CSM_CS1W-ETN21_DS_E_5_1
1
SYSMAC CS-series Ethernet Unit
CS1W-ETN21
Organically Connect the Production
Site and Management
• Select the required communications services according to
application needs to flexibly integrate PLCs with an Ethernet
information network.
Features
•Use Ethernet to implement various communications protocols.
•Implement FINS message communications using UDP/IP or TCP/IP with a user application on a host computer or with Support Software, such
as the CX-Programmer.
•Use the clock on an SNTP server to automatically adjust the clocks in the PLCs connected to the Ethernetnetwork. (An SNTP server is required
separately.)
•An FTP server is built in, so files can be used to transfer PLC data between network PLCs and workstations or personal computers with an FTP
client.
•Email can be used to send commands to the PLCs, or triggers can be set so that the PLCs will send PLC data or Ethernet Unit status to a host
computer.
•The standard UDP/IP and TCP/IP protocols are supported to enable communications with a wide range of devices, workstations, personal
computers, and Ethernet modules from other manufacturers.
•The SMTP/POP3/SNTP servers enable the use of host names instead of IP addresses. (A DNS server is required separately.)
System Configuration
CS1W-ETN21
Hub
CX-Programmer
CX-Integrator
SYSMAC Gateway
FinsGateway Twisted-pair cable
100 m
max. CS1W-ETN21
Ethernet Unit
(100Base-TX)
CJ1W-ETN21
Ethernet Unit
(100Base-TX)
CS-series
PLC CJ-series PLC

CS1W-ETN21
2
Ordering Information
•International Standards
•The standards are abbreviated as follows: U: UL, U1: UL (Class I Division 2 Products for Hazardous Locations), C: CSA, UC: cULus, UC1: cULus (Class I Division
2 Products for Hazardous Locations), CU: cUL, N: NK, L: Lloyd, and CE: EC Directives.
•Contact your OMRON representative for further details and applicable conditions for these standards.
Ethernet Unit
Note: There is no accessory for the CS-series Ethernet Unit.
Industrial Switching Hubs
Recommended Network Devices
The following products are recommended for use with the Ethernet Unit.
Unit type Product
Name
Specifications No. of
unit
numbers
allocated
Current
consumption (A) Model Standards
Communi
cations
cable Communications functions Duplexing Unitsper
CPU Unit 5 V system 26 V system
CS1 CPU
Bus Unit
Ethernet
Units
100BASE-
TX Cable
FINS communications service
(TCP/IP and UDP/IP), FTP
server function, socket service,
mail send service, mail
reception (remote command
reception), auto-adjustment of
PLC's internal clock, and server
host name specification
Not
supported 4 Units 1 0.38 −CS1W-ETN21 UC1, N, L,
CE
Product name Appearance
Specifications
Accessories Current
consumption
(A)
Model Standards
Functions No. of
pors
Failure
detection
Industrial
Switching Hubs
Quality of Service (QoS):
EtherNet/IP control data priority
Failure detection:
Broadcast storm and LSI error detection
10/100BASE-TX, Auto-Negotiation
3No
• Powersupply
connector
0.22 W4S1-03B UC, CE
5No 0.22W4S1-05B
5Yes
• Powersupply
connector
•Connector
for informing
error
0.22 W4S1-05C CE
Part Maker Model number Specifications
Hub 100BASE-TX
PHOENIX CONTACT SWITCH 5TX 10/100 Mbit/s 5-port hub
Twisted-pair cable
100BASE-TX
Fujikura F-LINK-E 0.5mm ×4P STP (shielded twisted-pair) cable: Category 5, 5e
Note: Impedance is limited to 100 Ω.
Fujikura CTP-LAN5 0.5mm ×4P UTP (unshielded twisted-pair) cable: Category 5, 5e
10BASE-T
Fujikura F-LINK-E 0.5mm ×4P STP (shielded twisted-pair) cable: Category 3, 4, 5, 5e
Note: Impedance is limited to 100 Ω.
Fujikura CTP-LAN5 0.5mm ×4P UTP(unshieldedtwisted-pair)cable:Category 3,4,5,
5e
Connectors
(Modular plug)
STP Plug
Panduit Corp MPS588 −
UTP Plug
Panduit Corp MP588-C −

