Swann SF31020N User manual

Halogen Oven and Air Fryer
Model: SF31020N
Help line: 01733 404703
v1.0

2
When using any electrical appliance, basic safety precautions should always be followed
including the following:
• Always ensure that the voltage on the rating label corresponds to the mains voltage in
your home
• Incorrect operation and improper use can damage the appliance and cause injury to the
user.
• This appliance can be used by children aged from 8 years and above if they have been
given supervision or instruction concerning use of the appliance in a safe way and if they
understand the hazards involved. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised. Keep the appliance and its cord out
of reach of children aged less than 8 years. Check the power cord and plug regularly for
any damage. If the cord or the plug is damaged, it must be replaced by the manufacturer
or qualified person in order to avoid an electrical hazard.
• Do not use the appliance if it has been dropped or damaged in any way. In case of damage,
take the unit in for examination and/or repair by an authorised service agent.
• Never immerse the unit in water or any other liquid for cleaning purposes.
• Remove the plug from the socket by gripping the plug. Do not pull on the cord to disconnect
the appliance from the mains. Always unplug the unit when not in use, before cleaning or
when adding or removing parts.
• The use of accessory attachments that are not recommended or supplied by the
manufacturer may result in injuries, fire or electric shock.
• Do not let the cord hang over the edge of a table or counter. Ensure that the cord is not
in a position where it can be pulled on inadvertently.
• Do not allow the cord to touch hot surfaces and do not place on or near a hot gas or
electric burner or in a heated oven.
• Do not use the appliance on a gas or electric cooking top or over or near an open flame.
• Use of an extension cord with this appliance is not recommended. However, if it is necessary
to use an extension lead, ensure that the lead is suited to the power consumption of the
appliance to avoid overheating of extension cord, appliance or plug point. Do not place the
extension cord in a position where it can be pulled on by children or animals or tripped
over.
• This appliance is not suitable for outdoor use. Do not use the appliance for anything other
than its intended use.
• Do not carry the appliance by the power cord.
• Do not leave the appliance unattended during use. Always unplug the unit when not in use
or before cleaning.
• Always operate the appliance on a smooth, even, stable surface. Do not place the unit on
a hot surface.
• Ensure that the unit is switched off after use.
• The manufacturer does not accept responsibility for any damage or injury caused by
improper or incorrect use, or for repairs carried out by unauthorised personnel.
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

3
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
CAUTION: SURFACES BECOME HOT DURING USE. ALWAYS USE THE
TONGS WHENEVER POSSIBLE
CAUTION: PLEASE ENSURE YOUR WORK TOP IS ABLE TO WITHSTAND A
TEMPERATURE OF AT LEAST 60 DEGREES CENTIGRADE FOR EXTENDED
PERIODS. IF IN DOUBT, MOUNT THE PRODUCT ON A SUITABLE WOODEN
PLINTH.
• In case of technical problems, switch off the product and do not attempt to repair it
yourself. Return the appliance to an authorised service facility for examination, adjustment
or repair. Always insist on the use of original spare parts. Failure to comply with the above
mentioned precautions and instructions, could affect the safe operation of this product.
• Your appliance must never be switched on through an external timer or any kind of
separate remote control system
CAUTION: PLEASE HANDLE THE TOUGHENED GLASS BOWL WITH
GREAT CARE - ESPECIALLY WHEN WET. REPLACEMENT BOWLS ARE
NOT COVERED BY YOUR WARRANTY
Description: Halogen Oven and Air Fryer
Model: SF31020N
Input Voltage: 220-240V
Frequency: 50/60Hz
Power consumption: 1300 Watts
TECHNICAL DATA

4
PARTS
Before first use, carefully remove all packaging and familiarise yourself with the
various parts of your product
TIMER TEMPERATURE
HANDLE. Switches unit off
when lifted
MOTOR UNIT
HALOGEN ELEMENT
EXTENDER RING
TOUGHENED GLASS
BOWL
BASE. Try to keep the glass
bowl in the base as much
as possible to reduce risk of
breakage
ACCESSORIES INCLUDED WITH THIS MODEL
• High and low wire racks
• Mesh racks x 2
• Tongs
• Motor unit stand
• Oil bottle
• Extender ring

