SY Electronics SY-EM-UHD-EX User manual
SY-EM-UHD-EX
SY Electronics Ltd, 7 Worrall Street, Salford, Manchester, M5 4TH, UK
Tel: +44 (0)161 868 3450 – Fax: +44 (0)161 868 3459
Web: sy.uk
Installation Guide
SY-EM-UHD-EX
4K UHD HDMI Audio Embedder / Extractor
with ARC
sy.uk 2V1.0
The SY-EM-UDH-EX audio embedder and extractor is an extremely versatile device, providing a
means to either embed another audio signal onto the HDMI output or extract HDMI audio signals
from the HDMI input. Three audio interface connections (Optical Toslink, digital Coax, and stereo
L/R) are employed, ensuring a convenient interface to any sound system.
The L/R and Coaxial audio signal ports can be set to either input (embed) or output (extract)
mode. The embedded audio can be selected from one of the three input types: optical, digital
coax or stereo analogue.
The simultaneous audio outputs can be either from the ARC channel or the audio extracted from
the incoming HDMI. Supported audio formats include 2 channel LPCM, Dolby AC3, and DTS.
Features
Can be set to either Embed or Extract audio signals to or from HDMI
Supports three audio signal types: optical, digital coax or stereo analogue L/R
Supports all resolutions to 4K UHD HDMI video
HDCP 1.4 and ARC supported
Selectable audio input for audio embedding mode
Simultaneous Extracted audio to: optical Toslink, digital coax S/PDIF and L+R analogue
Last operating state (settings) is maintained when repowered
Panel Description
Front Panel
Name
Description
EDID - Pass
EDID pass-through mode
EDID - 5.1
EDID set for 5.1ch sound mode
EDID - 2.0
EDID set for 2ch stereo mode
Embed - Opt
Embed audio from optical S/PDIF input onto HDMI out
Embed - Coax
Embed audio from digital Coax input onto HDMI out
Embed - L/R
Embed audio from Analogue L/R input onto HDMI out
IR
IR Sensor (for remote control)
Em
Lit: Audio Embed mode - Not lit: Audio Extract (de-embed) mode
ARC
Lit: ARC channel audio to all three outputs
EDID
EDID mode selection button (Pass, 5.1, 2.0)
Select
Audio embedding, source selection button (Optical, Coax, L/R)
Em/Ex
Embed or Extract (de-embed) mode button
ARC (Button)
ARC select button
Power (LED)
Lit: Standby mode
Power (Button)
Power ON / Standby button
V1.0 3sy.uk
Rear Panel
Name
Description
OPTICAL OUT
Toslink Optical output connector (F05)
HDMI OUT
HDMI output with Audio Return Channel (ARC)
L (IN/OUT)
Left analogue audio input (embed) or output (extract)
R (IN/OUT)
Right analogue audio input (embed) or output (extract)
COAX (IN/OUT)
Digital Coaxial S/PDIF input (embed) or output (extract)
OPTICAL IN
Toslink Optical input connector (F05)
HDMI IN
HDMI input
5V DC
5V DC power supply input
Using the SY-EM-UHD-EX
Connect the SY-EM-UHD-EX to your system as required.
The operational mode can be set up, using the front panel buttons as below:
Control Buttons
The Em/Ex button toggles the unit between the Embedding and Extraction modes.
When in Audio Extraction mode (and ARC set to OFF), the audio is extracted and outputted
simultaneously to all 3 audio outputs (analogue L/R only when LPCM 2.0 available).
When in Audio Embedding mode, the Select button selects which audio input source is
embedded onto the HDMI output signal.
Em LED
Operating Mode
ON
Audio Embedding activated
Use Select button to choose one of the audio input sources (Optical, Coax or L/R)
OFF
Audio Extraction (de-embed) to all audio outputs (Optical, Coax, L/R)
When ARC LED is OFF, audio outputs Extracted (de-embed) from HDMI input
When ARC LED is ON, audio outputs are from the ARC signal (HDMI output)
The EDID button selects the EDID mode for the digital audio data:
EDID LED
Operating Mode
Pass
The CEA audio data of the display device EDID defines the digital audio mode
5.1
The digital audio EDID is set to 5.1ch (6ch surround-sound)
2.0
The digital audio EDID is set to 2ch (stereo audio only)
Only the audio section of the display EDID is set as required. The Video section of the
display EDID is unaffected and simply passed through.