3
CS1W-ETN21
Mountable Racks
Ethernet Units Specifications
Model CS1 System CS1D System
CPU Rack
ExpansionBackplane
(including Long-
distance Expansion
Rack)
SYSBUS
Remote
I/O Slave
Rack
C200HX/HG/
HE
Expansion
I/O Rack
CPU Rack Expansion
Backplane
CS1W-BC CS1W-BI CS1D-BC CS1D-BI
@@3@@2@@3@@2052 042D 082S 092 082D
CS1W-ETN21 4 Units (per CPU Unit) Not supported Not supported 4 Units (per CPU Unit)
Item Specifications
Model number CS1W-ETN21
Type 100Base-TX (Can be used as 10Base-T)
Applicable PLCs CS-series PLCs
Unit classification CS-series CPU Bus Unit
Mounting location CPU Rack or Expansion Rack
Number of Units that can be mounted 4 max. (including Expansion Racks)
Transfer
specifications
Media access method CSMA/CD
Modulation method Baseband
Transmission paths Star form
Baud rate 100 Mbit/s (100Base-TX) 10 Mbit/s (10Base-TX)
Transmission media
Unshielded twisted-pair (UDP) cable
Categories: 5, 5e
Shielded twisted-pair (STP) cable
Categories: 100 Ωat 5, 5e
Unshielded twisted-pair (UDP) cable
Categories: 3, 4, 5, 5e
Shielded twisted-pair (STP) cable
Categories: 100 Ωat 3, 4, 5, 5e
Transmission distance 100 m (distance between hub and node)
Number of cascade connections No restrictions if switching hubs are used.
Current consumption (Unit) 380 mA max. at 5 V DC
Weight 200 g max.
Dimensions 35 ×130 ×101 mm (W ×H ×D)
Other general specifications Other specifications conform to the general specifications of the CS-series.

CS1W-ETN21
4
Communications Specifications
Item Ethernet Unit
Model number CS1W-ETN21
Physical layer 100BASE-TX, 10BASE-T
Number of nodes on FINS network 254
Server specification Specification by IP address or host name specifications (DNS client function)
Communications
service
FINS communications
service FINS/UDP FINS/TCP
FTP server function The CPU Unit's file memory (Memory Card or EM file memory) can be read/written.
Automatic clock
information adjustment The CPU Unit's internal clock data can be automatically adjusted to the clock data received from the SNTP server
Web functions The Unit settings can be made and status can be read from the Web browser using the Web server.
Mail functions Mail send functions
Mail receive functions
Socket service function TCP socket services
UDP socket services
FINS commands
RESET
CONTROLLER DATA READ
CONTROLLER STATUS READ
ECHOBACK TEST
BROADCAST TEST (READ RESULTS)
BROADCAST TEST (SEND TEST DATA)
ERROR LOG READ
ERROR LOG CLEAR
REQUEST TO OPEN UDP SOCKET
REQUEST TO RECEIVE UDP SOCKET
REQUEST TO SEND UDP SOCKET
REQUEST TO CLOSE UDP SOCKET
REQUEST TO OPEN TCP SOCKET (PASSIVE)
REQUEST TO OPEN TCP SOCKET (ACTIVE)
REQUEST TO RECEIVE TCP SOCKET
REQUEST TO SEND TCP SOCKET
REQUEST TO CLOSE TCP SOCKET
EXECUTE PING COMMAND
REQUEST TO CHANGE REMOTE NODE FOR FINS/TCP CONNECTION
REQUEST TO READ STATUS FOR FINS/TCP CONNECTION
IP ADDRESS TABLE WRITE
IP ADDRESS WRITE
IP ADDRESS TABLE READ
IP ROUTING TABLE READ
PROTOCOL STATUS READ
MEMORY STATUS READ
SOCKET STATUS READ
ADDRESS DATA READ
IP ADDRESS READ

