Supero SUPER P5MMA2 User manual

®
®
SUPER
Pentium System
P5MMA98/P5MMS98
P5MMA2/P5MMS2
USER’S MANUAL
Revision 1.3

The information in this User’s Manual has been carefully reviewed and is believed to be
accurate. The vendor assumes no responsibility for any inaccuracies that may be
contained in this document, makes no commitment to update or to keep current the
information in this manual, or to notify any person or organization of the updates.
SUPERMICRO COMPUTER reserves the right to make changes to the product described in
this manual at any time and without notice. This product, including software, if any, and
documentation may not, in whole or in part, be copied, photocopied, reproduced, translated
or reduced to any medium or machine without prior written consent.
IN NO EVENT WILL SUPERMICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR
INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE VENDOR SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF THE REPAIRING, REPLACING, OR
RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Unless you request and receive written permission from SUPERMICRO COMPUTER, you
may not copy any part of this document.
Information in this document is subject to change without notice. Other products and
companies referred to herein are trademarks or registered trademarks of their respective
companies or mark holders.
Copyright © 1997 by SUPERMICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America.

iii
Preface
About This Manual
This manual is written for system houses, PC technicians and
knowledgeable PC end users. It provides information for the instal-
lation and use of the SUPER P5MMA98/P5MMS98/P5MMA2/P5MMS2
motherboard, which supports the 75/90/100/120/133/150/166/180/
200/233 MHz Intel®Pentium®processor, Cyrix/IBM 5x86, 6x86,
AMD-K5, AMD-K6, MMXTM and future Pentium processors.
The Intel Pentium processor will take personal computer systems
to a new level of performance. The emergence of the PCI local bus
will also have a significant impact on PCs. Memory and I/O compo-
nents have also made significant strides in both performance and
integration, enhancing the CPU’s ability to move data quickly. Put-
ting these all together creates the next generation of PC systems.
Manual Organization
Chapter 1, Introduction, describes the features, specifications and
performance of the SUPER P5MMA98/P5MMS98/P5MMA2/P5MMS2
system board, provides detailed information about the chipset,
cache memory, main memory system, PC health monitoring, ACPI,
PC 98 and offers warranty information.
Refer to Chapter 2, Installation, for instructions on handling static-
sensitive devices, checking and/or configuring the jumpers for
manufacturing. Read this chapter when you want to configure CPU
and voltage settings, install or remove SIMM/DIMM memory mod-
ules, and to mount the system board in the chassis. Also refer to
this chapter to connect the floppy and hard disk drives, enhanced
IDE configurations, Infrared, USB, parallel port, serial ports, as well
as the cables for the power supply, reset cable, Keylock/Power LED,
speaker, overheat fan and keyboard.

If you encounter any problem, please see Chapter 3, Troubleshoot-
ing, which describes troubleshooting procedures for video, memo-
ry, and the setup configuration stored in memory. Instructions are
also included on contacting a technical assistance support repre-
sentative and returning merchandise for service and the BBS# for
BIOS upgrading.
P5MMA98/P5MMA2/P5MMS98/P5MMS2 User's Manual
iv

Preface
Table of Contents
Preface.......................................................................... iii
About This Manual ......................................................................................... iii
Manual Organization...................................................................................... iii
Quick Reference........................................................................................... viii
Chapter 1: Introduction ............................................. 1-1
1-1 Overview............................................................................................... 1-1
SUPER P5MMA98 Motherboard Layout ................................... 1-4
SUPER P5MMA2 Motherboard Layout ..................................... 1-5
SUPER P5MMS98 Motherboard Layout................................... 1-6
SUPER P5MMS2 Motherboard Layout ..................................... 1-7
SUPER P5MMA98 Features....................................................... 1-8
SUPER P5MMA2 Features ....................................................... 1-10
SUPER P5MMS98 Features..................................................... 1-12
SUPER P5MMS2 Features ....................................................... 1-14
1-2 PC Health Monitoring ....................................................................... 1-16
1-3 ACPI/PC 98 Features ....................................................................... 1-19
1-4 Power Supply .................................................................................... 1-21
1-5 Chipset Overview.............................................................................. 1-21
1-6 Super I/O Controller.......................................................................... 1-22
1-7 Warranty, Technical Support, and Service.................................. 1-23
Parts.............................................................................................. 1-23
BIOS .............................................................................................. 1-23
Labor............................................................................................. 1-23
Returns......................................................................................... 1-23
v

