Supero P8SGA User manual

®
P8SGA
USER’S MANUAL
Revision 1.1a
SUPER

Manual Revision 1.1a
Release Date: June 6, 2007
Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2007 by SUPER MICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
SUPER MICRO COMPUTER reserves the right to make changes to the product described in this
manual at any time and without notice. This product, including software, if any, and documenta-
tion may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any
medium or machine without prior written consent.
IN NO EVENT WILL SUPER MICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER SHALL NOT
HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING
OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
manufacturer’s instruction manual, may cause interference with radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, you are encouraged to try to correct the interference by one or more of
the following measures:
*Reorient or relocate the receiving antenna.
*Increase the separation between the equipment and the receiver.
*Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
*Consult the dealer or an experienced radio/television technician for help.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
WARNING: Handling of lead solder materials used
in this product may expose you to lead, a chemical
known to the State of California to cause birth
defects and other reproductive harm.

Preface
About This Manual
This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and use of
the P8SGA motherboard. The P8SGA supports single Intel Pentium®4
Processor (the Prescott Processor) in the 775-Land Grid Array Package at a sys-
tem bus speed of 800/533 MHz. The Pentium 4 Processor in the 775-Land Grid
Array Package is housed in a Flip-Chip Land Grid Array (FC-LGA4) package that
interfaces with the motherboard via an LGA775 socket. The package consists of a
processor core mounted on a substrate land-carrier. An integrated heat spreader
(IHS) is attached to the package substrate and core and serves as the contacting
surface for processor component thermal solutions, such as a heatsink. Please refer
to the motherboard specifications pages on our web site (http://www.supermicro.
com/products/motherboard/) for updates on this motherboard. This product is in-
tended to be professionally installed.
Manual Organization
Chapter 1 includes a checklist of what should be included in your mainboard box,
describes the features, specifications and performance of the P8SGA mainboard
and provides detailed information about the chipset.
Chapter 2 begins with instructions on handling static-sensitive devices. Read
this chapter when installing the processor and DDR memory modules and when
mounting the mainboard in the chassis. Also refer to this chapter to connect the
floppy and hard disk drives, the IDE interfaces, the parallel and serial ports, the
mouse and keyboard and the twisted wires for the power supply, the reset button,
the keylock/power LED and the speaker.
If you encounter any problems, see Chapter 3, which describes troubleshoot-
ing procedures for the video, the memory and the setup configuration stored in
CMOS. For quick reference, a general FAQ (Frequently Asked Questions) section
is provided. Instructions are also included for contacting technical support. In ad-
dition, you can visit our web site at www.supermicro.com/techsupport.htm for more
detailed information.
Chapter 4 includes an introduction to BIOS and provides detailed information on
running the CMOS Setup utility.
Appendix A provides BIOS POST Messages.
Appendix B lists BIOS POST Codes.
Preface
iii

P8SGAUser’s Manual
Table of Contents
Preface
About This Manual ...................................................................................................... iii
Manual Organization ................................................................................................... iii
Chapter 1: Introduction
1-1 Overview ......................................................................................................... 1-1
Checklist ..................................................................................................... 1-1
Contacting Supermicro ............................................................................... 1-2
SUPER P8SGAImage ............................................................... 1-3
P8SGA Layout ............................................................................ 1-4
P8SGAQuick Reference .............................................................. 1-5
E7205 Chipset: System Block Diagram ..................................................... 1-6
Motherboard Features .............................................................................. 1-7
1-2 Chipset Overview ........................................................................................... 1-9
1-3 PC Health Monitoring ................................................................................... 1-10
1-4 Power Configuration Settings ....................................................................... 1-10
1-5 Power Supply ............................................................................................... 1-11
1-6 Super I/O .........................................................................................................1-11
Chapter 2: Installation
2-1 Static-Sensitive Devices ................................................................................. 2-1
2-2 Processor and Heatsink Installation ............................................................... 2-2
2-3 Mounting the Motherboard in the Chassis ..................................................... 2-5
2-4 Installing DDR Memory .................................................................................. 2-6
2-5 I/O Port/Front Control Panel Connector Locations ........................................ 2-7
2-6 Connecting Cables ......................................................................................... 2-8
Power Supply Connectors ...................................................................... 2-8
IR Connector .............................................................................................. 2-8
PW_ON Connector .................................................................................. 2-9
Reset Connector ...................................................................................... 2-9
IDE LED ................................................................................................ 2-10
Power LED Connector ............................................................................ 2-10
Keylock Connector ................................................................................. 2-11
Speaker Connector ............................................................................... 2-11
iv

