SYSONCHIP Looket G7 User manual

Loocket G7
사용자 매뉴얼 v1.0
Looket G7 GPS System

Loocket G7
CONTENT
1. Designation
2. Unit Package
3. Caution
4. Main Function
•Do not plug in a car cigarette charger before starting a vehicle.
It may damage the fuse of the cigarette charger of Looket G7.

Loocket G7
Note
Thank you for purchasing Looket G7 GPS receiver.
Looket G7 is handheld GPS receiver using without any PDA or computing device.
Please carefully read this user guide instruction before using the product.
Disclaimer and limitation of liability
Sysonchip, Inc. and its affiliated companies assume no responsibility for any
damages and loss resulting from the use of this manual and also by deletion of
data as a result of malfunction, dead battery, or misuse of the product in any way.
Warning
Any kind of changes or modification of the product that are not officially
approved by Sysonchip will void the owner’s warranty and also any other
obligation of Sysonchip to repair or replace the product.
Information and instruction in the manual is subject to change without notice
at any time.

Loocket G7
1. Designation
1
2
3
4
5
6
8
1. Power ON/OFF Button
2. Function Button 1
3. Function Button 2
4. Function Button 3
5. 5-contacts Button
6. GPS Antenna
7. Speaker
8. Battery Status LED
Red –During charging battery with
connection to a power charger
Green –Battery is fully charging
7

Loocket G7
9
9. Battery cover

Loocket G7
10
11
12
13
10. Soft reset
11. Hold switch
12. Opeional external
antenna connector
13. Power jack 14
15
14. SD card socket
15. Stereo Earphones jack

Loocket G7
16
17 18
16. Style
17. Car mount holder
18. 24Pin SYNC&CNS connector

Loocket G7
Rechargeable and Removable Li-ion Battery (1,100mAh)Battery
High performance Helical AntennaGPS Antenna
64MB SDRAM and 32MB Flash MemoryMemory
AC Adapter : Input : 110V-230V 50Hz Output : 5V, 1.0A
Cigarette Car Charger : Input : 12V Output : 5V, 1.5A
Power
115 x 73 x 21 mmDimension
Mini USB Connector for Active Sync and Battery ChargingExternal Ports
3.5mm Stereo Headphone Jack and Built-in SpeakerAudio
1 SD(Secure Digital)/MMC(Multi Media Card) Memory Card SlotExpansion Slot
5-way Navigation Jog Button
4 function Buttons (Home, GPS, Map enlargement, Map reduction)
Touch Screen
Hold Button
Power ON/OFF
User Controls
Samsung Wise View 3.5" TFT LCD 320x240 pixels with Landscape ModeDisplay
SiRFstarIIIGPS Chipset
Samsung S3C2440A RISC Microprocessor at 400MHzProcessor
Microsoft Windows CE.NET 4.2Operating System

Loocket G7
2. Unit Package
-Looket G7 GPS Receiver
-Car Charger
-USB Sync Cable
-Rechargeable Lithium-ion Battery
-Device holder for Car Mount
-AC Adapter (Option)
-External Antenna (Option)
•Package contents might vary
depending on countries without notice

Loocket G7
3. Caution
-Never connect or disconnect the power with wet hand.
-Do not leave Looket G7 in places of high Temperature, such as in a sun-heated car.
-Do not damage the AC adapter cord by pulling or stretching.
-Never drop of strong impact on Looket G7.
-Keep magnetic objects (credit cards, floppy disk, etc.) away from Looket G7.
-If the Looket G7 is subjected to a sudden temperature change,
for example by bringing it from a cold place into a warm room, condensation may
form on the inside. Use the device after the temperature difference has subsided.

Loocket G7
4. Main Function
4.1 Navigation
1. Looket G7 main screen.
Tap “Navigation”
2. Navigation software starts.

Loocket G7
4. Main Function
4.2 Media Player
1. Looket G7 main screen.
Tap “Media Player”
2. Media Player starts.

Loocket G7
4. Main Function
4.2 Media Player
3. Tap “file”and
select the “open file”
4. Select the folder for media files.

Loocket G7
4. Main Function
4.3 MP3 Player
1. Looket G7 main screen.
Tap “Mp3 Player”
2. Mp3 Player starts.

Loocket G7
4. Main Function
4.3 MP3 Player
3. Tap “mp3 file”in the list 4. You can change the sound mode.

Loocket G7
4. Main Function
4.4 Memo
1. Looket G7 main screen.
Tap “Memo”
2. Memo Program starts.

Loocket G7
4. Main Function
4.5 Memo
3. Tap “file”and
select the “open…”
4. Select the folder for text files.

Loocket G7
4. Main Function
4.5 Setup
1. Looket G7 main screen.
Tap “Setup”
2. Setup main screen
Tap “Backlight”

Loocket G7
4. Main Function
4.5 Setup
3. Backlight main screen.
Control the backlight and tap
“save”
4. Volume main screen.
Control the volume and tap “save”

Loocket G7
4. Main Function
4.5 Setup
5. Power main screen.
Check the power state and tap “save”6. Power main screen.
You can change the turn off time
