SVP UDR-70 User manual

UDR-70 Portable Receiver
User Manual
V1.0

Accessories included in this manual:
QPT Pan & Tilt Positioner
SCDA
HAP-60

I
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Contents
Chapter 1: Introduction
This first chapter provides a general description of the Ultra High
Definition UDR-70 receiver equipment.
Chapter 2: Technical features
The second part offers the physical and environmental characteristics
of the Receiver.
Chapter 3: How to order
The third part provides the user with information on ordering and
different configurations available for these Receivers.
Chapter 4: Receiver Operation and Menus
This fourth part provides the user with all the necessary information
to control and operate the equipment properly. It is detailed the
function of each button on the keyboard. It is also explained how the
information is shown on the display, receiver menus, alarms, etc.
Chapter 5: Autotracking Antenna
In this chapter the Autotracking antenna control and how to configure
this option is explained.
Chapter 6: GPS
This chapter indicates the operation of the UDR-70 GPS system and
specifies the parameters that are shown in the GPS screen.
Chapter 7: Web Server
This chapter provides a detailed description of the Web Server tool.
This feature allows controlling the UDR-70 receiver through a website.
Chapter 8: Equipment Installation
This chapter indicates the available connections of the receiver, their
characteristics and the installation.
Chapter 9: Down Converter

II
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
This section provides the user all the necessary information to
understand the general operation characteristics of the down-
converter.
Chapter 10: Preventive maintenance
This chapter explain the procedure that should be followed during the
Receiver's live.
Chapter 11: Warranty
This chapter contains warranty considerations and conditions.
Annex A: QPT User’s Guide
Annex B: SCDA User’s Guide
Annex C: HAP-60 User’s Guide
Annex D: Modulation standards

III
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Dear Customer,
We would like to thank you for selecting this equipment and welcome
you to the SVP’s growing family of products.
We are sure that the addition of this equipment will give complete
satisfaction to you with your existing installation.
Please read these instructions carefully and keep them in hand in case
you need to refer to them.

IV
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
About this manual
This user’s guide provides indications and explanations about how to
set up the UDR-70 receiver easily for the most common use cases.
This document is intended to help first time users:
-To find their way around the GUI.
-To understand the different possibilities of the UDR-70
receiver.
-To configure the UDR-70 for their specific configurations.
Symbols
The symbols that appear in this manual are:
An information message which indicates explanations
for the proper operation of the equipment.
It advises users that if they do not avoid, make or take
specific actions, the device could be damaged.
In the places where this symbol appears it means that
by pressing the Down button of the equipment the user
can access the next screen.
In the options where this symbol appears, means that
pressing the OK button, the user can access the
submenu related to that option or can change the value
of the parameter.
<> These symbols mean that the parameter can be modified
on the same screen with the right and left keys.

V
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Important Notes
1. The UDR-70 H.265 Portable receiver is fully compatible with the
DVB-T standard included in European Standard ETSI EN300744,
with DVB-T2 standard included in ETSI EN300755, with DVB-T
standard included in European Standard ETSI EN300744, with
DVB-S2 standard included in EN302307 and with DVB-S standard
included in ETSI EN 300421. It also complies with the ISDB-T
International technical standard (optional).
2. The control unit has a 70 MHz input connection available through
which it is possible to receive the signal from the RF head via a
triax cable or optical fiber in DVB-T2, DVB-T, DVB-S2 or DVB-S
mode.
3. This device has the ASI and IP outputs available when the input is
ASI. Besides, it has also the ASI output available when the input
is IP.
4. The UDR-70 receiver can receive DVB-T2/T signals from the down
converter that is connected to it.
5. The complete receiver system consists of two parts: firstly, there
is a ODU unit, which is installed outdoors next to the receiver
antenna, and secondly, the UDR-70 receiver which demodulates
the 70MHz delivered by the down converter.
6. On the receiver site it is important to determine if the channel in
which the transmission will be done is interfered, if any other
transmission is being done in that channel.
7. The receiver must be well chilled. Some space must be left next
to the sides of the UDR-70 receiver for ventilation purposes. This
is especially important when it is installed in a rack case.
8. Special care should be taken with SDI cables. Quality and length
are very important especially with 12G-SDI or 3G-SDI signals.
9. It is not advisable to use a power supply lead with a cross-section
less than that of the lead supplied, since this would cause a drop
in the supply voltage and deficient operation of the equipment.
10.Only authorized personnel should open the unit. Any repair or
warranty will be invalidated if the seals are broken.

