Sycamore Ceiling fan User manual

Sycamore Ceiling Fan
nature + technology
Instruction Manual
INSTALLATION - OPERATION - MAINTENANCE - WARRANTY
TM

Introduction ................................................
Important Safety Precautions . . . . ................................
UnpackingYourSycamoreFan ...................................
Preparing Ceiling, Installing Hanger Bracket
and Making Hanger Bracket Electrical Connections ....................
Preparing and Installing Fan Motor Assembly
and Making Fan Motor Assembly Electrical Connections ................
Installing Wall Controller
and Making Wall Controller Electrical Connections . ...................
Wall Controller Installation Wiring Diagram . . . .......................
Setting Accessory Remote Control Codes . . . .......................
Installing Accessory Remote Control Receiver
and Making Remote Control Receiver Electrical Connections . . ...........
Accessory Remote Control Installation Diagram . . . ...................
Preparing and Installing Fan Motor Housing . . .......................
Preparing and Installing Fan Blade . . . . . . . . .......................
Operating Your Sycamore Fan . . . . . . . . . . . . .......................
CareandCleaning...........................................
Trouble Shooting . . ..........................................
GeneralInformationonCeilingFans ..............................
TechnicalSpecifications .......................................
Warranty ..................................................
Page 1
Page 2
Page 4
Page 6
Page 10
Page 14
Page 17
Page 18
Page 21
Page 25
Page 26
Page 29
Page 33
Page 35
Page 36
Page 37
Page 38
Page 39
Table of Contents
0
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE

Thank you for choosing a Sycamore™ Ceiling Fan. You have chosen the best! We are confident that your
new ceiling fan will provide many years of service and enjoyment.
Please read and follow these instructions carefully, and be mindful of all warnings shown throughout this
manual.
GENERAL PRECAUTIONS
This fan must be installed by a licensed and qualified electrician according to local authority
regulations.
Be cautious! Read all instructions and safety information, and review the accompanying assembly
diagrams before installing your new fan.
Close supervision is necessary when the product is used by children or invalid people. Do not allow
children to use it as a toy.
Introduction 1
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE

Important Safety Precautions
2
LOCATION AND INSTALLATION REQUIREMENTS FOR YOUR FAN
MECHANICAL ISSUES
To provide adequate clearance from the floor the lowest point on the fan blade must be at least 2.1m (7’)
from the floor.
Note: For a fan mounted directly to the ceiling, the lowest point of the fan blade is approximately 365mm
(14 ½”) below the ceiling.
Make sure that the chosen location of the fan will not allow the rotating fan blade to come into contact with
any object.
Ensure ceiling joists are sound and of adequate size and strength to support a 35Kg (77lb) load.
To reduce the risk of fire, electrical shock or personal injury, ensure that the fan mounting bracket is
supported directly from the building structure. DO NOT mount to an outlet box.
The mounting bracket must be firmly screwed to a load bearing structure e.g. a concrete ceiling, steel
structure or timber frame. If a timber frame is to be added it must be securely nailed or screwed between
two beams.
Do not remove the fan from the ceiling after installation.
Do not attach the Fan Blade before the Fan Motor Housing is installed and secured. To protect the finish,
the Fan Blade and the Fan Motor Housing should be kept in their cartons until ready to be installed.
After the fan is completely installed, check to make sure that all connections are secure to prevent the fan
from falling and/or causing damage or injury.
To reduce the risk of personal injury, do not bend or damage the motor Drive Shaft or Fan Blade when
handling or installing them.
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE

Important Safety Precautions 3
ELECTRICAL ISSUES
Do not attempt to control the operation of this fan from any wall controller that is not approved
by Hunter Pacific International Pty Limited for use with this fan. DO NOT use a solid state wall
controller. The use of an unapproved wall controller voids the warranty.
NOTE
The fan and hanger bracket must be earthed.
The fan can be used in conjunction with some home automation systems. For further information please
contact Hunter Pacific International Pty Limited.
To avoid possible electric shock during installation, be sure electricity is turned off at the main power box
before commencing work. Disconnect power by removing fuse or turning off circuit breaker before
installing the fan. Ensure all spliced connections are adequately insulated.
Nothing in this manual is intended to instruct or assist untrained or unqualified persons to install this
product. Additionally, it is the responsibility of the installer and user to apply common sense and care at all
times.
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE

