SureLife ThinTemp AET-R1F1 User manual

Intended use
Thank you for purchasing the SureLife® ThinTemp® Infrared
Thermometer, type AET-R1F1. This Infrared Thermometer is
a non-sterile, reusable, handheld device. It can be used by
consumers in homecare environment and doctors in clinic
as reference. It is intended for measuring the human body
temperature of individuals three months of age and older by
detecting infrared heat from the center of the forehead.
• For safe and proper use of this product, be sure to read
and fully understand Safety Precautions contained in
this user manual.
• Keep this manual with you for a convenient reference.
• Keep this manual in a proper way and avoid any loss.
• If you need other information that is not listed in the
instructions-for-use packet, please contact MHC Medical
Products at [phone].
The correct measurement method
to follow:
Measure forehead.
Distance 0.59” to 1.97”(15mm to 50mm)
Correct measurement method
1. Turn the thermometer on by
pressing the “ ” button. Choose
mode by pressing the“ ” button on
the shuto mode. A beep sound
will be heard following which the
screen will indication with ---˚F (˚C),
indicating the unit is ready for use.
2. Place the thermometer probe point
near the forehead and press the“ ”
button and release after ~1 second
and the thermometer will beep and
display the accurate temperature.
Whenever consecutive readings
are required, please wait for at least
5 seconds. The above procedure
can be repeated as many times as
required.
3. To turn o the device press and
hold the “ ”button for 5 seconds.
The thermometer will turn o
automatically after 60 seconds of
not being in use.
1
2
3
Unit description
Display information
Measuring location symbol: The icon indicates the correct
measuring position.
Temperature data indicator: The temperature reading is
displayed after measuring.
Temperature unit indicator: Unit of measuring temperature
shows ˚F or ˚C.
Low battery symbol: The icon prompts you to replace the
battery when the power is low.
Memory symbol: It shows in memory query mode currently.
Load and replace batteries
When the battery symbol “ ” appears, please replace with new
batteries immediately. The steps are as follows:
1. To remove the battery cover, press down on and slide the
battery cover towards the bottom of the thermometer.
2. Install 2 x AAA batteries according to the correct
positive and negative pole as shown on the inside
of the battery compartment.
3. Close the battery cover.
Warning:
Please take out the battery if you do not use the thermometer
for a long time. Please refer to the relevant laws and regulations
for the disposal of waste batteries.
Before take a measurement
1. It is suggested to read through the entire instructions for use
packet to understand how to operate the thermometer.
2. In order to avoid aecting accuracy of the device due to the
external too cold or too hot environment, it must be placed
in general environment of room temperature of 60.8˚F-95˚F
(16˚C-35˚C) for at least 30 minutes before use to avoid
incorrect measurement results.
3. The person measured should be kept at room temperature
for at least 20 minutes to make body temperature balanced.
4. After strenuous exercise, you should rest for at least 30
minutes before taking measurement.
5. Wipe the skin dry and push aside hair strands before
commencing.
6. When repeated measurements are made continuously,
move away the probe between each measurement and
rest for at least 5s before making the next to obtain the
most correct result.
7. The normal reading value is about 95.9˚F~100˚F
(35.5˚C~37.8˚C). The user should frequently take his or her
own temperature to know their average temperature. Pay
attention to physical changes or consult your doctor if there
is any abnormality.
8. Check to make sure the probe is clean before each
measurement to ensure accuracy of temperature reading.
See Page 7 for instructions on how to properly clean the
thermometer.
Correct position to measure
Forehead temperature mode
The correct measurement method
to follow:
Measure the forehead.
Distance 0.59” to 1.97” (15mm to 50mm)
Instructions for Use
1. Turn the thermometer on by pressing “ ” button.
2. A beep sound will be then heard and the screen will then
indication ----˚F (˚C). The unit is now ready for use. Using the
correct measuring position, point the thermometer’s probe
to the forehead, press “ ” and release after ~1 second, the
thermometer will beep and display the temperature. If a
consecutive reading is required then please wait for at least
5 second. Repeat the above procedure as often as required.
3. Press and hold the“ ”switch for 5 seconds to turn o the
thermometer. Or the unit will switch o automatically after
60 seconds.
• If a reading below 89.6˚F (32˚C) is recorded a“Lo”sign will
be displayed followed by 2 consecutive beeps.
• If a reading above 100˚F (37.8˚C) is recorded there will be
6 consecutive beeps.
• If a reading above 107.96˚F (42.2˚C) is recorded a“Hi” sign
will be displayed followed by 2 consecutive beeps.
Recalling Readings from Memory
1. Ensure the thermometer is switched o.
2. Press and hold the“ ”button for 4 seconds to put the device
on memory mode. The last reading will be displayed.
3. Press and release the“ ” button again to display the
next reading in a sequence from the last reading to
the rst reading.
4. The thermometer has the memory to recall the last
32 readings.
5. The thermometer will automatically turn o if it idles for
more than 12 seconds.
Changing Temperature Scales
1. Ensure the thermometer is switched o.
2. Press and hold the“ ”button for 8 seconds to bring it
into temperature mode. The current temperature unit
will be displayed.
3. Release and press the “ ” button again to toggle and
select between ˚C and ˚F.
4. The thermometer will switch o automaticaly if it idles
for more than 4 seconds.
Disposal
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact you local government for information
regarding the collection systems available. If electrical
appliances are disposed of in landlls or dumps,
hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and
well-being.
Explanation of Marks or Symbols
The following symbols may appear on the manual, Infrared
Thermometer and its accessories.
MUST OBSERVE
Means Obligatory with detailed items expressed in
words or gures within or beside the mark. Left one
means General Compulsory.
Follow instructions for use.
IMPLICATION OF SYMBOL
Type-BF applied part.
CE Mark: conforms to essential requirements of the
Medical Device Directive 93/42/EEC.
Caution: Consult accompanying documents.
Do not dispose this product as unsorted municipal
waste. Collection of such waste separately for
special treatment is necessary.
Transport package shall be kept away from rain.
Transport package shall not be exposed to sunlight.
Indicates correct upright position of the transport
package.
Contents of the transport package are fragile
therefore it shall be handled with care.
Indicates temperature limits within which the
transport package shall be stored and handled.
Non-ionizing electromagnetic radiation
Do not roll
Lot number
Production date
The device should not be used after the expiration
date listed on the retail box.
Protected against solid foreign objects of 12.5mm
dianeter and greater. protected against vertically
falling water drops when the device is tilted up
to 15˚.
Manufacturer
Authorized Representative in the European
Community
1 2 3 4 5
Memory symbol
Low battery
symbol
Measuring location symbol
Temperature unit
indicator
Temperature data
indicator
1 2 3
Battery compartment
(enlarged to
show detail)

Intended use
Thank you for purchasing the SureLife® ThinTemp® Infrared
Thermometer, type AET-R1F1. This Infrared Thermometer is
a non-sterile, reusable, handheld device. It can be used by
consumers in homecare environment and doctors in clinic
as reference. It is intended for measuring the human body
temperature of individuals three months of age and older by
detecting infrared heat from the center of the forehead.
• For safe and proper use of this product, be sure to read
and fully understand Safety Precautions contained in
this user manual.
• Keep this manual with you for a convenient reference.
• Keep this manual in a proper way and avoid any loss.
• If you need other information that is not listed in the
instructions-for-use packet, please contact MHC Medical
Products at [phone].
The correct measurement method
to follow:
Measure forehead.
Distance 0.59” to 1.97” (15mm to 50mm)
Correct measurement method
1. Turn the thermometer on by
pressing the “ ” button. Choose
mode by pressing the“ ” button on
the shuto mode. A beep sound
will be heard following which the
screen will indication with ---˚F (˚C),
indicating the unit is ready for use.
2. Place the thermometer probe point
near the forehead and press the“ ”
button and release after ~1 second
and the thermometer will beep and
display the accurate temperature.
Whenever consecutive readings
are required, please wait for at least
5 seconds. The above procedure
can be repeated as many times as
required.
3. To turn o the device press and
hold the “ ” button for 5 seconds.
The thermometer will turn o
automatically after 60 seconds of
not being in use.
1
2
3
Unit description
Display information
Measuring location symbol: The icon indicates the correct
measuring position.
Temperature data indicator: The temperature reading is
displayed after measuring.
Temperature unit indicator: Unit of measuring temperature
shows ˚F or ˚C.
Low battery symbol: The icon prompts you to replace the
battery when the power is low.
Memory symbol: It shows in memory query mode currently.
Load and replace batteries
When the battery symbol “ ” appears, please replace with new
batteries immediately. The steps are as follows:
1. To remove the battery cover, press down on and slide the
battery cover towards the bottom of the thermometer.
2. Install 2 x AAA batteries according to the correct
positive and negative pole as shown on the inside
of the battery compartment.
3. Close the battery cover.
Warning:
Please take out the battery if you do not use the thermometer
for a long time. Please refer to the relevant laws and regulations
for the disposal of waste batteries.
Before take a measurement
1. It is suggested to read through the entire instructions for use
packet to understand how to operate the thermometer.
2. In order to avoid aecting accuracy of the device due to the
external too cold or too hot environment, it must be placed
in general environment of room temperature of 60.8˚F-95˚F
(16˚C-35˚C) for at least 30 minutes before use to avoid
incorrect measurement results.
3. The person measured should be kept at room temperature
for at least 20 minutes to make body temperature balanced.
4. After strenuous exercise, you should rest for at least 30
minutes before taking measurement.
5. Wipe the skin dry and push aside hair strands before
commencing.
6. When repeated measurements are made continuously,
move away the probe between each measurement and
rest for at least 5s before making the next to obtain the
most correct result.
7. The normal reading value is about 95.9˚F~100˚F
(35.5˚C~37.8˚C). The user should frequently take his or her
own temperature to know their average temperature. Pay
attention to physical changes or consult your doctor if there
is any abnormality.
8. Check to make sure the probe is clean before each
measurement to ensure accuracy of temperature reading.
See Page 7 for instructions on how to properly clean the
thermometer.
Correct position to measure
Forehead temperature mode
The correct measurement method
to follow:
Measure the forehead.
Distance 0.59” to 1.97” (15mm to 50mm)
Instructions for Use
1. Turn the thermometer on by pressing “ ” button.
2. A beep sound will be then heard and the screen will then
indication ----˚F (˚C). The unit is now ready for use. Using the
correct measuring position, point the thermometer’s probe
to the forehead, press “ ” and release after ~1 second, the
thermometer will beep and display the temperature. If a
consecutive reading is required then please wait for at least
5 second. Repeat the above procedure as often as required.
3. Press and hold the“ ”switch for 5 seconds to turn o the
thermometer. Or the unit will switch o automatically after
60 seconds.
• If a reading below 89.6˚F (32˚C) is recorded a“Lo”sign will
be displayed followed by 2 consecutive beeps.
• If a reading above 100˚F (37.8˚C) is recorded there will be
6 consecutive beeps.
• If a reading above 107.96˚F (42.2˚C) is recorded a“Hi” sign
will be displayed followed by 2 consecutive beeps.
Recalling Readings from Memory
1. Ensure the thermometer is switched o.
2. Press and hold the“ ”button for 4 seconds to put the device
on memory mode. The last reading will be displayed.
3. Press and release the“ ” button again to display the
next reading in a sequence from the last reading to
the rst reading.
4. The thermometer has the memory to recall the last
32 readings.
5. The thermometer will automatically turn o if it idles for
more than 12 seconds.
Changing Temperature Scales
1. Ensure the thermometer is switched o.
2. Press and hold the“ ”button for 8 seconds to bring it
into temperature mode. The current temperature unit
will be displayed.
3. Release and press the “ ” button again to toggle and
select between ˚C and ˚F.
4. The thermometer will switch o automaticaly if it idles
for more than 4 seconds.
Disposal
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact you local government for information
regarding the collection systems available. If electrical
appliances are disposed of in landlls or dumps,
hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and
well-being.
Explanation of Marks or Symbols
The following symbols may appear on the manual, Infrared
Thermometer and its accessories.
MUST OBSERVE
Means Obligatory with detailed items expressed in
words or gures within or beside the mark. Left one
means General Compulsory.
Follow instructions for use.
IMPLICATION OF SYMBOL
Type-BF applied part.
CE Mark: conforms to essential requirements of the
Medical Device Directive 93/42/EEC.
Caution: Consult accompanying documents.
Do not dispose this product as unsorted municipal
waste. Collection of such waste separately for
special treatment is necessary.
Transport package shall be kept away from rain.
Transport package shall not be exposed to sunlight.
Indicates correct upright position of the transport
package.
Contents of the transport package are fragile
therefore it shall be handled with care.
Indicates temperature limits within which the
transport package shall be stored and handled.
Non-ionizing electromagnetic radiation
Do not roll
Lot number
Production date
The device should not be used after the expiration
date listed on the retail box.
Protected against solid foreign objects of 12.5mm
dianeter and greater. protected against vertically
falling water drops when the device is tilted up
to 15˚.