v
Serial Ports ............................................................................................. 2-12
CD Header ............................................................................................. 2-12
Fan Headers .......................................................................................... 2-13
Chassis Intrusion .................................................................................... 2-13
ATX PS/2 Keyboard/Mouse Ports ......................................................... 2-14
Universal Serial Bus (USB)..................................................................... 2-14
Wake-On-Ring.......................................................................................... 2-15
Wake-On-LAN .......................................................................................... 2-15
Ethernet Port ............................................................................................ 2-15
VGA Connector ........................................................................................ 2-16
SMB Header............................................................................................. 2-16
Overheat LED........................................................................................... 2-17
AC'97 Output............................................................................................ 2-17
2-7 Jumper Settings ............................................................................................ 2-18
Explanation of Jumpers ......................................................................... 2-18
CMOS Clear ........................................................................................... 2-18
USB Wake-Up .......................................................................................... 2-19
Watch Dog Enable/Disable ...................................................................... 2-19
Keyboard Wake-Up .................................................................................. 2-20
Gigabit LAN Enable.................................................................................. 2-20
2-8 Parallel Port, Floppy/Hard Drive and Audio Connections ............................ 2-21
Parallel Port Connector ........................................................................... 2-21
Floppy Connector .................................................................................... 2-22
IDE Connectors ....................................................................................... 2-22
2-9 Installing Software ........................................................................................ 2-23
SuperO Doctor III ..................................................................................... 2-25
Chapter 3: Troubleshooting
3-1 Troubleshooting Procedures ........................................................................... 3-1
Before Power On....................................................................................... 3-1
No Power................................................................................................... 3-1
No Video .................................................................................................. 3-1
Memory Errors........................................................................................... 3-2
Losing the System’s Setup Configuration ................................................ 3-2
3-2 Technical Support Procedures ....................................................................... 3-2
3-3 Frequently Asked Questions .......................................................................... 3-3
3-4 Returning Merchandise for Service ................................................................. 3-5
Table of Contents

P8SGA User’s Manual
Chapter 4: BIOS
4-1 Introduction ....................................................................................................... 4-1
4-2 Running Setup ................................................................................................. 4-2
4-3 Main BIOS Setup ............................................................................................. 4-2
Main BIOS Setup Menu ........................................................................... 4-3
4-4 Advanced BIOS Setup...................................................................................... 4-5
4-4.1 Advanced BIOS Features ................................................................ 4-5
4-4.2 Advanced Chipset Control ............................................................... 4-7
4-4.3 I/O Device Configuration.................................................................. 4-9
4-4.4 PnP Configuration .......................................................................... 4-11
4-4.5 Hardware Monitors......................................................................... 4-13
4-4.6 Processor & Clock Options............................................................ 4-14
4-5 Security ........................................................................................................... 4-15
4-6 Boot ............................................................................................................... 4-16
4-7 Exit ................................................................................................................. 4-17
Appendices:
Appendix A: BIOS POST Messages .........................................................................A-1
Appendix B: BIOS POST Codes................................................................................B-1
vi

Chapter 1: Introduction
1-1
Chapter 1
Introduction
1-1 Overview
Checklist
Congratulations on purchasing your computer motherboard from an acknowledged
leader in the industry. Supermicro boards are designed with the utmost attention to
detail to provide you with the highest standards in quality and performance.
Please check that the following items have all been included with your motherboard.
If anything listed here is damaged or missing, contact your retailer.
All Included in the Retail Box Only
One (1) Supermicro Mainboard
Two (2) SATA cables
One (1) COM port cable with bracket
One (1) IDE cable
One (1) floppy drive ribbon cable
One (1) I/O shield
One (1) Supermicro CD containing drivers and utilities
One (1) User's/BIOS Manual

1-2
P8SGA User’s Manual
Contacting Super Micro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: Super Micro, Taiwan
4F, No. 232-1 Liancheng Road
Chung-Ho 235, Taipei Hsien, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone], ext.132 or 139

Chapter 1: Introduction
1-3
Figure 1-1. P8SGA Image
An Important Note to the User
• All images, layouts and contents included in this manual were based upon the
latest PCB revision available at the time of publishing of this manual. The moth-
erboard you've received may or may not look exactly the same as the graphics
shown in this manual.

