indicate the part is also available in black.
Chapter 1: Introduction
1-1

1-2
SUPERWORKSTATION 5035G-T User's Manual
1-2 Motherboard Features
At the heart of the SuperWorkstation 5035G-T lies the PDSGE, a single processor
motherboard. Below are the main features of the PDSGE.
Chipset Overview
The PDSGE is based on Intel’s 955X chipset. See Figure 1-1 for a block diagram
of the chipset. The 955X chipset is made up of two main components:
The Memory Controller Hub (MCH)
The I/O Controller Hub (6300ESB)
Memory Controller Hub (MCH)
The MCH includes the host (CPU) interface, memory interface, I/O controller hub in-
terface, CSA interface and AGP interface. It contains advanced power management
logic and supports dual-channel (interleaved) DDR memory, providing bandwidth of
up to 6.4 GB/s using DDR-400 SDRAM. The MCH supports the following front side
bus/memory bus configurations: 800 MHz FSB with a 400/333 memory interface, a
533 MHz FSB with a 333/266 memory interface and a 400 MHz FSB with a 266 MHz
memory interface. The AGP interface supports 8x data transfers and operates at a
peak bandwidth of 2.1 GB/s. The CSA (Communications Streaming Architecture)
interface connects the MCH to a Gigabit Ethernet controller.
I/O Controller Hub (6300ESB)
The 6300ESB ICH controller hub provides the I/O subsystem with access to the rest
of the system. It integrates two Serial ATA (SATA) host controllers, a dual-channel
Ultra ATA/100 bus master IDE controller, an SMBus 2.0 controller, the LPC/Flash
BIOS interface, the PCI-X (66MHz) 1.0 interface, the PCI 2.2 interface and the System
Management Controller.

Chapter 1: Introduction
1-3
Processors
The PDSGE supports a single Intel®Pentium®D or Pentium 4 processor of up
to 3.80 GHz in an LGA775 ZIF socket. Please refer to the support section of our
web site for a complete listing of supported processors.
Memory
The PDSGE has four (4) 240-pin DIMM sockets that can support up to 8 GB of
unbuffered DDR2-667/533/400 SDRAM modules. (Memory operates in a dual-
channel, or interleaved configuration for increased performance.)
Serial ATA
A Serial ATA controller is incorporated into the ICH7R bridge of the 955X chipset
to provide a four-port Serial ATA subsystem. The SATA drives are hot-swappable
units and are RAID 0, RAID 1, RAID 5 and RAID 10 supported.
Note: The operating system you use must have RAID support to enable the hot-
swap capability and RAID function of the Serial ATA drives.
PCI Expansion Slots
The PDSGE has three 32-bit, 33 MHz (5V) PCI slots, two 64-bit 133 MHz (3.3V)
PCI-X slots, one PCI-Express x1 slot and one PCI-Express x16 slot. The SC733T-
450 chassis can accommodate cards being installed in all seven slots.
Ethernet Ports
The PDSGE has an Intel®82573V Gigabit Ethernet controller integrated onboard,
which supports one Gigabit LAN port.
Onboard Controllers/Ports
An onboard IDE controller supports one floppy drive and up to four Ultra ATA 100
hard drives or ATAPI devices. Onboard I/O backpanel ports include two serial COM
ports, one parallel port, three USB ports, PS/2 mouse and keyboard ports and one
Gigabit LAN (RJ45) port.

1-4
SUPERWORKSTATION 5035G-T User's Manual
Other Features
Other onboard features that promote system health include eight voltage monitors,
a chassis intrusion header, auto-switching voltage regulators, chassis and CPU
overheat sensors, virus protection and BIOS rescue.
Figure 1-1 . Intel 955X Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
GLENWOOD
SLOTS
LGA775_PROCESSOR
ICH-7R
USB
PORT_0~7
FWH
LPC I/O
MS.
KB. FDD. SER.1
SER.2
PRN.
PRI_IDE
VRM 10.1
CTRL
ADDR DATA
UDMA/100
LPC
PCI_32_BUS
DDR2_667/533
VRM V10.1
DMI
3_PCI_x32
DIMM_CHA
S-ATA/300
4 x SATA
CK410 CLK
1 PCIE_x16
GRAPHIC
MCH
DIMM_CHB
PORTS
PCIE_x16
Gb_LAN
SLOTS
1_PCIE_x1
PCIEx1
W83627HF 5.1-CH
AUDIO
FSB: 1066/800/533MHz
LPCUSB 2.0/1.1
AC97
PCIEx4
PXH-V
2x PCIX_64
PCI-X BUS

Chapter 1: Introduction
1-5
1-3 Chassis Features
The SuperWorkstation 5035G-T is a mid-tower workstation type configuration. The
following is a general outline of the main features of the SC733T-450 chassis.
System Power
When configured as a SuperWorkstation 5035G-T, the SC733T-450 chassis in-
cludes a single low-noise 450W power supply.
Serial ATA Subsystem
The SC733T-450 chassis was designed to support up to four Serial ATA hard drives.
The Serial ATA drives are hot-swappable units. ATA/100 IDE drives are also sup-
ported.
Control Panel
The SC733T-450's control panel provides important system monitoring and control
information. LEDs indicate power on, network activity, hard disk drive activity and
overheat conditions. The control panel also includes a main power button and a
system reset button.
Rear I/O Panel
The rear I/O panel on the SC733T-450 provides seven motherboard expansion slots
and is fitted with an I/O backplane to support the ports on the PDSGE motherboard
(see Figure 1-2).
Cooling System
The SC733T-450 chassis has an innovative cooling design that features one 12-
cm exhaust fan and one 9-cm thermal cooling fan. The fans plug into headers
on the motherboard and operate at an rpm determined by a settiing in BIOS (see
Chapter 7).

