QUICK START GUIDE: AEC Coprocessor Module
What Ships in the Box
• AEC Coprocessor Module.
• Two 4-40 Phillips head screws.
• This Quick Start Guide.
What You Need to Provide
• Radius NX 4x4 or Radius NX 12x8
• Anti-static work station.
Getting Help
Composer, the Windows software that
configures Symetrix Dante Network Audio
hardware, includes a help file which acts as
a complete User’s Guide for both hardware
and software. If you have questions beyond
the scope of this Quick Start Guide, contact
our Customer Support Group in the following
ways:
Tel: [phone] ext. 5
6:00 am to 5:00 pm PST
Monday through Friday
Web: https://www.symetrix.co
Email: [email protected]
Forum: https://forum.symetrix.co

www.symetrix.co | +1.425.778.7728
PN 53-0082 Rev C 02/22
2 of 3
QUICK START GUIDE: AEC Coprocessor Module
ESD Warning
This product can be damaged by electrostatic discharge
(ESD). When handling, care must be taken so that the
devices are not damaged. Damage due to inappropriate
handling is not covered by the warranty.
The following precautions must be taken:
• Do not open the protective conductive packaging until
you have read the following, and are at an approved
anti-static work station.
• Use a conductive wrist strap attached to a good earth
ground.
• Always discharge yourself by touching a grounded bare
metal surface or approved anti-static mat before picking
up an ESD-sensitive electronic component.
• Use an approved anti-static mat to cover your work
surface.
Card Removal and Installation
Once you are properly grounded, follow this sequence of
steps to properly set-up and congure the Symetrix AEC
Coprocessor Module in your Radius NX 4x4 or Radius NX
12x8 hardware.
First, make sure the unit is powered down. Next, you must
remove the two rack ears and the lid. To do this, remove the
6 Phillips head screws from the rack ears and the 3 Phillips
head screws from the rear of the frame. Lift the lid up using
the two tabs in the rear of the lid.
If your Radius NX 4x4 or Radius NX 12x8 unit has an AEC
Coprocessor Module installed, unscrew and remove it
by removing the two stainless steel Phillips head screws
located on the top of the card. Gently pull the card up to
disconnect the two 50-pin connectors. The card is no longer
attached to the frame. Carefully remove the card from the
chassis.
To install a new module, align and feed the connectors on
the AEC Coprocessor Module and align the screw holes
in the card with the stando󰀨s on the motherboard. Look
through this hole and align with the stando󰀨 and then,
carefully, apply an even downward pressure until you feel
the card seat into the 50-pin sockets. Use the two stainless
steel screws provided and mount the board to the stando󰀨.
Do not over tighten these screws. The 50-pin connectors on
the Symetrix AEC Coprocessor Module should not be under
any tension when properly installed.
Finally, replace the lid and rack ears.
Step 1:
Step 2:
To watch a video showing
AEC Coprocessor Module
installation, scan QR code.

www.symetrix.co | +1.425.778.7728
PN 53-0082 Rev C 02/22
3 of 3
QUICK START GUIDE: AEC Coprocessor Module
The Symetrix Limited Warranty
By using Symetrix products, the Buyer agrees to be bound by the terms of
this Symetrix Limited Warranty. Buyers should not use Symetrix products
until the terms of this warranty have been read.
What is Covered by this Warranty:
Symetrix, Inc. expressly warrants that the product will be free from defects
in material and workmanship for ve (5) years from the date the product
is shipped from the Symetrix factory. Symetrix’s obligations under this
warranty will be limited to repairing, replacing, or partially crediting original
purchase price at Symetrix’s option, the part or parts of the product which
prove defective in material or workmanship within the warranty period,
provided that the Buyer gives Symetrix prompt notice of any defect or failure
and satisfactory proof thereof. Symetrix may, at its option, require proof of
the original date of purchase (copy of original authorized Symetrix Dealer’s
or Distributor’s invoice). Final determination of warranty coverage lies
solely with Symetrix. This Symetrix product is designed and manufactured
for use in professional audio systems and is not intended for other usage.
