SVP UDR-108 User manual

UDR-108 RECEIVER
MANUAL
V1.0

Accessories included in this manual:
Down Converter &
Switchable Down-
Converter
QPT Pan & Tilt Positioner
Multisector Antennas
GPS-02
Receiver with
Antenna
NX-820 voice
and GPS
Transmitter

UDR-108 Diversity Receiver
MANUAL V1.0 3
Contents
Chapter 1: Introduction
The first chapter provides a general description of the UHD Definition UDR-
108 Receiver.
Chapter 2: Technical features
The second part offers the physical and environmental characteristics of the
Receiver.
Chapter 3: How to order
The third part provides the user with information on ordering and different
configurations available for these Receivers.
Chapter 4: Receiver Operation and Menus
The fourth part provides the user with all the necessary information to control
and operate the equipment properly. The function of each button on the
keyboard is detailed. It also outlines how the information is shown on the
display, Receiver’s menus, alarms, etc.
Chapter 5: Autotracking Antenna
In this chapter the Autotracking antenna control and how to configure this
option is explained.
Chapter 6: GPS
This chapter indicates the operation of the Receiver GPS system and specifies
the parameters that are shown in the GPS screen.
Chapter 7: Web Server
This chapter provides a detailed description of the Web Server tool. This
feature allows the control of the Receiver through a website.
Chapter 8: Equipment Installation
This chapter indicates the available connections of the Receiver, the
characteristics, and the installation.
Chapter 9: Mechanical Dimensions
In this chapter, the mechanical drawing of the units described in this manual
are included.
Chapter 10: Preventive maintenance
This chapter explain the procedure that should be followed during the
Receiver's live.
Chapter 11: Warranty
This chapter contains warranty considerations and conditions.
Annex A. DC & User Guide
The annex A includes the user guide for DC COFDM down converters.

UDR-108 Diversity Receiver
MANUAL V1.0 4
Annex B. QPT User Guide
This annex indicates how to install and use the QPT-20 and QPT-90 with SVP
Broadcast Microwave’s tracking system.
Annex C. NX-820 User Guide
This annex provides a brief description of the technical features of the UHF
GPS&Voice transceiver.
Annex D Multisector Antennas User Guide
This annex includes the user guide for the multisector antennas, both
diversity and switching antennas developed by SVP.
Annex E. Video over IP Monitoring on a PC
Here how to use the video over IP output connection to a computer is
explained.
Annex F. GPS-02 Receiver
This annex includes all the characteristics for the external GPS Receiver with
antenna.

UDR-108 Diversity Receiver
MANUAL V1.0 5
Dear Customer,
We would like to thank you for selecting this equipment and welcome you to
the SVP’s growing family of products.
We are sure that the addition of this equipment will give complete satisfaction
to you with your existing installation.
Please read these instructions carefully and keep them to hand in case you
need to refer to them.

UDR-108 Diversity Receiver
MANUAL V1.0 6
About this manual
This user’s guide provides indications and explanations about how to set up
the Receiver easily in the most common cases.
This document is intended to help first time users:
•To find their way around the GUI.
•To understand the different possibilities of the Receiver.
•To configure the UDR series for their specific configurations.
Symbols
The symbols that appear in this manual are:
An information message which indicates explanations for the
proper operation of the equipment.
It advises users that if they do not avoid, make or take specific
actions, the device could be damaged.
In places where this symbol appears it means that by pressing the
Down button the user can access the next screen.
In the options where this symbol appears, means that pressing the
OK button, the user can access the submenu related to that option
or can change the value of the parameter.
These symbols mean that the parameter can be modified on the
same screen with the right and left keys.

UDR-108 Diversity Receiver
MANUAL V1.0 7
Important Notes
•UDR series are HEVC, H.264 and Mpeg-2 decoder, and DVB-T2, DVB-T
and ISDB-T with up to 8 diversities Receivers, these Receivers are fully
compatible with the DVB-T2 standard included in ETSI EN30075, with
DVB-T standard included in European Standard ETSI EN300744 and
ISDB-T included in ARIB STD-B31 standard.
•The complete Receiver system consists of two parts: firstly, there are
one or more down-converters, which are installed outdoors next to the
Receiver antennas and secondly, the UDR series Receiver which
demodulates the IF delivered by the down converter.
•These Receivers are commonly used with SVP DC down converters,
which are available from 1.3 to 10.5 GHz in different frequency bands.
•On the Receiver site it is important to determine if the channel in which
the transmission will be done has interference, if any other transmission
is being done in that channel.
•While the equipment is being installed, the power supply of the down-
converters should be disabled in the Setup Configuration menu in order
to avoid the risk of short circuits.
•If Celflex 1/2 coaxial cables are used, the maximum length is 150 m. On
the other hand, if RG-214 coaxial cables are used, the maximum length
is limited to 100m.
•The Receiver must be well ventilated. Some space must be left next to
the sides of the Receiver for ventilation purposes. This is especially
important when it is installed in a rack case.
•Special care should be taken with 4K cables. Quality and length are very
important especially with 12G signals.
•If the user wants to install the rack mount demodulator unit horizontally,
guides should be used, due to the weight of the equipment.
•It is not advisable to use a power supply lead with a cross-section less
than that of the lead supplied, since this would cause a drop in the supply
voltage and a deficiency in the operation of the equipment.
•Only authorized personnel should open the unit. Any repair or warranty
will be invalidated if the seals are broken.

