Synology DX1215 User manual

DX1215 User’s Guide


Table of Contents
TOC
3
5 Chapter 1: Getting Started
5Package Contents
6Expansion Unit at a Glance
7LED Indicator Behavior
7Default/Manual Switch Behavior
8 HardwareSpecications
9Safety Instructions
11 Chapter 2: Setting Up
11 Tools and Parts for Drive Installation
11 Install Drives
15 Connect with Synology DiskStation
17 ConrmConnectionandManageStorageSpaces
19 ReplaceSystemFan
20 Learn More
Synology_UG_DX1215_20141113


1
5
Thank you for purchasing this Synology DX1215 expansion unit. This
product is specially designed to expand the storage capacity of a Synology
DiskStation. In the chapters below, we'll provide instructions to set up and
start using this expansion unit.
Package Contents
Before starting, please check the package contents to verify that you have
receivedtheitemsbelow.
Main unit x 1 AC power cord x 1
User’s guide x 1
Screws for 2.5”
drives x 52 Drive tray key x 2 Expansion Cable
(Inniband x 1)
Getting Started

6 Chapter 1: Getting Started
Expansion Unit at a Glance
Article Name Location Description
1STATUS
Indicator
Front
Displaysthestatusofthesystem.Formore
information,pleaseseetheLED Indicator
Behavior table at Page 7.
2ALERT
Indicator
Displayswarningsregardingfanortemperature.
Formoreinformation,pleaseseetheLED Indicator
Behavior table at Page 7.
3 POWER Button
1. Press to power on the expansion unit.
2. Press and hold to shut down.
Note: The expansion unit will be turned on or off
automaticallywhenthelinkedDiskStationpowers
on or off. However, the POWER button has no
power-offfunctionwhenvolumeiscreatedto
preventaccidentalvolumedamage.
4 LINK Indicator Displays the status of the linked DiskStation.
5Drive Status
Indicators
Displaysthestatusofdrives.Formoreinformation,
please see the LED Indicator Behavior at Page 7.
6 Drive Tray Install drives (hard disk drives or solid state drives)
here.
7Drive Tray
Lock
The drive tray lock is designed for locking/unlocking
the trays to the expansion unit.
Front Back

Chapter 1: Getting Started 7
Article Name Location Description
8 Fan
Back
Disposes of excess heat and cools the expansion
unit.Ifthefanmalfunctions,theALERTLED
indicator will show a blinking red light.
9 Power Port ConnecttheACpowercordhere.
10 Expansion Port
ConnectSynologyDiskStationhere.Forthelist
ofsupportedmodels,pleaseseetheHardware
Specications table at Page 8.
11
DEFAULT/
MANUAL
Switch
Inthedefaultmode,theexpansionunitcanauto
power on/off with the linked DiskStation, while in
themanualmode,theexpansionunitcannotauto
power on with the DiskStation when using as its
independentvolume.Formoreinformation,please
see the Default/Manual Switch Behavior table
below.
LED Indicator Behavior
Indicator Color Status Description
POWER Blue Static Powered on
Off Powered off
STATUS
Green Static Volumenormal
Orange Blinking Volumedegraded
Off Novolumeorvolumecrashed
HDD hibernation
ALERT Red Blinking Systemfanmalfunctioning
Off Systemfannormal
Drive status
(on trays)
Green Static Drive ready and idle
Blinking Accessingdrive
Orange Static Drive error
Off No internal drive
LINK Green Static Connected to Synology DiskStation
Off Not connected to Synology DiskStation
Default/Manual Switch Behavior
Mode Behavior
Default Autopoweron/off
Manual No auto power on

8 Chapter 1: Getting Started
HardwareSpecications
Internal Drives 3.5"or2.5"SATA(II)orSATA(III)X12
Expansion Port # 1
Maximum Raw Capacity 72TB (12 x 6TB drives)
Hot Swappable Drive Yes
Size (HxWxD) (mm) 270x300x340mm
Weight 9.02 kg
System Fan 2x(120x120x25mm)
Overheating Auto Shutdown Yes
Power Recovery SyncedwithDiskStation(Defaultmode)
AC Input Power Voltage 100Vto240VAC
Power Frequency 50/60Hz, Single Phase
Operating Temperature 5°C~35°C(40°F~95°F)
Storage Temperature -20°C~60°C(-5°F~140°F)
Relative Humidity 5% to 95% RH
Certication FCCClassB,CEClassB,BSMIClassB
Supported Models DS3615xs, DS3612xs, DS2413+
Note:
1 Please visit www.synology.comforthelatestcompatiblemodels.
2 DSM needs to be upgraded to version 5.1 or above.