Manufacturer
Authorized Representative in the European
Community
1 2 3 4 5
Memory symbol
Low battery
symbol
Measuring location symbol
Temperature unit
indicator
Temperature data
indicator
1 2 3
Battery compartment
(enlarged to
show detail)

Intended use
Thank you for purchasing the SureLife® ThinTemp® Infrared
Thermometer, type AET-R1F1. This Infrared Thermometer is
a non-sterile, reusable, handheld device. It can be used by
consumers in homecare environment and doctors in clinic
as reference. It is intended for measuring the human body
temperature of individuals three months of age and older by
detecting infrared heat from the center of the forehead.
• For safe and proper use of this product, be sure to read
and fully understand Safety Precautions contained in
this user manual.
• Keep this manual with you for a convenient reference.
• Keep this manual in a proper way and avoid any loss.
• If you need other information that is not listed in the
instructions-for-use packet, please contact MHC Medical
Products at [phone].
The correct measurement method
to follow:
Measure forehead.
Distance 0.59” to 1.97” (15mm to 50mm)
Correct measurement method
1. Turn the thermometer on by
pressing the “ ” button. Choose
mode by pressing the“ ” button on
the shuto mode. A beep sound
will be heard following which the
screen will indication with ---˚F (˚C),
indicating the unit is ready for use.
2. Place the thermometer probe point
near the forehead and press the“ ”
button and release after ~1 second
and the thermometer will beep and
display the accurate temperature.
Whenever consecutive readings
are required, please wait for at least
5 seconds. The above procedure
can be repeated as many times as
required.
3. To turn o the device press and
hold the “ ” button for 5 seconds.
The thermometer will turn o
automatically after 60 seconds of
not being in use.
1
2
3
Unit description
Display information
Measuring location symbol: The icon indicates the correct
measuring position.
Temperature data indicator: The temperature reading is
displayed after measuring.
Temperature unit indicator: Unit of measuring temperature
shows ˚F or ˚C.
Low battery symbol: The icon prompts you to replace the
battery when the power is low.
Memory symbol: It shows in memory query mode currently.
Load and replace batteries
When the battery symbol “ ” appears, please replace with new
batteries immediately. The steps are as follows:
1. To remove the battery cover, press down on and slide the
battery cover towards the bottom of the thermometer.
2. Install 2 x AAA batteries according to the correct
positive and negative pole as shown on the inside
of the battery compartment.
3. Close the battery cover.
Warning:
Please take out the battery if you do not use the thermometer
for a long time. Please refer to the relevant laws and regulations
for the disposal of waste batteries.
Before take a measurement
1. It is suggested to read through the entire instructions for use
packet to understand how to operate the thermometer.
2. In order to avoid aecting accuracy of the device due to the
external too cold or too hot environment, it must be placed
in general environment of room temperature of 60.8˚F-95˚F
(16˚C-35˚C) for at least 30 minutes before use to avoid
incorrect measurement results.
3. The person measured should be kept at room temperature
for at least 20 minutes to make body temperature balanced.
4. After strenuous exercise, you should rest for at least 30
minutes before taking measurement.
5. Wipe the skin dry and push aside hair strands before
commencing.
6. When repeated measurements are made continuously,
move away the probe between each measurement and
rest for at least 5s before making the next to obtain the
most correct result.
7. The normal reading value is about 95.9˚F~100˚F
(35.5˚C~37.8˚C). The user should frequently take his or her
own temperature to know their average temperature. Pay
attention to physical changes or consult your doctor if there
is any abnormality.
8. Check to make sure the probe is clean before each
measurement to ensure accuracy of temperature reading.
See Page 7 for instructions on how to properly clean the
thermometer.
Correct position to measure
Forehead temperature mode
The correct measurement method
to follow:
Measure the forehead.
Distance 0.59” to 1.97” (15mm to 50mm)
Instructions for Use
1. Turn the thermometer on by pressing “ ” button.
2. A beep sound will be then heard and the screen will then
indication ----˚F (˚C). The unit is now ready for use. Using the
correct measuring position, point the thermometer’s probe
to the forehead, press “ ” and release after ~1 second, the
thermometer will beep and display the temperature. If a
consecutive reading is required then please wait for at least
5 second. Repeat the above procedure as often as required.
3. Press and hold the“ ”switch for 5 seconds to turn o the
thermometer. Or the unit will switch o automatically after
60 seconds.
• If a reading below 89.6˚F (32˚C) is recorded a“Lo”sign will
be displayed followed by 2 consecutive beeps.
• If a reading above 100˚F (37.8˚C) is recorded there will be
6 consecutive beeps.
• If a reading above 107.96˚F (42.2˚C) is recorded a“Hi” sign
will be displayed followed by 2 consecutive beeps.
Recalling Readings from Memory
1. Ensure the thermometer is switched o.
2. Press and hold the“ ”button for 4 seconds to put the device
on memory mode. The last reading will be displayed.
3. Press and release the“ ” button again to display the
next reading in a sequence from the last reading to
the rst reading.
4. The thermometer has the memory to recall the last
32 readings.
5. The thermometer will automatically turn o if it idles for
more than 12 seconds.
Changing Temperature Scales
1. Ensure the thermometer is switched o.
2. Press and hold the“ ”button for 8 seconds to bring it
into temperature mode. The current temperature unit
will be displayed.
3. Release and press the “ ” button again to toggle and
select between ˚C and ˚F.
4. The thermometer will switch o automaticaly if it idles
for more than 4 seconds.
Disposal
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact you local government for information
regarding the collection systems available. If electrical
appliances are disposed of in landlls or dumps,
hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and
well-being.
Explanation of Marks or Symbols
The following symbols may appear on the manual, Infrared
Thermometer and its accessories.
MUST OBSERVE
Means Obligatory with detailed items expressed in
words or gures within or beside the mark. Left one
means General Compulsory.
Follow instructions for use.
IMPLICATION OF SYMBOL
Type-BF applied part.
CE Mark: conforms to essential requirements of the
Medical Device Directive 93/42/EEC.
Caution: Consult accompanying documents.
Do not dispose this product as unsorted municipal
waste. Collection of such waste separately for
special treatment is necessary.
Transport package shall be kept away from rain.
Transport package shall not be exposed to sunlight.
Indicates correct upright position of the transport
package.
Contents of the transport package are fragile
therefore it shall be handled with care.
Indicates temperature limits within which the
transport package shall be stored and handled.
Non-ionizing electromagnetic radiation
Do not roll
Lot number
Production date
The device should not be used after the expiration
date listed on the retail box.
Protected against solid foreign objects of 12.5mm
dianeter and greater. protected against vertically
falling water drops when the device is tilted up
to 15˚.
Manufacturer
Authorized Representative in the European
Community
1 2 3 4 5
Memory symbol
Low battery
symbol
Measuring location symbol
Temperature unit
indicator
Temperature data
indicator
1 2 3
Battery compartment
(enlarged to
show detail)

Intended use
Thank you for purchasing the SureLife® ThinTemp® Infrared
Thermometer, type AET-R1F1. This Infrared Thermometer is
a non-sterile, reusable, handheld device. It can be used by
consumers in homecare environment and doctors in clinic
as reference. It is intended for measuring the human body
temperature of individuals three months of age and older by
detecting infrared heat from the center of the forehead.
• For safe and proper use of this product, be sure to read
and fully understand Safety Precautions contained in
this user manual.
• Keep this manual with you for a convenient reference.
• Keep this manual in a proper way and avoid any loss.
• If you need other information that is not listed in the
instructions-for-use packet, please contact MHC Medical
Products at [phone].
The correct measurement method
to follow:
Measure forehead.
Distance 0.59” to 1.97” (15mm to 50mm)
Correct measurement method
1. Turn the thermometer on by
pressing the “ ” button. Choose
mode by pressing the“ ” button on
the shuto mode. A beep sound
will be heard following which the
screen will indication with ---˚F (˚C),
indicating the unit is ready for use.
2. Place the thermometer probe point
near the forehead and press the“ ”
button and release after ~1 second
and the thermometer will beep and
display the accurate temperature.
Whenever consecutive readings
are required, please wait for at least
5 seconds. The above procedure
can be repeated as many times as
required.
3. To turn o the device press and
hold the “ ” button for 5 seconds.
The thermometer will turn o
automatically after 60 seconds of
not being in use.
1
2
3
Unit description
Display information
Measuring location symbol: The icon indicates the correct
measuring position.
Temperature data indicator: The temperature reading is
displayed after measuring.
Temperature unit indicator: Unit of measuring temperature
shows ˚F or ˚C.
Low battery symbol: The icon prompts you to replace the
battery when the power is low.
Memory symbol: It shows in memory query mode currently.
Load and replace batteries
When the battery symbol “ ” appears, please replace with new
batteries immediately. The steps are as follows:
1. To remove the battery cover, press down on and slide the
battery cover towards the bottom of the thermometer.
2. Install 2 x AAA batteries according to the correct
positive and negative pole as shown on the inside
of the battery compartment.
3. Close the battery cover.
Warning:
Please take out the battery if you do not use the thermometer
for a long time. Please refer to the relevant laws and regulations
for the disposal of waste batteries.
Before take a measurement
1. It is suggested to read through the entire instructions for use
packet to understand how to operate the thermometer.
2. In order to avoid aecting accuracy of the device due to the
external too cold or too hot environment, it must be placed
in general environment of room temperature of 60.8˚F-95˚F
(16˚C-35˚C) for at least 30 minutes before use to avoid
incorrect measurement results.
3. The person measured should be kept at room temperature
for at least 20 minutes to make body temperature balanced.
4. After strenuous exercise, you should rest for at least 30
minutes before taking measurement.
5. Wipe the skin dry and push aside hair strands before
commencing.
6. When repeated measurements are made continuously,
move away the probe between each measurement and
rest for at least 5s before making the next to obtain the
most correct result.
7. The normal reading value is about 95.9˚F~100˚F
(35.5˚C~37.8˚C). The user should frequently take his or her
own temperature to know their average temperature. Pay
attention to physical changes or consult your doctor if there
is any abnormality.
8. Check to make sure the probe is clean before each
measurement to ensure accuracy of temperature reading.
See Page 7 for instructions on how to properly clean the
thermometer.
Correct position to measure
Forehead temperature mode
The correct measurement method
to follow:
Measure the forehead.
Distance 0.59” to 1.97” (15mm to 50mm)
Instructions for Use
1. Turn the thermometer on by pressing “ ” button.
2. A beep sound will be then heard and the screen will then
indication ----˚F (˚C). The unit is now ready for use. Using the
correct measuring position, point the thermometer’s probe
to the forehead, press “ ” and release after ~1 second, the
thermometer will beep and display the temperature. If a
consecutive reading is required then please wait for at least
5 second. Repeat the above procedure as often as required.
3. Press and hold the“ ”switch for 5 seconds to turn o the
thermometer. Or the unit will switch o automatically after
60 seconds.
• If a reading below 89.6˚F (32˚C) is recorded a“Lo”sign will
be displayed followed by 2 consecutive beeps.
• If a reading above 100˚F (37.8˚C) is recorded there will be
6 consecutive beeps.
• If a reading above 107.96˚F (42.2˚C) is recorded a“Hi” sign
will be displayed followed by 2 consecutive beeps.
Recalling Readings from Memory
1. Ensure the thermometer is switched o.
2. Press and hold the“ ”button for 4 seconds to put the device
on memory mode. The last reading will be displayed.
3. Press and release the“ ” button again to display the
next reading in a sequence from the last reading to
the rst reading.
4. The thermometer has the memory to recall the last
32 readings.
5. The thermometer will automatically turn o if it idles for
more than 12 seconds.
Changing Temperature Scales
1. Ensure the thermometer is switched o.
2. Press and hold the“ ”button for 8 seconds to bring it
into temperature mode. The current temperature unit
will be displayed.
3. Release and press the “ ” button again to toggle and
select between ˚C and ˚F.
4. The thermometer will switch o automaticaly if it idles
for more than 4 seconds.
Disposal
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact you local government for information
regarding the collection systems available. If electrical
appliances are disposed of in landlls or dumps,
hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and
well-being.
Explanation of Marks or Symbols
The following symbols may appear on the manual, Infrared
Thermometer and its accessories.
MUST OBSERVE
Means Obligatory with detailed items expressed in
words or gures within or beside the mark. Left one
means General Compulsory.
Follow instructions for use.
IMPLICATION OF SYMBOL
Type-BF applied part.
CE Mark: conforms to essential requirements of the
Medical Device Directive 93/42/EEC.
Caution: Consult accompanying documents.
Do not dispose this product as unsorted municipal
waste. Collection of such waste separately for
special treatment is necessary.
Transport package shall be kept away from rain.
Transport package shall not be exposed to sunlight.
Indicates correct upright position of the transport
package.
Contents of the transport package are fragile
therefore it shall be handled with care.
Indicates temperature limits within which the
transport package shall be stored and handled.
Non-ionizing electromagnetic radiation
Do not roll
Lot number
Production date
The device should not be used after the expiration
date listed on the retail box.
Protected against solid foreign objects of 12.5mm
dianeter and greater. protected against vertically
falling water drops when the device is tilted up
to 15˚.
Manufacturer
Authorized Representative in the European
Community
1 2 3 4 5
Memory symbol
Low battery
symbol
Measuring location symbol
Temperature unit
indicator
Temperature data
indicator
1 2 3
Battery compartment
(enlarged to
show detail)

Intended use
Thank you for purchasing the SureLife® ThinTemp® Infrared
Thermometer, type AET-R1F1. This Infrared Thermometer is
a non-sterile, reusable, handheld device. It can be used by
consumers in homecare environment and doctors in clinic
as reference. It is intended for measuring the human body
temperature of individuals three months of age and older by
detecting infrared heat from the center of the forehead.