Unpacking your Sycamore Fan
4
Unpack your fan and check the contents. You should have two cartons - a Motor Carton and a Blade
Carton. Do not discard the cartons. If warranty replacement or repair is ever necessary, the fan should be
returned in the original packaging.
Examine all parts. You should have the following:
Fan Motor Assembly
x 1 unit
Hanger Bracket
x 1 unit
Fan Motor Housing
x 1 unit
Fan Blade
x 1 unit
Screw
x 2 units (1 + 1 Spare)
Washer
x 2 units
Washer
x 2 units
Screw
x 2 units
Screw
x 2 units
Hanger Bracket Hardware
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
Blade Hardware

Unpacking your Sycamore Fan 5
Remote Control
Transmitter
x 1 unit
Remote Control Receiver
x 1 unit
Remote Control (Accessory)
Battery
x1 unit
Wall Controller
Speed Controller
x 1 unit
Rotary Speed Switch
x 1 unit
Capacitor
x 1 unit
Clip
x 1 unit
Double Sided Tape
x 1 unit
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
Warning: Do not attempt to control the operation of this fan from any wall controller that is not
approved by Hunter Pacific International Pty. Limited for use with this fan. Do not use a solid
state wall controller. The use of an unapproved wall controller voids the warranty.
Note:
Back Plate, Face Plate and ON/OFF switch are
not supplied with fan.
Note:
Remote Control Transmitter may vary from one
shown.

Ceiling
Supply Wiring
Installation using Ceiling Mounting Box Installation directly mounted to Ceiling Joist
Check that the mounting location is of
adequate strength to support the fan.
Ensure the Supply Wiring is of
sufficient length.
approx.
75mm (3”)
Before commencing installation, turn off electricity supply at the main power box.
Disconnect power by removing fuse or turning off circuit breaker before commencing work.
Checking Ceiling Condition and Preparing for Fan Installation
6
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
ACeiling Joist
behind ceiling
A
Ceiling
35KG
A

Hanger Bracket
Embedded Mounting Box
Secure Hanger Bracket to Mounting Box using
screws and washers provided. Ensure screws are
securely tightened.
Note:
The Hanger Bracket can be securely
screwed to a Mounting Box embedded in
concrete or other load bearing material.
Mounting Boxes embedded in or secured to
non-structural material (e.g. plasterboard)
are not suitable.
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
Attaching Hanger Bracket to Ceiling using an Embedded Mounting Box 7

Hanger Bracket
Power Drill
90mm (3 ½ “)
Drill holes in Ceiling Joist at approximately
90mm (3 ½”) centres for Hanger Bracket
mounting. Ceiling Joist behind
Secure Hanger Bracket to Ceiling Joist using screws
and washers provided. Ensure screws are securely
tightened.
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
Attaching Hanger Bracket directly to Ceiling
8

Make NEUTRAL and EARTH connections from incoming Mains
supply to NEUTRAL and EARTH terminals on Hanger Bracket as
appropriate. Make SWITCHED LIVE (Active) connection from Wall
Controller to LIVE terminal on Hanger Bracket.
UNSWITCHED LIVE (Active) wire from incoming Mains supply
should be looped to Wall Controller using an insulated joiner.
UNSWITCHED LIVE (Active) to be connected directly to
Hanger Bracket terminal.
must not
Terminal Block
EARTH
SWITCHED LIVE
from Wall Controller
NEUTRAL
B
Ensure that electrical connections
are good and that terminal block
screws are secure.
A
A
B
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
Connecting Live, Neutral and Earth Wires from Supply Wiring to Terminal Block on Hanger Bracket 9

A
Remove one Fan Motor Housing fixing
screw, and put it aside for re-assembly
during Fan Motor Housing installation.
Check that the Suspension Ball fixing
screw is securely tightened.
Adjust remaining two Fan Motor Housing
fixing screws to provide clearance for
installing Fan Motor Housing.
6 - 8mm (1/4” - 5/8”)
C
Fan Motor Housing
Fixing Screw
B
C
Suspension Ball
C
B
A
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
Preparing Fan Motor Assembly
10
If installing a fan with a Suspension Rod, refer to Additional Instruction Manual for Suspended Installation for
remaining installation steps.

