Surveon CAM6120 User manual

CAM6120
Speed Dome Indoor Network Camera
Hardware Manual
Release 1.0
October 2010

I
AllRightsReserved©SurveonTechnology2010
CopyrightStatement
No part of this publication may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, manual or otherwise, without the prior written consent of
Surveon Technology Inc.
Disclaimer
Surveon Technology makes no representations or warranties with respect to
the contents hereof and specifically disclaim any implied warranties of
merchantability or fitness for any particular purpose. Furthermore, Surveon
Technology reserves the right to revise this publication and to make changes
from time to time in the content hereof without obligation to notify any
person of such revisions or changes. Product specifications are also subject to
change without notice.
Trademarks
Surveon and Surveon logo are trademarks of Surveon Technology Inc. Other
names prefixed with “NVR” are trademarks of Surveon Technology Inc. All
other names, brands, products or services are trademarks or registered
trademarks of their respective owners

II
Table of Contents
Copyright Statement........................................................................... I
Table of Contents ..............................................................................II
Safety Precautions ............................................................................IV
Device Site Recommendations..............................................................IV
Regulatory Compliance Information....................................................... V
Chapter 1. Product Overview............................................................... 1
1.1. Features and Benefits................................................................ 1
Chapter 2. Hardware Overview............................................................. 2
2.1. Overview................................................................................ 2
2.2. Setup .................................................................................... 3
DIP Switches................................................................................3
Alarm Out Mode ......................................................................3
RS-485 Protocol Switch..............................................................3
Camera ID Switch.....................................................................4
Cabling Specifications ....................................................................4
AC24V Power Cable ..................................................................4
RS-485 Twisted Pair..................................................................5
Video Out BNC ........................................................................5
Alarm In/Out..........................................................................5
Network Connector RJ45............................................................5
Chapter 3. Installation........................................................................ 6
3.1. Indoor Installation Structural Drawing............................................ 6
3.2. Embedded Mounting (False Ceiling)............................................... 7
3.3. Attached Mounting (Fixed Ceiling) ................................................ 9
3.4. Wall Mounting (Fixed Bracket) ....................................................11
Chapter 4. Troubleshooting ................................................................13
4.1. Checking Firmware Version........................................................13
4.2. Upgrading Firmware.................................................................13
4.3. Resetting to Factory Default Settings............................................13

III
Chapter 5. Technical Specifications......................................................14

IV
Safety Precautions
Electric Shock Warning
This equipment may cause electric shocks if not handled properly.
Access to this equipment should only be granted to trained operators
and maintenance personnel who have been instructed of, and fully
understand the possible hazardous conditions and the consequences of
accessing non-field-serviceable units such as the power supplies.
The system must be unplugged before moving, or in the even that it
becomes damaged.
Reliable Grounding
Particular attention should be given to prepare reliable grounding for the
power supply connection. It is suggested to use a direct connection to the
branch circuit. Check for proper grounding before powering on the device.
Overloading Protection
The device should be installed according to specifications. Provide a suitable
power source with electrical overload protection. Do not overload the AC
supply branch circuit that provides power to the device.
ESD Precautions
Please observe all conventional anti-ESD methods while handling the device.
The use of a grounded wrist strap and an anti-static work pad are
recommended. Avoid dust and debris in your work area.
Device Site Recommendations
The device should be installed according to specifications. This device should
be operated at a site that is:
Clean, dry, and free of excessive airborne particles.
Well-ventilated and away from heat sources such as direct sunlight
and radiators
Clear of vibration or physical shock.
Away from strong electromagnetic fields produced by other devices.
Available with properly grounded wall outlet for power. In regions
where power sources are unstable, apply surge suppression.
Available with sufficient space behind the device for cabling.

V
Regulatory Compliance Information
Regulatory Compliance Information
FCC/CE Class A
IEC 60950
Shown below is the location of the compliance statement label.
FCC (applies in the U.S. and Canada)
FCC Class A Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules (47 CFR, Part 2,
Part 15 and CISPR PUB. 22 Class A). These limits are designed to provide
reasonable protection against harmful interference when the equipment is
operated in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in
accordance with this user’s guide, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, you are encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of FCC Rules. Operation is subject to
the following two conditions: 1) this device may not cause harmful
interference, and 2) this device must accept any interference received,
including interference that may cause undesired operation.
Warning!
A shielded power cord is required in order to meet FCC emission limits and
also to prevent interference with nearby radio and television reception. Use
only shielded cables to connect I/O devices to this equipment. You are
cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the
equipment.