UDR-108 Diversity Receiver
MANUAL V1.0 8
First Aid in Case of Electric Shock
DO NOT TOUCH THE VICTIM WITH YOUR BARE HANDS until the circuit is
broken. SWITCH OFF ELECTRIC CURRENT FOR MAINS. If this is not possible,
PROTECT YOURSELF with DRY insulating material and pull the victim clear of
the conductor.
If breathing has stopped, indicated by unconsciousness, lack of respiratory
movements and a ‘blue’ look to cheeks, lips, ears and nails, START
RESUSCITATION AT ONCE.
EMERGENCY RESUSCITATION – THE EXPIRED AIR METHOD
(Approved by the Royal Life Saving Society)
1. If possible, lie the victim on his back with his head slightly higher than
his feet. Clear the mouth and throat of any obvious obstruction.
2. Kneel on one side of the victim, level with his head. LIFT THE JAW
AND TILT THE HEAD BACK AS FAR AS POSSIBLE (Figs. 1a and 1b)
3. One of the following may happen:
4. Breathing may begin and consciousness returns.
5. Breathing may begin but consciousness NOT returns.
Turn the victim on his side and ensure that the airway
is kept clear.
6. Breathing may return but be NOISY which means that
the airway is not fully clear. Try to clear the airway.
7. IF THERE NO SIGN OF BREATHING:
8. Check that the head is still tilted back.
9. Take a deep breath.
10. Pinch the victim’s nose and blow firmly into his mouth
(Fig. 2). As you do, the chest will RISE.
11. Turn your head away and take another breath,
watching for the chest to FALL (Fig. 3).
12. Start with four quick breaths and then continue with
one breath every five seconds (i.e. 12 times a
minute). This should be continued until the victim
revives or a doctor certifies death.
13. As consciousness returns the victim will start to
breathe on his own, and a ‘pink’ color replaces the
‘blue’ look: this is the time to stop resuscitation.
Continue to hold his chin up and so keep the airway
clear.
14. In the case of injuries to the mouth, it may be necessary to use
mouth-to-nose resuscitation. Seal the victim’s mouth with your cheek
and blow firmly into his nose, proceeding as above.

UDR-108 Diversity Receiver
MANUAL V1.0 9
15. In the case of severe facial injuries, it may be necessary to do a
manual method of artificial respiration (Silvester-Brosch or Holger
Nielsen). Briefly, these methods apply compression to ribcage with
the victim lying on his back (S-B) or face down (H.N.) with associated
movement of his arms up and out. The cycle of movement should
take about five seconds, i.e. the normal breathing phase.
16. Whatever the method, it is ESSENTIAL to commence resuscitation
WITHOUT DELAY and to send for medical assistance immediately.
TREATMENT FOR BURNS
If the victim is also suffering from burns, then, without hindrance to
resuscitation, observe the following:
1. DO NOT ATTEMP TO REMOVE CLOTHING ADHERING TO THE BURN.
2. If possible, alleviate the pain from the burnt part by immersing in cold
water.
3. If help as available or as soon as resuscitation is no longer required,
the wound should be covered with a DRY clean dressing.
4. Oil or grease in any form should not be applied.
5. If severely burnt, get the victim to hospital immediately.

