Svan SVCC9070 User manual

HOOD USER GUIDE
ENGLISH
CAMPANA INCLINADA 90CM
CRISTAL BLANCO_SVCC9070
CAMPANA INCLINADA 90CM
CRISTAL NEGRO_SVCC9070N Read this manual prior to performing any task!

1, en_US
This device is designed exclusively for domestic use
SVAN TRADING SL CIUDAD DE CARTAGENA 20 (FUENTE DEL JARRO)
PATERNA 46988 VALENCIA Spain
Telephone: [phone]
12.03.2019
HOOD USER GUIDE ENGLISH
2

Table of contents
1 Technical Drawing...................................................................................... 4
2 WARNING AND SAFETY PRECAUTIONS................................................. 5
2.1 LETHAL RISK, DANGER OF POISONING......................................... 7
3 USAGE WITH AND WITHOUT CARBON FILTER.................................... 11
4 Carbon Filter Replacement...................................................................... 12
5 CLEANING AND PREVENTIVE MAINTENANCE..................................... 13
5.1 ALUMINIUM FILTER CLEANING....................................................... 13
5.2 Washing in Dishwasher...................................................................... 14
5.3 Hand Wash......................................................................................... 14
6 APPLIANCE POSITION............................................................................. 15
7 CLEANING AND PREVENTIVE MAINTENANCE..................................... 16
7.1 Installation and Unpacking of the Appliance...................................... 16
7.2 Recommendations for Energy Saving................................................ 16
8 CONTENT OF PACKAGE.......................................................................... 17
9 OVERVIEW OF hood................................................................................. 18
10 ASSEMBLY OF PRODUCT....................................................................... 19
10.1 Installation Diagram and Components............................................. 19
11 AIR EXIT INSTALLATION.......................................................................... 21
12 ASSEMBLY OF SHEET METAL FLUES................................................... 22
13 USE OF PRODUCT.................................................................................... 23
13.1 3 Spd Touch Product Usage............................................................ 23
13.2 Using Push Button Product.............................................................. 24
14 REPLACING THE LAMPS......................................................................... 25
14.1 Halogen Lamp Replacement............................................................ 25
14.2 Plug Lamp Replacement.................................................................. 25
15 AUTHORIZED SERVICE........................................................................... 27
16 TECHNICAL TABLE.................................................................................. 29
Table of contents
12.03.2019 HOOD USER GUIDE ENGLISH 3

1 Technical Drawing
Fig. 1: 3420 DIMENSIONED TECHNICAL DRAWING
Technical Drawing
12.03.2019
HOOD USER GUIDE ENGLISH
4

2 WARNING AND SAFETY PRECAU-
TIONS
WARNING AND SAFETY PRECAU-
TIONS
nThis appliance can be used by
children of 8 years and older,
people with physical, sensory or
mental capability deficiency or
people with lack of experience or
knowledge; as long as they are
provided supervision or instruc-
tions for the safe use of the appli-
ance and they comprehend the
dangers.
nChildren should not tamper with
the appliance. Cleaning and user
maintenance operations must not
be performed by children unless
supervised.
nThis product is designed for home
use.
nUsage voltage of your product is
220-240 Volt~50-60 Hz.
nPower cord of your product is fitted
with a grounded plug. This cord
must be plugged into a grounded
outlet.
nThe whole electrical wiring must
be installed by a qualified electri-
cian.
nInstallation by unauthorized per-
sons could lead to poor operation
performance, damage to the
product, and accidents.
nFeeder cable of the appliance
mustn't be exposed to jamming or
crashing during assembly. Feeder
cable mustn't be placed near the
cooker. In such cases, it might
melt down and lead to fire.
nDo not plug in the appliance before
the installation.
nMake sure that the installation
place allows the user to easily
unplug the power cable in case of
any danger.
nDo not touch your product's lamps
when they work for a long time.
The lamps may burn your hand as
they will be hot.
nKitchen hoods are manufactured
for household use in normal home
cooking. There is a risk of malfunc-
tion in other types of use, and the
product guarantee will be void.
nComply with the rules and instruc-
tions regarding discharge of out-
going air, stipulated by the relevant
authorities. (This warning does not
apply to uses without flue.)
nFlammable foods must not be
cooked under the appliance.
nStart your product after you place
pot, pan etc. on the stoves. Other-
wise, high temperature may cause
same parts of your products to
deform.
nTurn off the cooker's burner before
taking the saucepan, pan, etc. off
the cooker.
nDo not leave boiling oil on the
stove. Pots that contain boiling oil
may catch fire by itself.
nSince oils could catch fire when
you cook fried foods in particular,
be careful about your curtains and
tablecloths.
nEnsure timely replacement of the
filters. Filters not replaced in a
timely manner pose risk of fire due
to accumulated grease deposits on
them.
WARNING AND SAFETY PRECAUTIONS
12.03.2019 HOOD USER GUIDE ENGLISH 5
