Rydeen CM-S1000P User manual

Product features:
1. Waterproof: IP69K approved
2. Nightvision distance: approx. 16.4ft (5 IR lights)
3. Day / Night sensor for automatic adjustment
4. Wider viewing angle up to 140 degrees
Precautious:
Side camera
1. Be cautious when mounting camera and wiring near fuel tank.
Model: CM-S1000P
2. The device is designed to work with +12 volt DC power supply.
Assembly:
Specifications:
DC 9 - 16V
-4℉~ 158℉, RH 95% max.
f=1.7mm, F=2.0
140°
Auto
+48 dB
Auto
1/60 -1/100,000 second
Auto
Day: 12V / 55mA; Night: 12V / 120mA
Power Supply:
Operating Temperature:
Lens:
Lens Angle:
BLC:
Current Consumption:
Electronic Shutter:
Resolution:
Minimum Illumination:
Microphone:
Horizontal Sync. Freq.:
Video Output:
Gamma Consumption:
Scanning System:
Internal
AGC:
S/N Ratio:
White Balance:
Sync. System:
2:1 Interlace
0.45
500 TV Lines
0.1 Lux (day), 0 Lux (with IR)
Built in microphone
15.734KHz
1.0 vp-p,75 Ohm
Owner's Manual
Image Device:
TV System:
Effective Pixels:
Sensing Area:
1/3” Color CMOS PC1089
NTSC
728 x 488 pixels
0.18 inch x 0.14 inch
■CAMERA
①
■ACCESSORIES
②
①Camera (enclosure is detachable) X1
②Assembly parts for fixing camera
●Spring washer M4*1 (stainless steel) X3
●Cross recessed pan head screws ST4*20 X3

Installation:
(1) Find an appropriate location for installation (Illustration 1).
(2) Drill holes according to the size of front enclosure as illustration 2.
(Illustration 1) (Illustration 2)
location 1
location 2
Φ20 hole
(Illustration 3)
Cross recessed pan head screws ST4*20
(3) Fix the front body to the location (illustration 3).
(4) Fix the rear enclosure onto the front enclosure; adjust camera angle; lock the front and
rear enclosure using screws (Illustration 4).
(Illustration 4)
Camera
(5) Connect the camera tail and the extension cable inside the vehicle (Illustration 5).
Extension Cable
(Illustration 5)
Camera Tail
Direction Arrow
(Illustration 6)
Rear of the Vehicle
Bumper
(6) Loosen the screw between the camera and vehicle body and adjust the camera to a best
viewing angle (Illustration 6).
camera camera
Monitor Image
about 137°
Angle of the Lens
Vehicle Body