Chapter 2: Installation............................................... 2-1
2-1 Static-Sensitive Devices ................................................................... 2-1
Precautions ................................................................................... 2-1
Unpacking...................................................................................... 2-1
2-2 Configuring System Board Jumpers.............................................. 2-2
Manufacturing Settings ............................................................... 2-2
Changing the CPU Speed ......................................................... 2-3
CPU Voltage Settings ................................................................. 2-5
On-Board Memory ........................................................................ 2-6
Cache Size Selection .................................................................. 2-6
Green PC Function ...................................................................... 2-6
2-3 Mounting the Motherboard in the Chassis................................... 2-6
2-4 Connecting Cables............................................................................ 2-7
Power Supply Connectors.......................................................... 2-7
PS/2 Keyboard and Mouse Ports ............................................. 2-8
AT Keyboard Connector ............................................................... 2-9
Reset Cable Connector ............................................................ 2-10
Keylock/Power LED Cable Connector ................................... 2-10
Hard Drive LED .......................................................................... 2-11
Speaker Cable Connector........................................................ 2-11
PW_ON Connector..................................................................... 2-12
Infrared Connector ..................................................................... 2-12
FIR and CIR Connector ............................................................ 2-13
CMOS Clear................................................................................. 2-14
BIOS Flash Protection............................................................... 2-14
PC Health Monitor IRQ.............................................................. 2-14
Overheat LED.............................................................................. 2-15
External Battery ........................................................................... 2-15
Overheat Fan (2-pin) ................................................................. 2-16
Overheat Fan (3-pin) ................................................................. 2-16
CPU Fan....................................................................................... 2-17
vi

Table of Contents
vii
Chassis Fan ............................................................................... 2-17
Chassis Intrusion Connector .................................................. 2-18
Serial Ports.................................................................................. 2-18
USB Connectors......................................................................... 2-19
Power On/Off State .................................................................... 2-19
2-5 Installing/Removing the SIMM/DIMM Modules ........................... 2-20
SIMM/DIMM Module Installation............................................... 2-21
Removing SIMM/DIMM Modules .............................................. 2-21
2-6 Connecting Floppy and Hard Disk Drives.................................. 2-22
Parallel Port Connector ............................................................ 2-23
Floppy Connector ....................................................................... 2-24
Enhanced IDE Configurations ................................................ 2-25
Chapter 3: Troubleshooting...................................... 3-1
3-1 Troubleshooting Procedures ........................................................... 3-1
No Video ........................................................................................ 3-1
Troubleshooting Flowchart ........................................................ 3-2
Memory Error................................................................................. 3-3
Losing the System’s Setup Configuration.............................. 3-3
3-2 Technical Support Procedures........................................................ 3-4
3-3 Returning Merchandise for Service................................................ 3-4

