Supero SuperWorkstation 7044A-8 User manual

®
SUPERWORKSTATION 7044A-82
SUPERWORKSTATION 7044A-8
SUPERWORKSTATION 7044A-i2
SUPERWORKSTATION 7044A-i
USER’S MANUAL
1.0a
SUPER

The information in this User’s Manual has been carefully reviewed and is believed to be
accurate. The vendor assumes no responsibility for any inaccuracies that may be
contained in this document, makes no commitment to update or to keep current the
information in this manual, or to notify any person or organization of the updates. Please
Note: For the most up-to-date version of this manual, please see our
web site at www.supermicro.com.
SUPERMICRO COMPUTER reserves the right to make changes to the product described in
this manual at any time and without notice. This product, including software, if any, and
documentation may not, in whole or in part, be copied, photocopied, reproduced, translated
or reduced to any medium or machine without prior written consent.
IN NO EVENT WILL SUPERMICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM
THE USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE VENDOR
SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING,
INTEGRATING, INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR
DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of
Santa Clara County in the State of California, USA. The State of California, County of
Santa Clara shall be the exclusive venue for the resolution of any such disputes.
Supermicro's total liability for all claims will not exceed the price paid for the hardware
product.
Unless you request and receive written permission from SUPER MICRO COMPUTER, you
may not copy any part of this document.
Information in this document is subject to change without notice. Other products and
companies referred to herein are trademarks or registered trademarks of their respective
companies or mark holders.
Copyright © 2005 by SUPER MICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians.
It provides information for the installation and use of the SuperWorkstation 7044A-
82/7044A-8/7044A-i2/7044A-i. Installation and maintainance should be per-
formed by experienced technicians only.
The SuperWorkstation 7044A-82/7044A-8/7044A-i2/7044A-i is a high-end, dual
processor workstation based on the SC743S1-645/SC743i-645 4U tower/
rackmount chassis and the X6DA8-G2/X6DA8-G/X6DAE-G2/X6DAE-G, a dual
processor serverboard that supports single or dual Intel®XeonTM processors at
a Front Side (System) Bus speed of 800 MHz.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the SUPER X6DA8-G2/X6DA8-
G/X6DAE-G2/X6DAE-G serverboard and the SC743S1-645/SC743i-645 chassis,
which comprise the SuperWorkstation 7044A-82/7044A-8/7044A-i2/7044A-i.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the system into a rack and
check out the server configuration prior to powering up the system. If your server
was ordered without processor and memory components, this chapter will refer
you to the appropriate sections of the manual for their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.

SUPERWORKSTATION 7044A-82/7044A-8/7044A-i2/7044A-i Manual
iv
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperWorkstation 7044A-82/7044A-8/7044A-i2/7044A-i.
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the X6DA8-G2/X6DA8-G/X6DAE-G2/
X6DAE-G serverboard, including the locations and functions of connections,
headers and jumpers. Refer to this chapter when adding or removing processors
or main memory and when reconfiguring the serverboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC743S1-645/SC743i-645
server chassis. You should follow the procedures given in this chapter when
installing, removing or reconfiguring SCSI or peripheral drives and when replacing
system power supply units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed infor-
mation on running the CMOS Setup Utility.
Appendix A: BIOS POST Codes
Appendix B: Software Installation
Appendix C: System Specifications