• For safe and proper use of this product, be sure to read
and fully understand Safety Precautions contained in
this user manual.
• Keep this manual with you for a convenient reference.
• Keep this manual in a proper way and avoid any loss.
• If you need other information that is not listed in the
instructions-for-use packet, please contact MHC Medical
Products at [phone].
The correct measurement method
to follow:
Measure forehead.
Distance 0.59” to 1.97” (15mm to 50mm)
Correct measurement method
1. Turn the thermometer on by
pressing the “ ” button. Choose
mode by pressing the“ ” button on
the shuto mode. A beep sound
will be heard following which the
screen will indication with ---˚F (˚C),
indicating the unit is ready for use.
2. Place the thermometer probe point
near the forehead and press the“ ”
button and release after ~1 second
and the thermometer will beep and
display the accurate temperature.
Whenever consecutive readings
are required, please wait for at least
5 seconds. The above procedure
can be repeated as many times as
required.
3. To turn o the device press and
hold the “ ” button for 5 seconds.
The thermometer will turn o
automatically after 60 seconds of
not being in use.
1
2
3
Unit description
Display information
Measuring location symbol: The icon indicates the correct
measuring position.
Temperature data indicator: The temperature reading is
displayed after measuring.
Temperature unit indicator: Unit of measuring temperature
shows ˚F or ˚C.
Low battery symbol: The icon prompts you to replace the
battery when the power is low.
Memory symbol: It shows in memory query mode currently.
Load and replace batteries
When the battery symbol “ ” appears, please replace with new
batteries immediately. The steps are as follows:
1. To remove the battery cover, press down on and slide the
battery cover towards the bottom of the thermometer.
2. Install 2 x AAA batteries according to the correct
positive and negative pole as shown on the inside
of the battery compartment.
3. Close the battery cover.
Warning:
Please take out the battery if you do not use the thermometer
for a long time. Please refer to the relevant laws and regulations
for the disposal of waste batteries.
Before take a measurement
1. It is suggested to read through the entire instructions for use
packet to understand how to operate the thermometer.
2. In order to avoid aecting accuracy of the device due to the
external too cold or too hot environment, it must be placed
in general environment of room temperature of 60.8˚F-95˚F
(16˚C-35˚C) for at least 30 minutes before use to avoid
incorrect measurement results.
3. The person measured should be kept at room temperature
for at least 20 minutes to make body temperature balanced.
4. After strenuous exercise, you should rest for at least 30
minutes before taking measurement.
5. Wipe the skin dry and push aside hair strands before
commencing.
6. When repeated measurements are made continuously,
move away the probe between each measurement and
rest for at least 5s before making the next to obtain the
most correct result.
7. The normal reading value is about 95.9˚F~100˚F
(35.5˚C~37.8˚C). The user should frequently take his or her
own temperature to know their average temperature. Pay
attention to physical changes or consult your doctor if there
is any abnormality.
8. Check to make sure the probe is clean before each
measurement to ensure accuracy of temperature reading.
See Page 7 for instructions on how to properly clean the
thermometer.
Correct position to measure
Forehead temperature mode
The correct measurement method
to follow:
Measure the forehead.
Distance 0.59” to 1.97” (15mm to 50mm)
Instructions for Use
1. Turn the thermometer on by pressing “ ” button.
2. A beep sound will be then heard and the screen will then
indication ----˚F (˚C). The unit is now ready for use. Using the
correct measuring position, point the thermometer’s probe
to the forehead, press “ ” and release after ~1 second, the
thermometer will beep and display the temperature. If a
consecutive reading is required then please wait for at least
5 second. Repeat the above procedure as often as required.
3. Press and hold the“ ”switch for 5 seconds to turn o the
thermometer. Or the unit will switch o automatically after
60 seconds.
• If a reading below 89.6˚F (32˚C) is recorded a“Lo”sign will
be displayed followed by 2 consecutive beeps.
• If a reading above 100˚F (37.8˚C) is recorded there will be
6 consecutive beeps.
• If a reading above 107.96˚F (42.2˚C) is recorded a“Hi” sign
will be displayed followed by 2 consecutive beeps.
Recalling Readings from Memory
1. Ensure the thermometer is switched o.
2. Press and hold the“ ”button for 4 seconds to put the device
on memory mode. The last reading will be displayed.
3. Press and release the“ ” button again to display the
next reading in a sequence from the last reading to
the rst reading.
4. The thermometer has the memory to recall the last
32 readings.
5. The thermometer will automatically turn o if it idles for
more than 12 seconds.
Changing Temperature Scales
1. Ensure the thermometer is switched o.
2. Press and hold the“ ”button for 8 seconds to bring it
into temperature mode. The current temperature unit
will be displayed.
3. Release and press the “ ” button again to toggle and
select between ˚C and ˚F.
4. The thermometer will switch o automaticaly if it idles
for more than 4 seconds.
Disposal
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact you local government for information
regarding the collection systems available. If electrical
appliances are disposed of in landlls or dumps,
hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and
well-being.
Explanation of Marks or Symbols
The following symbols may appear on the manual, Infrared
Thermometer and its accessories.
MUST OBSERVE
Means Obligatory with detailed items expressed in
words or gures within or beside the mark. Left one
means General Compulsory.
Follow instructions for use.
IMPLICATION OF SYMBOL
Type-BF applied part.
CE Mark: conforms to essential requirements of the
Medical Device Directive 93/42/EEC.
Caution: Consult accompanying documents.
Do not dispose this product as unsorted municipal
waste. Collection of such waste separately for
special treatment is necessary.
Transport package shall be kept away from rain.
Transport package shall not be exposed to sunlight.
Indicates correct upright position of the transport
package.
Contents of the transport package are fragile
therefore it shall be handled with care.
Indicates temperature limits within which the
transport package shall be stored and handled.
Non-ionizing electromagnetic radiation
Do not roll
Lot number
Production date
The device should not be used after the expiration
date listed on the retail box.
Protected against solid foreign objects of 12.5mm
dianeter and greater. protected against vertically
falling water drops when the device is tilted up
to 15˚.
Manufacturer
Authorized Representative in the European
Community
1 2 3 4 5
Memory symbol
Low battery
symbol
Measuring location symbol
Temperature unit
indicator
Temperature data
indicator
1 2 3
Battery compartment
(enlarged to
show detail)

Warning
Do not use the thermometer under temperature extremes (below
16˚C/60.8˚F or over 35˚C/95˚F) or humidity extremes (below 15%RH
or over 80%RH).
*Failing to do so may cause inaccuracy.
Do not expose the thermometer to temperature extremes (below
-20˚C/-4˚F or over 55˚C/131˚F) or humidity extremes (below 15%RH
or over 93%RH).
*Failing to do so may cause inaccuracy.
Temperature probe has been shocked and lax.
*Contact MHC Medical Products immediately.
It is dangerous for patients to perform a self-evaluation and
self-treatment based on the measuring results. Be sure to follow
doctors’ instruction.
*A self-evaluation may cause a disease to worsen.
Don’t touch or blow infrared sensor.
*A contaminated or broken infrared sensor may cause inaccuracy.
Clean a contaminated infrared sensor with a soft dry cloth in a
gentle manner.
*Cleaning with toilet tissue or paper towel may scratch the infrared
sensor, causing inaccuracy.
Install the battery in the right position according to the manual.
*Incorrect replacement will cause battery heat.
Do not immerse the thermomter in liquids.
*This instrument is not waterproof.
Do not use a mobile phone nearby when the thermometer is
working.
*Portable and mobile RF communications equipment can aect
MEDICAL ELECTICAL EQUIPMENT. Falling to do so may cause
inaccuracy.
The probe glass is made from special material which is not easy
broken.
*If there is any damage, stop using it and contact MHC Medical
Products immediately.
Do not modify this equipment without authorization of the
manufacturer.
*Contact MHC Medical Products immediately.
The device is not repairable and contains no user serviceable parts.
*If there is any problem, contact MHC Medical Products immediately.
The device requires no calibration.
*If there is any problem, contact MHC Medical Products immediately.
No modication of this equipment is allowed.
*If there is any problem, contact MHC Medical Products immediately.
If this equipment is modied, appropriate inspection and testing
must be conducted to ensure continued safe use of the equipment.
*If there is any problem, contact MHC Medical Products immediately.
The operator shall not touch the thermometer and the patient
simultaneously.
Keep the machine out of children’s reach.
*For accidental swallow of battery of protective lm, please consult
the doctor at once.
For temperature dierence between storage area and measurement
site, condition the thermometer for about 30 minutes in room
temperature (measurement site).
*Failing to do so may cause inaccuracy.
Ensure that children do not use the instrument unsupervised.
*some parts are small enough to be swallowed.
Error Messages
Error
Message Problem Solution
Hi
Temperature is
higher than 42.2˚C
(108˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Lo
Temperature is
lower than 32˚C
(89.6˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Err Sensor not welded Contact MHC Medical Products.
Low power Replace with new batteries
ErH
The temperature
of the measuring
environment is
too high.
Decrease the temperature of
the environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
ErL
The temperature
of the measuring
environment is
too low
Increase the tmperature of the
environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
Maintenance, storage and calibration
Maintenance:
1. Gently remove any dirt on the body using a soft and
dry cloth.
2. Use a cotton swab or soft cloth absorbed with alcohol, and
gently wipe the lens of the temperature measuring head.
After using the product, the product can be sterilized with
70% medical alcohol on the soft towel or cotton sliver. If the
probe tip is damaged, please contact MHC Medical Products.
3. Don’t wash with water or detergent containing abrasive or
benzene.
4. Do not immerse in liquids.
Storage:
1. The device must not be stored or used in locations that are
excessively high or low temperature or humidity, in direct
sunlight, or in close proximity to an electrical current or in
dusty locations. Otherwise inaccuracies may occur.
2. Remove the battery if the thermometer is not used for
longer than one month.
Calibration:
This thermometer is calibrated at the time of manufacture.
If the thermometer is used according to the instruction,
periodic recalibration is not required. If at any time you
question the accuracy of the measurement, please contact
MHC Medical Products immediately.
Don’t attempt to modify or reassemble the thermometer.
Technical Specications
Parameter Specication
Measurement Mode Forehead mode
Measurement Units Fahrenheit (˚F) and Celsius (˚C)
Operating
Conditions
60.8˚F to 95˚F (16˚C-35˚C) with a relative
humidity of 15%-80%
Storage Conditions -4˚F to 131˚F (-20˚C-+55˚C) with a relative
humidity of 15%-93%
Measurement
Distance
0.59” to 1.97” (15mm to 50mm) from the
measuring point
Forehead
temperature
measurement range
and accuracy
Measurement range: 89.6˚F-108˚F
(32.0˚C-42.2˚C)
Measurement accuracy: ±0.4˚F
(95.0˚F-107.6˚F)\±0.2˚C (35.0˚C-42.0˚C);
±0.5˚F (±0.3˚C) other range.
Memories recall 32 measurement recall
Dimensions 5.9” x 1.46” x 0.64” (150mmx37mmx16.3mm)
Weight 51g without batteries
Battery 2xAAA batteries (DC.3V)
Switch o Automatically switches o after 1 minute
Product life 5 years
New battery life 1000 times
Standard
The product is made under the ISO80601-2-56.
Guarantee
Two-year warranty is available from purchasing date, excluding
user-caused failures listed below:
1. Failure resulted in unauthorized disassembly and
modication.
2. Failure resulted in unexpected drop during application or
transportation.
3. Failure resulted in operation away from proper instruction in
User’s Manual.
Included in delievery
• Infrared thermometer
• Instructions for use
• 2 x AAA batteries
Distributed by MHC Medical Products, LLC.
8695 Seward Road, Faireld, OH 45011
Tel: [phone]
Email: [e-mail]
Website: MHCmed.com
Manufactured by Alicn Medical Shenzhen, Inc.
4/F, B Building, Shenfubao Modern Optical Factory,
Kengzi Street, Pingshan District, 518122, Shenzhen City,
PEOPLE’S REPUBLIC OF CHINA
Electromagnetic Compatibility
The ME EQUIPMENT or ME SYSTEM is suitable for home
healthcare and hospital environments.
Warning: Do not use near active HF (high-frequency) surgical
equipment and the RF shielded room of an ME system for
magnetic resonance imaging, where the intensity of EM
disturbances is high.
Warning: Use of this equipment adjacent to or stacked with
other equipment should be avoided because it could result
in improper operation. If such use is necessary, this equipment
and the other equipment should be observed to verify that
they are operating normally.
If any: a list of all cables and maximum lengths of cables
(if applicable), transducers and other ACCESSORIES that are
replaceable by the RESPONSIBLE ORGANIZATION and that are
likely to aect compliance of the ME EQUIPMENT or ME SYSTEM
with the requirements of Clause 7 (EMISSIONS) and Clause 8
(IMMUNITY). ACCESSORIES may be specied either generically
(e.g. shielded cable, load impedance) or specically (e.g. by
MANUFACTURER and EQUIPMENT OR TYPE REFERENCE).