1-4
P8SGA User’s Manual
Figure 1-3. Motherboard Layout
(not drawn to scale)
S
UPER P8SGA
®
P4 CPU
LGA 775
JPWAKE
4-Pin 12V PWR
KB/MS
Parallel Port
COM1 Port
Video Port
USB
3/4/5/6
USB1/2
& LAN
JPUSB
Fan3
Clock
915G
Glantsdale
(North Bridge)
PCI-E x16
PCI-3
PCI-2
PCI-1
LAN CTRL
JPL
GLAN Enable
CDin
Aux.
PCI-E#3x1
AC97
COM2
FWH
J43
Clear CMOS
JL1
WOR
SATA0
SATA1
SATA2
SATA3
FP CTRL
Fan2
JF1
JOH1
Buzzer
JP5
IDE
24-PinA
TXPWR
SuperIO
Fan1
Front USB7/8
WD Reset
Chs Intru.
ICH6
J34
SMB
DIMM#1A (Blue)
DIMM#2A (Black)
DIMM#1B (Blue)
DIMM#2B (Black)
Floppy
Audio
WOL
JBT1
OH
J3
J27
J40
(South Bridge)
J13
J45
J11
J44
JG1
J31
J28
J41
KB/MS Wake-Up
J30
Battery
JPUSB2
JPUSB3
PCI-E#2x1
PCI-E#1 x1
Important Notes to the User
• All images, layouts and contents included in this manual were based upon the
latest PCB revision available at the time of publishing. The motherboard you've
received may or may not look exactly the same as the ones shown in this
manual.
• See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front panel
connections.
• " " indicates Pin 1.

Chapter 1: Introduction
1-5
P8SGA Quick Reference
Jumpers Description Default Setting
JBT1 CMOS Clear See Section 2-7
JP5 Watch Dog Pins 1-2 (Enabled)
JPL Giga-bit LAN Enable Pins 1-2 (Enabled)
JPUSB USB 1/2 Wake Up Pins 2-3 (Disabled)
JPUSB2 USB 3/4/5/6 Wake Up Pins 2-3 (Disabled)
JPUSB3 USB 7/8 Wake Up Pins 2-3 (Disabled)
JPWAKE KB/Mouse Wake-Up Pins 1-2 (Enabled)
Connectors Description
ATX PWR (J40) ATX 24-Pin Power Connector
CPU PWR (J41) 12V 4-pin Power Connector(*required)
Audio Audio Port
AUX Auxiliary (Audio) Input Header
CD In Audio CD Input Header
Chassis Intrusion (JL1) Chassis Intrusion Header
COM1, COM2 COM Port/Serial Port 1 & Port 2 Connectors
DIMM#1A,#2A,#1B,#2B Memory (DIMM) slots (1 through 4)
Fans 1-3 Fan1: CPU Fan, Fan2/3: Chassis Fan Headers
Floppy Connector Floppy Disk Connector
FR Control Panel (JF1) Front Control Panel Header
(G-) LAN Port Ethernet RJ45 (Gigabit LAN) Connector
IDE (J27) IDE Connector
OH LED (JOH1) Overheat LED Header
Printer (J30) Parallel Printer Port
KB/Mouse (J28) PS/2 Keyboard/Mouse
SATA #0-3 4 SATA Headers
SMB (J34) System Management Bus Header
USB 1/2 (J11) (Back Panel) Universal Serial Ports 1-2
USB 3/4/5/6 (J44) (Back Panel) Universal Serial Ports 3-6
USB7/8 (J43) (Front Panel) USB ports 7/8
VGA (JG1) Video/Graphic Connector
WOR (JWOR1) Wake-On-Ring Header

