1. Overview
This manual describes the SOC LBS Real-time GPS tracker for using in the fleet management and other location
utility.
We calls the SOC LBS Real-time GPS tracker as “LOOK’ET”, ourproduct name in this document from now on.
Chapter 1 describes the LOOK’ET hardware partand 2,3 describe security and safety.
Chapter 4 describes the stating and testing method.
Chapter 5 describes the specification of LOOK’ET.
1.1. Reference
[1] SOC LBS USB Driver Installation Guide
[2] PCApplication software Manual [ Control Center]
[3] PCApplication software Manual [ Diagnostic Monitor]
[4] PCApplication software Manual [ Upgrade Server]
[5] SOC LBS SW Interface

SysOnChip
SOC LBS LOOK’ET User Manual
7
1.2. Hardware overview
LOOK’ET has following hardware block diagram.
Fig 1. LOOK’ET hardware block diagram
LOOK’ET has following hardware appearance.
Fig 2. LOOK’ET appearance in front view

SysOnChip
SOC LBS LOOK’ET User Manual
8
Fig 3. LOOK’ET appearance in right side view
Fig 4. LOOK’ET appearance in left side view
Fig 5. . LOOK’ET appearance including tray

SysOnChip
SOC LBS LOOK’ET User Manual
9
1.3. Hardware interface description
1.3.1. Vehicle interface
LOOK’ET has 12 port signals to interface with vehicle.
1.3.1.1. Vehicle 12 pin interface pin out
Fig 6. Vehicle 12 pin connector cable part
Fig 7. Vehicle 12 pin connector LOOK’ET part
1.3.1.2. Vehicle 12 pin interface pin & cable description
Number Pin name Description Cable color
1 Digital output 1 General purpose output.500 mA max.@ 10 ~ 33V DC
To connect the vehicle, it needs Relay. Brown
2 Digital output 2 General purpose output.500 mA max.@ 10 ~ 33V DC
To connect the vehicle, it needs Relay. Brown
3 Analog input 1 General purpose analog input. Up to 33 V DC/10 bit resolution Yellow
4 Analog input 2 General purpose analog input. Up to 33 V DC/10 bit resolution Yellow
5 Digital input 1 General purpose input. High=10 V ~ 33 V DC, Low=0V Orange
6 Digital input 2 General purpose input. High=10 V ~ 33 V DC, Low=0V Orange
7 Digital input 3 General purpose input. High=10 V ~ 33 V DC, Low=0V Orange
8 IGNITION General purpose input. High=10 V ~ 33 V DC, Low=0V Blue
9 CANH NC. White
10 CANL NC. White
11 VIN Input power for the unit must be 12/24 volts for the unit to Red

SysOnChip
SOC LBS LOOK’ET User Manual
10
operate properly; A direct connection to the vehicle’s battery is
preferable. The 2A fuse in this cable is to protect the +12/24
volt input to the unit.
12 GND Wire to vehicle ground. Black
Table 1. Vehicle interface pin description table
1.3.2. USB interface
LOOK’ET supports USB 2.0 and mini-USB type connector.
1.3.3. RS232 interface
LOOK’ET supports RS232 to interface with external device like navigation..
Supported signal is RS232Tx,RS232Rx and GND. In normal LBS applications, It does not need to be connected.
1.3.4. External GPS antenna
LOOK’ET has internal GPS patch antenna in itself, but supports external GPS antenna.
1.3.5. External GSM/GPRS antenna
LOOK’ET has two types of GSM/GPRS antenna according to the supported bandwidth.

SysOnChip
SOC LBS LOOK’ET User Manual
11
1.3.6. LEDs
LOOK’ET has three LEDs for indicating operation status.
LED name Mark Description
Battery LED
It indicates the battery status.
In boot stage after power on, it blinks 4 times with 1 second period indicating boot
completion. If the boot stage has some error, it blinks forever.
After boot stage, It blinks if the battery voltage level is under 3.6V else on.
GPS LED
It indicates the GPS sync status.
This LED is on if the GPS has detected and synced. But GPS does not have
synced and is under searching sync, this LED is blinked.
GSM/GPRS LED
It indicates the GSM Tx / Rx status.
In boot stage after power on, it blinks 4 times with 1 second period indicating boot
completion. If the boot stage has some error, it blinks forever.
After boot stage,this LED is on when the GSM Tx or Rx operation is executed. LED
is off when LOOK’ET is in Idle mode.
Table 2. LED indications

SysOnChip
SOC LBS LOOK’ET User Manual
12
1.4 LOOK’ET basic operation scheme
LOOK’ET has several stages to debug status and operate in test mode.
User does not have to control this, but it is good to know to when the debugging command is valid.
1) Boot stage
After power on, Boot stage takes 25 seconds to check the flash memory status and user program updating request.
If the user want to upgrade LOOK’ET with the new binary file, it can be done in this time.
2)Application stage
After boot stage, application code will be executed. Application code waits 5 seconds to select the test mode before
initialization. If the user does not enter test mode value within 5 seconds, LOOK’ET proceeds the normal operation
mode. This test mode is just for the hardware testing so user does not have to enter this. After this, LOOK’ET does
initialization and waits in idle mode.
Consequently, user must waits the least 35 seconds after power on.