E
Ensure that lug on Hanger
Bracket is engaged in slot
in Suspension Ball.
Locate Suspension Ball in Hanger Bracket.
Position Fan Motor Assembly so that
Chassis arm with terminal block is facing
away from opening in Hanger Bracket.
Take care to keep Fan Motor Assembly level
during installation to avoid marking ceiling.
D
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
E
Installing Fan Motor Assembly into Hanger Bracket 11
D

Ensure electrical connections are good, and
that terminal block screws are secure.
Make EARTH (Green/Yellow) connection from
Fan Motor Assembly to appropriate terminal
on Hanger Bracket.
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
A
Connecting Earth Wire from Fan Motor Assembly to Hanger Bracket
12
EARTH
(Green / Yellow)
A

Make LIVE (Brown) and NEUTRAL (Blue)
connections from Fan Motor Assembly to
appropriate terminals on Hanger Bracket using pre-
installed wires on right side of Chassis terminal
block, as shown.
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
If you are using a Remote Control, skip this step and go to page 18.
B
Connecting Live and Neutral Wires from Fan Motor Assembly to Hanger Bracket - Wall Controller 13
Ensure that electrical connections are good, and
terminal block screws are secure.
B
LIVE
(Brown)
NEUTRAL
(Blue)

Attach Speed Controller to Back Plate.
Ensure that Orientation Mark is in top left corner, (viewed
from front), and numbers are oriented as shown.
Note: Back Plate, Face Plate
and ON/OFF Switch are not
supplied with fan.
Attach Capacitor to Clip using Double Sided Tape supplied.
Attach Clip to body of Speed Controller as shown.
Capacitor
0
1
2
3
Double Sided Tape
ON/OFF Switch
Clip
Orientation Mark
Back Plate
Speed
Controller
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
Warning: Do not attempt to control the operation of this fan from any wall controller that is not
approved by Hunter Pacific International Pty. Limited for use with this fan. Do not use a solid
state wall controller. The use of an unapproved wall controller voids the warranty.
Installing Wall Controller
14
1
1
2
2
3
3

SWITCHED
LIVE
PURPLE
BROWN
RED
UNSWITCHED LIVE
NEUTRAL
To Fan Hanger Bracket From Mains
Capacitor
ON/OFF
Switch
Speed
Controller
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
Note:
NEUTRAL wire may not be present in
some types of existing lighting circuit and
is not required. If present it may be
terminated as shown or otherwise
properly insulated.
Make electrical connections from Supply
Wiring to ON/OFF Switch, Speed
Controller, Capacitor and Fan Wiring as
shown. Ensure that electrical connections
are good, and terminal screws are secure.
Connecting Wires for Wall Controller 15
Warning: Do not attempt to control the operation of this fan from any wall controller that is not
approved by Hunter Pacific International Pty. Limited for use with this fan. Do not use a solid
state wall controller. The use of an unapproved wall controller voids the warranty.

Rotary Speed Switch
Front Plate
Back Plate
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
Fix pre-wired Wall Controller Back Plate to wall, clip
on Front Plate, and press on Rotary Speed Switch.
Installing Front Plate and Rotary Speed Switch
16

IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
NEUTRAL from Main Supply
LIVE (Active) from Mains Supply
EARTH Conductor
E(Green/Yellow)
E(Green/Yellow)
E(Green/Yellow)
(Red)
(Blue)
(Orange)
C3
1
2
C2
1
Loop
L(Brown)
(Brown)
(Purple)
(Red)
N (Blue)
Capacitor
Capacitor
Hanger
Bracket
Earth
Chassis
Earth
Chassis
Terminal
Block
Fan
Motor
M
1~
Hanger Bracket
Terminal Blocks
NEUTRAL to Wall Switch not required
but may be present in some existing
installations.
ON / OFF
Switch
Rotary Speed
Switch
(Purple)
(Yellow)
(Red)
Wall Controller
Wall Plate
TO FAN N (Blue)
TO FAN L (Brown)
Wall Controller Installation Wiring Diagram 17

Battery
Compartment
Door
9v Battery
Remote Control
Handset
Check Remote Control Transmitter (Handset) CODE switch
settings are identical to Receiver CODE switch settings (use point
of ball point pen to adjust switches).
Note:
Remote Control Transmitter may vary from one shown.
Install Battery as shown.
If you are using a Wall Controller, skip these steps and go to Page 26.
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: [phone]BEFORE LEAVING THE WORK SITE
Setting Code Switches for Remote Control Handset and Installing Battery
18