1-6
P8SGA User’s Manual
Figure 1-3. 915G Grantsdale Chipset:
System Block Diagram
Note: This is a general block diagram and may not exactly represent
the features on your motherboard. See the following pages for the
actual specifications of each motherboard.
GRANTSDALE
SLOTS
LGA775_PROCESSOR
ICH-6
USB
PORT_0~7
FWH
LPC I/O
MS.
KB. FDD. SER.1
SER.2
PRN.
PRI_IDE
VRM 10.1
ADDR CTRL CTRL
ADDR DATADATA
UDMA/100
LPC
PCI_32_BUS
DDR_SDRAM
VRM V10.1
DMI
3_PCI_x32
DIMM_CHA
S-ATA/150
4 x SATA
CK410 CLK
1 PCIE_x16
GRAPHIC
MCH DIMM_CHB
PORTS
PCIE_x16
INTEGRATED
GRAPHIC
Gb_LAN
SLOTS
3_PCIE_x1
PCIE_x1
W83627HF 5.1-CH
AUDIO
FSB: 800/533MHz
LPCUSB 2.0/1.1
AC97

Chapter 1: Introduction
1-7
Motherboard Features
CPU Latest CPU technology!
• Single Intel Pentium®4 Processor w/FSB 800 MHz or Celeron Processor
w/FSB 533 MHz in the 775-Land Grid Array Package.
• Supports Intel Hyper-Threading Technology.
Memory Latest memory technology!
• Dual/Single Channel DDR up to 4 GB of non-ECC unbuffered, two-way inter-
leaved or non-interleaved DDR-400/333 SDRAM in 4 DIMMS Note: See Section
2-4 for details.
Chipset Latest Intel chipset technology!
• Intel Glantsdale 915G
Expansion Slots
• One (1) PCI-Express x16 (intended for graphics)
• Three (3) PCI-Express x1
• Three (3) 32-bit PCI 33MHz (5V)
BIOS
• 4 Mb Firmware Hub AwardBIOS®Flash BIOS
• APM 1.2, DMI 2.3, PCI 2.2, ACPI 1.0, Plug and Play (PnP)
PC Health Monitoring
• Eight onboard voltage monitors for CPU core, +3.3V, +3.3V standby, +5V,
+1.5V, Vbat (battery voltage) and ±12V
• Fan status monitor with firmware/software 4 pin fan speed control
• SuperDoctor III, Watch Dog, NMI
• Environmental temperature monitoring via BIOS
• Power-up mode control for recovery from AC power loss
• System overheat LED and control
• System resource alert via Supero Doctor III
• Auto-switching voltage regulator for the CPU core

1-8
P8SGA User’s Manual
ACPI Features
• Microsoft OnNow
• Slow blinking LED for suspend state indicator
• BIOS support for USB keyboard
• Main switch override mechanism
• Internal/external modem ring-on
Onboard I/O
• 1 ATA/100 EIDE Channel s for a total of two IDE devices backward compatible
• Built in ICH6 SATA Controller, 4 connectors for 4 devices
• 1 floppy port interface (up to 2.88 MB)
• 2 Fast UART 16550 compatible serial ports
• Intel 82541 Gigabit Ethernet Controller
• 1 EPP (Enhanced Parallel Port) and ECP (Extended Capabilities Port) sup-
ported parallel port
• PS/2 mouse and PS/2 keyboard ports
• Up to 8 USB (Universal Serial Bus) 2.0 ports for a speed of up to 480Mbps 
Latest USB 2.0 technology!
• AC'97 audio high quality 6-channel sound
• Integrated (3rd generation) gfx core graphics on board
Other
• Wake-on-LAN
• Wake-on-Ring (WOR)
• Multiple CPU clock frequency ratio selections (set in BIOS)
• Suspend-to-RAM
• Onboard +5vsb warning LED ("LE1")
CD Utilities
• BIOS flash upgrade utility
• Drivers and software for Intel 915G chipset utilities
Dimensions
• ATX form factor, 12" x 9.5" (305 x 240 mm)