VI
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
First Aid in Case of Electric Shock
DO NOT TOUCH THE VICTIM WITH YOUR BARE HANDS until the circuit
is broken. SWITCH OFF. If this is not possible, PROTECT YOURSELF
with DRY insulating material and pull the victim clear of the conductor.
If breathing has stopped, indicated by unconsciousness, lack of
respiratory movements and a ‘blue’ look to cheeks, lips, ears and
nails, START RESUSCITATION AT ONCE.
EMERGENCY RESUSCITATION – THE EXPIRED AIR METHOD
(Approved by the Royal Life Saving Society)
1. If possible, lie the victim on his back with his head slightly
higher than his feet. Clear the mouth and throat of any obvious
obstruction.
2. Kneel on one side of the victim, level with his head. LIFT THE
JAW AND TILT THE HEAD BACK AS FAR AS POSSIBLE (Figs. 1a
and 1b)
3. One of the following may happen:
a) Breathing may begin and consciousness returns.
b) Breathing may begin but consciousness NOT
returns. Turn the victim on his side and ensure
that the airway is kept clear.
c) Breathing may return but be NOISY which
means that the airway is not fully clear. Try to
clear the airway.
4. IF THERE NO SIGN OF BREATHING:
a) Check that the head is still tilted back.
b) Take a deep breath.
c) Pinch the victim’s nose and blow firmly into his
mouth (Fig. 2). As you do, the chest will RISE.
d) Turn your head away and take another breath,
watching for the chest to FALL (Fig. 3).
5. Start with four quick breaths and then continue with
one breath every five seconds (i.e. 12 times a minute).
This should be continued until the victim revives or a
doctor certifies death.
6. As consciousness returns the victim will start to
breathe on his own, and a ‘pink’ color replaces the
‘blue’ look: this is the time to stop resuscitation.
Continue to hold his chin up and so keep the airway clear.

VII
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
7. In the case of injuries to the mouth, it may be necessary to use
mouth-to-nose resuscitation. Seal the victim’s mouth with your
cheek and blow firmly into his nose, proceeding as above.
8. In the case of severe facial injuries, it may be necessary to do
a manual method of artificial respiration (Silvester-Brosch or
Holger Nielsen). Briefly, these methods apply compression to
ribcage with the victim lying on his back (S-B) or face down
(H.N.) with associated movement of his arms up and out. The
cycle of movement should take about five seconds, i.e. the
normal breathing phase.
9. Whatever the method, it is ESSENTIAL to commence
resuscitation WITHOUT DELAY and to send for medical
assistance immediately.
TREATMENT FOR BURNS
If the victim is also suffering from burns, then, without hindrance to
resuscitation, observe the following:
a) DO NOT ATTEMP TO REMOVE CLOTHING ADHERING TO THE
BURN.
b) If possible, alleviate the pain from the burnt part by
immersing in cold water.
c) If help as available or as soon as resuscitation is no longer
required, the wound should be covered with a DRY clean
dressing.
d) Oil or grease in any form should not be applied.
e) If severely burnt, get the victim to hospital immediately.