V1.0 5sy.uk
Audio Extracting
Connect the SY-EM-UHD-EX between the HDMI source and the HDMI display.
Using the ARC and Em/Ex buttons, set to ARC OFF and Em OFF – Extraction activated.
All three outputs (Optical, Digital Coax, and L/R) simultaneously output the de-embedded signal
(extracted from the HDMI input).
Note: When set to ARC ON, then ARC audio is presented to all the outputs.
Please ensure that CEC is active for source and display CEC is active.
sy.uk 6V1.0
Specifications
Connectors
Video Input
HDMI female (Type A) – Up to 8m, using 26 AWG HDMI cable
Video Output
HDMI female (Type A) – Up to 8m, using 26 AWG HDMI cable
Optical Audio Input
S/PDIF fibre connector
Optical Audio Output
S/PDIF fibre connector
Coax Digital Audio
RCA phono (input or output)
Analogue Audio
2 x RCA phono (stereo L/R input or output)
5V DC
2.1 mm power jack
Video General
HDMI Spec
HDMI 1.4
HDCP Spec
HDCP 1.4
Video Rate
9GHz (300MHz pixel clock)
Video Resolutions
4K UHD (3840x2160p) @60Hz 4:2:0 24bit / @30Hz 4:4:4 24bit
4K HDR @24Hz 4:2:0 10bit BT.2020
All resolutions from 480i to1080p @60Hz 4:4:4 36bit
Controls
Em/Ex
Switches between Embedding or Extraction modes
Select
To select the audio source input (with ARC LED off) when the
audio embedding is enabled
ARC
Enable / disable audio extraction from the HDMI Output ARC
EDID
Selects the EDID mode (pass, 5.1 or stereo 2.0)
Power
Toggle power mode of the SY-EM-UHD-EX (ON / OFF)
IR
IR remote control for setting up the unit
Audio General
HDMI Audio Formats
Dolby true HD, Dolby AC3, DSD, DTS, DTS-HD, LPCM7.1
Optical Audio Formats
LPCM 2ch, 5.1ch, Dolby AC3, DTS - (Max BW: 25 MHz)
L/R Audio Format
Analogue stereo 2ch
L/R Audio Level
2V pk-pk Max. (0.7V RMS)
Digital audio sampling
Out: 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
In: 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
General
PSU
5V DC @ 1A
Power Consumption
2.5W max
Dimension (W*H*D)
205 x 26 x 74 mm
Weight
365 g
Temperature
0 ~ 45℃
Humidity
10% ~ 90% RH (non-condensing)
V1.0 7sy.uk
Safety Instructions
To ensure reliable operation of these products as well as protecting the safety of any person using
or handling these devices while powered, please observe the following instructions.
1. ONLY use the power supplies provided. Alternate supply may cause damage - Please check
Voltage, polarity and that it has sufficient power to supply the device it is connected to.
2. Do not operate these products outside the specified temperature and humidity range given
in the above specifications.
3. Ensure there is adequate ventilation, as these products generate heat while operating.
4. Repair of the equipment should only be carried out by qualified professionals as these
products contain sensitive devices that may be damaged by any mistreatment.
5. Only use these products indoors and in a dry environment. Do not allow any liquids or
harmful chemicals to come into contact with these products.
After Sales Service
1. Should you experience any problems while using these products, firstly refer to the
Troubleshooting section in this manual before contacting SY Technical Support.
2. When calling SY Technical Support, the following information should be provided:
Product name and model number
Product serial number
Details of the fault and any conditions under which the fault occurs.
3. These products have a two year standard warranty, beginning from the date of purchase as
stated on the sales invoice. For full details please refer to our Terms and Conditions.
4. SY Product warranty is automatically void under any of the following conditions:
The product is already outside of its warranty period
Damage to the product due to incorrect usage or storage
Damage caused by unauthorised repairs
Damage caused by accident or mistreatment of the product
5. Please direct any questions or problems you may have to your local dealer before contacting
SY Electronics.