v
Preface
Notes

vi
Table of Contents
Preface
About This Manual ....................................................................................................... iii
Manual Organization .................................................................................................... iii
Chapter 1: Introduction
1-1 Overview ............................................................................................................ 1-1
1-2 Serverboard Features ...................................................................................... 1-2
1-3 Server Chassis Features ................................................................................ 1-3
1-4 Contacting Supermicro ................................................................................... 1-6
Chapter 2: Quick Setup
2-1 Overview ............................................................................................................ 2-1
2-2 Unpacking the SuperWorkstation System.................................................... 2-1
2-3 Preparing for Setup ......................................................................................... 2-1
2-4 Installing the System into a Rack................................................................. 2-4
2-5 Checking the Serverboard Setup ................................................................... 2-8
2-6 Checking the Drive Bay Setup....................................................................... 2-9
Chapter 3: System Interface
3-1 Overview ............................................................................................................ 3-1
3-2 Control Panel Buttons..................................................................................... 3-1
Power ......................................................................................................... 3-1
Reset.......................................................................................................... 3-1
3-3 Control Panel LEDs......................................................................................... 3-2
Power ......................................................................................................... 3-2
HDD ............................................................................................................ 3-2
NIC.............................................................................................................. 3-2
Overheat ..................................................................................................... 3-2
Power Fail.................................................................................................. 3-3
3-4 SCSI Drive LEDs ............................................................................................. 3-3
3-5 LAN (Ethernet) Port LEDs.............................................................................. 3-3
Chapter 4: System Safety
4-1 Electrical Safety Precautions...........................................................................4-1
4-2 General Safety Precautions .............................................................................4-2
4-3 ESD Safety Precautions...................................................................................4-3
4-4 Operating Precautions ......................................................................................4-4
SUPERWORKSTATION 7044A-82/7044A-8/7044A-i2/7044A-i Manual

Chapter 5: Advanced Serverboard Setup
5-1 Handling the Serverboard ............................................................................. 5-1
5-2 PGA Processor and Heatsink Installation .................................................. 5-2
5-3 Connecting Cables ......................................................................................... 5-5
Connecting Data Cables ......................................................................... 5-5
Connecting Power Cables...................................................................... 5-5
Connecting the Control Panel ................................................................ 5-6
5-4 I/O Ports........................................................................................................... 5-7
5-5 Installing Memory ............................................................................................ 5-7
5-6 Adding PCI Cards ........................................................................................... 5-9
5-7 Serverboard Details ....................................................................................... 5-9
X6DA8-G2/X6DA8-G/X6DAE-G2/X6DAE-G Layout .......................... 5-10
X6DA8-G2/X6DA8-G/X6DAE-G2/X6DAE-G Quick Reference......... 5-11
5-8 Connector Definitions .................................................................................. 5-12
ATX Power Connector.......................................................................... 5-12
Processor Power Connector............................................................... 5-12
NMI Button ............................................................................................... 5-12
Power LED.............................................................................................. 5-12
HDD LED .................................................................................................. 5-13
NIC LEDs ................................................................................................. 5-13
Overheat LED (OH) ............................................................................... 5-13
Power Fail LED ...................................................................................... 5-13
Reset Button........................................................................................... 5-14
Power Button ......................................................................................... 5-14
Chassis Intrusion ................................................................................... 5-14
Universal Serial Bus (USB0/1) ............................................................ 5-14
Fan Headers........................................................................................... 5-15
Serial Ports ............................................................................................. 5-15
GLAN 1/2 (Ethernet Ports)................................................................... 5-15
ATX PS/2 Keyboard and Mouse Ports............................................... 5-15
Power LED/Speaker/NMI ....................................................................... 5-16
Wake-On-Ring ........................................................................................ 5-16
Wake-On-LAN ........................................................................................ 5-16
SMB .......................................................................................................... 5-16
Power Fault ............................................................................................ 5-17
Keylock Fault .......................................................................................... 5-17
Power Supply Fail Alarm Reset .......................................................... 5-17
5-9 Jumper Settings ............................................................................................ 5-18
Explanation of Jumpers ........................................................................ 5-18
vii
Table of Contents