5
CS1W-ETN21
External Interface
Ethernet Connectors
The following standards and specifications apply to the connectors for the Ethernet twisted-pair cable.
•Electrical specifications: Conforming to IEEE802.3 standards.
•Connector structure: RJ45 8-pin Modular Connector
(conforming to ISO 8877)
CS1W-ETN21
Each communications device connected to the Ethernet network is allocated a unique Ethernet address. For the Ethernet Unit, this Ethernet
address is shown on the right side of the Unit as a 12-digit hexadecimal number.
Connector pin Signal name Abbr. Signal direction
1 Transmission data +TD+Output
2 Transmission data −TD−Output
3 Reception data +RD+Input
4 Not used. −−
5 Not used. −−
6 Reception data −RD−Input
7 Not used. −−
8 Not used. −−
Hood Frame ground FG −
NODE
NO.
×160 ×161
UNIT
NO.
0
1
0
ETN21
RUN
ERC
SD
RD
LNK
100M
ERH
TCP
FTP
HOST
100BASE-TX
10BASE-T
Front
Indicators
Display the operating status of the Unit.
Unit Number Switch
Node Address Switches
Ethernet Connector
Used to connect the Ethernet twisted-pair cable.
Used to set the Ethernet Unit's unit number in
one digit hexadecimal.
Used to set the Ethernet Unit's FINS node
number in two digits hexadecimal.
ETHERNET UNIT
CS1W-ETN21
OMRONCorporation MADE INJAPAN
Lot No.
@@@@@@@@@@@@
Ethernet Address
Ethernet address (12 digits)

CS1W-ETN21
6
Unit Version Upgrade Information
Unit Version 1.3
Unit Version 1.4
Unit Version 1.5
Note: CX-Programmer version 8.2 or higher is required for unit version 1.5 functions.
Dimensions (Unit: mm)
CS1W-ETN21
Upgrade Details
Web function added The unit settings and status monitoring for the Ethernet Unit can be
easily performed from a Web browser.
Function prohibiting access using FINS/
UDP from nodes with dynamically changed
IP addresses
Access to change the remote IP address from a node using FINS/UDP
can be prohibited (IP address protection).
Upgrade Details
ETN11-compatible mode added to the
ETN21 settings for FINS/UDP.
A mode compatible with the CS1W-ETN11/CJ1W-ETN11 was added in
the operating specifications for FINS/UDP messages sent from a
different UDP port number than the FINS/UDP port number set in the
Ethernet Unit.
Upgrade Details
CIDR function added to subnet mask
settings
Anoptionsettingwasadded tothesubnetmasksettings toenableCIDR.
Enabling CIDR allows you to use classless IP addresses in the subnet
mask setting.
High-speed option added for socket service
This option can be set to improve communications performance for the
socket service that is implemented by manipulating dedicated control
bits. The performance is the same as the previous version if this option
is not set.
Linger option added to socket options for
TCP open requests. A linger option can now be set in the options for passive or active TCP open requests.
NODE
NO.
1
×160
0
×161
UNIT
NO.
100BASE-TX
10BASE-T
0
ETN21
RUN
ERC
SD
RD
LNK
100M
ERH
TCP
FTP
HOST
10135
130

7
CS1W-ETN21
Related Manuals
Man.No. Model Name Contents
W420 CS1W-ETN21
CJ1W-ETN21
Ethernet Units Operation
Manual
Construction of Networks
Provides information on operating and installing 100Base-TX Ethernet Units,
including details on basic settings and FINS communications.
Refer to the Communications Commands Reference Manual (W342) for details
onFINS commandsthatcanbesentto CS-seriesand CJ-seriesCPU Unitswhen
using the FINS communications service.
W421 CS1W-ETN21
CJ1W-ETN21
Ethernet Units Operation
Manual
Construction of Applications
Provides informationon constructing host applications for 100Base-TX Ethernet
Units, including functions for sending/receiving mail, socket service, automatic
clock adjustment, FTP server functions, and FINS communications.
W342
CS1G/H-CPU@@H
CS1G/H-CPU-@@EV1
CS1D-CPU@@H
CS1D-CPU@@S
CJ1M-CPU@@
CS1W-SCU21-V1
CS1W-SCB21-V1/41-V1
CJ1G/H-CPU@@H
CJ1G-CPU@@P
CJ1G-CPU@@
CJ1W-SCU21-V1/41-V1
Communications
Commands Reference
Manual
Describes the C-series (Host Link) and FINS communications commands used
when sending communications commands to CS-series and CJ-series CPU
Units.
W463 CXONE-AL@@C-V@/
AL@@D-V@CX-One Setup Manual Describes operating procedures for the CX-One FA Integrated Tool Package.
Refer to thismanual for operating procedures for the CX-One FA Integrated Tool
Package.
W464 CXONE-AL@@C-V@/
CXONE-AL@@D-V@
CS/CJ/CP/NSJ-series
CX-Integrator Network
Configuration Software
Operation Manual
Describes the operating procedures for the CX-Integrator.

