SUPRENT BT475BX User manual

BT475BX SUPRENT Beard Trimmer
This user manual tries to ensure the accuracy of
the information, please kindly point it out for
our improvement in the future, if there is any
errors on the images or the texts. We'd be very
appreciated for your support and effort.
In addition: If the technique of the trimmer has
been improved, it will be upgraded and updated
in the new version as well as the specification
without announcement.

Notes Before Usng · · · · · · · · · · · · · · · · · · · · · · · · · · 1
Parts Name · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2
How To Use · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3
How To Use · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4
Cleaning And Maintenance · · · · · · · · · · · · · · · · · · · 5
Cautions · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 6
Warranty Certificate · · · · · · · · · · · · · · · · · · · · · · · · · · 7

PARTS NAME
Cleaning Brush
B Limit Comb
(11-20mm)
A Limit Comb
(1-10mm)
Type C (USB
Charging Cable)
Here with information concerns your health and safety. It is obligatory
to learn about all instructions for use and safety information before first
usage of the trimmer.
●Connect the power supply adaptor to AC mains supply 100-240 V.
●Disconnect the power supply adaptor from the mains supply outlet
when not in use or before cleaning.
●The supplying cord should not hang over the edge of a table or desktop,
nor touch hot surface.
●Do not touch the power supply adaptor with wet hands, especially
when plugging or unplugging it from the mains supply outlet.
●For the operation with mains use only the adaptor supplied with the
beard trimmer.
●Connect only to easily accessible mains supply outlet.
●Do not cover the adaptor; it can lead to dangerous temperature increase.
●Do not use during bath.
●Never immerse the device and cord in water or other liquids.
●Do not place the beard trimmer on wet surface or cloth during operation.
●Do not place or store the device in the area where it can fall into water.
●Do not use the device with damaged comb attachment. It can cause
injuries hazard.
●This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge.
●Children should be supervised to ensure that they do not play with
the appliance.
●Do not apply not recommended attachments.
●
Put the towel around the neck to avoid getting the cut hair under the
collar.
●Use the beard trimmer only as intended according to the here with instructions.
12

HOW TO USE HOW TO USE
Loading Accumulators And Cordless Operatio Comb Attachments
Inserting/Replacing
(1) In order to load the device move the ON/OFF switch to “OFF” position.In-
sert the plug of the adapter into appropriate mains supply outlet
(100-240 V), the LED indicator will change from red to green when full
charged. When fully loaded the hair clipper can operate more than 90
inutes.
(1) It is possible to select one of two comb attachments:
-The comb A can cut hair for 20 cutting lengths from 1-10mm, 0.5 mm
per set.
-The comb B can cut hair for 20 cutting lengths from 11-20mm, 0.5 mm
per set.
(2) Select the attachment according to the length of cutting.
(3) Insert it into the side guiding grooves of the clipper.
(4) Make sure that the two side protrusions are visibly locked in fastening
inlets of the comb attachment.
(5) Replace one attachment removing it and inserting another as described-
above.
(6) Turn right the cutting length adjustment knob , to increase the length
of cutting or left to reduce it.
Cutting And Beard Trimming With Comb.
Make sure that the appliance is fully charged when you
start to cut. Only use appliance on clean, dry hair. Do
not use it on freshly washed hair.
(1) Comb the beard in the direction of growth.
(2) Slide the beard trimmer comb into the guiding grooves
(3) When you are trimming for the first time, start at the
maximum trimming length setting to familiarize yourself
with the appliance. Switch on the appliance.
(4) Switch on the appliance.
-Move the appliance through the hair slowly.
-To trim in the most effective way, move the
appliance against thedirection of hair growth.
-Since all hair does not grow in the same direction,
you need to move the appliance in different directions.
-Make sure that the flat part of the comb is always
fully in contact with the scalp to obtain an even result.
-To achieve a good result with curly, sparse or long
hair, use a comb to guide the hair towards the appliance.
Cutting Hair Without Attachment
You can cut the hair in uniform length of 0.5–1 mm
without comb attachment.
(1)
For clipping the hairline of bristle and whiskers, neck shaving:
-Move the hair clipper slowly along hair.
-Turn the device so, that the back part was directed
upwards.
-Place the edge of the cutting head without comb
attachment on desired length of bristle hairline.
(2) Move down the clipper in operation.
34

Clean off the hair bits
on blades.
1
Clean off the hair bits on
machine body.
One drop to each arrowhead.
Between the blades
to press the cleaning handle
to clean off the hair bits. Motor's voltage: DC 3.7V
Charging time: 1. 5 hours
Working time: >90 minutes
Rated power: 2 W
3
2
4
CLEANING AND MAINTENANCE
1. While cleaning the devices with a wet cloth, do not clean it with
corrosive solution in any condition. Do not immerse the clipper in the
water.
2. Please keep the beard trimmer away from the children.
3.
Please note that this clipper may become warm during operating or
charging, it is normal. When using, don't hold the power softine, in
order to prevent possible accidents.
4.If the non-detachable part of the cord is damaged, it should be replaced
by the producer or at a proper service point or by a qualified person
in order to avoid any hazards.
5 6

BT475BX
7