UDR-108 Diversity Receiver
MANUAL V1.0 10
Index
Index............................................................................................. 10
Chapter 1: Introduction................................................................. 13
Chapter 2: Technical features ........................................................ 15
Chapter 3: How to order ................................................................ 18
Chapter 4: Receiver Operation and Menus ..................................... 19
4.1 Display.................................................................................. 19
4.1.1 1st Main Screen .................................................................20
4.1.2 2nd Main Screen.................................................................22
4.1.3 3rd Main Screen .................................................................22
4.2 TFT Screen ............................................................................ 23
4.3 LEDs...................................................................................... 23
4.4 Front panel ........................................................................... 24
4.4.1 ON/OFF Button..................................................................25
4.4.2 OK Button ........................................................................25
4.4.3 Cross Button.....................................................................25
4.4.4 Left and Right Button .........................................................25
4.4.5 Up and Down Button..........................................................26
4.5 Menus ................................................................................... 27
4.5.1 Menu Navigation................................................................31
4.5.2 Menu Structure .................................................................32
Chapter 5: Autotracking Antenna (optional).................................. 81
5.1 Autotracking Multisector AMS Antenna................................. 82
5.1.1 How it Works ....................................................................82
5.1.2 Installation and Configuration..............................................83
5.2 Autotracking Parabolic Antenna............................................ 85
5.2.1 How it works.....................................................................85
5.2.2 Installation and Configuration..............................................86
Chapter 6: GPS Output Interfaces.................................................. 96
6.1 Transmitter’s GPS Data Output ............................................. 96
Chapter 7: Web Server / Serial Control.......................................... 99
7.1 Web server............................................................................ 99
7.1.1 Receiver menu ................................................................... 99
7.1.2 Web Page Overview ......................................................... 102
7.1.2.1 DVB-T INPUT................................................................ 102

UDR-108 Diversity Receiver
MANUAL V1.0 11
7.1.2.2 DVB-T2 INPUT.............................................................. 105
7.1.2.3 ISDB-T INPUT .............................................................. 108
7.1.2.4 ASI INPUT ................................................................... 110
7.1.2.5 TS over IP INPUT.......................................................... 112
7.1.2.6 DECODER .................................................................... 114
7.1.2.7 IP Output .................................................................... 119
7.1.2.8 UNIT........................................................................... 121
Chapter 8: Equipment Installation ............................................ 127
8.1 Introduction........................................................................ 127
8.2 Connections ........................................................................ 127
8.2.1 Power supply .................................................................. 129
8.2.2 Intermediate Frequency.................................................... 131
8.2.3 DVB-ASI Transport Stream................................................ 132
8.2.4 Video Outputs................................................................. 133
8.2.5 Genlock ......................................................................... 134
8.2.6 Transport Stream over IP (optional) ................................... 135
8.2.7 Audio Output .................................................................. 136
8.2.8 DATA 1 and DATA 2 Ports ................................................. 138
8.2.8.1.1 Data connector to Compass cable pinout........................ 139
8.2.9 Autotracking connector (Optional)...................................... 141
8.2.10 Remote control.............................................................. 148
8.2.11 USB............................................................................. 148
8.3 Down-Converter Installation............................................... 149
Chapter 9: Mechanical Dimensions .............................................. 150
9.1 UDR-108 Mechanical Drawing............................................. 151
9.2 DC Down Converter Mechanical Drawing ............................ 152
9.3 AM-206 Antenna Mechanical Drawing................................. 154
9.4 GPS-02 GPS Receiver Mechanical Drawing.......................... 155
Chapter 10: Preventive Maintenance ........................................... 156
10.1 Maintenance Schedule ...................................................... 156
10.2 Maintenance Procedures................................................... 156
10.3 Spare Parts ....................................................................... 156
Chapter 11: Warranty .................................................................. 157
11.1 Warranty information ....................................................... 157
11.2 Claim for damage in shipment........................................... 157
11.3 Return procedures ............................................................ 157
11.4 Transportation and packaging........................................... 158

UDR-108 Diversity Receiver
MANUAL V1.0 12
11.5 Authorization for evaluation ............................................. 158
Annex A: DC User Guide............................................................... 159
A.1 DC COFDM Down-Converter ................................................ 160
A.1.1 Description ...................................................................... 160
A.1.2 Technical Specifications................................................... 161
Annex B: QPT User Guide............................................................. 163
B.1 Description ......................................................................... 164
B.2 Technical Specifications...................................................... 165
B.2.1 QPT-20.......................................................................... 165
B.2.2 QPT-90.......................................................................... 168
Annex C: NX-820 User Guide ....................................................... 171
C.1 Description ......................................................................... 172
C.2 Technical Specifications...................................................... 173
Annex D: Multisector Antennas User Guide.................................. 175
D.1 AM-x06 Multisector Diversity Antenna................................ 176
D.1.1 Introduction ................................................................... 176
D.1.2 Technical Specifications.................................................... 177
D.2 AM-x04 Multisector Antenna............................................... 181
D.2.1 Introduction ................................................................... 181
D.3.2 Technical Specifications.................................................... 182
D.3 AMS-x06 Multisector Switch Antennas................................ 184
D.3.1 Introduction ................................................................... 184
D.3.2 Technical Specifications.................................................... 185
Annex E: Video over IP Monitoring on a PC.................................. 189
E.1 Introduction........................................................................ 189
E.2 VLC media player ................................................................ 189
E.2.1 VLC as a player ............................................................... 189
E.2.2 VLC as a recorder ............................................................ 194
Annex F: GPS-02 Receiver ........................................................... 197
F.1 Description.......................................................................... 197
F.2 Technical Specifications ...................................................... 198
Glossary....................................................................................... 200