If any: the performance of the ME EQUIPMENT or ME SYSTEM
that was determined to be ESSENTIAL PERFORMANCE and a
description of what the OPERATOR can expect if the ESSENTIAL
PERFORMANCE is lost or degraded due to EM DISTURBANCES
(the dened term “ESSENTIAL PERFORMANCE” need not be used).
1. All necessary instructions for maintaining BASIC SAFETY and
ESSENTIAL PERFORMANCE with regard to electromagnetic
disturbances for the excepted service life.
2. Guidance and manufacturer’s declaration -electromagnetic
emissions and Immunity.
Table 1
Guidance and manufacturer’s declaration –
electromagnetic emission
Emmisions Test Compliance
RF emissions
CISPR 11 Group 1
RF emissions
CISPR11 Class B
Harmonic emissions
IEC 61000-3-2 N/A
Voltage uctuations/icker emissions
IEC 61000-3-3 N/A
Table 2
Guidance and manufacturer’s declaration –
electromagnetic Immunity
Immunity Test IEC 60601-1-2
Test level Compliance Level
Electrostatic
discharge (ESD) IEC
61000-4-2
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
Electrical fast
transient/burst IEC
61000-4-4
Power supply lines:
±2 kV
input/output lines:
±1 kV
N/A
Surge
IEC 61000-4-5
line(s) to line(s): ±1 kV
line(s) to earth: ±2 kV
100 kHz repetition
frequency
N/A
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines.
IEC 61000-4-11
0% 0.5 cycle
At 0˚, 45˚, 90˚, 135˚,
180˚, 225˚, 270˚,
and 315˚
0% 1 cycle
And
70% 25/30 cycles
Singel phase: at 0
0% 300 cycle
N/A
Power frequency
magnetic eld
IEC 61000-4-8
30 A/m
50Hz/60Hz
30 A/m
50Hz/60Hz
Conduced RF
IEC61000-4-6
150Khz to 80MHz:
3Vrms
6Vrms (in ISM and
amateur radio bands)
80% Am at 1kHz
N/A
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
NOTE UTis the a.c. mians voltage prior to application of the test level.
Table 3
Guidance and manufacturer’s declaration - electromagnetic Immunity
Radiated RF
IEC61000-4-3
(Test
specications
for ENCLOSURE
PORT IMMUNITY
to RF wireless
communications
equipment)
Test
Frequency
(MHz)
Band
(MHz) Service Modulation Modulation (W)
Distance
(m)
IMMUNITY
TEST LEVEL
(V/m)
385 380–
390
TETRA
400
Pulse
modulation
18 Hz
1,8 0.3 27
450 380–
390
GMRS
460,
FRS
460
FM
± 5 kHz
deviation
1kHz sine
2 0.3 28
710
704–
787
LTE
Band
13,
17
Pulse
modulation
217 Hz
0,2 0.3 9
745
780
810
800–
960
GSM
800/900,
TETRA
800,
iDEN
820,
CDMA
850,
LTE
Band 5
Pulse
modulation
18 Hz
2 0.3 28
870
930
1720
1700–
1990
GSM
1800;
CDMA
1900;
GSM
1900;
DECT;
LTE
Band 1,
3,4,25;
UMTS
Pulse
modulation
217 Hz
2 0.3 28
1845
1970
2450 2400–
2570
Bluetooth,
WLAN,
802.11
b/g/n,
RFID
2450,
LTE
Band 7
Pulse
modulation
217 Hz
2 0.3 28
5240 5100–
5800
WLAN
802.11
a/n
Pulse
modulation
217 Hz
0,2 0.3 95240
5785
6 7 8 9 10
Version: 1.0
Date modied: 2020-04-17 AD-102620.1
Warning
Do not use the thermometer under temperature extremes (below
16˚C/60.8˚F or over 35˚C/95˚F) or humidity extremes (below 15%RH
or over 80%RH).
*Failing to do so may cause inaccuracy.
Do not expose the thermometer to temperature extremes (below
-20˚C/-4˚F or over 55˚C/131˚F) or humidity extremes (below 15%RH
or over 93%RH).
*Failing to do so may cause inaccuracy.
Temperature probe has been shocked and lax.
*Contact MHC Medical Products immediately.
It is dangerous for patients to perform a self-evaluation and
self-treatment based on the measuring results. Be sure to follow
doctors’ instruction.
*A self-evaluation may cause a disease to worsen.
Don’t touch or blow infrared sensor.
*A contaminated or broken infrared sensor may cause inaccuracy.
Clean a contaminated infrared sensor with a soft dry cloth in a
gentle manner.
*Cleaning with toilet tissue or paper towel may scratch the infrared
sensor, causing inaccuracy.
Install the battery in the right position according to the manual.
*Incorrect replacement will cause battery heat.
Do not immerse the thermomter in liquids.
*This instrument is not waterproof.
Do not use a mobile phone nearby when the thermometer is
working.
*Portable and mobile RF communications equipment can aect
MEDICAL ELECTICAL EQUIPMENT. Falling to do so may cause
inaccuracy.
The probe glass is made from special material which is not easy
broken.
*If there is any damage, stop using it and contact MHC Medical
Products immediately.
Do not modify this equipment without authorization of the
manufacturer.
*Contact MHC Medical Products immediately.
The device is not repairable and contains no user serviceable parts.
*If there is any problem, contact MHC Medical Products immediately.
The device requires no calibration.
*If there is any problem, contact MHC Medical Products immediately.
No modication of this equipment is allowed.
*If there is any problem, contact MHC Medical Products immediately.
If this equipment is modied, appropriate inspection and testing
must be conducted to ensure continued safe use of the equipment.
*If there is any problem, contact MHC Medical Products immediately.
The operator shall not touch the thermometer and the patient
simultaneously.
Keep the machine out of children’s reach.
*For accidental swallow of battery of protective lm, please consult
the doctor at once.
For temperature dierence between storage area and measurement
site, condition the thermometer for about 30 minutes in room
temperature (measurement site).
*Failing to do so may cause inaccuracy.
Ensure that children do not use the instrument unsupervised.
*some parts are small enough to be swallowed.
Error Messages
Error
Message Problem Solution
Hi
Temperature is
higher than 42.2˚C
(108˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Lo
Temperature is
lower than 32˚C
(89.6˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Err Sensor not welded Contact MHC Medical Products.
Low power Replace with new batteries
ErH
The temperature
of the measuring
environment is
too high.
Decrease the temperature of
the environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
ErL
The temperature
of the measuring
environment is
too low
Increase the tmperature of the
environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
Maintenance, storage and calibration
Maintenance:
1. Gently remove any dirt on the body using a soft and
dry cloth.
2. Use a cotton swab or soft cloth absorbed with alcohol, and
gently wipe the lens of the temperature measuring head.
After using the product, the product can be sterilized with
70% medical alcohol on the soft towel or cotton sliver. If the
probe tip is damaged, please contact MHC Medical Products.
3. Don’t wash with water or detergent containing abrasive or
benzene.
4. Do not immerse in liquids.
Storage:
1. The device must not be stored or used in locations that are
excessively high or low temperature or humidity, in direct
sunlight, or in close proximity to an electrical current or in
dusty locations. Otherwise inaccuracies may occur.
2. Remove the battery if the thermometer is not used for
longer than one month.
Calibration:
This thermometer is calibrated at the time of manufacture.
If the thermometer is used according to the instruction,
periodic recalibration is not required. If at any time you
question the accuracy of the measurement, please contact
MHC Medical Products immediately.
Don’t attempt to modify or reassemble the thermometer.
Technical Specications
Parameter Specication
Measurement Mode Forehead mode
Measurement Units Fahrenheit (˚F) and Celsius (˚C)
Operating
Conditions
60.8˚F to 95˚F (16˚C-35˚C) with a relative
humidity of 15%-80%
Storage Conditions -4˚F to 131˚F (-20˚C-+55˚C) with a relative
humidity of 15%-93%
Measurement
Distance
0.59” to 1.97” (15mm to 50mm) from the
measuring point
Forehead
temperature
measurement range
and accuracy
Measurement range: 89.6˚F-108˚F
(32.0˚C-42.2˚C)
Measurement accuracy: ±0.4˚F
(95.0˚F-107.6˚F)\±0.2˚C (35.0˚C-42.0˚C);
±0.5˚F (±0.3˚C) other range.
Memories recall 32 measurement recall
Dimensions 5.9” x 1.46” x 0.64” (150mmx37mmx16.3mm)
Weight 51g without batteries
Battery 2xAAA batteries (DC.3V)
Switch o Automatically switches o after 1 minute
Product life 5 years
New battery life 1000 times
Standard
The product is made under the ISO80601-2-56.
Guarantee
Two-year warranty is available from purchasing date, excluding
user-caused failures listed below:
1. Failure resulted in unauthorized disassembly and
modication.
2. Failure resulted in unexpected drop during application or
transportation.
3. Failure resulted in operation away from proper instruction in
User’s Manual.
Included in delievery
• Infrared thermometer
• Instructions for use
• 2 x AAA batteries
Distributed by MHC Medical Products, LLC.
8695 Seward Road, Faireld, OH 45011
Tel: [phone]
Email: [e-mail]
Website: MHCmed.com
Manufactured by Alicn Medical Shenzhen, Inc.
4/F, B Building, Shenfubao Modern Optical Factory,
Kengzi Street, Pingshan District, 518122, Shenzhen City,
PEOPLE’S REPUBLIC OF CHINA
Electromagnetic Compatibility
The ME EQUIPMENT or ME SYSTEM is suitable for home
healthcare and hospital environments.
Warning: Do not use near active HF (high-frequency) surgical
equipment and the RF shielded room of an ME system for
magnetic resonance imaging, where the intensity of EM
disturbances is high.
Warning: Use of this equipment adjacent to or stacked with
other equipment should be avoided because it could result
in improper operation. If such use is necessary, this equipment
and the other equipment should be observed to verify that
they are operating normally.
If any: a list of all cables and maximum lengths of cables
(if applicable), transducers and other ACCESSORIES that are
replaceable by the RESPONSIBLE ORGANIZATION and that are
likely to aect compliance of the ME EQUIPMENT or ME SYSTEM
with the requirements of Clause 7 (EMISSIONS) and Clause 8
(IMMUNITY). ACCESSORIES may be specied either generically
(e.g. shielded cable, load impedance) or specically (e.g. by
MANUFACTURER and EQUIPMENT OR TYPE REFERENCE).
If any: the performance of the ME EQUIPMENT or ME SYSTEM
that was determined to be ESSENTIAL PERFORMANCE and a
description of what the OPERATOR can expect if the ESSENTIAL
PERFORMANCE is lost or degraded due to EM DISTURBANCES
(the dened term “ESSENTIAL PERFORMANCE” need not be used).
1. All necessary instructions for maintaining BASIC SAFETY and
ESSENTIAL PERFORMANCE with regard to electromagnetic
disturbances for the excepted service life.
2. Guidance and manufacturer’s declaration -electromagnetic
emissions and Immunity.
Table 1
Guidance and manufacturer’s declaration –
electromagnetic emission
Emmisions Test Compliance
RF emissions
CISPR 11 Group 1
RF emissions
CISPR11 Class B
Harmonic emissions
IEC 61000-3-2 N/A
Voltage uctuations/icker emissions
IEC 61000-3-3 N/A
Table 2
Guidance and manufacturer’s declaration –
electromagnetic Immunity
Immunity Test IEC 60601-1-2
Test level Compliance Level
Electrostatic
discharge (ESD) IEC
61000-4-2
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
Electrical fast
transient/burst IEC
61000-4-4
Power supply lines:
±2 kV
input/output lines:
±1 kV
N/A
Surge
IEC 61000-4-5
line(s) to line(s): ±1 kV
line(s) to earth: ±2 kV
100 kHz repetition
frequency
N/A
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines.
IEC 61000-4-11
0% 0.5 cycle
At 0˚, 45˚, 90˚, 135˚,
180˚, 225˚, 270˚,
and 315˚
0% 1 cycle
And
70% 25/30 cycles
Singel phase: at 0
0% 300 cycle
N/A
Power frequency
magnetic eld
IEC 61000-4-8
30 A/m
50Hz/60Hz
30 A/m
50Hz/60Hz
Conduced RF
IEC61000-4-6
150Khz to 80MHz:
3Vrms
6Vrms (in ISM and
amateur radio bands)
80% Am at 1kHz
N/A
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
NOTE UTis the a.c. mians voltage prior to application of the test level.