P5MMA98/P5MMA2/P5MMS98/P5MMS2 User's Manual
viii
Quick Reference
Jumpers Function Page
JP2 CMOS Clear 2-14
JP3 External Battery 2-15
JP5, JP6, JP7 Bus Speed 2-3
JP9 (MMA98) Overheat Fan (2 pins) 2-16
JP15 (MMS98) Overheat Fan (2 pins) 2-16
JP24 (MMA98) Power On/Off State 2-19
JP27 (MMS98) Power On/Off State 2-19
J7 Boot Block Protection 2-14
J35, J36 Clock Multiplier 2-3
J45 (MMS98) Overheat LED 2-15
J46, J47, J48, J49 (MMA98) CPU Voltage 2-5
J55 (MMS98) IRQ for PC Health 2-14
J43 (MMA98) IRQ for PC Health 2-14
J42 (MMA98) Overheat LED 2-15
J51, J44 (MMA98) CPU Fan 2-16
J54 (MMS98) CPU Fan 2-16
J41 (MMA98) Overheat Fan (3 pins) 2-16
J53 (MMS98) Overheat Fan (3 pins) 2-16
J58 (MMS98) Chassis Fan 2-17
J59 (MMS98) Chassis Intrusion 2-18
J50 (MMA98) Chassis Intrusion 2-18
J37 (MMS98) USB 2-19
J38 (MMA98) USB 2-19

1-1
Chapter 1: Introduction
Chapter 1
Introduction
1-1 Overview
SUPER P5MMA98, P5MMS98, P5MMA2, P5MMS2 are PC 98-ready
motherboards designed to maximize user satisfaction and simplic-
ity in managing the personal computer. The four motherboards
support Intel®Pentium® 233/200/180/166/150/133/120/100/90/75
MHz, Cyrix/IBM 5x86, 6x86, AMD-K5, AMD-K6 and MMXTM processors.
They are based on Intel's advanced 430TX chipset to provide the
best possible platform for multimedia applications. They support
Synchronous DRAM (SDRAM), Concurrent PCI, and 33 MB/s Ultra
DMA for fast disk reads and writes.
All motheboards support PC Health Monitoring features including
CPU fan auto-off in sleep mode, CPU overheat alarm and LED,
hardware BIOS virus protection, and a switching voltage regulator
for the CPU core. SUPER P5MMA98 and P5MMS98 have an LM78
chip on-board which support additional PC Health Monitoring fea-
tures, including seven voltage monitors, fan status monitors with
firmware/software control on/off, CPU/chassis temperature moni-
tors, Intel LANDesk®Client Manager support, and system resource
alert. A chassis intrusion detection prevents system tampering.
ACPI/PC 98 features include Microsoft®OnNow power manage-
ment, with a slow blinking LED to indicate the system is in the
sleep state, BIOS support for the USB (Universal Serial Bus) key-
board, and real time clock wake-up alarm. The motherboards pro-
vide a main switch override mechanism, and external modem ring-
on if the system is in a SoftOff state.
SUPER P5MMA98 and P5MMA2 are ATX size (12" x 8.3"). SUPER
P5MMS98 and P5MMS2 are baby AT size (11" x 8.3"). All support up
to 256 MB of FPM, EDO, or SDRAM, with 512 KB pipelined burst
SRAM or L2 cache, using two 168-pin unbuffered 3.3 V DIMM sock-

1-2
SUPER P5MMA98/P5MMS98/P5MMA2/P5MMS2 User’s Manual
ets and four 72-pin 5 V SIMM sockets. They include four PCI and
four ISA slots with two EIDE, one floppy, ECP/EPP parallel port, PS/
2 mouse and keyboard connectors, two 16550-based serial ports,
two USBs, and a fast IR port. SUPER P5MMS98 and P5MMS2 sup-
port 2 Mb/s back-up tapes.
Figure 1-1. SUPER P5MMA98 Motherboard Picture

1-3
Chapter 1: Introduction
Figure 1-2. SUPER P5MMS98 Motherboard Picture
For maximum flexibility, all four motherboards support AT or ATX-
type power supply. The AMI WinBIOS has a 1 Mb flash memory for
convenient BIOS upgrade. The BIOS supports Advanced Power
Management (APM), Plug and Play, and PC health management.