5
HOW TO USE
This product uses air flow in conjunction with a halogen element to cook food quickly
and efficiently. Some of the many benefits are:
• Reduced cooking times
• Little or no pre-heating needed
• Even cooking with little or no fat required
• Compact, space-saving design
Before we start, it’s usually a good idea to line the bottom of the bowl with aluminium
foil. This should help with cleaning after use as the foil with catch most crumbs and
fat during the cooking process. If you do it right, you should be able to simply lift out
the foil after cooking leaving the bowl nice and clean. When you shape your foil liner,
make sure it doesn’t come up the side of the bowl more than 1 inch (25mm) as this
could interfere with air circulation.
You can of course use the product without a foil liner in the bottom - some people
might actually like washing up?
Let’s cook a pie!
For this, you won’t need the extender ring. Put the pie on the low rack and put it in the
bowl. Place the motor unit on top of the bowl. Leave the lid up for now.
Set the thermostat to 220C
If it’s a chilled (not frozen) pie, set the timer to 15 mins. TIP: with manual timers like
these, it’s best to turn the knob past where you want it to be then turn it BACK to your
desired time setting.
Connect the motor unit to the mains. Press the lid down until it clicks into place. The
unit will illuminate and the cooking process will begin. During the cooking process, the
light will cycle on and off as it maintains the required temperature.
Cooking time will vary depending on what kind of pie it is. 15 minutes should be more
than enough for most. For pasties, it might be too much time. Long story short: keep
an eye on it. If your pie is frozen, no problem. Just increase the cooking time to 20-
25 mins - same temperature.
It goes without saying, ensure ALL food is piping hot throughout before consuming!

6
HOW TO USE
Using the mesh racks
Use these in conjunction with the high or low wire racks to cook foods that might fall
through the wire racks. Eg: chips!
For best results use frozen/oven chips. Spread thinly across the mesh racks.
Remember, the product uses hot circulating air to cook food so try to leave plenty of
air space around food you are cooking.
Place 1 mesh rack on the lower wire rack and place 1 mesh rack on the high wire
rack.
Use the extender ring to allow more space for air to circulate. Fit the motor unit
Set temperature to 200C. Set timer to 7 mins
Press lid down until it clicks into place.
Again: 7 minutes is an approximate time. We don’t know how thick or thin your chips
are, so keep an eye on them.
As you become more familiar with the product, you’ll develop a feel for the best
cooking times.
TIP: When removing food, always use the supplied tong accessory to lift the whole
rack out of the oven
ANOTHER TIP: When removing the lid from the oven, use the supplied lid rack
accessory to rest it on
If you’re a lover of bacon, sausage, burgers etc don’t forget to line the bottom of the
bowl with foil. Then observe (with some satisfaction) all the fat that drips on to the foil
during cooking. None of that fat will ever reach your waistline!
Keep this in mind, though, if you are using both racks for double decker type cooking.
Put the food that is likely to drip on the lower rack if possible.

7
HOW TO USE
GENERAL COOKING GUIDES:
Cakes
Preheat the oven this time. 220-230C for about 3 mins. When selecting an appro-
priate cake tin to use, be sure that it will fit comfortably in the bowl. Always place the
tin on the low rack - never directly on the bottom of the bowl. Cooking time depends
entirely on the volume of the cake you are making. It’s easy to monitor cooking
through the glass bowl though.
Bread Rolls
To reheat, wrap in foil and place on low rack. Set temperature at 200C. Heat for
about 5 mins.
Bacon
Drape rashers directly over high rack. Avoid overlapping. Cook for 7 mins at 200C.
A little more if you like it extra crispy.
Sausage
Place directly on high rack. Set temperature at 180-200C. 10 mins for chilled. 15-
20 mins for frozen (depending on thickness)
Toast
Set directly on high rack. Avoid overlapping. Set temperature to max. No recom-
mended cooking time just take it out when you’re happy with the colour! Usually
there is no need to turn the bread. The air circulation should toast both sides at
once.
Popcorn
Spread about 200g popping corn on to mesh tray. Set temperature to max. Cook-
ing time about 10-12 mins. Look at it go!
TIP: It’s best to use the extender ring for most applications as it allows the air to
circulate better. However, if you are cooking something that needs a “grilled” finish,
eg bacon, then it’s best to use without the extender ring.