Chapter 1: Introduction
1-9
1-2 Chipset Overview
The Intel Grantsdale (915G) chipset contains two primary components: the Graphics
Memory Controller Hub (GMCH) and the I/O Controller Hub (ICH6). The Grantsdale
(915G) provides the performance and feature-set required for high-end single-pro-
cessor desktop solutions.
Graphics Memory Controller Hub (GMCH)
The function of the GMCH is to manage the data flow between five interfaces: the
CPU interface Front Side Bus (FSB), System Memory Interface (DRAM controller),
PCI Express Graphic Interface, I/O Controller and the Direct Media Interface (DMI).
The GMCH is optimized for the Prescott Processors in an LGA775 Package. It
supports one or two channels of unbuffered, non-ECC DDR 400/333 SDRAM. It
also supports the PCI-Express-based external graphics solutions.
The ACPI component provides the data buffering and interface arbitration required
for the system to interface efficiently. The Direct Media Interface (DMI) is a point-
to-point interconnection between the Grantsdale GMCH and the ICH6. Virtually
all communication between the GMCH and the ICH occurs over the Direct Media
Interface. DMI supports 2GB/s (IGB/s each direction) of bandwidth, using a 100
MHz differential clock.
Intel ICH6 System Features
The I/O Controller Hub provides the I/O subsystem with access to the rest of the
system. Functions and capabilities include:
*PCI Express Base Specification, Rev. 1.0a-compliant
*PCI 2.3
*ACPI Power Management Logic Support
*USB host interface
*Enhanced DMA Controller
*System Management Bus
*Low Pin Count (LPC) Interface
*Firmware Hub (FWH) Interface
Graphics Features/Display
The Grantsdale GMCH provides an integrated graphics accelerator, delivering 3D,
2D and video capabilities. It also provides interfaces to a progressive scan analog
monitor and two DVO devices. It is compliant with DVI specification and has a
high-speed interface to a digital display.

1-10
P8SGA User’s Manual
1-3 PC Health Monitoring
This section describes the PC health monitoring features of the P8SGA. The moth-
erboard has an onboard System Hardware Monitor chip that supports PC health
monitoring.
Eight Onboard Voltage Monitors for the CPU Core, Chipset
Voltage, +3.3V, +3.3V standby, +5V, 1.5V, Vbat and ±12V
The onboard voltage monitor will scan these voltages continuously. Once a voltage
becomes unstable, it will give a warning or send an error message to the screen.
Users can adjust the voltage thresholds to define the sensitivity of the voltage
monitor.
Fan Status Monitor with Firmware/Software
The PC health monitor can check the RPM status of the cooling fans via Supero
Doctor.
CPU Overheat LED and Control
This feature is available when the user enables the CPU overheat monitoring in the
BIOS. This allows the user to define an overheat temperature threshold. When this
temperature reaches the threshold, the CPU thermal trip feature will be activated,
and it will send a signal to the Speaker LED and, at the same time, the CPU speed
will be decreased to reduce heat dissipation.
1-4 Power Configuration Settings
This section describes features of your motherboard that deal with power and
power settings.
Slow Blinking LED for Suspend-State Indicator
When the CPU goes into a suspend state, the chassis power LED will start blinking
to indicate that the CPU is in suspend mode. When the user presses any key, the
CPU will wake-up and the LED will automatically stop blinking and remain on.
BIOS Support for USB Keyboard
If the USB keyboard is the only keyboard in the system, the keyboard will function
like a normal keyboard during system boot-up.
Main Switch Override Mechanism
When an ATX power supply is used, the power button can function as a system
suspend button. When the user presses the power button, the system will enter

