SyncusTech EMB-BYT1000 User manual
EMB-BYT1000
Custom General
Description Rev 0.2
SYNCUSTECH
Synchronous with Customer
USER MANUAL
Page 2 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
Contents
1. TECHNICAL SPECIFICATIONS ················································· 4
2. JUMPERS & CONNECTORS ···················································· 5
2.1 Quick Listing of Jumpers ···································································· 6
2.2 Quick Listing of Connector ·································································· 6
3. INSTALLATION & DESCRIPTION ·············································· 7
3.1 JUMPER INSTALLATION ··································································· 7
3.1.1 J1 & J2 : RS232/485 SELECT ·································································· 7
3.1.2 J3 : CMOS CLEAR ················································································ 7
3.1.3 J4 : FLAT PANEL BACKLIGHT SELECT ····················································· 7
3.1.4 J5 : FLAT PANEL BACKLIGHT CON SELECT ············································· 7
3.1.5 J6 : Flat Panel LCD POWER Select··························································· 7
3.1.6 J7 : mSATA/PCIe SELECT (w/ CN16) ······················································· 7
3.2 CONNECTOR DESCRIPTION ···························································· 8
3.2.1 CN1 : TEMP CONNECTOR ····································································· 8
3.2.2 CN2 : POWER & RESET BUTTON ··························································· 8
3.2.3 CN3 : RS422/485 CONNECTOR ······························································ 8
3.2.4 CN4 : 20PIN DUAL COM2, COM5 HEADER ··············································· 8
3.2.5 CN5 : PS2 KEYBOARD, MOUSE HEADER ················································ 9
3.2.6 CN6 : TPM 1.2 INTERFACE HEADER ······················································· 9
3.2.7 CN7 : DIO(GPIO) HEADER ····································································· 9
3.2.8 CN8 : DUAL COM3, COM4 CONNECTOR ·················································10
3.2.9 CN9 : COM1, VGA CONNECTOR ····························································10
3.2.10 CN10 & CN11 : RJ45 + DUAL USB CONNECTOR ······································ 11
3.2.11 CN12 : USB 3.0 CONNECTOR ······························································· 11
3.2.12 CN13 : HDMI CONNECTOR ··································································· 11
3.2.13 CN14 : FLAT PANEL (Backlight control) SELECT ········································12
3.2.14 CN15 : FLAT PANEL ·············································································12
3.2.15 CN16 : mSATA / mPCIe CONNECTOR ·····················································13
3.2.16 CN17 : SATA POWER CONNECTOR ·······················································13
3.2.17 CN18 & CN19 : SATA CONNECTOR ························································14
3.2.18 CN20 : USB4,5 EXTENSION HEADER ·····················································14
3.2.19 CN21 : AUDIO HEADER ········································································14
3.2.20 CN22 : POWER CONNECTOR (12V DC) ··················································14
3.2.21 CN24 : FAN1 CONNECTOR ···································································14
3.2.22 CN25 : FAN2 CONNECTOR ···································································14
Page 3 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
4. I/O MAP ··············································································· 15
5. IRQ LIST·············································································· 16
6. MEMORY MAP ····································································· 16
7. BLOCK DIAGRAM ································································ 17
Page 4 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
1. TECHNICAL SPECIFICATIONS
Module Function Description
Processor System
CP
U
(SOC)
Intel® AtomTM
E38
XX
Max. Speed 1.46 ~ 1.91GHz
L2 Cache 512KB ~2MB
Instruction set 64-bit
BIOS UEFI
Memory
Technology DDR3L
Max. Capacity 8GB
Socket 1 x 204-pin DDR3 SODIMM
Graphics
Controller Intel® HD Graphics
LVDS Supports 18-bit single channel
Dual Display Support
Ethernet Interface 10/100/1000 Mbps
Controller Realtek RTL8111F
Audio AC'97 Codec Realtek ALC262 2-channel
SATA Max Data Transfer 300 MB/s
Channel SATA2 2channel ( Internal type )
Rear I/O
VGA 1 x 15P VGA
Ethernet 2 x RJ45
USB2.0 4 x USB 2.0/1.1 ports
USB3.0 (SS) 1 x USB 3.0 ports
Serial 3 x 9P RS232
HDMI 1 x HDMI Connector
Internal connector
Serial 3 x Serial header ( 2 x 232, 1 x 232/422/485)
USB 2 x USB 2.0/1.1 ports
TPM 1 x 20 pin Interface port
SATA 2 x SATA2
DIO 1 x 8-bit DIO(GPIO)
PS/2 (KB & Mouse) 1 x Keyboard/Mouse connector
LVDS 1 x 40pin
AUDIO 1 x 10pin HEADER, SPK,LINE_OUT, MIC_IN etc.