1-4
SUPER P5MMA98/P5MMS98/P5MMA2/P5MMS2 User’s Manual
®
S UPER P5MMA98
J3
PRINTER
NOTE: DO NOT
POPULATE U6, J33,
AND J34 AT THE
SAMETIME!
————–———–—Intel CPU Speed————––—–————
J36 J35 JP5 JP6 JP7
233 OFF OFF 1-2 2-3 2-3 (MMX)
200 OFF ON 1-2 2-3 2-3
180 OFF ON 2-3 2-3 1-2
166 ON ON 1-2 2-3 2-3
150 ON ON 2-3 2-3 1-2 (60 MHz Bus)
150 ON OFF 2-3 1-2 1-2 (75 MHz Bus)
133 ON OFF 1-2 2-3 2-3
120 ON OFF 2-3 2-3 1-2
100 OFF OFF 1-2 2-3 2-3
90 OFF OFF 2-3 2-3 1-2
75 OFF OFF 2-3 2-3 2-3
——–—–——————————–—————————————
Bank2
J40
J35
J36
1
1
1
J49
J46
J47
J48
Bank1
Bank1
Bank2
Bank1
Bank0
U6
U5
JJ10
J9
J10
J8
J11
J12
J13
J14
BT2
-
BATTERY
+
1
1JP23
JJP23
JP7
JP6
JP5
1
1
FLOPPY
IDE 2 IDE 1
J19
J20 J21
1
11
Figure 1-3. SUPER P5MMA98 Motherboard Layout
BIOS
J42
U1
1 1
1
1
JP3 JP2 J7
J43
AT POWER
PW1
ATX POWER
J16
JP9
J44
J41
PMC FAN
J41, JP9: THERMAL FAN
U29
J4
PS/2 KB
PS/2
MOUSE
J37
USB
J38
J5
COM2
JJ5
COM1
J34
J33
J32
J31
CPU
U14 1
U16
U17
U13
U15
IR
HDD LED/KB LOCK/SPEAKER
PWRSW RESET
U39
LM78
——–——— Manufacturer Settings ————
JP2: 1-2 J40: OFF
JP24: 2-3 J43: OPEN
J7: 1-2
——–———————–————––——–—–—
——–—————————–————————
Cyrix/IBM Jumper Settings: p. 2-4
AMD Jumper Settings: p. 2-4
Future CPU Settings: p. 2-5
CPU Voltage Settings: p. 2-5
CMOS Clear: p. 2-14
——–———————–————––——–—–—
J51
J50
JP24
1
1

1-5
Chapter 1: Introduction
®
S UPER P5MMA2
J3
PRINTER
NOTE: DO NOT
POPULATE U6, J33,
AND J34 AT THE
SAMETIME!
————–———–—Intel CPU Speed————––—–————
J36 J35 JP5 JP6 JP7
233 OFF OFF 1-2 2-3 2-3 (MMX)
200 OFF ON 1-2 2-3 2-3
180 OFF ON 2-3 2-3 1-2
166 ON ON 1-2 2-3 2-3
150 ON ON 2-3 2-3 1-2 (60 MHz Bus)
150 ON OFF 2-3 1-2 1-2 (75 MHz Bus)
133 ON OFF 1-2 2-3 2-3
120 ON OFF 2-3 2-3 1-2
100 OFF OFF 1-2 2-3 2-3
90 OFF OFF 2-3 2-3 1-2
75 OFF OFF 2-3 2-3 2-3
——–—–——————————–—————————————
Bank2
J40
J35
J36
1
1
1
J49
J46
J47
J48
Bank1
Bank1
Bank2
Bank1
Bank0
U6
U5
JJ10
J9
J10
J8
J11
J12
J13
J14
BT2
-
BATTERY
+
1
1JP23
JJP23
HDD LED/KB LOCK/SPEAKER
JP7
JP6
JP5
1
1
FLOPPY
IDE 2 IDE 1
J19
J20 J21
1
11
Figure 1-4. SUPER P5MMA2 Motherboard Layout
BIOS
J42
U1
1 1
1
1
JP3 JP2 J7
J43
RESET
AT POWER
PW1
ATX POWER
J16
JP9
J44
J41
PMC FAN
J41, JP9: THERMAL FAN
U29
J4
PS/2 KB
PS/2
MOUSE
J37
USB
J38
J5
COM2
JJ5
COM1
PWRSWIR
J34
J33
J32
J31
CPU
U14 1
U16
U17
U13
U15
JP24
——–——— Manufacturer Settings ————
JP2: 1-2 J40: OFF
JP24: 2-3 J43: OPEN
J7: 1-2
——–———————–————––——–—–—
——–—————————–————————
Cyrix/IBM Jumper Settings: p. 2-4
AMD Jumper Settings: p. 2-4
Future CPU Settings: p. 2-5
CPU Voltage Settings: p. 2-5
CMOS Clear: p. 2-14
——–———————–————––——–—–—
1