viii
CMOS Clear............................................................................................. 5-18
GLAN Enable/Disable............................................................................. 5-19
SCSI Controller Enable/Disable ............................................................ 5-19
SCSI Termination Enable/Disable......................................................... 5-19
Watch Dog Enable/Disable ................................................................... 5-20
AC'97 Audio Enable/Disable................................................................. 5-20
Third Power Supply Alarm Enable/Disable........................................ 5-21
Power Force On Enable/Disable ......................................................... 5-21
5-10 Onboard Indicators ...................................................................................... 5-22
GLAN1/GLAN2 LEDs ............................................................................. 5-22
5-11 Parallel Port, Floppy/Hard Disk Drive and SCSI Connections............... 5-22
Parallel Port Connector ......................................................................... 5-22
Floppy Connector................................................................................... 5-23
IDE Connectors ...................................................................................... 5-23
Ultra320 SCSI Connectors.................................................................... 5-24
Chapter 6: Advanced Chassis Setup
6-1 Static-Sensitive Devices ................................................................................. 6-1
6-2 Front Control Panel ........................................................................................ 6-3
6-3 System Fans ................................................................................................... 6-4
Fan Failure................................................................................................ 6-4
Replacing System Fans .......................................................................... 6-4
6-4 Drive Bay Installation..................................................................................... 6-6
SCSI Drives............................................................................................... 6-6
Installing Components in the 5.25" Drive Bays .................................. 6-9
6-5 Power Supply ............................................................................................... 6-10
Power Supply Failure ........................................................................... 6-10
Replacing the Power Supply ............................................................... 6-10
Chapter 7: BIOS
7-1 Introduction...................................................................................................... 7-1
7-2 Running Setup................................................................................................. 7-2
7-3 Main BIOS Setup............................................................................................. 7-2
7-4 Advanced Setup............................................................................................. 7-7
7-5 Security.......................................................................................................... 7-19
7-6 Boot ................................................................................................................ 7-21
7-7 Exit .................................................................................................................. 7-22
SUPERWORKSTATION 7044A-82/7044A-8/7044A-i2/7044A-i Manual

Table of Contents
ix
Appendices:
Appendix A: BIOS POST Codes ........................................................................... A-1
Appendix B: Software Installation ....................................................................... B-1
Appendix C: System Specifications .................................................................... C-1

Notes
x
SUPERWORKSTATION 7044A-82/7044A-8/7044A-i2/7044A-i Manual

Chapter 1
Introduction
1-1 Overview
The Supermicro SuperWorkstation 7044A-82/7044A-8/7044A-i2/7044A-i is a
high-end dual processor workstation that can be utilized either in a tower or in
a rackmount configuration. The 7044A-82/7044A-8/7044A-i2/7044A-i is com-
prised of two main subsystems: the SC743S1-645/SC743i-645 high-end server
chassis and the X6DA8-G2/X6DA8-G/X6DAE-G2/X6DAE-G dual XeonTM proces-
sor serverboard. Please refer to our web site for information on operating sys-
tems that have been certified for use with your workstation.
In addition to the serverboard and chassis, various hardware components have
been included with the SuperWorkstation, as listed below:
zOne (1) 3.5" floppy drive [FPD-PNSC-02(1)]
zFour (4) hot-swap 8-cm chassis PWM fans (FAN-0074)
zOne (1) air shroud (CSE-PT54)
zTwo (2) 5.25" dummy drive trays [CSE-PT36(B)]
zOne (1) front control panel cable (CBL-0049)
zOne (1) round floppy cable (CBL-0040)
zOne (1) IDE cable (CBL-0036, 7044A-i2/7044A-i only)
zOne (1) round CD-ROM cable (CBL-0039)
zOne (1) I/O shield (CSE-PT57)
zSCSI Accessories (7044A-82/7044A-8 only)
One (1) SCSI backplane with SAF-TE (CSE-SCA-743S1)
One (1) 2' SCSI drop cable (CBL-037-U320)
Eight (8) SCA 1-inch high SCSI drive carriers [CSE-PT17(B)]
zOptional: Two (2) Xeon passive heatsinks (SNK-P0010)
One (1) rackmount kit [CSE-PT26(B)]
Chapter 1: Introduction
1-1