mSATA /PCIe 1 x mSATA /PCIe mode (Selectable)
FAN 2 x SYSTEM cooling fan connector
POWER 1 x 4pin power connector
Power Requirements
Typical DC 12V Input (Tolerance ±10%)
Environment Operating Temp 0 ~ 60 °C (32 ~ 140 °F)
Physical Dimensions 115mm x 165mm
Page 5 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
2. JUMPERS & CONNECTORS
The figures below show all the connectors and jumpers.
Jumpers and Connectors
Page 6 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
2.1 Quick Listing of Jumpers
J1 RS422/485 CONTROL SELECT
J2 RS232/RS422,485 SELECT
J3 CMOS CLEAR
J4 FLAT PANEL (Backlight) POWER SELECT
J5 FLAT PANEL (Backlight control) POWER SELECT
J6 FLAT PANEL (VDD) POWER SELECT
J7 mSATA / mPCIe SELECT
2.2 Quick Listing of Connector
CN1 TEMP CONNECTOR
CN 2 POWER BUTTON / RESET CONNECTOR
CN 3 SERIAL (RS-422/485) CONNECTOR
CN 4 SERIAL (2 x RS-232 ) CONNECTOR
CN 5 PS/S (KEYBOARD / MOUSE) CONNECTOR
CN 6 TPM 1.2 INTERFACE CONNECTOR
CN 7 DIO (GPIO 8 BIT) CONNECTOR
CN 8 SERIAL (2 x RS-232 ) CONNECTOR
CN 9 VGA COM DUAL CONNECTOR
CN 10 RJ45 + DUAL USB2.0 CONNECTOR
CN 11 RJ45 + DUAL USB2.0 CONNECTOR
CN 12 DUAL USB3.0 CONNECTOR
CN 13 HDMI CONNECTOR
CN 14 FLAT PANEL (Backlight) POWER CONNECTOR
CN 15 FLAT PANEL CONNECTOR
CN 16 mSATA / mPCIe CONNECTOR
CN 17 SATA POWER CONNECTOR
CN 18 SATA1 CONNECTOR
CN 19 SATA2 CONNECTOR
CN 20 USB2.0 CONNECTOR
CN 21 AUDIO CONNECTOR
CN 22 ATX 4PIN POWER CONNECTOR [12V DC]
CN 23 SYSTEM FAN1 (4P) POWER CONNECTOR
CN 24 SYSTEM FAN2 (3P) POWER CONNECTOR
Page 7 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
INSTALLATION & DESCRIPTION
3.1 JUMPER INSTALLATION
3.1.1 J1 & J2 : RS232/485 SELECT
PIN
DESCRIPTION PIN No
1
-
2
S
elect RS485
(1
-
2)
2-3 Select RS422 (2-3)
3.1.2 J3 : CMOS CLEAR
PIN
DESCRIPTION PIN No
1-2 Normal operation (1-2)
2-3 CMOS Clear (2-3)
3.1.3 J4 : FLAT PANEL BACKLIGHT SELECT
PIN
DESCRIPTION PIN No
1-2 Select +5V (1-2)
2-3 Select +12V
(2-3)
3.1.4 J5 : FLAT PANEL BACKLIGHT CON SELECT
PIN
DESCRIPTION PIN No
1
-
2
Select +5V
(1
-
2)
2-3 Select +3.3V (2-3)
3.1.5 J6 : Flat Panel LCD POWER Select
PIN
DESCRIPTION PIN No
1-2 Select +3.3V (1-2)
2-3 Select +5V (2-3)
3-4 Select +5V (3-4)
4-5 Select +12V (4-5)
3.1.6 J7 : mSATA/PCIe SELECT (w/CN16)
PIN
DESCRIPTION PIN No