Table 3
Guidance and manufacturer’s declaration - electromagnetic Immunity
Radiated RF
IEC61000-4-3
(Test
specications
for ENCLOSURE
PORT IMMUNITY
to RF wireless
communications
equipment)
Test
Frequency
(MHz)
Band
(MHz) Service Modulation Modulation (W)
Distance
(m)
IMMUNITY
TEST LEVEL
(V/m)
385 380–
390
TETRA
400
Pulse
modulation
18 Hz
1,8 0.3 27
450 380–
390
GMRS
460,
FRS
460
FM
± 5 kHz
deviation
1kHz sine
2 0.3 28
710
704–
787
LTE
Band
13,
17
Pulse
modulation
217 Hz
0,2 0.3 9
745
780
810
800–
960
GSM
800/900,
TETRA
800,
iDEN
820,
CDMA
850,
LTE
Band 5
Pulse
modulation
18 Hz
2 0.3 28
870
930
1720
1700–
1990
GSM
1800;
CDMA
1900;
GSM
1900;
DECT;
LTE
Band 1,
3,4,25;
UMTS
Pulse
modulation
217 Hz
2 0.3 28
1845
1970
2450 2400–
2570
Bluetooth,
WLAN,
802.11
b/g/n,
RFID
2450,
LTE
Band 7
Pulse
modulation
217 Hz
2 0.3 28
5240 5100–
5800
WLAN
802.11
a/n
Pulse
modulation
217 Hz
0,2 0.3 95240
5785
6 7 8 9 10
Version: 1.0
Date modied: 2020-04-17 AD-102620.1

Warning
Do not use the thermometer under temperature extremes (below
16˚C/60.8˚F or over 35˚C/95˚F) or humidity extremes (below 15%RH
or over 80%RH).
*Failing to do so may cause inaccuracy.
Do not expose the thermometer to temperature extremes (below
-20˚C/-4˚F or over 55˚C/131˚F) or humidity extremes (below 15%RH
or over 93%RH).
*Failing to do so may cause inaccuracy.
Temperature probe has been shocked and lax.
*Contact MHC Medical Products immediately.
It is dangerous for patients to perform a self-evaluation and
self-treatment based on the measuring results. Be sure to follow
doctors’ instruction.
*A self-evaluation may cause a disease to worsen.
Don’t touch or blow infrared sensor.
*A contaminated or broken infrared sensor may cause inaccuracy.
Clean a contaminated infrared sensor with a soft dry cloth in a
gentle manner.
*Cleaning with toilet tissue or paper towel may scratch the infrared
sensor, causing inaccuracy.
Install the battery in the right position according to the manual.
*Incorrect replacement will cause battery heat.
Do not immerse the thermomter in liquids.
*This instrument is not waterproof.
Do not use a mobile phone nearby when the thermometer is
working.
*Portable and mobile RF communications equipment can aect
MEDICAL ELECTICAL EQUIPMENT. Falling to do so may cause
inaccuracy.
The probe glass is made from special material which is not easy
broken.
*If there is any damage, stop using it and contact MHC Medical
Products immediately.
Do not modify this equipment without authorization of the
manufacturer.
*Contact MHC Medical Products immediately.
The device is not repairable and contains no user serviceable parts.
*If there is any problem, contact MHC Medical Products immediately.
The device requires no calibration.
*If there is any problem, contact MHC Medical Products immediately.
No modication of this equipment is allowed.
*If there is any problem, contact MHC Medical Products immediately.
If this equipment is modied, appropriate inspection and testing
must be conducted to ensure continued safe use of the equipment.
*If there is any problem, contact MHC Medical Products immediately.
The operator shall not touch the thermometer and the patient
simultaneously.
Keep the machine out of children’s reach.
*For accidental swallow of battery of protective lm, please consult
the doctor at once.
For temperature dierence between storage area and measurement
site, condition the thermometer for about 30 minutes in room
temperature (measurement site).
*Failing to do so may cause inaccuracy.
Ensure that children do not use the instrument unsupervised.
*some parts are small enough to be swallowed.
Error Messages
Error
Message Problem Solution
Hi
Temperature is
higher than 42.2˚C
(108˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Lo
Temperature is
lower than 32˚C
(89.6˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Err Sensor not welded Contact MHC Medical Products.
Low power Replace with new batteries
ErH
The temperature
of the measuring
environment is
too high.
Decrease the temperature of
the environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
ErL
The temperature
of the measuring
environment is
too low
Increase the tmperature of the
environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
Maintenance, storage and calibration
Maintenance:
1. Gently remove any dirt on the body using a soft and
dry cloth.
2. Use a cotton swab or soft cloth absorbed with alcohol, and
gently wipe the lens of the temperature measuring head.
After using the product, the product can be sterilized with
70% medical alcohol on the soft towel or cotton sliver. If the
probe tip is damaged, please contact MHC Medical Products.
3. Don’t wash with water or detergent containing abrasive or
benzene.
4. Do not immerse in liquids.
Storage:
1. The device must not be stored or used in locations that are
excessively high or low temperature or humidity, in direct
sunlight, or in close proximity to an electrical current or in
dusty locations. Otherwise inaccuracies may occur.
2. Remove the battery if the thermometer is not used for
longer than one month.
Calibration:
This thermometer is calibrated at the time of manufacture.
If the thermometer is used according to the instruction,
periodic recalibration is not required. If at any time you
question the accuracy of the measurement, please contact
MHC Medical Products immediately.
Don’t attempt to modify or reassemble the thermometer.
Technical Specications
Parameter Specication
Measurement Mode Forehead mode
Measurement Units Fahrenheit (˚F) and Celsius (˚C)
Operating
Conditions
60.8˚F to 95˚F (16˚C-35˚C) with a relative
humidity of 15%-80%
Storage Conditions -4˚F to 131˚F (-20˚C-+55˚C) with a relative
humidity of 15%-93%
Measurement
Distance
0.59” to 1.97” (15mm to 50mm) from the
measuring point
Forehead
temperature
measurement range
and accuracy
Measurement range: 89.6˚F-108˚F
(32.0˚C-42.2˚C)
Measurement accuracy: ±0.4˚F
(95.0˚F-107.6˚F)\±0.2˚C (35.0˚C-42.0˚C);
±0.5˚F (±0.3˚C) other range.
Memories recall 32 measurement recall
Dimensions 5.9” x 1.46” x 0.64” (150mmx37mmx16.3mm)
Weight 51g without batteries
Battery 2xAAA batteries (DC.3V)
Switch o Automatically switches o after 1 minute
Product life 5 years
New battery life 1000 times
Standard
The product is made under the ISO80601-2-56.
Guarantee
Two-year warranty is available from purchasing date, excluding
user-caused failures listed below:
1. Failure resulted in unauthorized disassembly and
modication.
2. Failure resulted in unexpected drop during application or
transportation.
3. Failure resulted in operation away from proper instruction in
User’s Manual.
Included in delievery
• Infrared thermometer
• Instructions for use
• 2 x AAA batteries
Distributed by MHC Medical Products, LLC.
8695 Seward Road, Faireld, OH 45011
Tel: [phone]
Email: [e-mail]
Website: MHCmed.com
Manufactured by Alicn Medical Shenzhen, Inc.
4/F, B Building, Shenfubao Modern Optical Factory,
Kengzi Street, Pingshan District, 518122, Shenzhen City,
PEOPLE’S REPUBLIC OF CHINA
Electromagnetic Compatibility
The ME EQUIPMENT or ME SYSTEM is suitable for home
healthcare and hospital environments.
Warning: Do not use near active HF (high-frequency) surgical
equipment and the RF shielded room of an ME system for
magnetic resonance imaging, where the intensity of EM
disturbances is high.
Warning: Use of this equipment adjacent to or stacked with
other equipment should be avoided because it could result
in improper operation. If such use is necessary, this equipment
and the other equipment should be observed to verify that
they are operating normally.
If any: a list of all cables and maximum lengths of cables
(if applicable), transducers and other ACCESSORIES that are
replaceable by the RESPONSIBLE ORGANIZATION and that are
likely to aect compliance of the ME EQUIPMENT or ME SYSTEM
with the requirements of Clause 7 (EMISSIONS) and Clause 8
(IMMUNITY). ACCESSORIES may be specied either generically
(e.g. shielded cable, load impedance) or specically (e.g. by
MANUFACTURER and EQUIPMENT OR TYPE REFERENCE).
If any: the performance of the ME EQUIPMENT or ME SYSTEM
that was determined to be ESSENTIAL PERFORMANCE and a
description of what the OPERATOR can expect if the ESSENTIAL
PERFORMANCE is lost or degraded due to EM DISTURBANCES
(the dened term “ESSENTIAL PERFORMANCE” need not be used).
1. All necessary instructions for maintaining BASIC SAFETY and
ESSENTIAL PERFORMANCE with regard to electromagnetic
disturbances for the excepted service life.
2. Guidance and manufacturer’s declaration -electromagnetic
emissions and Immunity.
Table 1
Guidance and manufacturer’s declaration –
electromagnetic emission
Emmisions Test Compliance
RF emissions
CISPR 11 Group 1
RF emissions
CISPR11 Class B
Harmonic emissions
IEC 61000-3-2 N/A
Voltage uctuations/icker emissions
IEC 61000-3-3 N/A
Table 2
Guidance and manufacturer’s declaration –
electromagnetic Immunity
Immunity Test IEC 60601-1-2
Test level Compliance Level
Electrostatic
discharge (ESD) IEC
61000-4-2
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
Electrical fast
transient/burst IEC
61000-4-4
Power supply lines:
±2 kV
input/output lines:
±1 kV
N/A
Surge
IEC 61000-4-5
line(s) to line(s): ±1 kV
line(s) to earth: ±2 kV
100 kHz repetition
frequency
N/A
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines.
IEC 61000-4-11
0% 0.5 cycle
At 0˚, 45˚, 90˚, 135˚,
180˚, 225˚, 270˚,
and 315˚
0% 1 cycle
And
70% 25/30 cycles
Singel phase: at 0
0% 300 cycle
N/A
Power frequency
magnetic eld
IEC 61000-4-8
30 A/m
50Hz/60Hz
30 A/m
50Hz/60Hz
Conduced RF
IEC61000-4-6
150Khz to 80MHz:
3Vrms
6Vrms (in ISM and
amateur radio bands)
80% Am at 1kHz
N/A
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
NOTE UTis the a.c. mians voltage prior to application of the test level.
Table 3
Guidance and manufacturer’s declaration - electromagnetic Immunity
Radiated RF
IEC61000-4-3
(Test
specications
for ENCLOSURE
PORT IMMUNITY
to RF wireless
communications
equipment)
Test
Frequency
(MHz)
Band
(MHz) Service Modulation Modulation (W)
Distance
(m)
IMMUNITY
TEST LEVEL
(V/m)
385 380–
390
TETRA
400
Pulse
modulation
18 Hz
1,8 0.3 27
450 380–
390
GMRS
460,
FRS
460
FM
± 5 kHz
deviation
1kHz sine
2 0.3 28
710
704–
787
LTE
Band
13,
17
Pulse
modulation
217 Hz
0,2 0.3 9
745
780
810
800–
960
GSM
800/900,
TETRA
800,
iDEN
820,
CDMA
850,
LTE
Band 5
Pulse
modulation
18 Hz
2 0.3 28
870
930
1720
1700–
1990
GSM
1800;
CDMA
1900;
GSM
1900;
DECT;
LTE
Band 1,
3,4,25;
UMTS
Pulse
modulation
217 Hz
2 0.3 28
1845
1970
2450 2400–
2570
Bluetooth,
WLAN,
802.11
b/g/n,
RFID
2450,
LTE
Band 7
Pulse
modulation
217 Hz
2 0.3 28
5240 5100–
5800
WLAN
802.11
a/n
Pulse
modulation
217 Hz
0,2 0.3 95240
5785
6 7 8 9 10
Version: 1.0
Date modied: 2020-04-17 AD-102620.1
Warning
Do not use the thermometer under temperature extremes (below
16˚C/60.8˚F or over 35˚C/95˚F) or humidity extremes (below 15%RH
or over 80%RH).
*Failing to do so may cause inaccuracy.
Do not expose the thermometer to temperature extremes (below
-20˚C/-4˚F or over 55˚C/131˚F) or humidity extremes (below 15%RH
or over 93%RH).
*Failing to do so may cause inaccuracy.
Temperature probe has been shocked and lax.
*Contact MHC Medical Products immediately.
It is dangerous for patients to perform a self-evaluation and
self-treatment based on the measuring results. Be sure to follow
doctors’ instruction.
*A self-evaluation may cause a disease to worsen.
Don’t touch or blow infrared sensor.
*A contaminated or broken infrared sensor may cause inaccuracy.
Clean a contaminated infrared sensor with a soft dry cloth in a
gentle manner.
*Cleaning with toilet tissue or paper towel may scratch the infrared
sensor, causing inaccuracy.
Install the battery in the right position according to the manual.
*Incorrect replacement will cause battery heat.
Do not immerse the thermomter in liquids.
*This instrument is not waterproof.
Do not use a mobile phone nearby when the thermometer is
working.
*Portable and mobile RF communications equipment can aect
MEDICAL ELECTICAL EQUIPMENT. Falling to do so may cause
inaccuracy.
The probe glass is made from special material which is not easy
broken.
*If there is any damage, stop using it and contact MHC Medical
Products immediately.
Do not modify this equipment without authorization of the
manufacturer.
*Contact MHC Medical Products immediately.
The device is not repairable and contains no user serviceable parts.
*If there is any problem, contact MHC Medical Products immediately.
The device requires no calibration.
*If there is any problem, contact MHC Medical Products immediately.
No modication of this equipment is allowed.
*If there is any problem, contact MHC Medical Products immediately.
If this equipment is modied, appropriate inspection and testing
must be conducted to ensure continued safe use of the equipment.
*If there is any problem, contact MHC Medical Products immediately.
The operator shall not touch the thermometer and the patient
simultaneously.
Keep the machine out of children’s reach.
*For accidental swallow of battery of protective lm, please consult
the doctor at once.