1-2
SUPERWORKSTATION 7044A-82/7044A-8/7044A-i2/7044A-i Manual
1-2 Serverboard Features
At the heart of the 7044A-82/7044A-8/7044A-i2/7044A-i lies the X6DA8-G2/
X6DA8-G/X6DAE-G2/X6DAE-G, a dual processor serverboard based on Intel's
E7525 chipset and designed to provide maximum performance. Below are the
main features of the X6DA8-G2/X6DA8-G/X6DAE-G2/X6DAE-G. (See Figure 1-1
for a block diagram of the E7525 chipset).
Processors
The X6DA8-G2/X6DA8-G/X6DAE-G2/X6DAE-G supports single or dual 604-pin
Intel Xeon processors at a FSB speed of 800 MHz. Please refer to the
serverboard description pages on our web site for a complete listing of supported
processors (http://www.supermicro.com).
Memory
The X6DA8-G2/X6DAE-G2 has eight 240-pin DIMM slots that can support up to
16 GB of registered ECC DDR2-400 (PC3200) SDRAM. The memory is an
interleaved configuration, which requires modules of the same size and speed to
be installed in pairs.
The X6DA8-G/XDAE-G has eight 184-pin DIMM slots that can support up to 16
GB of registered ECC DDR333 or 32 GB of registered ECC DDR266 SDRAM. The
memory is an interleaved configuration, which requires modules of the same size
and speed to be installed in pairs.
Onboard SCSI (X6DA8-G2/X6DA8-G only)
Onboard SCSI is provided with an Adaptec AIC-7902 SCSI chip, which supports
dual channel, Ultra320 SCSI at a throughput of 320 MB/sec for each channel.
The X6DA8-G2/X6DA8-G provides two LVD Ultra320 SCSI ports.
PCI Expansion Slots
The X6DA8-G2/X6DA8-G/X6DAE-G2/X6DAE-G has six PCI expansion slots,
which includes one x16@4GB/sec PCI-Express slot, one x4@2GB/sec PCI-
Express slot, three 64-bit PCI-X slots (one 64-bit PCI-X 133 slot, one PCI-X 100
slot and one PCI-X 100MHz ZCR slot) and one 32-bit 33MHz PCI slot (w/PCI
graphics card support).

1-3
Chapter 1: Introduction
Onboard Controllers/Ports
One floppy drive controller and two onboard ATA/100 controllers are provided to
support up to four hard drives or ATAPI devices. The color-coded I/O ports
include two COM ports, a parallel port, four USB 2.0 ports, PS/2 mouse and
keyboard ports and Line-In, Line-Out and Mic jacks. Two front side USB ports
are also included on the front of the chassis. The X6DA8-G2 and X6DAE-G2 have
two and the X6DA8-G and X6DAE-G have one gigabit Ethernet port.
Other Features
Other onboard features that promote system health include onboard voltage
monitors, a chassis intrusion header, auto-switching voltage regulators, chassis
and CPU overheat sensors, virus protection and BIOS rescue.
1-3 Server Chassis Features
The SuperWorkstation 7044A-82/7044A-8/7044A-i2/7044A-i is a scaleable server
platform designed with today's most state-of-the-art features. The following is a
general outline of the main features of the SC743S1-645/SC743i-645 server chas-
sis. (7044A-82/7044A-8: SC743S1-645 7044A-i2/7044A-i: SC743i-645
Note: The SC743S1-645 and SC743i-645 are two versions of the same chassis.
The only difference between them is the SC743S1-645 is equipped with a SCSI
backplane and drive trays while the SC743i-645 is not.
System Power
The 7044A-82/7044A-8/7044A-i2/7044A-i features a single 645W power supply.
This power supply unit has been designed to operate at a low noise level to make
it ideal for use in a workstation environment.
SCSI Subsystem (7044A-82/7044A-8 only)
The SCSI subsystem supports up to eight 80-pin SCA Ultra320 SCSI hard drives.
(Any standard 1" drives are supported. SCA = Single Connection Attachment.)
The SCSI drives are connected to a single-channel SCA backplane with SAF-TE.
The SCSI drives are also hot-swap units. A RAID controller card can be used with
the SCA backplane to provide data security.
Note: The operating system you use must have RAID support to enable the hot-
swap capability of the SCSI drives.