1-6
SUPER P5MMA98/P5MMS98/P5MMA2/P5MMS2 User’s Manual
Figure 1-5. SUPER P5MMS98 Motherboard Layout
®
SUPER P5MMS98
J8 J9 J10 J42
J11 J12 J13 J14
JP3
1
EXT
BATTERY
USB
J38
J37
BATTERY +
-
BT2 JP14
1PS/2
MOUSE
JP12
PS/2
MOUSE
JP13
PS/2
KB
1
1
JP10
COM1
COM2
JP9 JP11 AT KB
PW1
J20J21
IDE
# 2
IDE
# 1
Bank
0Bank 1
U5 U6
J16
ATX POWER
J551U1
BIOS
J51
J50
J49
J48
SMM SLOT
J56
U15 J32J33J34 J31
Bank
1
U13
NOTE: DO NOT
POPULATE U6, J33,
AND J34 AT THE
SAMETIME!
CPU
296-pin ZIF
1
J47
J35 J36
J23 KEYLOCK PS ON RESET
SPEAKER
J57
J53
U17 U16
JP15
J45
Bank
1Bank
2Bank 2
1J7
J54
J59
1
U18
1U14
1
JP7 JP5 JP6
U37
LM78
J58
J3
PARALLEL
J19
FLOPPY
1
1
U29
FIR CON
CONSUMER
IR
1JP17
1JP18
HD LED
JP27
JP2
1
1
——–——— Manufacturer Settings ————
JP2: 1-2 J47: OFF
JP27: 2-3 J55: OPEN
J7: 1-2
——–———————–————––——–—–—
——–—————————–————————
Cyrix/IBM Jumper Settings: p. 2-4
AMD Jumper Settings: p. 2-4
Future CPU Settings: p. 2-5
CPU Voltage Settings: p. 2-5
CMOS Clear: p. 2-14
——–———————–————––——–—–—
————–———–—Intel CPU Speed————––—–————
J36 J35 JP5 JP6 JP7
233 OFF OFF 1-2 2-3 2-3 (MMX)
200 OFF ON 1-2 2-3 2-3
180 OFF ON 2-3 2-3 1-2
166 ON ON 1-2 2-3 2-3
150 ON ON 2-3 2-3 1-2 (60 MHz Bus)
150 ON OFF 2-3 1-2 1-2 (75 MHz Bus)
133 ON OFF 1-2 2-3 2-3
120 ON OFF 2-3 2-3 1-2
100 OFF OFF 1-2 2-3 2-3
90 OFF OFF 2-3 2-3 1-2
75 OFF OFF 2-3 2-3 2-3
——–—–——————————–—————————————