For temperature dierence between storage area and measurement
site, condition the thermometer for about 30 minutes in room
temperature (measurement site).
*Failing to do so may cause inaccuracy.
Ensure that children do not use the instrument unsupervised.
*some parts are small enough to be swallowed.
Error Messages
Error
Message Problem Solution
Hi
Temperature is
higher than 42.2˚C
(108˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Lo
Temperature is
lower than 32˚C
(89.6˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Err Sensor not welded Contact MHC Medical Products.
Low power Replace with new batteries
ErH
The temperature
of the measuring
environment is
too high.
Decrease the temperature of
the environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
ErL
The temperature
of the measuring
environment is
too low
Increase the tmperature of the
environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
Maintenance, storage and calibration
Maintenance:
1. Gently remove any dirt on the body using a soft and
dry cloth.
2. Use a cotton swab or soft cloth absorbed with alcohol, and
gently wipe the lens of the temperature measuring head.
After using the product, the product can be sterilized with
70% medical alcohol on the soft towel or cotton sliver. If the
probe tip is damaged, please contact MHC Medical Products.
3. Don’t wash with water or detergent containing abrasive or
benzene.
4. Do not immerse in liquids.
Storage:
1. The device must not be stored or used in locations that are
excessively high or low temperature or humidity, in direct
sunlight, or in close proximity to an electrical current or in
dusty locations. Otherwise inaccuracies may occur.
2. Remove the battery if the thermometer is not used for
longer than one month.
Calibration:
This thermometer is calibrated at the time of manufacture.
If the thermometer is used according to the instruction,
periodic recalibration is not required. If at any time you
question the accuracy of the measurement, please contact
MHC Medical Products immediately.
Don’t attempt to modify or reassemble the thermometer.
Technical Specications
Parameter Specication
Measurement Mode Forehead mode
Measurement Units Fahrenheit (˚F) and Celsius (˚C)
Operating
Conditions
60.8˚F to 95˚F (16˚C-35˚C) with a relative
humidity of 15%-80%
Storage Conditions -4˚F to 131˚F (-20˚C-+55˚C) with a relative
humidity of 15%-93%
Measurement
Distance
0.59” to 1.97” (15mm to 50mm) from the
measuring point
Forehead
temperature
measurement range
and accuracy
Measurement range: 89.6˚F-108˚F
(32.0˚C-42.2˚C)
Measurement accuracy: ±0.4˚F
(95.0˚F-107.6˚F)\±0.2˚C (35.0˚C-42.0˚C);
±0.5˚F (±0.3˚C) other range.
Memories recall 32 measurement recall
Dimensions 5.9” x 1.46” x 0.64” (150mmx37mmx16.3mm)
Weight 51g without batteries
Battery 2xAAA batteries (DC.3V)
Switch o Automatically switches o after 1 minute
Product life 5 years
New battery life 1000 times
Standard
The product is made under the ISO80601-2-56.
Guarantee
Two-year warranty is available from purchasing date, excluding
user-caused failures listed below:
1. Failure resulted in unauthorized disassembly and
modication.
2. Failure resulted in unexpected drop during application or
transportation.
3. Failure resulted in operation away from proper instruction in
User’s Manual.
Included in delievery
• Infrared thermometer
• Instructions for use
• 2 x AAA batteries
Distributed by MHC Medical Products, LLC.
8695 Seward Road, Faireld, OH 45011
Tel: [phone]
Email: [e-mail]
Website: MHCmed.com
Manufactured by Alicn Medical Shenzhen, Inc.
4/F, B Building, Shenfubao Modern Optical Factory,
Kengzi Street, Pingshan District, 518122, Shenzhen City,
PEOPLE’S REPUBLIC OF CHINA
Electromagnetic Compatibility
The ME EQUIPMENT or ME SYSTEM is suitable for home
healthcare and hospital environments.
Warning: Do not use near active HF (high-frequency) surgical
equipment and the RF shielded room of an ME system for
magnetic resonance imaging, where the intensity of EM
disturbances is high.
Warning: Use of this equipment adjacent to or stacked with
other equipment should be avoided because it could result
in improper operation. If such use is necessary, this equipment
and the other equipment should be observed to verify that
they are operating normally.
If any: a list of all cables and maximum lengths of cables
(if applicable), transducers and other ACCESSORIES that are
replaceable by the RESPONSIBLE ORGANIZATION and that are
likely to aect compliance of the ME EQUIPMENT or ME SYSTEM
with the requirements of Clause 7 (EMISSIONS) and Clause 8
(IMMUNITY). ACCESSORIES may be specied either generically
(e.g. shielded cable, load impedance) or specically (e.g. by
MANUFACTURER and EQUIPMENT OR TYPE REFERENCE).
If any: the performance of the ME EQUIPMENT or ME SYSTEM
that was determined to be ESSENTIAL PERFORMANCE and a
description of what the OPERATOR can expect if the ESSENTIAL
PERFORMANCE is lost or degraded due to EM DISTURBANCES
(the dened term “ESSENTIAL PERFORMANCE” need not be used).
1. All necessary instructions for maintaining BASIC SAFETY and
ESSENTIAL PERFORMANCE with regard to electromagnetic
disturbances for the excepted service life.
2. Guidance and manufacturer’s declaration -electromagnetic
emissions and Immunity.
Table 1
Guidance and manufacturer’s declaration –
electromagnetic emission
Emmisions Test Compliance
RF emissions
CISPR 11 Group 1
RF emissions
CISPR11 Class B
Harmonic emissions
IEC 61000-3-2 N/A
Voltage uctuations/icker emissions
IEC 61000-3-3 N/A
Table 2
Guidance and manufacturer’s declaration –
electromagnetic Immunity
Immunity Test IEC 60601-1-2
Test level Compliance Level
Electrostatic
discharge (ESD) IEC
61000-4-2
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
Electrical fast
transient/burst IEC
61000-4-4
Power supply lines:
±2 kV
input/output lines:
±1 kV
N/A
Surge
IEC 61000-4-5
line(s) to line(s): ±1 kV
line(s) to earth: ±2 kV
100 kHz repetition
frequency
N/A
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines.
IEC 61000-4-11
0% 0.5 cycle
At 0˚, 45˚, 90˚, 135˚,
180˚, 225˚, 270˚,
and 315˚
0% 1 cycle
And
70% 25/30 cycles
Singel phase: at 0
0% 300 cycle
N/A
Power frequency
magnetic eld
IEC 61000-4-8
30 A/m
50Hz/60Hz
30 A/m
50Hz/60Hz
Conduced RF
IEC61000-4-6
150Khz to 80MHz:
3Vrms
6Vrms (in ISM and
amateur radio bands)
80% Am at 1kHz
N/A
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
NOTE UTis the a.c. mians voltage prior to application of the test level.
Table 3
Guidance and manufacturer’s declaration - electromagnetic Immunity
Radiated RF
IEC61000-4-3
(Test
specications
for ENCLOSURE
PORT IMMUNITY
to RF wireless
communications
equipment)
Test
Frequency
(MHz)
Band
(MHz) Service Modulation Modulation (W)
Distance
(m)
IMMUNITY
TEST LEVEL
(V/m)
385 380–
390
TETRA
400
Pulse
modulation
18 Hz
1,8 0.3 27
450 380–
390
GMRS
460,
FRS
460
FM
± 5 kHz
deviation
1kHz sine
2 0.3 28
710
704–
787
LTE
Band
13,
17
Pulse
modulation
217 Hz
0,2 0.3 9
745
780
810
800–
960
GSM
800/900,
TETRA
800,
iDEN
820,
CDMA
850,
LTE
Band 5
Pulse
modulation
18 Hz
2 0.3 28
870
930
1720
1700–
1990
GSM
1800;
CDMA
1900;
GSM
1900;
DECT;
LTE
Band 1,
3,4,25;
UMTS
Pulse
modulation
217 Hz
2 0.3 28
1845
1970
2450 2400–
2570
Bluetooth,
WLAN,
802.11
b/g/n,
RFID
2450,
LTE
Band 7
Pulse
modulation
217 Hz
2 0.3 28
5240 5100–
5800
WLAN
802.11
a/n
Pulse
modulation
217 Hz
0,2 0.3 95240
5785
6 7 8 9 10
Version: 1.0
Date modied: 2020-04-17 AD-102620.1

Warning
Do not use the thermometer under temperature extremes (below
16˚C/60.8˚F or over 35˚C/95˚F) or humidity extremes (below 15%RH
or over 80%RH).
*Failing to do so may cause inaccuracy.
Do not expose the thermometer to temperature extremes (below
-20˚C/-4˚F or over 55˚C/131˚F) or humidity extremes (below 15%RH
or over 93%RH).
*Failing to do so may cause inaccuracy.
Temperature probe has been shocked and lax.
*Contact MHC Medical Products immediately.
It is dangerous for patients to perform a self-evaluation and
self-treatment based on the measuring results. Be sure to follow
doctors’ instruction.
*A self-evaluation may cause a disease to worsen.
Don’t touch or blow infrared sensor.
*A contaminated or broken infrared sensor may cause inaccuracy.
Clean a contaminated infrared sensor with a soft dry cloth in a
gentle manner.
*Cleaning with toilet tissue or paper towel may scratch the infrared
sensor, causing inaccuracy.
Install the battery in the right position according to the manual.
*Incorrect replacement will cause battery heat.
Do not immerse the thermomter in liquids.
*This instrument is not waterproof.
Do not use a mobile phone nearby when the thermometer is
working.
*Portable and mobile RF communications equipment can aect
MEDICAL ELECTICAL EQUIPMENT. Falling to do so may cause
inaccuracy.
The probe glass is made from special material which is not easy
broken.
*If there is any damage, stop using it and contact MHC Medical
Products immediately.
Do not modify this equipment without authorization of the
manufacturer.
*Contact MHC Medical Products immediately.
The device is not repairable and contains no user serviceable parts.
*If there is any problem, contact MHC Medical Products immediately.
The device requires no calibration.
*If there is any problem, contact MHC Medical Products immediately.
No modication of this equipment is allowed.
*If there is any problem, contact MHC Medical Products immediately.
If this equipment is modied, appropriate inspection and testing
must be conducted to ensure continued safe use of the equipment.
*If there is any problem, contact MHC Medical Products immediately.
The operator shall not touch the thermometer and the patient
simultaneously.
Keep the machine out of children’s reach.
*For accidental swallow of battery of protective lm, please consult
the doctor at once.
For temperature dierence between storage area and measurement
site, condition the thermometer for about 30 minutes in room
temperature (measurement site).
*Failing to do so may cause inaccuracy.
Ensure that children do not use the instrument unsupervised.
*some parts are small enough to be swallowed.
Error Messages
Error
Message Problem Solution
Hi
Temperature is
higher than 42.2˚C
(108˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Lo
Temperature is
lower than 32˚C
(89.6˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Err Sensor not welded Contact MHC Medical Products.
Low power Replace with new batteries
ErH
The temperature
of the measuring
environment is
too high.
Decrease the temperature of
the environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
ErL
The temperature
of the measuring
environment is
too low
Increase the tmperature of the
environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
Maintenance, storage and calibration
Maintenance:
1. Gently remove any dirt on the body using a soft and
dry cloth.
2. Use a cotton swab or soft cloth absorbed with alcohol, and
gently wipe the lens of the temperature measuring head.
After using the product, the product can be sterilized with
70% medical alcohol on the soft towel or cotton sliver. If the
probe tip is damaged, please contact MHC Medical Products.
3. Don’t wash with water or detergent containing abrasive or
benzene.
4. Do not immerse in liquids.
Storage:
1. The device must not be stored or used in locations that are
excessively high or low temperature or humidity, in direct
sunlight, or in close proximity to an electrical current or in
dusty locations. Otherwise inaccuracies may occur.
2. Remove the battery if the thermometer is not used for
longer than one month.
Calibration:
This thermometer is calibrated at the time of manufacture.
If the thermometer is used according to the instruction,
periodic recalibration is not required. If at any time you
question the accuracy of the measurement, please contact
MHC Medical Products immediately.
Don’t attempt to modify or reassemble the thermometer.
Technical Specications
Parameter Specication
Measurement Mode Forehead mode
Measurement Units Fahrenheit (˚F) and Celsius (˚C)
Operating
Conditions
60.8˚F to 95˚F (16˚C-35˚C) with a relative
humidity of 15%-80%
Storage Conditions -4˚F to 131˚F (-20˚C-+55˚C) with a relative
humidity of 15%-93%
Measurement
Distance
0.59” to 1.97” (15mm to 50mm) from the
measuring point
Forehead
temperature
measurement range
and accuracy
Measurement range: 89.6˚F-108˚F
(32.0˚C-42.2˚C)
Measurement accuracy: ±0.4˚F
(95.0˚F-107.6˚F)\±0.2˚C (35.0˚C-42.0˚C);
±0.5˚F (±0.3˚C) other range.
Memories recall 32 measurement recall
Dimensions 5.9” x 1.46” x 0.64” (150mmx37mmx16.3mm)
Weight 51g without batteries
Battery 2xAAA batteries (DC.3V)
Switch o Automatically switches o after 1 minute
Product life 5 years
New battery life 1000 times
Standard
The product is made under the ISO80601-2-56.