1-2 PCIe mode (1-2)
2-3 mSATA mode (2-3)
CN18 SATA CONNECTOR Disabled
Page 8 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
3.2 CONNECTOR DESCRIPTION
3.2.1 CN1 : TEMP CONNECTOR
PIN
SIGNAL PIN
SIGNAL PIN No
1
1.8V
2
GND
3 CS 4 CLK
5 MISO 6 MOSI
3.2.2 CN2 : POWER & RESET BUTTON
PIN
SIGNAL PIN
SIGNAL PIN No
1 NC 2 +3.3V
3 +3.3V 4 +3.3V
5 SATA_LED 6 GND
7 GND 8 POWER SW
9 RESET SW 10 GND
3.2.3 CN3 : RS422/485 CONNECTOR
PIN
SIGNAL PIN No
1 422RX-
2 422RX+
3 422TX-_485-
4 422TX+_485+
3.2.4 CN4 : 20PIN DUAL COM2, COM5 HEADER
PIN
SIGNAL PIN
SIGNAL PIN No
1
3.3V
2
SRXD2
3 STXD2 4 SDTR2
5 SDCD2 6 RESET SW
(
OPTION
)
7 SRTS2 8 SCTS2
9 SRI2 10 GND
11 SDCD5 12 SDSR5
13 SRXD5 14 SRTS5
15 STXD5 16 SCTS5
17 SDTR5 18 SRI5
19 GND 20 NC
Page 9 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
3.2.5 CN5 : PS2 KEYBOARD, MOUSE HEADER
PIN
SIGNAL PIN No
1 VCC
2 MOUSE DATA
3 MOUSE CLK
4 K/B DATA
5 K/B CLOCK
6 GND
7 NC
3.2.6 CN6 : TPM 1.2 INTERFACE HEADER
PIN
SIGNAL PIN
SIGNAL PIN No
1
L_CLKOUT1
2
GND
3 L_FRAME_N 4 NC
5 RESET 6 5V
7 L_AD3 8 L_AD2
9 3.3V 10 L_AD1
11 L_AD0 12 GND
13 SMB_CLK_RESU 14 SMB_DATA_RES
15 3.3V 16 L_SERIRQ
17 GND 18 L_CLKRUN_N
19 LPCPD 20 NC
3.2.7 CN7 : DIO(GPIO) HEADER
PIN
SIGNAL PIN
SIGNAL PIN No
1 5V 2 DIO4
3 DIO0 4 DIO5
5 DIO1 6 DIO6
7 DIO2 8 DIO7
9 DIO3 10 GND
Page 10 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
3.2.8 CN8 : DUAL COM3, COM4 CONNECTOR
PIN
SIGNAL PIN
SIGNAL PIN No
1
DCD3
10
DCD4
2 RXD3 11 RXD4
3 TXD3 12 TXD4
4 DTR3 13 DTR4
5 GND 14 GND
6 DSR3 15 DSR4
7 RTS3 16 RTS4
8 CTS3 17 CTS4
9 RI3 18 RI4
3.2.9 CN9 : COM1, VGA CONNECTOR
PIN
SIGNAL PIN
SIGNAL PIN No
V1 RED 1 DCD1
V2 GREEN 2 RXD1
V3 BLUE 3 TXD1
V4 NC 4 DTR1
V5 GND 5 GND
V6 GNDDAC 6 DSR1
V7 GNDDAC 7 RTS1
V8 GNDDAC 8 CTS1
V9 VCCDDC 9 RI1
V10
GND
V11
NC
V12
DDCDAT
V13
HSYNC
V14
VSYNC
V15
DDCCLK
Page 11 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
3.2.10 CN10 & CN11 : RJ45 + DUAL USB CONNECTOR
PIN
SIGNAL PIN
SIGNAL PIN No
U1
VCC
S1
VCC
U2 DATAN S2 TD0P
U3 DATAP S3 TD0N
U4 GND S4 TD1P
U5 VCC S5 TD1N
U6 DATAN S6 TD2P
U7 DATAP S7 TD2N
U8 GND S8 TD3P
S9 TD3N
S10
GND
3.2.11 CN12 : USB 3.0 CONNECTOR
PIN
SIGNAL PIN
SIGNAL PIN No
1 VCC 2 NC
3 NC 4 GND
5 RX1_DN 6 RX1_DP
7 GND 8 TX1_DN
9 TX1_DP
3.2.12 CN13 : HDMI CONNECTOR
