Swann NVW-500CAM User manual

Swann Communications warrants this product against defects in workmanship and material for a period of
one (1) year from its original purchase date. You must present your receipt as proof of purchase for warranty
validation. Any unit which proves defective during the stated period will be repaired without charge for parts or
labour or replaced at the sole discretion of Swann. The end user is responsible for all freight charges incurred
to send the product to Swann’s repair centres. The end user is responsible for all shipping costs incurred when
shipping from and to any country other than the country of origin.
The warranty does not cover any incidental, accidental or consequential damages arising from the use of or
the inability to use this product. Any costs associated with the fitting or removal of this product by a tradesman
or other person or any other costs associated with its use are the responsibility of the end user. This warranty
applies to the original purchaser of the product only and is not transferable to any third party. Unauthorized end
user or third party modifications to any component will render all warranties void. By law some countries do not
allow limitations on certain exclusions in this warranty. Where applicable by local laws, regulations and legal
rights will take precedence.
For Australia: Our goods come with guarantees which cannot be excluded under Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be
of acceptable quality.
Wireless Camera
Heat & motion-sensing video transmitted wirelessly, sensor
spot-lights, sirens, 2-way audio & color night vision
Instruction Manual
Security Made Smarter
Limited Warranty - Terms & Conditions6
EN
MNVW500CAMREV1E | © Swann 2021
Helpdesk & Resources
Security Made Smarter
Visit Swann Support Center at support.swann.com. You can register
your product for dedicated customer support, download guides, find
answers to commonly asked questions, and more.
Product Registration Customer Support
Product Manuals Frequently Asked Questions
Support Community
1. Take into consideration what you want to monitor
and where you’ll get the best view of it.
2. How you’re going to connect the camera to your
monitoring system; remember that cables and con-
nections should be kept out of the weather.
3. How to keep the camera out of harm’s way. It’s
recommended to mount your camera at an elevated
position.
4. Place your camera as close to the area of inter-
est as practicable. The best position is from about
13ft/4m above looking slightly down, keeping in mind
the details you are looking for.
5. Although the sky looks nice when you look at the
live view from your camera, it is an unlikely direction
for an offender to approach. Make sure your camera
has minimal sky in it as the light in daylight can make
the foreground of the image darker.
6. Think about the most likely way a potential offend-
er may approach your home, use your camera to give
you the best coverage of these areas.
7. The camera’s casing is resistant to different weath-
er conditions and tampering. It would take an over-
whelming event to damage the housing.
8. Even though the camera is weather and water-
resistant, prolonged exposure to adverse weather
conditions such as sunlight or excessive moisture,
may eventually damage the internal components of
the camera and adversely affect its performance.
9. Run cables inside a wall cavity or other protected
enclosure, and ensure that all wiring and connectors
are insulated and protected from moisture.
10. Don’t put your cable near live electrical wiring. AC
electricity generates radio “noise” which can inter-
fere with the signal from your camera.
Camera Location Tips5
NVW-500CAM

Introduction
Congratulations on the purchase of your Swann Wi-Fi
NVR Security Camera.
• 1080p Full HD video transmitted wirelessly to
your NVR
• SwannNet™ technology for the best available
Wi-Fi signal
• Controllable sensor spotlights & sirens
• True Detect™ heat & motion sensing
Important instructions
1. Make sure the camera is fixed correctly and stable
if fastened in place.
2. Never place strain of any kind on the power con-
nection and/or power adapter.
3. Do not operate if wires and terminals are exposed.
Important Note: All jurisdictions have specific laws
and regulations relating to the use of cameras. Be-
fore using any camera for any purpose, it is the buy-
er’s responsibility to be aware of all applicable laws
and regulations that limit the use of cameras.
About this Manual: The content in this manual is for
information purposes only and is subject to change
without notice. While every effort is made to ensure
that this manual is accurate at the time of printing,
no liability is assumed for any errors that occurred.
The camera can be mounted onto a flat surface using the screws and wall plugs provided. The surface must
have sufficient strength to hold the camera (the camera illustrated is for instructional purposes only).
→ Position the camera in the location you want to mount it, and mark the screw holes on the surface to
position the screws (a mounting template has been included). Then, using the appropriate screws for the
surface you’re fixing the camera to, secure the camera in place.
→ If you’re mounting to a wooden surface, then screw the camera directly to the surface.
→ If you’re mounting to a masonry surface (bricks, concrete or similar), then you’ll need to use wall plugs.
1Mounting the Camera4
Aiming the camera
1. Loosen both screws (use a Phillips head screwdriver) to ad-
just the camera’s orientation. This enables you to rotate the
camera so no matter what direction it is facing, your images
will be the right way up. Tighten each screw to secure in place.
2. Loosen the screw to tilt the camera up or down. Tighten the
screw to secure in place.
3. To pan the camera left or right, loosen the screw and position
accordingly. Tighten the screw to secure in place.
Connect the output on the power cable to the power input on the camera then connect the input on the power
cable to the power adapter. The pair/reset button is used to restore factory default settings and to pair the
camera to your NVR (if network settings are changed or when adding a new camera).
Connecting the Camera2
2
Power
Output
Power
Input
Power Cable
Power Adapter
3
1
Power
Input
Pair/Reset
Leave the antenna in a vertical
position for best reception.
Connect the power adapter to
a power outlet then press the
outlet’s switch to the ON posi-
tion to supply power.
Pairing the Camera3
For instructions on how to configure your camera
for motion detection, changing image settings,
and other functions available, please consult the
manual for your NVR. Go to support.swann.com,
search for your model, then download.
1. In Live View mode, click a channel that you want to pair the camera to.
2. A Pair button appears. Press this button to commence pairing. A message will appear stating that you need
to press the pair button on the camera.
3. Remove the cap covering the pair button. Press and hold the pair button for 3 seconds then release. The
camera will commence pairing and the camera’s IR LEDs will start flashing.
4. After a short moment the camera will be paired and you will see the camera’s image on-screen. If the camera
fails to pair, repeat the above instructions and try again.
Channel 2 28/04/2021 01:14:41 PM
Channel 3 28/04/2021 01:14:41 PM Channel 4 28/04/2021 01:14:41 PM
Off-line
Press the Pair button to
commence pairing.
2
1
3

Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this
device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body
4 FCC Statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation
of the device.
The term “IC: “ before the certification/registration number only signifies that the Industry Canada technical
specifications were met. This product meets the applicable Industry Canada technical specifications. Cet
appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS)
d'Innovation, Sciences et Développement économique Canada. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage,
et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
This equipment should be installed and operated with a minimum distance of 20 centimetersbetween the
radiator and your body.
Cet équipement doit être installé et utilisé à une distance minimale de 20 centimètres entre leradiateur et
votre corps.
4 IC Statement