1-4
SUPERWORKSTATION 7044A-82/7044A-8/7044A-i2/7044A-i Manual
Front Control Panel
The SuperWorkstation 7044A-82/7044A-8/7044A-i2/7044A-i's control panel pro-
vides you with system monitoring and control. LEDs indicate system power,
HDD activity, network activity, overheat condition and power supply failure. A
main power button and a system reset button are also included.
Note: the power supply fail LED is intended for use with redundant power supply
systems and so is not needed for the 7044A-82/7044A-8/7044A-i2/7044A-i.
I/O Backplane
The SC743S1-645/SC743i-645 is an ATX form factor chassis that can be used as
a tower or mounted in a 4U rackmount configuration. The I/O backplane provides
six expansion slots, two COM ports, a parallel port, four USB 2.0 ports, PS/2
mouse and keyboard ports, one or two (depending on the serverboard) gigabit
Ethernet port(s) and Line-In, Line-Out and Microphone jacks (see Figure 5-3).
Cooling System
The SC743S1-645/SC743i-645 chassis has an innovative cooling design that
includes four 8-cm hot-plug PWM (Pulse Width Modulation) system cooling fans
located in the middle of the chassis. The chassis fans work with an air shroud
to cool the areas where the most heat is generated. All chassis fans operate
continuously at 5000 rpm.

1-5
Chapter 1: Introduction
Figure 1-1. Intel E7525 Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
MC H
NOCONA P R OCE S S OR # 2VRM
CL OCK
ADDR CTRL DAT A
NOCONA P R OCE S S OR # 1
ADDR CTRL DAT A DAT A
ADDR CTRL
ICH5R
HUB
DDR I I - 4 0 0
A
PXH
B
PCI EXP. A
1 PCI - X
SLOT3
1 PCI - X
PCI - X BUS( 100 MHZ)
Gbi t L AN
SLOT2
J13
PCI - X BUS( 100 MHZ)
J14
1 PCI - EXP
SLOT4
J17
PCI EXP. B, C ( X16)
J15
1 PCI - EXP
S L OT 6
DI MMs
IDE
PRI / SEC
UDMA/ 100
X8X4
X4
DI MMs
0, 1
SATA
SATA
LPC BUSUS B
US B P ORT
0, 1, 2, 3,
BMC CON. FWHLPC I / O
PARALLEL
PORT
MS .
FDD. SER. 1
SER. 2
KB.
4 DDR I I - 400
4 DDR I I - 400
DDR I I - 4 0 0
SCSI
7902
PCI BUS( 32- BI T)
PCI 32 BI T
S L OT 5
AC 97
J19
1 PCI - X
SLOT1
J12
H/ W
MO N I T O R
5, 6, 7, 8

1-6
SUPERWORKSTATION 7044A-82/7044A-8/7044A-i2/7044A-i Manual
1-4 Contacting Supermicro
Headquarters
Address: SuperMicro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: SuperMicro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: SuperMicro, Taiwan
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: su[email protected]
Tel: [phone], ext. 132 or 139

Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your SuperWorkstation
7044A-82/7044A-8/7044A-i2/7044A-i up and running. Following these steps in
the order given should enable you to have the system operational within a mini-
mum amount of time. This quick setup assumes that your system has come to
you with the processors and memory preinstalled. If your system is not already
fully integrated with a serverboard, processors, system memory etc., please turn
to the chapter or section noted in each step for details on installing specific
components. The SuperWorkstation 7044A-82/7044A-8/7044A-i2/7044A-i may
be employed either as a tower or rackmounted as a 4U chassis. If using it
in a tower configuration, please read Server Precautions in the next section
and then skip ahead to Section 2-5.
2-2 Unpacking the System
You should inspect the box the system was shipped in and note if it was dam-
aged in any way. If the server itself shows damage you should file a damage
claim with the carrier who delivered it.
Decide on a suitable location for the SuperWorkstation 7044A-82/7044A-8/
7044A-i2/7044A-i. It should be situated in a clean, dust-free area that is well
ventilated. Avoid areas where heat, electrical noise and electromagnetic fields
are generated. You will also need it placed near a grounded power outlet. Read
the Rack and Server Precautions in the next section.
2-3 Preparing for Setup
The box the system was shipped in may include two sets of rail assemblies, two
rail mounting brackets and mounting screws needed for installing the system into
a rack (optional kit). Follow the steps in the order given to complete the instal-
lation process in a minimum amount of time. Please read this section in its
entirety before you begin the installation procedure outlined in the sections that
follow.