VI
This device is in conformity with the EMC.
Notice for Class A Product
This notice is for class A product only. If the equipment under test is a class B
product, this notice should be disregarded.
Class A ITE is a category of all other ITE which satisfies the class A ITE limits
but not the class B ITE limits. Such equipment should not be restricted in its
sale but the following warning shall be included in the instruction for use.
Warning:
This is class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
CCC
For Power Supplies’ compatibility to China Compulsory Certification.
Surveon is committed to being properly prepared and taking all the necessary
steps that will result in our compliance with the new European directive,
RoHS (2002/95/EC), on or before the specific dates set forth in those
applicable laws and regulations. Surveon is applying its own internal efforts
and expertise and is working closely with customers and suppliers to achieve
compliance while maintaining an uninterrupted supply of quality products.
Surveon is currently investigating, evaluating, and qualifying our materials
and components to ensure that products sold on or after 1 July 2006, in such
territory, are in compliance with the above regulations.
Disposal of Old Electrical & Electronic Equipment (Applicable in the European
Union and other European countries with separate collection systems) This
symbol on the product or on its packaging indicates that this product shall
not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic
equipment. By proper waste handling of this product you ensure that it has
no negative consequences for the environment and human health, which
could otherwise be caused if this product is thrown into the garbage bin. The
recycling of materials will help to conserve natural resources.

1
Surveon Network Camera Hardware Manual
Chapter 1. Product Overview
1.1. Features and Benefits
This IP device is a cutting-edge digital video transmission device. It can
compress and transmit real-time images of outstanding quality using a
reasonable amount of bandwidth through a standard TCP/IP network. The
following features make this IP camera an outstanding choice when building
an intelligent IP surveillance system:
Megapixel Video Quality
High image quality is essential in security surveillance applications. It is
important to be able to clearly capture an incident in progress and
identify persons or objects involved. A Megapixel camera gives exceptional
video quality, even greater than that of traditional analog cameras, which
means that more detail or larger areas can be covered.
H.264/MPEG-4/MJPEG Compression
Motion JPEG, MPEG-4, and H.264 (also known as MPEG-4 Part 10/AVC),
each employ different techniques to reduce the amount of data
transferred and stored in a network video system. Network cameras that
support multiple compression standards are ideal for maximum flexibility
and integration possibilities.
Dual Streaming
Dual-stream design enables simultaneous support of real-time video
monitoring, video recording, or mobile viewing applications which require
different resolutions, compression formats and frame rates.
Tampering Detection
This is an intelligent video analytics application available only in selected
network cameras in the market. When a camera is manipulated in any way
(e.g. accidental redirection, blocking, defocusing, spray-painted, covered
or damaged), it can automatically trigger recording and alert notifications.

www.surveon.com
2
Surveon CAM6120
Chapter 2. Hardware Overview
2.1. Overview

3
Surveon Network Camera Hardware Manual
2.2. Setup
DIP Switches
Alarm Out Mode
Alarm Out Mode can be set as NC (normally close) or NO (normally open).
RS-485 Protocol Switch
1, 2 - RS-485 IN (1), OUT(2) Terminal Resistor ON/OFF ;
oDaisy-chained Connection: Set RS-485 In and Out terminal resistors
ON (Default).
oParallel Connection: Set the first and last cameras terminal resistors
ON. The equipment in the middle set to OFF.
3 - RS-485 Communication Mode Selection
oOn – Full duplex (4 wiring) system.
oOff – Half duplex (2 wiring) system.
4, 5 - RS-485 Transmission Speed
DIP Switch 4 5
2400 bps ON ON
4800 bps OFF ON
9600 bps ON OFF
19200 bps OFF OFF

www.surveon.com
4
Surveon CAM6120
6 Protocol Selection
Leave DIP 7-0 ON MLP2 (Merit Lilin Protocol 2)
Camera ID Switch
Please ensure the camera is ID is set according to the following illustration:
Cabling Specifications
AC24V Power Cable
Recommend Cable:
Accessory Connector Information
Note: CONNECT THIS TO 24VAC CLASS 2 POWER SUPPLY ONLY

5
Surveon Network Camera Hardware Manual
RS-485 Twisted Pair
Video Out BNC
oVideo Signal Output CVBS 1.0Vp-p 75 BNC
oRecommend Data Cable: 5C2V
Alarm In/Out
Each fast dome contains 6 alarm inputs and 1 alarm output.
oAlarm Input Voltage: 5.6V max.
oAlarm Output: 1A 24VDC
oRecommend Data Cable:
oUL26 AWG 80 C 300V
oUL24 AWG 80 C 300V
Network Connector RJ45
oLAN : 10/100Mbps
oRecommend Data Cable : CAT5

www.surveon.com
6
Surveon CAM6120
Chapter 3. Installation
3.1. Indoor Installation Structural Drawing

7
Surveon Network Camera Hardware Manual
3.2. Embedded Mounting (False Ceiling)

www.surveon.com
8
Surveon CAM6120

9
Surveon Network Camera Hardware Manual
3.3. Attached Mounting (Fixed Ceiling)

www.surveon.com
10
Surveon CAM6120

11
Surveon Network Camera Hardware Manual
3.4. Wall Mounting (Fixed Bracket)

www.surveon.com
12
Surveon CAM6120