Terms and ConditionsAgreement
Read and understand this catalog.
Please read and understand this catalog before purchasing the products. Please consult your OMRON representative if you
have any questions or comments.
Warranties.
(a) Exclusive Warranty. Omron’s exclusive warranty is that the Products will be free from defects in materials and workmanship
for a period of twelve months from the date of sale by Omron (or such other period expressed in writing by Omron). Omron
disclaims all other warranties, express or implied.
(b) Limitations. OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, ABOUT
NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OF THE PRODUCTS. BUYER
ACKNOWLEDGES THAT IT ALONE HAS DETERMINED THAT THE
PRODUCTS WILLSUITABLY MEETTHE REQUIREMENTS OF THEIR INTENDED USE.
Omron further disclaims all warranties and responsibility of any type for claims or expenses based on infringement by the
Products or otherwise of any intellectual property right. (c) Buyer Remedy. Omron’s sole obligation hereunder shall be, at
Omron’s election, to (i) replace (in the form originally shipped with Buyer responsible for labor charges for removal or
replacement thereof) the non-complying Product, (ii) repair the non-complying Product, or (iii) repay or credit Buyer an amount
equal to the purchase price of the non-complying Product; provided that in no event shall Omron be responsible for warranty,
repair, indemnity or any other claims or expenses regarding the Products unless Omron’s analysis confirms that the Products
were properly handled, stored, installed and maintained and not subject to contamination, abuse, misuse or inappropriate
modification. Return of any Products by Buyer must be approved in writing by Omron before shipment. Omron Companies shall
not be liable for the suitability or unsuitability or the results from the use of Products in combination with any electrical or
electronic components, circuits, system assemblies or any other materials or substances or environments. Any advice,
recommendations or information given orally or in writing, are not to be construed as an amendment or addition to the above
warranty.
See http://www.omron.com/global/ or contact your Omron representative for published information.
Limitation on Liability; Etc.
OMRON COMPANIES SHALLNOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIALDAMAGES,
LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS,
WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, NEGLIGENCE OR STRICT LIABILITY.
Further, in no event shall liability of Omron Companies exceed the individual price of the Product on which liability is asserted.
Suitability of Use.
Omron Companies shall not be responsible for conformity with any standards, codes or regulations which apply to the
combination of the Product in the Buyer’s application or use of the Product. At Buyer’s request, Omron will provide applicable
third party certification documents identifying ratings and limitations of use which apply to the Product. This information by itself
is not sufficient for a complete determination of the suitability of the Product in combination with the end product, machine,
system, or other application or use. Buyer shall be solely responsible for determining appropriateness of the particular Product
with respect to Buyer’s application, product or system. Buyer shall take application responsibility in all cases.
NEVER USE THE PRODUCT FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR PROPERTY OR IN LARGE
QUANTITIES WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO ADDRESS THE RISKS,
AND THAT THE OMRON PRODUCT(S) IS PROPERLY RATED AND INSTALLED FOR THE INTENDED USE WITHIN THE
OVERALL EQUIPMENT OR SYSTEM.
Programmable Products.
Omron Companies shall not be responsible for the user’s programming of a programmable Product, or any consequence
thereof.
Performance Data.
Data presented in Omron Company websites, catalogs and other materials is provided as a guide for the user in determining
suitability and does not constitute a warranty. It may represent the result of Omron’s test conditions, and the user must correlate
it to actual application requirements. Actual performance is subject to the Omron’s Warranty and Limitations of Liability.
Change in Specifications.
Product specifications and accessories may be changed at any time based on improvements and other reasons. It is our
practice to change part numbers when published ratings or features are changed, or when significant construction changes are
made. However, some specifications of the Product may be changed without any notice. When in doubt, special part numbers
may be assigned to fix or establish key specifications for your application. Please consult with your Omron’s representative at
any time to confirm actual specifications of purchased Product.
Errors and Omissions.
Information presented by Omron Companies has been checked and is believed to be accurate; however, no responsibility is
assumed for clerical, typographical or proofreading errors or omissions.
2015.7
In the interest of product improvement, specifications are subject to change without notice.
OMRON Corporation
Industrial Automation Company
http://www.ia.omron.com/
(c)Copyright OMRON Corporation 2015 All Right Reserved.