1-7
Chapter 1: Introduction
Figure 1-6. SUPER P5MMS2 Motherboard Layout
®
SUPER P5MMS2
J8 J9 J10 J42
J11 J12 J13 J14
JP3
1
EXT
BATTERY
USB
J38
J37
BATTERY +
-
BT2 JP14
1
JP2
JP12
PS/2
MOUSE
JP13
PS/2
KB
1
1
JP10
COM1
COM2
JP9 JP11 AT KB
PW1
J20J21
IDE
# 2
IDE
# 1
Bank
0Bank 1
U5 U6
J16
ATX POWER
J551U1
BIOS
J51
J50
J49
J48
SMM SLOT
J56
U15 J32J33J34 J31
Bank
1
U13
NOTE: DO NOT
POPULATE U6, J33,
AND J34 AT THE
SAMETIME!
CPU
296-pin ZIF
1
J47
J35 J36
J23
HD LED
KEYLOCK PS ON RESET
SPEAKER
J57
J53
U17 U16
JP15
J45
Bank
1Bank
2Bank 2
1J7
J54
U18
1U14
1
JP7 JP5 JP6
J58
J3
PARALLEL
J19
FLOPPY
1
1
U29
FIR CON
CONSUMER
IR
1JP17
1JP18
JP27
PS/2
MOUSE 1
1
——–——— Manufacturer Settings ————
JP2: 1-2 J47: OFF
JP27: 2-3 J55: OPEN
J7: 1-2
——–———————–————––——–—–—
——–—————————–————————
Cyrix/IBM Jumper Settings: p. 2-4
AMD Jumper Settings: p. 2-4
Future CPU Settings: p. 2-5
CPU Voltage Settings: p. 2-5
CMOS Clear: p. 2-14
——–———————–————––——–—–—
————–———–—Intel CPU Speed————––—–————
J36 J35 JP5 JP6 JP7
233 OFF OFF 1-2 2-3 2-3 (MMX)
200 OFF ON 1-2 2-3 2-3
180 OFF ON 2-3 2-3 1-2
166 ON ON 1-2 2-3 2-3
150 ON ON 2-3 2-3 1-2 (60 MHz Bus)
150 ON OFF 2-3 1-2 1-2 (75 MHz Bus)
133 ON OFF 1-2 2-3 2-3
120 ON OFF 2-3 2-3 1-2
100 OFF OFF 1-2 2-3 2-3
90 OFF OFF 2-3 2-3 1-2
75 OFF OFF 2-3 2-3 2-3
——–—–——————————–—————————————

1-8
SUPER P5MMA98/P5MMS98/P5MMA2/P5MMS2 User’s Manual
SUPER P5MMA98 Features
The following list covers the general features of SUPER P5MMA98.
CPU
•Pentium 233, 200, 180, 166, 150, 133, 120, 100, 90, 75 MHz,
MMXTM, Cyrix/IBM 5x86, 6x86, AMD-K5, K6, and future processors
Cache
•512 KB pipelined burst synchronous secondary cache
Memory
•256 MB of SDRAM, EDO or Fast Page DRAM memory
•4 72-pin 5V SIMM sockets and 2 168-pin unbuffered 3.3V DIMM
sockets
Chipset
•Intel 430TX
Expansion Slots
•4 PCI slots and 4 ISA slots
PC Health Monitoring (LM78)
•Seven on-board voltage monitors
•Three-fan status monitors with firmware/software control on/off
•CPU/chassis temperature control
•CPU fan auto-off in sleep mode
•CPU overheat control, alarm, and LED
•Chassis intrusion detection
•System resource alert
•Hardware BIOS virus protection
•Switching voltage regulator for the CPU core
•Intel LANDesk®Client Manager (LDCM) support
ACPI/PC 98 Features
•Microsoft OnNow (ATX power only)
•Slow blinking LED for sleep-state indicator
•BIOS support for USB keyboard
•Real time clock wake-up alarm
•Main switch override mechanism
•External modem ring-on if system is in SoftOff state