UDR-108 Diversity Receiver
MANUAL V1.0 13
Chapter 1: Introduction
The UDR-108 and UDR-104 Receivers perform DVB-T2, DVB-T and ISDB-T
demodulations. The later enables compatibility with nearly all types of COFDM
Transmitters. The DVB-T2 modulation outperforms other modulations and
offers much higher data rate and therefore, higher quality or much more
robust signal than DVB-T and ISDB-T, making longer and more difficult links
possible.
It integrates up to 8 diversities in DVB-T2, DVB-T and ISDB-T demodulations,
using spatial diversity based on MRC (Maximum Ration Combining)
technique, which reduces the effects of multipath and fading losses.
The down-converters are connected to an independent Receiver antenna in
order to provide diversity. This allows the user to install different antennas to
take advantage of their combined characteristics or employ antennas with
similar characteristics orientated in different directions in order to offer wider
coverage. The use of a diversity system makes the link more robust and offers
better performance than a non-diversity system.
This Receiver features HEVC, H.264 and MPEG-2 decoding for up to UHD
definition.
ASI input and Transport Stream over IP input make it possible to use this
Receiver as a standalone decoder. Besides, the ASI output and the Transport
Stream over IP output enable the user to handle the Receiver as a
demodulator.
This new generation of Receivers has several outputs: 12G-SDI, 4 x 3G-SDI
and one 12G SFP Optical Interface. The received signal is simultaneously
reproduced in all the outputs. User data or GPS data can be received over the
data channel.
The easy control, operation and monitoring make these Receivers very
manageable. All the parameters of the Receiver can be configured in the field
using the front panel and display or the web-browser.
From now on, the Receivers UDR-108 and UDR-104 will be referred as
the Receiver, as the content of this manual is applicable to all three
models, unless any configuration or feature is specific to a model.

UDR-108 Diversity Receiver
MANUAL V1.0 14
Figure 1.1 AM Multisector Antenna connection figure

UDR-108 Diversity Receiver
MANUAL V1.0 15
Chapter 2: Technical features
RF Stage DVB-T2, DVB-T and ISDB-T:
Frequency Range:
Input Level Range:
Diversity Technique:
1.3 to 10.5 GHz (Depending on the
Down converter used)
DVB-T2 @ 2 GHz: -20 to -102 dBm
DVB-T2 @ 5 GHz: -20 to -101 dBm
MRC (Maximum Ratio Combining)
Tuning Step:
10 kHz
Diversity:
IF Input connector:
8 in the UDR-108
4 in the UDR-104
TNC 50 Ohms (Default)
BNC 75 Ohms (Optional)
Demodulation:
DVB-T2:
COFDM 1K, 2K, 4K
QPSK, 16QAM, 64QAM, 256QAM
LDPC FEC: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6
IG: 1/8, 1/16, 1/32
Bandwidth: 1.7, 5, 6, 7, 8 MHz
Max. bitrate: 46.4 Mbps
DVB-T:
COFDM 2K
QPSK, 16QAM, 64QAM
FEC: 1/2, 2/3, 3/4, 5/6, 7/8
IG: 1/8, 1/16, 1/32
Bandwidth: 5, 6, 7, 8 MHz
Max. bitrate: 31.67 Mbps
ISDB-T:
COFDM 2K, 4K and 8K
QPSK, 16QAM, 64QAM
FEC: 1/2, 2/3, 3/4, 5/6, 7/8
IG: 1/4, 1/8, 1/16, 1/32
Bandwidth: 6, 7, 8 MHz
Max. bitrate: 31 Mbps