8
HOW TO USE
Temp (C) Food Amount Time (mins)
200 Whole chicken 1.6kg 60-70
200 Sliced pork 500g 7-8
200 Drumsticks 8 pcs 15
250 Fish (chilled) 10 pcs 7-8 mins
200 Clam 500g 5-7 mins
250 Shrimp 500g 5-6 mins
250 Corn on cob 4 pcs 10 mins
250 Potato 500g 25 mins
200 Beef roast 1kg 60-70 mins
200 Pies/pastry top 4 pcs 8-10 mins
150 Brownies - 18-20 min
150 Cakes/loaf - 30-35
The above chart is only a rough guide and based on chilled not frozen food. For
best estimate, follow the cooking time for FAN ASSISTED oven on the food be-
ing cooked as a starting point. The Halogen Oven and Air Fryer will usually be
quicker because it needs little or no heat up time.
PARTS LISTING
If you need a spare part or accessory for this product, use the references below:
SF31020N-01: Glass bowl
SF31020N-02: High wire rack
SF31020N-03: Low wire rack
SF31020N-04: Mesh tray
SF31020N-05: Tongs
Visit our website at www.swan-brand.co.uk and buy online
Or call our service line: 01733 404703

9
HOW TO USE
CLEANING
All the metal accessories eg racks, tongs etc can be put in the dishwasher.
The product does have a wash function, which is good for removing any baked on
stains in the bottom of the bowl.
To use the wash function, allow the unit to go cold. Fill with warm water about a
third of the way up the side of the bowl. Drop the racks etc into the bottom and add
a squirt of washing up liquid.
Fit the motor unit. Set temperature to WASH. Set timer to 20 mins. Press lid down
until it clicks into place. The wash cycle will begin. You can see the air vortex stir the
detergent solution as it works.
The glass bowl can also be washed up in the conventional way or even in a dish-
washer - if you can fit it in!
Take GREAT care when handling the bowl. It is quite heavy and can be slippy when
wet. Try to keep it in the base as much as possible when moving/cleaning. Please
be aware that toughened glass is “stressed”. This means that even small chips in
the edges caused by metal utensils or impacts with tap edges can lead to sudden
breakage - in the same way that car windscreens can break due to stone chips.
The motor unit can be cleaned with soft cloth or kitchen towel moistened with mild
detergent solution. NEVER immerse any part of the motor unit in water or run it un-
der the tap. ALWAYS disconnect from mains supply before cleaning the motor unit.
Don’t use harsh chemical or abrasive cleaners as this can damage the product.
HINTS & TIPS ONLINE!
We have lots more information online about cooking with Halogen Air Fryers. Check
our website at www.swan-brand.co.uk and click the Halogen Air Fryers link.
If you have any hints, tips and recipes of your own, we would love to hear about them
on our Facebook page!

10
The wires in the mains lead are coloured in accordance with the following code:
BLUE NEUTRAL
BROWN LIVE
GREEN/YELLOW EARTH
As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings
identifying the terminals on your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or
coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked
with the letter L or coloured red. The wire which is coloured GREEN/YELLOW must be connected to the
terminal which is marked with the letter E or (earth symbol) and is coloured GREEN or GREEN/YELLOW.
WARNING: THIS APPLIANCE MUST BE EARTHED
BS PLUG
WARRANTY
This product is guaranteed for 2 years from the date of original purchase. If any defect arises due to faulty
materials of workmanship the faulty products must be returned to the place of purchase. Refunds or
replacement is at the discretion of the store.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• Swan Products Ltd has limited liability for incidental or consequential loss or damage.
• This guarantee is valid in the UK and Eire Only.
We Swan Products Ltd declare that this product conforms to the following product legislation in
accordance with the following directive(s):
2004/108/EC The EMC Directive (the Electromagnetic Compatibility Directive).
2006/95EC. The LVD Directive (Low Voltage Directive).
2011-65-EU. The RoHS directive (Restriction of Hazardous Substances Directive)
EC 1935/2004 Food Contact
DOCUMENTATION

11
DISPOSAL OF UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You
are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items. Please visit www.weeeireland.ie for access to information
about the recycling of electrical items purchased in Ireland. The WEEE directive, introduced in
August 2006, states that all electrical items must be recycled, rather than taken to landfill. Please arrange
to take this appliance to your local Civic Amenity site for recycling, once it has reached the end of its life.
SWAN BRAND HERITAGE
In 1933 Swan were the first to develop an
electric heating element t hat could be
immersed in water.
This led to the Swan
kettle range that could boil up to six pints
of water in just over nine minutes - pretty
hot for the time! These days it takes about
two minutes for a Swan kettle to boil.
Did you know...

www.swan-brand.co.uk
Copyright © Swan Products Ltd.
PO Box 3117, Stoke-on-Trent ST4 9GD
Est.1931
We love
what we do
s
2year
GUARANTEE
we’re proud
of our quality
Scan this QR code
to hear about
our story
Find us on Facebook
*
* on selected products