With respect to products purchased by consumers for personal, family, or
household use, Symetrix expressly disclaims all implied warranties,
including, but not limited to, warranties of merchantability and tness
for a particular purpose. This limited warranty, with all terms, conditions
and disclaimers set forth herein, shall extend to the original purchaser and
anyone who purchases the product within the specied warranty period
from an authorized Symetrix Dealer or Distributor. This limited warranty
gives the Buyer certain rights. The Buyer may have additional rights
provided by applicable law.
What is not Covered by this Warranty:
This warranty does not apply to any non-Symetrix branded hardware
products or any software even if packaged or sold with Symetrix Products.
Symetrix does not authorize any third party, including any dealer or sales
representative, to assume any liability or make any additional warranties
or representation regarding this product information on behalf of Symetrix.
This warranty also does not apply to the following:
1. Damage caused by improper use, care, or maintenance or failure to
follow the instructions contained in the Quick Start Guide or Help File.
2. Symetrix product that has been modied. Symetrix will not perform
repairs on modied units.
3. Symetrix software. Some Symetrix products contain embedded
software or apps and may also be accompanied by control software
intended to be run on a personal computer.
4. Damage caused by accident, abuse, misuse, exposure to liquids, re,
earthquake, acts of God, or other external causes.
5. Damage caused by improper or unauthorized repair of a unit. Only
Symetrix technicians and Symetrix international distributors are
authorized to repair Symetrix products.
6. Cosmetic damage, including but not limited to, scratches and dents,
unless failure has occurred due to a defect in materials or
workmanship within the warranty period.
7. Conditions caused by normal wear and tear or otherwise due to the
normal aging of Symetrix products.
8. Damage caused by use with another product.
9. Product on which any serial number has been removed, altered or defaced.
10. Product that isn’t sold by an authorized Symetrix Dealer or Distributor.
Buyer Responsibilities:
Symetrix recommends the Buyer make backup copies of site les before
having a unit serviced. During service it is possible that the site le will be
erased. In such an event, Symetrix is not responsible for the loss or the
time it takes to reprogram the site le.
Legal Disclaimers and Exclusion of other
Warranties:
The foregoing warranties are in lieu of all other warranties, whether oral,
written, express, implied or statutory. Symetrix, Inc. expressly disclaims
any IMPLIED warranties, including tness for a particular purpose or
merchantability. Symetrix’s warranty obligation and Buyer’s remedies
hereunder are SOLELY and exclusively as stated herein.
Limitation of Liability:
The total liability of Symetrix on any claim, whether in contract, tort
(including negligence) or otherwise arising out of, connected with,
or resulting from the manufacture, sale, delivery, resale, repair,
replacement or use of any product will not exceed the retail price of the
product or any part thereof which gives rise to the claim. In no event
will Symetrix be liable for any incidental or consequential damages,
including but not limited to, damage for loss of revenue, cost of
capital, claims of Buyers for service interruptions or failure to supply,
and costs and expenses incurred in connection with labor, overhead,
transportation, installation or removal of products, substitute facilities or
supply houses.
Servicing a Symetrix Product:
The remedies set forth herein shall be the Buyer’s sole and exclusive
remedies with respect to any defective product. No repair or
replacement of any product or part thereof will extend the applicable
warranty period for the entire product. The specic warranty for any
repair will extend for a period of 90 days following the repair or the
remainder of the warranty period for the product, whichever is longer.
Residents of the United States may contact the Symetrix Technical
Support Department for a Return Authorization (RA) number and
additional in-warranty or out-of-warranty repair information.
If a Symetrix product requires repair services outside of the United
States please contact the local Symetrix dealer or distributor for
instructions on how to obtain service.
Products may be returned by Buyer only after a Return
Authorization number (RA) has been obtained from Symetrix. Buyer
will prepay all freight charges to return the product to the Symetrix factory.
Symetrix reserves the right to inspect any products which may be the
subject of any warranty claim before repair or replacement is carried
out. Products repaired under warranty will be returned freight prepaid
via commercial carrier by Symetrix, to any location within the continental
United States. Outside the continental United States, products will be
returned freight collect.