Guarantee
Two-year warranty is available from purchasing date, excluding
user-caused failures listed below:
1. Failure resulted in unauthorized disassembly and
modication.
2. Failure resulted in unexpected drop during application or
transportation.
3. Failure resulted in operation away from proper instruction in
User’s Manual.
Included in delievery
• Infrared thermometer
• Instructions for use
• 2 x AAA batteries
Distributed by MHC Medical Products, LLC.
8695 Seward Road, Faireld, OH 45011
Tel: [phone]
Email: [e-mail]
Website: MHCmed.com
Manufactured by Alicn Medical Shenzhen, Inc.
4/F, B Building, Shenfubao Modern Optical Factory,
Kengzi Street, Pingshan District, 518122, Shenzhen City,
PEOPLE’S REPUBLIC OF CHINA
Electromagnetic Compatibility
The ME EQUIPMENT or ME SYSTEM is suitable for home
healthcare and hospital environments.
Warning: Do not use near active HF (high-frequency) surgical
equipment and the RF shielded room of an ME system for
magnetic resonance imaging, where the intensity of EM
disturbances is high.
Warning: Use of this equipment adjacent to or stacked with
other equipment should be avoided because it could result
in improper operation. If such use is necessary, this equipment
and the other equipment should be observed to verify that
they are operating normally.
If any: a list of all cables and maximum lengths of cables
(if applicable), transducers and other ACCESSORIES that are
replaceable by the RESPONSIBLE ORGANIZATION and that are
likely to aect compliance of the ME EQUIPMENT or ME SYSTEM
with the requirements of Clause 7 (EMISSIONS) and Clause 8
(IMMUNITY). ACCESSORIES may be specied either generically
(e.g. shielded cable, load impedance) or specically (e.g. by
MANUFACTURER and EQUIPMENT OR TYPE REFERENCE).
If any: the performance of the ME EQUIPMENT or ME SYSTEM
that was determined to be ESSENTIAL PERFORMANCE and a
description of what the OPERATOR can expect if the ESSENTIAL
PERFORMANCE is lost or degraded due to EM DISTURBANCES
(the dened term “ESSENTIAL PERFORMANCE” need not be used).
1. All necessary instructions for maintaining BASIC SAFETY and
ESSENTIAL PERFORMANCE with regard to electromagnetic
disturbances for the excepted service life.
2. Guidance and manufacturer’s declaration -electromagnetic
emissions and Immunity.
Table 1
Guidance and manufacturer’s declaration –
electromagnetic emission
Emmisions Test Compliance
RF emissions
CISPR 11 Group 1
RF emissions
CISPR11 Class B
Harmonic emissions
IEC 61000-3-2 N/A
Voltage uctuations/icker emissions
IEC 61000-3-3 N/A
Table 2
Guidance and manufacturer’s declaration –
electromagnetic Immunity
Immunity Test IEC 60601-1-2
Test level Compliance Level
Electrostatic
discharge (ESD) IEC
61000-4-2
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
Electrical fast
transient/burst IEC
61000-4-4
Power supply lines:
±2 kV
input/output lines:
±1 kV
N/A
Surge
IEC 61000-4-5
line(s) to line(s): ±1 kV
line(s) to earth: ±2 kV
100 kHz repetition
frequency
N/A
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines.
IEC 61000-4-11
0% 0.5 cycle
At 0˚, 45˚, 90˚, 135˚,
180˚, 225˚, 270˚,
and 315˚
0% 1 cycle
And
70% 25/30 cycles
Singel phase: at 0
0% 300 cycle
N/A
Power frequency
magnetic eld
IEC 61000-4-8
30 A/m
50Hz/60Hz
30 A/m
50Hz/60Hz
Conduced RF
IEC61000-4-6
150Khz to 80MHz:
3Vrms
6Vrms (in ISM and
amateur radio bands)
80% Am at 1kHz
N/A
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
NOTE UTis the a.c. mians voltage prior to application of the test level.
Table 3
Guidance and manufacturer’s declaration - electromagnetic Immunity
Radiated RF
IEC61000-4-3
(Test
specications
for ENCLOSURE
PORT IMMUNITY
to RF wireless
communications
equipment)
Test
Frequency
(MHz)
Band
(MHz) Service Modulation Modulation (W)
Distance
(m)
IMMUNITY
TEST LEVEL
(V/m)
385 380–
390
TETRA
400
Pulse
modulation
18 Hz
1,8 0.3 27
450 380–
390
GMRS
460,
FRS
460
FM
± 5 kHz
deviation
1kHz sine
2 0.3 28
710
704–
787
LTE
Band
13,
17
Pulse
modulation
217 Hz
0,2 0.3 9
745
780
810
800–
960
GSM
800/900,
TETRA
800,
iDEN
820,
CDMA
850,
LTE
Band 5
Pulse
modulation
18 Hz
2 0.3 28
870
930
1720
1700–
1990
GSM
1800;
CDMA
1900;
GSM
1900;
DECT;
LTE
Band 1,
3,4,25;
UMTS
Pulse
modulation
217 Hz
2 0.3 28
1845
1970
2450 2400–
2570
Bluetooth,
WLAN,
802.11
b/g/n,
RFID
2450,
LTE
Band 7
Pulse
modulation
217 Hz
2 0.3 28
5240 5100–
5800
WLAN
802.11
a/n
Pulse
modulation
217 Hz
0,2 0.3 95240
5785
6 7 8 9 10
Version: 1.0
Date modied: 2020-04-17 AD-102620.1
Warning
Do not use the thermometer under temperature extremes (below
16˚C/60.8˚F or over 35˚C/95˚F) or humidity extremes (below 15%RH
or over 80%RH).
*Failing to do so may cause inaccuracy.
Do not expose the thermometer to temperature extremes (below
-20˚C/-4˚F or over 55˚C/131˚F) or humidity extremes (below 15%RH
or over 93%RH).
*Failing to do so may cause inaccuracy.
Temperature probe has been shocked and lax.
*Contact MHC Medical Products immediately.
It is dangerous for patients to perform a self-evaluation and
self-treatment based on the measuring results. Be sure to follow
doctors’ instruction.
*A self-evaluation may cause a disease to worsen.
Don’t touch or blow infrared sensor.
*A contaminated or broken infrared sensor may cause inaccuracy.
Clean a contaminated infrared sensor with a soft dry cloth in a
gentle manner.
*Cleaning with toilet tissue or paper towel may scratch the infrared
sensor, causing inaccuracy.
Install the battery in the right position according to the manual.
*Incorrect replacement will cause battery heat.
Do not immerse the thermomter in liquids.
*This instrument is not waterproof.
Do not use a mobile phone nearby when the thermometer is
working.
*Portable and mobile RF communications equipment can aect
MEDICAL ELECTICAL EQUIPMENT. Falling to do so may cause
inaccuracy.
The probe glass is made from special material which is not easy
broken.
*If there is any damage, stop using it and contact MHC Medical
Products immediately.
Do not modify this equipment without authorization of the
manufacturer.
*Contact MHC Medical Products immediately.
The device is not repairable and contains no user serviceable parts.
*If there is any problem, contact MHC Medical Products immediately.
The device requires no calibration.
*If there is any problem, contact MHC Medical Products immediately.
No modication of this equipment is allowed.
*If there is any problem, contact MHC Medical Products immediately.
If this equipment is modied, appropriate inspection and testing
must be conducted to ensure continued safe use of the equipment.
*If there is any problem, contact MHC Medical Products immediately.
The operator shall not touch the thermometer and the patient
simultaneously.
Keep the machine out of children’s reach.
*For accidental swallow of battery of protective lm, please consult
the doctor at once.
For temperature dierence between storage area and measurement
site, condition the thermometer for about 30 minutes in room
temperature (measurement site).
*Failing to do so may cause inaccuracy.
Ensure that children do not use the instrument unsupervised.
*some parts are small enough to be swallowed.
Error Messages
Error
Message Problem Solution
Hi
Temperature is
higher than 42.2˚C
(108˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Lo
Temperature is
lower than 32˚C
(89.6˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Err Sensor not welded Contact MHC Medical Products.
Low power Replace with new batteries
ErH
The temperature
of the measuring
environment is
too high.
Decrease the temperature of
the environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
ErL
The temperature
of the measuring
environment is
too low
Increase the tmperature of the
environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
Maintenance, storage and calibration
Maintenance:
1. Gently remove any dirt on the body using a soft and
dry cloth.
2. Use a cotton swab or soft cloth absorbed with alcohol, and
gently wipe the lens of the temperature measuring head.
After using the product, the product can be sterilized with
70% medical alcohol on the soft towel or cotton sliver. If the
probe tip is damaged, please contact MHC Medical Products.
3. Don’t wash with water or detergent containing abrasive or
benzene.
4. Do not immerse in liquids.
Storage:
1. The device must not be stored or used in locations that are
excessively high or low temperature or humidity, in direct
sunlight, or in close proximity to an electrical current or in
dusty locations. Otherwise inaccuracies may occur.
2. Remove the battery if the thermometer is not used for
longer than one month.
Calibration:
This thermometer is calibrated at the time of manufacture.
If the thermometer is used according to the instruction,
periodic recalibration is not required. If at any time you
question the accuracy of the measurement, please contact
MHC Medical Products immediately.
Don’t attempt to modify or reassemble the thermometer.
Technical Specications
Parameter Specication
Measurement Mode Forehead mode
Measurement Units Fahrenheit (˚F) and Celsius (˚C)
Operating
Conditions
60.8˚F to 95˚F (16˚C-35˚C) with a relative
humidity of 15%-80%
Storage Conditions -4˚F to 131˚F (-20˚C-+55˚C) with a relative
humidity of 15%-93%
Measurement
Distance
0.59” to 1.97” (15mm to 50mm) from the
measuring point
Forehead
temperature
measurement range
and accuracy
Measurement range: 89.6˚F-108˚F
(32.0˚C-42.2˚C)
Measurement accuracy: ±0.4˚F
(95.0˚F-107.6˚F)\±0.2˚C (35.0˚C-42.0˚C);
±0.5˚F (±0.3˚C) other range.
Memories recall 32 measurement recall
Dimensions 5.9” x 1.46” x 0.64” (150mmx37mmx16.3mm)
Weight 51g without batteries
Battery 2xAAA batteries (DC.3V)
Switch o Automatically switches o after 1 minute
Product life 5 years
New battery life 1000 times
Standard
The product is made under the ISO80601-2-56.
Guarantee
Two-year warranty is available from purchasing date, excluding
user-caused failures listed below:
1. Failure resulted in unauthorized disassembly and
modication.
2. Failure resulted in unexpected drop during application or
transportation.
3. Failure resulted in operation away from proper instruction in
User’s Manual.
Included in delievery
• Infrared thermometer
• Instructions for use
• 2 x AAA batteries
Distributed by MHC Medical Products, LLC.
8695 Seward Road, Faireld, OH 45011
Tel: [phone]
Email: [email protected]
Website: MHCmed.com
Manufactured by Alicn Medical Shenzhen, Inc.
4/F, B Building, Shenfubao Modern Optical Factory,
Kengzi Street, Pingshan District, 518122, Shenzhen City,
PEOPLE’S REPUBLIC OF CHINA
Electromagnetic Compatibility
The ME EQUIPMENT or ME SYSTEM is suitable for home
healthcare and hospital environments.
Warning: Do not use near active HF (high-frequency) surgical
equipment and the RF shielded room of an ME system for
magnetic resonance imaging, where the intensity of EM
disturbances is high.
Warning: Use of this equipment adjacent to or stacked with
other equipment should be avoided because it could result
in improper operation. If such use is necessary, this equipment
and the other equipment should be observed to verify that
they are operating normally.
If any: a list of all cables and maximum lengths of cables
(if applicable), transducers and other ACCESSORIES that are
replaceable by the RESPONSIBLE ORGANIZATION and that are
likely to aect compliance of the ME EQUIPMENT or ME SYSTEM
with the requirements of Clause 7 (EMISSIONS) and Clause 8
(IMMUNITY). ACCESSORIES may be specied either generically
(e.g. shielded cable, load impedance) or specically (e.g. by
MANUFACTURER and EQUIPMENT OR TYPE REFERENCE).
If any: the performance of the ME EQUIPMENT or ME SYSTEM
that was determined to be ESSENTIAL PERFORMANCE and a
description of what the OPERATOR can expect if the ESSENTIAL
PERFORMANCE is lost or degraded due to EM DISTURBANCES
(the dened term “ESSENTIAL PERFORMANCE” need not be used).
1. All necessary instructions for maintaining BASIC SAFETY and
ESSENTIAL PERFORMANCE with regard to electromagnetic
disturbances for the excepted service life.
2. Guidance and manufacturer’s declaration -electromagnetic
emissions and Immunity.
Table 1
Guidance and manufacturer’s declaration –
electromagnetic emission
Emmisions Test Compliance
RF emissions
CISPR 11 Group 1
RF emissions
CISPR11 Class B
Harmonic emissions
IEC 61000-3-2 N/A
Voltage uctuations/icker emissions
IEC 61000-3-3 N/A
Table 2
Guidance and manufacturer’s declaration –
electromagnetic Immunity
Immunity Test IEC 60601-1-2
Test level Compliance Level
Electrostatic
discharge (ESD) IEC
61000-4-2
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
Electrical fast
transient/burst IEC
61000-4-4
Power supply lines:
±2 kV
input/output lines:
±1 kV
N/A
Surge
IEC 61000-4-5
line(s) to line(s): ±1 kV
line(s) to earth: ±2 kV
100 kHz repetition
frequency
N/A
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines.