Chapter 1: Introduction
1-11
a SoftOff state. The monitor will be suspended and the hard drive will spin down.
Pressing the power button again will cause the whole system to wake-up. During
the SoftOff state, the ATX power supply provides power to keep the required circuitry
in the system "alive." In case the system malfunctions and you want to turn off the
power, just press and hold the power button for 4 seconds. The power will turn off
and no power will be provided to the motherboard.
Wake-On-Ring (WOR) Header
Wake-up events can be triggered by a device such as the external modem ringing
when the system is in the SoftOff state. Note that external modem ring-on can only
be used with an ATX 2.01 (or above) compliant power supply.
1-5 Power Supply
As with all computer products, a stable power source is necessary for proper and
reliable operation. It is even more important for processors that have high CPU
clock rates of 1 GHz and faster.
The P8SGA accommodates 12V ATX power supplies. Although most
power supplies generally meet the specifications required by the CPU, some are
inadequate. A 2 amps of current supply on a 5V Standby rail is strongly recom-
mended.
It is strongly recommended that you use a high quality power supply that meets
12V ATX power supply Specification 1.1 or above. It is also required that the 12V
4-pin power connection (J41) be used for high-load configurations. In areas where
noisy power transmission is present, you may choose to install a line filter to shield
the computer from noise. It is recommended that you also install a power surge
protector to help avoid problems caused by power surges.
1-6 Super I/O
The disk drive adapter functions of the Super I/O chip include a floppy disk drive
controller that is compatible with industry standard 82077/765, a data separator,
write pre-compensation circuitry, decode logic, data rate selection, a clock genera-
tor, drive interface control logic and interrupt and DMA logic. The wide range of
functions integrated onto the Super I/O greatly reduces the number of components
required for interfacing with floppy disk drives. The Super I/O supports two 360
K, 720 K, 1.2 M, 1.44 M or 2.88 M disk drives and data transfer rates of 250 Kb/s,
500 Kb/s or 1 Mb/s.

1-12
P8SGA User’s Manual
It also provides two high-speed, 16550 compatible serial communication ports
(UARTs). Each UART includes a 16-byte send/receive FIFO, a programmable baud
rate generator, complete modem control capability and a processor interrupt sys-
tem. Both UARTs provide legacy speed with baud rate of up to 115.2 Kbps as well
as an advanced speed with baud rates of 250 K, 500 K, or 1 Mb/s, which support
higher speed modems.
The Super I/O provides functions that comply with ACPI (Advanced Configuration
and Power Interface), which includes support of legacy and ACPI power manage-
ment through a SMI or SCI function pin. It also features auto power management
to reduce power consumption.

Chapter 2: Installation
2-1
Chapter 2
Installation
2-1 Static-Sensitive Devices
Electric Static Discharge (ESD) can damage electronic components. To prevent
damage to your system board, it is important to handle it very carefully. The following
measures are generally sufficient to protect your equipment from ESD.
Precautions
• Use a grounded wrist strap designed to prevent static discharge.
• Touch a grounded metal object before removing the board from the antistatic
bag.
• Handle the board by its edges only; do not touch its components, peripheral
chips, memory modules or gold contacts.
• When handling chips or modules, avoid touching their pins.
• Put the motherboard and peripherals back into their antistatic bags when not in
use.
• For grounding purposes, make sure your computer chassis provides excellent
conductivity between the power supply, the case, the mounting fasteners and
the motherboard.
• Use only the correct type of CMOS onboard battery as specified by the Manufac-
turer. Do not install the CMOS onboard battery upside down to avoid a possible
explosion.
Unpacking
The motherboard is shipped in antistatic packaging to avoid static damage. When
unpacking the board, make sure the person handling it is static protected.
Installation Procedures
Follow the procedures as listed below to install the motherboard into a chassis:
1. Install the processor and the heatsink to the motherboard.
2. Install the motherboard in the chassis.
3. Install the memory modules and add-on cards.
4. Connect cables and install controllers/drivers.

2-2
P8SGA User's Manual
2-2 Processor and Heatsink Fan Installation
When handling the processor package, avoid placing direct pres-
sure on the label area of the fan.
IMPORTANT: Always connect the power cord last and always remove it before add-
ing, removing or changing any hardware components. Make sure that you install
the processor into the CPU socket before you install the CPU heatsink.
(*Note: The CPU heatsink fan is included only with the retail versions of the P8SGA.
If you buy a processor separately, use only a Supermicro or Intel certified heatsink
and fan.)
!
Installation of the LGA775 Processor
1. Press the socket lever to release
the load plate, which covers the CPU
socket, from its locking position.
Socket Lever
2. Gently lift the socket lever to open
the load plate.
Load Plate
Load Plate