2-2
SUPERWORKSTATION 7044A-82/7044A-8/7044A-i2/7044A-i Manual
Choosing a Setup Location:
- Leave enough clearance in front of the system to enable you to open
the front door completely (~25 inches).
- Leave approximately 30 inches of clearance in the back of the system
to allow for sufficient airflow and ease in servicing.
- This product is for installation in a Restricted Access Location only (dedi-
cated equipment rooms, service closets, etc.)
Rack Precautions:
- Ensure that the leveling jacks on the bottom of the rack are fully extended
to the floor with the full weight of the rack resting on them.
- In single rack installation, stabilizers should be attached to the rack.
- In multiple rack installations, the racks should be coupled together.
- Always make sure the rack is stable before extending a component
from the rack.
- You should extend only one component at a time - extending two or
more simultaneously may cause the rack to become unstable.
Server Precautions:
- Review the electrical and general safety precautions in Chapter 4.
- Determine the placement of each component in the rack before you
install the rails.
- Install the heaviest server components on the bottom of the rack first, and
then work up.
- Use a regulating uninterruptible power supply (UPS) to protect the
server from power surges, voltage spikes and to keep your system operat-
ing in case of a power failure.
-Allow the hot plug SCSI drives and power supply units to cool before
touching them.
- Always keep the rack's front door and all panels and components on
the servers closed when not servicing to maintain proper cooling.
! !
Warnings and Precautions!

Chapter 2: Server Installation
2-3
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating
temperature of the rack environment may be greater than the ambient tem-
perature of the room. Therefore, consideration should be given to installing
the equipment in an environment compatible with the manufacturer’s maxi-
mum rated ambient temperature (Tmra).
Reduced Airflow
Equipment should be mounted into a rack so that the amount of airflow
required for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition
does not arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might
have on overcurrent protection and power supply wiring. Appropriate consid-
eration of equipment nameplate ratings should be used when addressing this
concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack
itself should be grounded. Particular attention should be given to power
supply connections other than the direct connections to the branch circuit
(i.e. the use of power strips, etc.).

2-4
SUPERWORKSTATION 7044A-82/7044A-8/7044A-i2/7044A-i Manual
2-4 Installing the System into a Rack
This section provides information on installing the system into a rack unit. Rack
installation requires the use of the optional rackmount kit [CSE-PT26(B)]. If the
system has already been mounted into a rack or if you are using it as a tower,
you can skip ahead to Sections 2-5 and 2-6. There are a variety of rack units
on the market, which may mean the assembly procedure will differ slightly. The
following is a guideline for installing the workstation into a rack with the rack rails
provided in the rackmount kit. You should also refer to the installation instruc-
tions that came with the rack unit you are using.
Identifying the Sections of the Rack Rails:
The optional rackmount kit (CSE-PT26 or CSE-PT26B - black) includes two rack
rail assemblies. Each of these assemblies consist of three sections: an inner
fixed chassis rail that secures to the chassis, an outer rack rail that secures
directly to the rack itself and two rail brackets, which also attack to the rack (see
Figure 2-1.) The inner and outer rails must be detached from each other to
install.
To remove the inner chassis rail, pull it out as far as possible - you
should hear a "click" sound as a locking tab emerges from inside the rail
assembly and locks the inner rail. Depress the locking tab to pull the
inner rail completely out. Do this for both assemblies (one for each side).
Figure 2-1. Identifying the Sections of the Rack Rails
Inner rail
Outer rail
Rail brackets