IEC 61000-4-11
0% 0.5 cycle
At 0˚, 45˚, 90˚, 135˚,
180˚, 225˚, 270˚,
and 315˚
0% 1 cycle
And
70% 25/30 cycles
Singel phase: at 0
0% 300 cycle
N/A
Power frequency
magnetic eld
IEC 61000-4-8
30 A/m
50Hz/60Hz
30 A/m
50Hz/60Hz
Conduced RF
IEC61000-4-6
150Khz to 80MHz:
3Vrms
6Vrms (in ISM and
amateur radio bands)
80% Am at 1kHz
N/A
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
NOTE UTis the a.c. mians voltage prior to application of the test level.
Table 3
Guidance and manufacturer’s declaration - electromagnetic Immunity
Radiated RF
IEC61000-4-3
(Test
specications
for ENCLOSURE
PORT IMMUNITY
to RF wireless
communications
equipment)
Test
Frequency
(MHz)
Band
(MHz) Service Modulation Modulation (W)
Distance
(m)
IMMUNITY
TEST LEVEL
(V/m)
385 380–
390
TETRA
400
Pulse
modulation
18 Hz
1,8 0.3 27
450 380–
390
GMRS
460,
FRS
460
FM
± 5 kHz
deviation
1kHz sine
2 0.3 28
710
704–
787
LTE
Band
13,
17
Pulse
modulation
217 Hz
0,2 0.3 9
745
780
810
800–
960
GSM
800/900,
TETRA
800,
iDEN
820,
CDMA
850,
LTE
Band 5
Pulse
modulation
18 Hz
2 0.3 28
870
930
1720
1700–
1990
GSM
1800;
CDMA
1900;
GSM
1900;
DECT;
LTE
Band 1,
3,4,25;
UMTS
Pulse
modulation
217 Hz
2 0.3 28
1845
1970
2450 2400–
2570
Bluetooth,
WLAN,
802.11
b/g/n,
RFID
2450,
LTE
Band 7
Pulse
modulation
217 Hz
2 0.3 28
5240 5100–
5800
WLAN
802.11
a/n
Pulse
modulation
217 Hz
0,2 0.3 95240
5785
6 7 8 9 10
Version: 1.0
Date modied: 2020-04-17 AD-102620.1

Warning
Do not use the thermometer under temperature extremes (below
16˚C/60.8˚F or over 35˚C/95˚F) or humidity extremes (below 15%RH
or over 80%RH).
*Failing to do so may cause inaccuracy.
Do not expose the thermometer to temperature extremes (below
-20˚C/-4˚F or over 55˚C/131˚F) or humidity extremes (below 15%RH
or over 93%RH).
*Failing to do so may cause inaccuracy.
Temperature probe has been shocked and lax.
*Contact MHC Medical Products immediately.
It is dangerous for patients to perform a self-evaluation and
self-treatment based on the measuring results. Be sure to follow
doctors’ instruction.
*A self-evaluation may cause a disease to worsen.
Don’t touch or blow infrared sensor.
*A contaminated or broken infrared sensor may cause inaccuracy.
Clean a contaminated infrared sensor with a soft dry cloth in a
gentle manner.
*Cleaning with toilet tissue or paper towel may scratch the infrared
sensor, causing inaccuracy.
Install the battery in the right position according to the manual.
*Incorrect replacement will cause battery heat.
Do not immerse the thermomter in liquids.
*This instrument is not waterproof.
Do not use a mobile phone nearby when the thermometer is
working.
*Portable and mobile RF communications equipment can aect
MEDICAL ELECTICAL EQUIPMENT. Falling to do so may cause
inaccuracy.
The probe glass is made from special material which is not easy
broken.
*If there is any damage, stop using it and contact MHC Medical
Products immediately.
Do not modify this equipment without authorization of the
manufacturer.
*Contact MHC Medical Products immediately.
The device is not repairable and contains no user serviceable parts.
*If there is any problem, contact MHC Medical Products immediately.
The device requires no calibration.
*If there is any problem, contact MHC Medical Products immediately.
No modication of this equipment is allowed.
*If there is any problem, contact MHC Medical Products immediately.
If this equipment is modied, appropriate inspection and testing
must be conducted to ensure continued safe use of the equipment.
*If there is any problem, contact MHC Medical Products immediately.
The operator shall not touch the thermometer and the patient
simultaneously.
Keep the machine out of children’s reach.
*For accidental swallow of battery of protective lm, please consult
the doctor at once.
For temperature dierence between storage area and measurement
site, condition the thermometer for about 30 minutes in room
temperature (measurement site).
*Failing to do so may cause inaccuracy.
Ensure that children do not use the instrument unsupervised.
*some parts are small enough to be swallowed.
Error Messages
Error
Message Problem Solution
Hi
Temperature is
higher than 42.2˚C
(108˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Lo
Temperature is
lower than 32˚C
(89.6˚F).
Operate the thermometer only
between the specied temperature
ranges. In the event of a repeated
error message, contact MHC
Medical Products.
Err Sensor not welded Contact MHC Medical Products.
Low power Replace with new batteries
ErH
The temperature
of the measuring
environment is
too high.
Decrease the temperature of
the environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
ErL
The temperature
of the measuring
environment is
too low
Increase the tmperature of the
environment, keep it within
60.8˚F-95˚F (16˚C-35˚C).
Maintenance, storage and calibration
Maintenance:
1. Gently remove any dirt on the body using a soft and
dry cloth.
2. Use a cotton swab or soft cloth absorbed with alcohol, and
gently wipe the lens of the temperature measuring head.
After using the product, the product can be sterilized with
70% medical alcohol on the soft towel or cotton sliver. If the
probe tip is damaged, please contact MHC Medical Products.
3. Don’t wash with water or detergent containing abrasive or
benzene.
4. Do not immerse in liquids.
Storage:
1. The device must not be stored or used in locations that are
excessively high or low temperature or humidity, in direct
sunlight, or in close proximity to an electrical current or in
dusty locations. Otherwise inaccuracies may occur.
2. Remove the battery if the thermometer is not used for
longer than one month.
Calibration:
This thermometer is calibrated at the time of manufacture.
If the thermometer is used according to the instruction,
periodic recalibration is not required. If at any time you
question the accuracy of the measurement, please contact
MHC Medical Products immediately.
Don’t attempt to modify or reassemble the thermometer.
Technical Specications
Parameter Specication
Measurement Mode Forehead mode
Measurement Units Fahrenheit (˚F) and Celsius (˚C)
Operating
Conditions
60.8˚F to 95˚F (16˚C-35˚C) with a relative
humidity of 15%-80%
Storage Conditions -4˚F to 131˚F (-20˚C-+55˚C) with a relative
humidity of 15%-93%
Measurement
Distance
0.59” to 1.97” (15mm to 50mm) from the
measuring point
Forehead
temperature
measurement range
and accuracy
Measurement range: 89.6˚F-108˚F
(32.0˚C-42.2˚C)
Measurement accuracy: ±0.4˚F
(95.0˚F-107.6˚F)\±0.2˚C (35.0˚C-42.0˚C);
±0.5˚F (±0.3˚C) other range.
Memories recall 32 measurement recall
Dimensions 5.9” x 1.46” x 0.64” (150mmx37mmx16.3mm)
Weight 51g without batteries
Battery 2xAAA batteries (DC.3V)
Switch o Automatically switches o after 1 minute
Product life 5 years
New battery life 1000 times
Standard
The product is made under the ISO80601-2-56.
Guarantee
Two-year warranty is available from purchasing date, excluding
user-caused failures listed below:
1. Failure resulted in unauthorized disassembly and
modication.
2. Failure resulted in unexpected drop during application or
transportation.
3. Failure resulted in operation away from proper instruction in
User’s Manual.
Included in delievery
• Infrared thermometer
• Instructions for use
• 2 x AAA batteries
Distributed by MHC Medical Products, LLC.
8695 Seward Road, Faireld, OH 45011
Tel: [phone]
Email: [email protected]
Website: MHCmed.com
Manufactured by Alicn Medical Shenzhen, Inc.
4/F, B Building, Shenfubao Modern Optical Factory,
Kengzi Street, Pingshan District, 518122, Shenzhen City,
PEOPLE’S REPUBLIC OF CHINA
Electromagnetic Compatibility
The ME EQUIPMENT or ME SYSTEM is suitable for home
healthcare and hospital environments.
Warning: Do not use near active HF (high-frequency) surgical
equipment and the RF shielded room of an ME system for
magnetic resonance imaging, where the intensity of EM
disturbances is high.
Warning: Use of this equipment adjacent to or stacked with
other equipment should be avoided because it could result
in improper operation. If such use is necessary, this equipment
and the other equipment should be observed to verify that
they are operating normally.
If any: a list of all cables and maximum lengths of cables
(if applicable), transducers and other ACCESSORIES that are
replaceable by the RESPONSIBLE ORGANIZATION and that are
likely to aect compliance of the ME EQUIPMENT or ME SYSTEM
with the requirements of Clause 7 (EMISSIONS) and Clause 8
(IMMUNITY). ACCESSORIES may be specied either generically
(e.g. shielded cable, load impedance) or specically (e.g. by
MANUFACTURER and EQUIPMENT OR TYPE REFERENCE).
If any: the performance of the ME EQUIPMENT or ME SYSTEM
that was determined to be ESSENTIAL PERFORMANCE and a
description of what the OPERATOR can expect if the ESSENTIAL
PERFORMANCE is lost or degraded due to EM DISTURBANCES
(the dened term “ESSENTIAL PERFORMANCE” need not be used).
1. All necessary instructions for maintaining BASIC SAFETY and
ESSENTIAL PERFORMANCE with regard to electromagnetic
disturbances for the excepted service life.
2. Guidance and manufacturer’s declaration -electromagnetic
emissions and Immunity.
Table 1
Guidance and manufacturer’s declaration –
electromagnetic emission
Emmisions Test Compliance
RF emissions
CISPR 11 Group 1
RF emissions
CISPR11 Class B
Harmonic emissions
IEC 61000-3-2 N/A
Voltage uctuations/icker emissions
IEC 61000-3-3 N/A
Table 2
Guidance and manufacturer’s declaration –
electromagnetic Immunity
Immunity Test IEC 60601-1-2
Test level Compliance Level
Electrostatic
discharge (ESD) IEC
61000-4-2
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
±8 kV contact
±2 kV, ±4 kV,
±8 kV, ±15 kV air
Electrical fast
transient/burst IEC
61000-4-4
Power supply lines:
±2 kV
input/output lines:
±1 kV
N/A
Surge
IEC 61000-4-5
line(s) to line(s): ±1 kV
line(s) to earth: ±2 kV
100 kHz repetition
frequency
N/A
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines.
IEC 61000-4-11
0% 0.5 cycle
At 0˚, 45˚, 90˚, 135˚,
180˚, 225˚, 270˚,
and 315˚
0% 1 cycle
And
70% 25/30 cycles
Singel phase: at 0
0% 300 cycle
N/A
Power frequency
magnetic eld
IEC 61000-4-8
30 A/m
50Hz/60Hz
30 A/m
50Hz/60Hz
Conduced RF
IEC61000-4-6
150Khz to 80MHz:
3Vrms
6Vrms (in ISM and
amateur radio bands)
80% Am at 1kHz
N/A
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
10 V/m
80 MHz –2,7 GHz
80% AM at 1 kHz
NOTE UTis the a.c. mians voltage prior to application of the test level.
Table 3
Guidance and manufacturer’s declaration - electromagnetic Immunity
Radiated RF
IEC61000-4-3
(Test
specications
for ENCLOSURE
PORT IMMUNITY
to RF wireless
communications
equipment)
Test
Frequency
(MHz)
Band
(MHz) Service Modulation Modulation (W)
Distance
(m)
IMMUNITY
TEST LEVEL
(V/m)
385 380–
390
TETRA
400
Pulse
modulation
18 Hz
1,8 0.3 27
450 380–
390
GMRS
460,
FRS
460
FM
± 5 kHz
deviation
1kHz sine
2 0.3 28
710
704–
787
LTE
Band
13,
17
Pulse
modulation
217 Hz
0,2 0.3 9
745
780
810
800–
960
GSM
800/900,
TETRA
800,
iDEN
820,
CDMA
850,
LTE
Band 5
Pulse
modulation
18 Hz
2 0.3 28
870
930
1720
1700–
1990
GSM
1800;
CDMA
1900;
GSM
1900;
DECT;
LTE
Band 1,
3,4,25;
UMTS
Pulse
modulation
217 Hz
2 0.3 28
1845
1970
2450 2400–
2570
Bluetooth,
WLAN,
802.11
b/g/n,
RFID
2450,
LTE
Band 7
Pulse
modulation
217 Hz
2 0.3 28
5240 5100–
5800
WLAN
802.11
a/n
Pulse
modulation
217 Hz
0,2 0.3 95240
5785
6 7 8 9 10
Version: 1.0
Date modied: 2020-04-17 AD-102620.1