PIN
SIGNAL PIN
SIGNAL PIN No
1 HDMI_D2_DP 11 SHLD_CK
2 SHLD_D2 12 HDMI_CLK_DN
3 HDMI_D2_DN 13 NC
4 HDMI_D1_DP 14 NC
5 SHLD_D1 15 HDMI_SCL
6 HDMI_D1_DN 16 HDMI_SDA
7 HDMI_D0_DP 17 GND
8 SHLD_D0 18 VCC
9 HDMI_D0_DN 19 DDI0_HDMI_HPD
10 HDMI_CLK_DP
Page 12 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
3.2.13 CN14 : FLAT PANEL (Backlight control) SELECT
PIN
SIGNAL PIN No
1 VCC_BLT
2 VCC_BLT
3 BLT_EN
4 BLT_CTRL
5 GND
3.2.14 CN15 : FLAT PANEL
LVDD : "J6" Flat Panel LCD POWER Select
BLT_VCC : " J4" Flat Panel BACKLIGHT Select
PIN
SIGNAL PIN
SIGNAL PIN No
1
LVDD
2
LVDD
3 3.3V 4 NC
5 NC 6 BLT_EN
7 BLT_VCC 8 BLT_CTRL
9 BLT_VCC 10 BLT_VCC
11 GND 12 GND
13 LVDS_BD3P 14 LVDS_AD3P
15 LVDS_BD3N 16 LVDS_AD3N
17 GND 18 GND
19 LVDS_BCLKP 20 LVDS_ACLKP
21 LVDS_BCLKN 22 LVDS_ACLKN
23 GND 24 GND
25 LVDS_BD2P 26 LVDS_AD2P
27 LVDS_BD2N 28 LVDS_AD2N
29 GND 30 GND
31 LVDS_BD1P 32 LVDS_AD1P
33 LVDS_BD1N 34 LVDS_AD1N
35 GND 36 GND
37 LVDS_BD0P 38 LVDS_AD0P
39 LVDS_BD0N 40 LVDS_AD0N
Page 13 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
3.2.15 CN16 : mSATA / mPCIe CONNECTOR
PIN
SIGNAL PIN
SIGNAL PIN No
1
PCIE_WAKE_N
2
3.3V
3 NC 4 GND
5 NC 6 1.5V
7 PCIE_R_CLKRE 8 NC
9 GND 10 NC
11 PCIE_REFCLK2_ 12 NC
13 PCIE_REFCLK2_ 14 NC
15 GND 16 NC
17 NC 18 GND
19 NC 20 W_DISABLE#
21 GND 22 PERST#
23 RX0_DN 24 3.3V
25 RX0_DP 26 GND
27 GND 28 1.5V
29 GND 30 SMB_PCIE_CLK
31 TX0_DN 32 SMB_PCIE_DAT
33 TX0_DP 34 GND
35 GND 36 USB2_DN
37 GND 38 USB2_DP
39 3.3V 40 GND
41 3.3V 42 NC
43 GND 44 NC
45 NC 46 NC
47 NC 48 1.5V
49 NC 50 GND
51 NC 52 3.3V
3.2.16 CN17 : SATA POWER CONNECTOR
PIN
SIGNAL PIN No
1 5V
2 GND
Page 14 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
3.2.17 CN18 & CN19 : SATA CONNECTOR
PIN
SIGNAL PIN
SIGNAL PIN No
1
GND
4
GND
2 TX+ 5 RX-
3 TX- 6 RX+
7 NC
3.2.18 CN20 : USB4,5 EXTENSION HEADER
PIN
SIGNAL PIN
SIGNAL PIN No
1 VCC 2 VCC
3 USB2_P4_DN 4 USB2_P5_DN
5 USB2_P4_DP 6 USB2_P5_DP
7 GND 8 GND
10 NC
3.2.19 CN21 : AUDIO HEADER
PIN
SIGNAL PIN
SIGNAL PIN No
1 LINE_IN_L 2 LINE_IN_R
3 LINE_IN_JD 4 GND
5 MIC_L 6 MIC_R
7 MIC_JD 8 FRONT_JD
9 FRONT_L 10 FRONT_R
3.2.20 CN22 : POWER CONNECTOR (12V DC)
PIN
SIGNAL PIN No
1
GND
2 GND
3 12V DC
4 12V DC
3.2.21 CN24 : FAN1 CONNECTOR
PIN
SIGNAL PIN
SIGNAL PIN No
1 VCC 2 VCC