1
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Main Index
Chapter 1: Introduction................................................................... 4
Chapter 2: Technical features .......................................................... 5
Chapter 3: How to Order.................................................................. 9
Chapter 4: Receiver Operation and Menus..................................... 10
4.1 Display...............................................................................................10
4.1.1 1st Main Screen for the DVB-T...........................................11
4.1.2 1st Main Screen for the DVB-T2 .........................................13
4.1.3 1st Main Screen for the DVB-S/S2 (optional)........................16
4.1.4 1st Main Screen for the ASI Input.......................................18
4.1.5 1st Main Screen for the IP Input.........................................19
4.1.6 2nd Main Screen (For the DVB-T2/T)...................................20
4.2 Menus ................................................................................................21
4.2.1 Menu Navigation.............................................................25
4.2.2 Menu Structure...............................................................26
4.2.2.1 Input Select Menu .....................................................................26
4.2.2.1.1 DVB-T.................................................................................27
4.2.2.1.2 DVB-T2 ...............................................................................29
4.2.2.1.3 ISDB-T................................................................................31
4.2.2.1.4 DVB-S/S2 (optional)..............................................................33
4.2.2.1.5 ASI.....................................................................................35
4.2.2.1.6 IP (Optional) ........................................................................35
4.2.2.2 Decoder Menu...........................................................................39
4.2.2.2.1 Decoder Video Screen............................................................39
4.2.2.2.2 Decoder Audio Screen............................................................42
4.2.2.2.3 Decoder Data .......................................................................43
4.2.2.2.4 Decoder Service Screen .........................................................43
4.2.2.2.5 Decoder IP Output.................................................................44
4.2.2.2.6 Decoder Descrambler.............................................................46
4.2.2.3 Autotracking Menu.....................................................................47
4.2.2.4 Unit.........................................................................................56
4.2.2.4.1 Profile .................................................................................56
4.2.2.4.2 Profiles Config ......................................................................56
4.2.2.4.3 Unit Alarms Screen................................................................57
4.2.2.4.4 Measurements Screen............................................................58
4.2.2.4.5 Unit Remote (Webserver).......................................................60
4.2.2.4.6 Unit Miscellaneous Screen ......................................................61
4.2.2.4.7 Unit Firmware Screen ............................................................65
Chapter 5: Autotracking Antenna (optional).................................. 70
5.1 Autotracking Multisector AMS Antenna.....................................................71
5.1.1 How Does It Work...........................................................71
5.1.2 Installation and Configuration ...........................................72
5.2 Autotracking Parabolic Antenna ..............................................................74

2
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
5.2.1 How Does It Work...........................................................74
5.2.2 Installation and Configuration ...........................................75
Chapter 6: GPS .............................................................................. 85
6.1 Transmitter`s GPS Data Output..............................................................85
Chapter 7: Web Server................................................................... 88
7.1 Introduction ........................................................................................88
7.2 Web Page Overview..............................................................................91
7.2.1 DVB-T INPUT .................................................................91
7.2.2 DVB-T2 INPUT................................................................94
7.2.3 DVB-S2/S INPUT.............................................................97
7.2.4 ASI INPUT .....................................................................98
7.2.5 IP INPUT .......................................................................99
7.2.6 DECODER.................................................................... 101
7.2.7 IP Output .................................................................... 106
7.2.8 UNIT........................................................................... 108
Chapter 8: Equipment Installation............................................... 115
8.1 Introduction ......................................................................................115
8.2 Connections ......................................................................................115
8.2.1 Power supply................................................................ 116
AC Power supply...................................................................................116
DC Power supply...................................................................................117
8.2.2 Intermediate frequency.................................................. 119
Intermediate frequency input I.F. ............................................................119
8.2.3 DVB-ASI Transport Stream............................................. 119
DVB-ASI Transport Stream Input.............................................................119
DVB-ASI Transport Stream Output...........................................................120
8.2.4 Video Outputs .............................................................. 120
8.2.5 Genlock....................................................................... 121
Genlock Input.......................................................................................121
8.2.6 Transport Stream over IP(optional).................................. 121
8.2.7 Audio output................................................................ 123
8.2.8 GPS / Data .................................................................. 124
8.2.9 Remote control............................................................. 125
8.2.10 USB............................................................................ 125
8.3 Rack Unit Installation..........................................................................126
8.4 Down-Converter and parabolic antenna installation..................................127
8.5 Antenna Installation ...........................................................................128
Chapter 9: Down Converter ......................................................... 129
9.1 Front Panel........................................................................................129
9.2 Display.............................................................................................130
9.2.1 Receiver threshold ........................................................ 131
9.2.1.1 DVB-T2..................................................................................131
9.2.1.2 DVB-T ...................................................................................134
9.3 Alarms .............................................................................................136
9.4 Connections ......................................................................................137