Chapter 1: Getting Started 9
Safety Instructions
Keepawayfromdirectsunlightandawayfromchemicals.Makesure
theenvironmentdoesnotexperienceabruptchangesintemperatureor
humidity.
Placetheproductrightsideupatalltimes.
Do not place near any liquids.
Beforecleaning,unplugthepowercord.Wipewithdamppapertowels.
Donotusechemicaloraerosolcleaners.
Topreventtheunitfromfallingover,donotplaceoncartsorany
unstable surfaces.
Thepowercordmustplugintothecorrectsupplyvoltage.Makesure
thatthesuppliedACvoltageiscorrectandstable.
Toremoveallelectricalcurrentfromthedevice,ensurethatallpower
cordsaredisconnectedfromthepowersource.
Risk of explosion if battery is replaced with an incorrect type. Dispose of
used batteries appropriately.

10 Chapter 1: Getting Started

2
11
Tools and Parts for Drive Installation
• Ascrewdriver
• Atleastone3.5”or2.5”SATAdrive
(Please visit www.synology.comforcompatibledrivemodels.)
Warning:Ifyouinstalladrivethatcontainsdata,thesystemwillformatthedrive
and erase all data. If you still need the data, please back it up before installation.
Install Drives
1 Press the right part of the drive tray to pop out the handle.
Setting Up

12 Chapter 2: Setting Up
2 Pullthedrivetrayhandleinthedirectionasindicatedbelowtoremovethe
drive tray.
3 Load drives in the drive trays:
• For 3.5” drives: Place the drive in the drive tray. Turn the tray upside
down and tighten screws into the four spots indicated below to secure the
drive.
• For 2.5” drives: Place the drive in the drive tray. Turn the tray upside
down and tighten screws into the four spots indicated below to secure the
drive.

Chapter 2: Setting Up 1313
4 Inserttheloadeddrivetrayintotheemptydrivebay.
Note:Makesurethetrayispushedinalltheway.Otherwise,thedrivemightnotbe
able to function properly.
5 Pressthehandleinushwiththefrontpaneltoholdthedrivetrayinplace.

14 Chapter 2: Setting Up
6 Insert the drive tray key into the drive tray lock, turn the key clockwise to lock
thehandleofthedrivetray,andthenremovethekey.
7 Repeatthestepsabovetoassembletheotherdrivesyouhaveprepared.
8 Drivesarenumberedasshownbelow.
Note:IfyouwanttocreateaRAIDvolume,werecommendallinstalleddrivesbe
thesamesizeinordertooptimizedrivecapacityusage.

Chapter 2: Setting Up 1515
Connect with Synology DiskStation
1 Connect one end of the power cord to the power port of the expansion unit,
and the other to the power outlet.
2 Connect one end of the expansion cable to the expansion unit, and the other
tothemainDiskStationunit.

16 Chapter 2: Setting Up
3 Power on the expansion unit:
• If the DEFAULT/MANUAL switch is switched to DEFAULT, the
expansionunitwillpoweronoroffautomaticallywhenthelinked
DiskStation powers on or off.
• If the DEFAULT/MANUAL switch is switched to MANUAL, press the
POWER button located on the front panel to power on the expansion unit.

Chapter 2: Setting Up 1717
ConrmConnectionandManageStorageSpaces
1 LogintotheDiskStationManager(DSM)ofthemainDiskStationunit.
2 Go to Control Panel > External Devices > External Devicestoconrmthe
expansion unit is successfully connected.
3 Go to Storage Managertomanagestoragespacecreationorexpansion.
• If you want to create a new volume on the expansion, click Create and
follow the instructions of the wizard.

18 Chapter 2: Setting Up
• If you want to expand an existing volume with expansion unit, select
thevolumeyouwanttoexpandfromthevolumelist,clickManage, and
follow the instructions of the wizard.
Fordetailedinformationaboutvolumemanagement,gotoStorage Manager
and see DSM Help.
Limitations:Beforeusingthisexpansionunit,pleaseseethelimitationsbelow.
•ThisexpansionunitcanbelinkedtoonlyoneSynologyDiskStationatatime.
•ThedataofsomeDSMpackagescanbestoredontheexpansionunitonlyifyou
createanexpandedvolumewithit.Thedatacannotbestoredontheexpansion
unitifanindependentvolumehasbeencreatedonit.
•Drives previously used in a Synology DiskStation are not readable when directly
insertingthemintothisexpansionunit,andviseversa.

Chapter 2: Setting Up 1919
ReplaceSystemFan
Yourexpansionunit'sALERTLEDindicatorwillshowablinkingredlightif
eitherofthesystemfansisnotworking.Followthestepsbelowtoreplace
themalfunctioningfanmodulewithagoodone.
1 Shut down your expansion unit. Disconnect all cables connected to your
expansionunitforpreventinganypossibledamages.
2 Pullthe6pushpinsthatsecurethefanmodule.
3 Toremovethemalfunctioningfanmodule,yousimplyneedtopullitoutfrom
your expansion unit.

20 Chapter 2: Setting Up
4 Installthenewfanmodule:
a Installthenewmodulewiththepowerconnectoratthebottom,sothatit
can be properly put onto the chassis.
b Makesureallsixpushpinsarepulledoutwardsbeforethemoduleis
attached, and then press the push pins back into place to secure the fan
module.
Learn More
Congratulations!Yourexpansionunitissetupnow.Formoreinformationor
online resources, please visit www.synology.com