3 USB2_P4_DN 4 USB2_P5_DN
3.2.22 CN25 : FAN2 CONNECTOR
PIN
SIGNAL PIN
SIGNAL PIN No
1
G
ND
2
12V
3 FANTAC
Page 15 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
4. I/O MAP
The Address Map of I/O Port in Main chipset
000H – 00FH 8237 DMA Controller
020H – 03FH 8259 Interrupt Controller
040H – 05FH 8254 Timer
060H – 06FH 8042 K/B Controller
070H – 07FH 641828 RTC, NMI
080H – 09FH DMA Page Register
0A0H – 0BFH 8259 Interrupt Controller 2
0C0H – 0DFH 8237 DMA Controller 2
0F0H Co-processor Clear
0F1H Co-processor Reset
0F8H – 0FFH Co-processor (Math. coprocessor)
The address map of I/O Port in Main Board
1F0H – 1F7H HDD
200H – 207H USER reserved
278H – 27FH USER reserved
2B0H – 2F7H USER reserved
2F8H – 2FFH Serial port 2, COM2
300H –377H USER reserved
378H – 37FH LPT Port 1
380H – 3AFH USER reserved
3B0H – 3BFH USER reserved
3C0H – 3CFH EGA
3D0H – 3DFH CGA
3F0H – 3F7H FDD
3F8H – 3FFH Serial Port 1, COM1
Page 16 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
5. IRQ LIST
IRQ Number IRQ Object
IRQ0 Timer
IRQ1 PS/2 Keyboard
IRQ2 Second 8259
IRQ3 COM 2
IRQ4 COM 1
IRQ5 Reserved
IRQ6 FDD
IRQ7 LPT
IRQ8 Real time Clock
IRQ9 Reserved
IRQ10 Reserved
IRQ11 Reserved
IRQ12 Reserved & PS/2 Mouse
IRQ13 80287 NMI
IRQ14 HDD
IRQ15 Reserved
6. MEMORY MAP
Address(HEX) Hardware
00000000 – 0009FFFF For PNP BIOS in System Board
000A0000 – 000AFFFF National Geode Xpress Graphics (TM)
000B0000 – 000BFFFF National Geode Xpress Graphics (TM)
000E0000 – 000EFFFF Mother Board Resource
000F0000 – 000F3FFF Mother Board Resource
000F4000 – 000F7FFF Mother Board Resource
000F8000 – 000FBFFF Mother Board Resource
000FC000 – 000FFFFF Mother Board Resource
00100000 – 03D7FFFF For PNP BIOS in System Board
07D80000 – 07D8007F National Xpress Audio (TM) PCI Bridge
40008000 – 4000FFFF For PNP BIOS in System Board
40010000 – 40010FFF For PNP BIOS in System Board
40012000 – 400120FF National Cx5530 ACPI Bridge
40018000 – 407FFFFF For PNP BIOS in System Board
40800000 – 40FFFFFF National Geode Xpress Graphics (TM)
41000000 – 41017FFF For PNP BIOS in System Board
FFFC0000 – FFFFFFFF For PNP BIOS in System Board
Page 17 www.syncus.co.kr / www.syncustech.com
SyncusTech
USER MANUAL |
EMB
-
BYT1000
7. BLOCK DIAGRAM
Table of contents