1-9
Chapter 1: Introduction
BIOS
•AMI®Flash BIOS with 1 Mb flash memory
•Advanced Power Management (APM) Green PC Function
•Plug and Play (PnP) and boot block support
•Desktop Management Interface 2.0 (DMI)
On-Board I/O
•2 EIDE interfaces support Mode 4, Ultra DMA Modes 0, 1, 2 with
transfer rates up to 33 MB/s
•1 floppy interface
•2 Fast UART 16550 serial ports
•EPP (Enhanced Parallel Port) and ECP (Extended Capabilities
Port) parallel port
•PS/2 mouse and PS/2 keyboard, 2 USB ports, Infra-red port
Power Supply
•ATX power supply (AT optional)
Board Type
•ATX size (12" x 8.3")

1-10
SUPER P5MMA98/P5MMS98/P5MMA2/P5MMS2 User’s Manual
SUPER P5MMA2 Features
The following list covers the general features of SUPER P5MMA2.
CPU
•Pentium 233, 200, 180, 166, 150, 133, 120, 100, 90, 75 MHz,
MMXTM, Cyrix/IBM 5x86, 6x86, AMD-K5, K6, and future processors
Cache
•512 KB pipelined burst synchronous secondary cache
Memory
•256 MB of SDRAM, EDO or Fast Page DRAM memory
•4 72-pin 5V SIMM sockets and 2 168-pin unbuffered 3.3V DIMM
sockets
Chipset
•Intel 430TX
Expansion Slots
•4 PCI slots and 4 ISA slots
PC Health Monitoring
•CPU fan auto-off in sleep mode
•CPU overheat control, alarm, and LED
•Hardware BIOS virus protection
•Switching voltage regulator for the CPU core
ACPI/PC 98 Features
•Microsoft OnNow (ATX power only)
•Slow blinking LED for sleep-state indicator
•BIOS support for USB keyboard
•Real time clock wake-up alarm
•Main switch override mechanism
•External modem ring-on if system is in SoftOff state
BIOS
•AMI®Flash BIOS with 1 Mb flash memory
•Advanced Power Management (APM) Green PC Function
•Plug and Play (PnP) and boot block support
•Desktop Management Interface 2.0 (DMI)

1-11
Chapter 1: Introduction
On-Board I/O
•2 EIDE interfaces support Mode 4, Ultra DMA Modes 0, 1, 2 with
transfer rates up to 33 MB/s
•1 floppy interface
•2 Fast UART 16550 serial ports
•EPP (Enhanced Parallel Port) and ECP (Extended Capabilities
Port) parallel port
•PS/2 mouse and PS/2 keyboard
• 2 USB ports, Infra-red port
Power Supply
•ATX power supply (AT optional)
Board Type
•ATX size (12" x 8.3")

1-12
SUPER P5MMA98/P5MMS98/P5MMA2/P5MMS2 User’s Manual
SUPER P5MMS98 Features
The following list covers the general features of SUPER P5MMS98.
CPU
•Pentium 233, 200, 180, 166, 150, 133, 120, 100, 90, 75 MHz,
MMXTM, Cyrix/IBM 5x86, 6x86, AMD-K5, K6, and future processors
Cache
•512 KB pipelined burst synchronous secondary cache
Memory
•256 MB of SDRAM, EDO or Fast Page DRAM memory
•4 72-pin 5V SIMM sockets and 2 168-pin unbuffered 3.3V DIMM
sockets
Chipset
•Intel 430TX
Expansion Slots
•4 PCI slots and 4 ISA slots
PC Health Monitoring (LM78)
•Seven on-board voltage monitors
•Three-fan status monitors with firmware/software control on/off
•CPU/chassis temperature control
•CPU fan auto-off in sleep mode
•CPU overheat control, alarm, and LED
•Chassis intrusion detection
•System resource alert
•Hardware BIOS virus protection
•Switching voltage regulator for the CPU core
•Intel LANDesk®Client Manager (LDCM) support
ACPI/PC 98 Features
•Microsoft OnNow (ATX power only)
•Slow blinking LED for sleep-state indicator
•BIOS support for USB keyboard
•Real time clock wake-up alarm
•Main switch override mechanism
•External modem ring-on if system is in SoftOff state