3
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
9.4.1 IF connector................................................................. 137
Chapter 10: Preventive Maintenance ........................................... 138
10.1 Maintenance Schedule......................................................................138
10.2 Maintenance Procedures ...................................................................138
10.3 Spare parts ....................................................................................139
Chapter 11: Warranty .................................................................. 140
11.1 Warranty information .......................................................................140
11.2 Claim for damage in shipment ...........................................................140
11.3 Return procedures ...........................................................................140
11.4 Transportation and packaging............................................................142
11.5 Authorization for evaluation...............................................................142
Annex A: QPT User’s Guide .......................................................... 143
A.1 Description ............................................................................ 144
A.2 Technical Specifications......................................................... 145
A.2.2 QPT-90.............................................................................................145
Annex B: SCDA User’s Guide........................................................ 147
B.1 Description ............................................................................ 148
B.2 Technical Specifications......................................................... 149
B.3 Mechanical Drawings............................................................. 150
B.4 Configurations....................................................................... 151
Annex C: HAP-60 User’s Guide..................................................... 153
C.1 Description ............................................................................ 154
C.2 Technical Specifications......................................................... 155
Annex D: Modulation Standards................................................... 156
D.1. DVB-T ............................................................................... 156
D.1.1. How Does It Work .......................................................... 156
D.2. DVB-T2 ............................................................................. 157
D.2.1. How Does It Work .......................................................... 157
D.2.2. DVB-T2 New Features..................................................... 157
D.3.3. DVB-T vs DVB-T2........................................................... 159
D.3. DVB-S............................................................................... 160
D.3.1. How Does It Work .......................................................... 160
D.4. DVB-S2 ............................................................................. 161
D.4.1. How Does It Work .......................................................... 161
D.4.2. Pilots in DVB-S2............................................................. 164
D.4.3. DVB-S vs DVB-S2........................................................... 164

4
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Chapter 1: Introduction
The new UDR-70 is a digital UHD portable receiver designed by SVP Broadcast
Microwave to perform DVB-T, DVB-T2 DVB-S2 (optional) and DVB-S (optional).
The latest enables compatibility with neatly all types of COFDM transmitters. The
former modulation outperforms DVB-T modulation and offers much higher data
rate, and therefore, higher quality signal or much more robust signal than DVB-
T, making possible longer and more difficult links. The DVB-S2 modulation
outperforms DVB-S modulation due to DVB-S2 has four modulation modes
available (QPSK, 8PSK, 16APSK and 32APSK) while the DVB-S only has one
modulation available (QPSK). Besides, DVB-S2 uses LDPC code while DVB-S
employs Viterbi code.
The UDR-70 is a ‘two-box’ system with 70 MHz intermediate frequency. It consists
of a control unit and a RF head connected with triax cable or fiber optic. The
distance between the control unit and the RF heads can be up to 600 m with
triax.
It is an H.265, H.264 and MPEG-2 12G/3G/HD/SD professional broadcast quality
decoder. Also, it works in 4:2:2 with 10 bits. Ultra low latency (end to end) of
less than one frame is achieved as long as it is used together with SVP
transmitters.
ASI input and Transport Stream over IP input make it possible to use this Receiver
as a standalone decoder. Besides, the ASI output and the Transport Stream over
IP output enable the user to handle the Receiver as a demodulator.

5
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Chapter 2: Technical features
RF Stage (ODU):
Frequency band: 2 GHz, 4 GHz, 6 GHz, 7 GHz, 10 GHz and 13 GHz
Frequency Stability: ±2.5 ppm
Tuning Step: 10 KHz
Input Level Range: DVB-T2 @ 2 GHz: -20 to -102 dBm (4 Mbit/s)
DVB-T2 @ 5 GHz: -20 to -101 dBm (4 Mbit/s)
Noise Figure: 2.5 dB
IF Frequency: 70 MHz over triax
70 MHz over fiber-Optic (Optional)
IF Stage DVB-T2, DVB-T, DVB-S2 and DVB-S (IDU):
Frequency: 70 MHz over triax
70 MHz over fiber-Optic (Optional)
Demodulation:
DVB-T2 COFDM 1K, 2K, 4K
QPSK, 16QAM, 64QAM, 256QAM
LDPC FEC: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6
IG: 1/4, 19/128, 1/8, 19/256, 1/16, 1/32
1/128
Bandwidth: 1.7, 5, 6, 7, 8 MHz
Max. bit rate: 46.4 Mbps
Min. bit rate: 1 Mbps
DVB-T COFDM 2K mode
QPSK, 16QAM, 64QAM
FEC: 1/2, 2/3, 3/4, 5/6, 7/8
IG: 1/4, 1/8, 1/16, 1/32
Bandwidth: 5, 6, 7, 8 MHz
Max. bit rate: 31.67 Mbps
DVB-S2/S (optional): DVB-S: QPSK
DVB-S2: QPSK, 8PSK, 16 APSK, 32 APSK
LDPC FEC (DVB-S2): 1/4, 1/3, 2/5, 1/2,
3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
FEC (DVB-S): 1/2, 2/3, 3/4, 5/6, 7/8
Max. Symbol Rate 25 Msymb/s
Max. Bandwidth: 30 MHz
Max. Bitrate: 109 Mbps