UDR-108 Diversity Receiver
MANUAL V1.0 16
Decoder:
Modes:
HEVC, H.264 and MPEG2
Latency:
Encoder+Decoder
UHD 59p = 66ms
UHD 50p = 75ms
FHD 59p = 55ms
FHD 50p = 70ms
FHD 59i = 83ms
FHD 50i = 98ms
Audio Decoder:
MPEG-1 Layer 1, MPEG-1 Layer 2 and AAC-LC
Video:
Outputs:
12G-SDI
4 x 3G-SDI, HD-SDI and SD-SDI (optional)
1 x SFP 12G Optical interface
Formats:
Profile:
Genlock:
2160p–23.98/24/25/29.97/30/50/59.94 /60 Hz
1080p-23.98/24/25/29.97/30/50/59.94/60 Hz
1080i-50/59.94/60 Hz
720p-23.98/24/25/29.97/30/50/59.94/60 Hz
576i-50 Hz
480i-59.94 Hz
4.2.2/4.2.0, 8/10-bit
Tri Level Composite
Audio:
Channel Quantity:
Outputs:
SDI Embedded 16 channels (8 pairs)
Analogue 2 pair Line level
SDI Embedded
Analogue
Data Channels:
Data channel:
User data/GPS
Data rate:
1,200 to 57,600 bps

UDR-108 Diversity Receiver
MANUAL V1.0 17
ASI and IP:
Outputs and Inputs:
ASI Transport Stream
Transport Stream over IP (Optional)
Decryption:
BISS:
BISS-1 and BISS-E
AES (Optional):
AES-128 and AES-256
Control and Monitorization of the device:
Control Interfaces:
Front panel and display
Web Server
Monitoring:
Decoder parameters
Demodulation parameters
Frequency and input level
MER, BER, C/N
Alarms, warnings, logbook and clock
Video:
TFT Video screen 5″
Antenna Control (Optional):
Parabolic:
Local GPS, Remote GPS, Compass and
Inclinometer
Control of QPT positioner
Power Supply:
AC input:
100 to 240 V
DC input:
9 to 36 V
Mechanical:
Size:
2 RU Half rack size
Weight:
3.2 kg

UDR-108 Diversity Receiver
MANUAL V0 18
Chapter 3: How to order

UDR-108 Diversity Receiver
MANUAL V0 19
Chapter 4: Receiver Operation and Menus
This section contains all the necessary information to operate, control and
configure the Receiver.
4.1 Display
To switch the equipment on and off, press ON/OFF button. When the
equipment is turned on, the display will show a start-up, and then it will
display the company logo, to show the first main screen, please press OK
button. To change from one main screen to another, the OK button must be
pressed.
•1st main screen: displays the most important parameters of the received
signal.
•2nd main screen: shows signal reception conditions, level and quality (for
DVB-T2, DVB-T and ISDBT).
•3rd main screen: displays the level of the eight received signals on the
whole screen (for DVB-T2 and DVB-T).
It is important to consider that the 1st main screen is different
depending on the standard of the received signal and the selected
input.
Next, the main screen for each input type (DVB-T2, DVB-T, ISDBT, ASI and
IP) is shown:

UDR-108 Diversity Receiver
MANUAL V0 20
4.1.1 1st Main Screen
In the table below, the function of each parameter is explained.
Figure 4.1: 1st Main screen DVB-T2
Parameter nº
Function
1
Received standard (DVB-T2)
2
Received bitrate (Mbps)
3
Video Codification (H.264 / MPEG-2)
4
Video Format (1080p, 1080i, 720p, 576i, 480i)
5
Video options:
Profile (4:2:0 or 4:2:2)
Delay (Standard (S), Super Low delay (SL)) or Ultra Low
delay (UL).
6
Characters 1 (Audio 1) and 2 (Audio 2):
Audio status indication (Audio 1 and 2 not darkened ->
audio received | darkened -> audio not received)
Character 3:
Data status indication (not darkened -> data received |
darkened -> data not received)
7
Reception frequency (MHz)
8
Modulation (QPSK, 16QAM, 64QAM, 256QAM)
9
LDPC FEC (1/2, 3/5, 2/3, 3/4, 4/5, 5/6)
10
Guard Interval (1/4, 19/128, 1/8, 19/256, 1/16, 1/32)
11
Bandwidth (1.7, 5, 6, 7, 8 MHz)
12
Number of carriers (2k, 4k, 8k and 8k_ext)
13
Diversity Technique: Mobile (M) or Fixed (F)
14
Number of cuts occurred to the input RF signal: In case there is a
cut in the RF received signal, the number of cuts counter will
increase its value in 1. To reset and set to 0 this value, press left
button.
Table 4.1: Main screen for DVB-T2 standard