1-6
SUPERWORKSTATION 5035G-T User's Manual
Figure 1-2. Rear I/O Panel
Keyboard
Mouse COM1/COM2 Ports USB0/1 PortsUSB3/4/5/6 Ports
Parallel Port LineIn/LineOut/MICLAN Port

Chapter 1: Introduction
1-7
1-4 Contacting Supermicro
Headquarters
Address: SuperMicro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: SuperMicro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: SuperMicro, Taiwan
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone], ext.132 or 139

1-8
SUPERWORKSTATION 5035G-T User's Manual
Notes

Chapter 2: System Installation
2-1
Chapter 2
System Installation
2-1 Overview
This chapter provides a quick setup checklist to get your SuperWorkstation 5035G-
T up and running. Following the steps in the order given should enable you to
have the system operational within a minimal amount of time. If your system is
not already fully integrated with a motherboard, processor, system memory etc.,
please turn to the chapter or section noted in each step for details on installing
specific components.
2-2 Unpacking the System
You should inspect the box the SuperWorkstation 5035G-T was shipped in and note
if it was damaged in any way. If the server itself shows damage, you should file a
damage claim with the carrier who delivered it.
Decide on a suitable location for setting up and operating the SuperWorkstation
5035G-T. It should be situated in a clean, dust-free area that is well ventilated.
Avoid areas where heat, electrical noise and electromagnetic fields are generated.
You will also need it placed near a grounded power outlet.
Once the SuperWorkstation 5035G-T is placed in the appropriate location, slide the
locking tabs on each caster down to keep it stationary.
!!
Warnings and Precautions!
- Ensure that the caster wheels on the workstation are locked.
- Review the electrical and general safety precautions in Chapter 4.
- Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a power
failure.
-Allow the power supply units and hot-swap Serial ATA drive to cool before touching
them.
- To maintain proper cooling, always keep all chassis panels closed and all SATA
carriers installed when not being serviced.

2-2
SUPERWORKSTATION 5035G-T User's Manual
2-3 Setting Up the System
You should first open the left side panel (when facing the front of the chassis)
to make sure the motherboard is properly installed and all connections have been
made.
Checking the Motherboard Setup
1. Accessing the inside of the System (Figure 2-1)
Begin by removing the two screws from the back lip of the side cover (this is the
left cover when looking at the chassis from the front.) Grab the handle and gently
pull the side cover out to release it from its position. Once the side cover is out of
its position, slide the cover out of the chassis.
2. Check the CPU (processor)
You may have one processor already installed into the system board. The processor
should have its own heatsink attached. See Chapter 5 for instructions on processor
installation.
3. Check the system memory
Your system may have come with system memory already installed. Make sure all
DIMMs are fully seated in their slots. For details on adding system memory, refer
to Chapter 5.
4. Installing add-on cards
If desired, you can install up to seven add-on cards to the system. See Chapter 5
for details on installing PCI-E/PCI-X/PCI add-on cards.
5. Check all cable connections and airflow
Make sure all power and data cables are properly connected and not blocking the
airflow. See Chapter 5 for details on cable connections.

Chapter 2: System Installation
2-3
Figure 2-1. Accessing the Inside of the 5035G-T

2-4
SUPERWORKSTATION 5035G-T User's Manual
Checking the Drive Bay Setup
Next, you should check to make sure the peripheral drives and the Serial ATA drive
and Serial ATA backplane have been properly installed and all essential connec-
tions have been made.
1. Accessing the peripheral drive bays
To install or remove a component in the 3.5" and/or 5.25" drive bay(s), you will
need to remove the side chassis cover. See the installation and removal sec-
tions for the peripheral drives in Chapter 6.
2. Check the Serial ATA disk drives
Depending upon your system's configuration, your system may have up to four
Serial ATA drives already installed. If you need to install or remove an SATA
drive, please refer to the appropriate section in Chapter 6.
3. Check the airflow
Cooling air is provided by a 9-cm internal cooling fan and a 12-cm exhaust fan.
The system component layout was carefully designed to promote sufficient
airflow throughout the chassis. Also note that all power and data cables have
been routed in such a way that they do not block the airflow generated by the
fan. Please keep this in mind when rerouting or adding/removing cables.
4. Supplying power to the system
The last thing you must do is to provide input power to the system. Plug the
power cord from the power supply unit into a high-quality power strip that offers
protection from electrical noise and power surges. It is recommended that you
use an uninterruptible power supply (UPS).