6
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Decoder:
Modes: HEVC, H.264 and Mpeg-2
Latency Encoder + Decoder: UHD 59p = 66ms
UHD 50p = 75ms
FHD 59p = 55ms
FHD 50p = 70ms
FHD 59i = 83ms
FHD 50i = 98ms
Audio decoder: MPEG-1 Layer 1, MPEG-1 Layer2 and AAC-LC
Video:
Outputs: 1 x 12G-SDI
4 x 3G-SDI, HD-SDI and SD-SDI
1 x SFP 12G Optical interface
Formats: 2160p 23.98/24/25/29.97/30/50/59.94/60 Hz
1080p 23.98/24/25/29.97/30/50/59.94/60 Hz
1080i 50/59.94/60 Hz
720p 23.98/24/25/29.97/30/50/59.94/60 Hz
576i 50 Hz
480i 59.94 Hz
Profile: 4.2.2/4.2.0, 8/10-bit
Genlock: Tri Level Composite
Audio:
Channel Quantity: SDI Embedded 16 channels (8 pairs)
Analogue 2 pair Line level
Output: SDI Embedded
Analogue
Data Channels:
Data channel: User data/GPS
Data rate: 1,200 to 57,600 bps
ASI and IP:
Outputs and Inputs: ASI Transport Stream
Transport Stream over IP (Optional)

7
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Decryption:
BISS: BISS-1 and BISS-E
AES: AES-128 and AES-256
Control and Monitorization of the device:
Control Interfaces: Front panel & display
Web Browser interface
Monitoring: Decoder parameters
Demodulation parameters
Frequency and input level
MER, BER, C/N
Alarms, warnings, logbook and clock
Video: TFT Video screen 5”
Antenna Control (Optional):
Parabolic: Autotracking with positioner in 2 axis
Remote polarization control
Multisector: Autotracking with panel switching
Power Supply:
AC input: 90 to 240 V
DC input: 9 to 36 V

8
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Mechanical:
Control unit: 2 RU Half rack size
Weight: 3.2 Kg
RF head: 2 RU Half rack size
Weight: 3.2 Kg
Max. distance control 400 m (triax cable 11 mm)
unit- RF head 2000 m with Fiber-Optic
Control unit-IF head connection Triax Lemo 3
SMPTE Fiber-Optic Lemo (Optional)

9
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Chapter 3: How to Order

10
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Chapter 4: Receiver Operation and Menus
This section contains all the necessary information to operate, control and
configure the UDR-70 receiver.
4.1 Display
To switch the equipment on and off, press ON/OFF button. When the equipment
is turned on, the display will show a start-up, and then it will display the first
main screen. To change from one main screen to another, the OK button must
be pressed.
1st main screen: displays the most important parameters of the received
signal.
2nd main screen: shows signal reception conditions, level and quality of the
received signal (for DVB-T2 and DVB-T).
It is important to consider that the 1st main screen is different depending on the
standard of the received signal and on the selected input.
Next there are shown the linkages between the input and the character displayed
in the principal screen:
Audio A
Data
DATA D
GPS G
Table 1: Linkages between the input and the character displayed

11
UDR-70 H.265 Portable Receiver
USER’S MANUAL V1.0
Next, the main screen for each input type (DVB-T2, DVB-T, ASI and IP) is
shown:
4.1.1 1st Main Screen for the DVB-T
In the table below, the function of each parameter is explained. These values are
numbered in the order they appear in the main screen.
Parameter
nº
Function
1 Received standard (DVB-T)
2 Received bitrate (Mbps)
3 Video Codification (H.265 / MPEG-2)
4 Video Format (1080p, 1080i, 720p, 576i,
480i)
5
Video options:
Profile (4:2:0 or 4:2:2)
Delay (Standard (S), Low delay (L) or
Super Low delay (SL))
DVBT: 8.0Mb MPEG2 576/50i 420/S
2,300.00MHz QPSK 2/3 1/32 8MHz 2K 0
Received Signal Standard
Reception Frequency
Bitrate
Video
Codification
Output Video
Signal Format
Profile
Delay
Number of Cuts
FEC
Modulation
Guard
Interval
FEC
Bandwidth
Carriers
Figure 1: 1st Main screen DVB-T