SysOnChip
SOC LBS LOOK’ET User Manual
13
2. Security
It is important for the efficient and safe operation to read this information before use LOOK’ET.
This chapter contains important information for the safe and reliable use of the
LOOK’ET. Please read this chapter carefully before starting to use LOOK’ET.
(1) Risk of explosion if battery is replaced by incorrect type. dispose of used batteries according to the instructions.
(2) To minimize the exposure to RF energy, It is recommended to place the antenna more than 20 centimeter from
human body.
(3) Turn your LOOK’ET modem device OFF in health care facilities when any regulations posted in the area instruct
you to do so. Hospitals or health care facilities may be using RF monitoring equipment.
(4) Turn your LOOK’ET device OFF in blasting area when any regulations posted in the area instruct you to do so.
(5) Turn your LOOK’ET device OFF before boarding any aircraft. Use it on the ground only with crew permission. Do
not use it in the air.
(6) Do not allow children to play with your LOOK;ET device. Children could hurt themselves or be damaged with
playing that.
(7) Turn your LOOK’ET device off when in any area with a potentially explosive atmosphere. Modem or its
accessories could generate sparks. Sparks in such areas could cause an explosion or fire resulting in bodily injury or
even death.
(8) The antenna shall be mounted in such a position that no part of the human body will
normally rest close to any part of the antenna. It is also recommended to use the
equipment not close to medical devices as for example hearing aids and pacemakers.
3. Safety standards
This GSM/GPS modem complies with all applicable RF safety standards.
The embedded GSM/GPRS/GPS modem meets the safety standards for RF receivers
and the standards and recommendations for the protection of public exposure to RF
electromagnetic energy established by government bodies and professional organizations, such as directives of the
European Community, in matters of radio frequency electromagnetic energy.

SysOnChip
SOC LBS LOOK’ET User Manual
14
4. Basic startup and testing
The SOC LBS LOOK’ET has been made to make installation, testing and configuration simple. For vehicle
installation and testing for correct working after installation we recommend the installer to use a Notebook or Desktop
PC via USB 2.0 interface.
The program for debugging/controlling LOOK’ET is provided in view of both target side and network side.
DM(Diagnostic Monitor) is the target side program and CC(Control Center) is network side program for debugging
and controlling.
Before the LOOK’ET is installed, we recommend configuring the unit functions and setup using the LOOL’ET DM
program including setup configuration. The LOOK’ET has many functions that will allow the unit to operate for
different user applications including security and fleet management.
4.1. Needed accessory and programs
LOOK’ET product has many hardware accessories and software programs to operate correctly.
No. Component name Quantity Remarks
1 LOOK’ET body 1 ea. Hardware.
2 External GPS antenna 1 ea. Hardware.
3 External GSM/GPRS antenna 1 ea. Hardware.
4 12 Pin Vehicle interface connector & cable 1 ea. Hardware.
5 Internal battery 1 ea. Hardware.
6 USB mini-type connector & cable 1 ea. Hardware.
7 RS232 connector & cable Not included. Hardware.
8 Tray for Fix LOOK’ET 1 ea. Hardware.
9 USB Driver install file 1 set. Software.
10 DM(Diagnostic Monitor) Program 1 set. Software.
11 CC(Control Center) Program 1 set. Software.
12 UPGS(Update Server) Program 1 set. Software.
Fig 8. Hardware/Software accessories

SysOnChip
SOC LBS LOOK’ET User Manual
15
4.1.1. Hardware accessories
1) LOOK’ET body
Fig 9. HardwareAccessory : Body
2) External GPS antenna
Fig 10. HardwareAccessory : External GPS antenna
3) External GSM/GPRS antenna
Fig 11. HardwareAccessory : External GSM/GPRS antenna

SysOnChip
SOC LBS LOOK’ET User Manual
16
4) 12 Pin Vehicle interface connector & cable
Fig 12. Hardware Accessory : vehicle 12 pin connector & cable
5) Internal battery
Fig 13. HardwareAccessory : Internal battery
6) USB mini-type connector & cable
Fig 14. Hardware Accessory : USB mini-type connector & cable

SysOnChip
SOC LBS LOOK’ET User Manual
17
7) RS232 connector & cable
None. Not needed.
8) Tray for Fix LOOK’ET
Fig 15. HardwareAccessory : LOOK’ET tray(Cradle)

SysOnChip
SOC LBS LOOK’ET User Manual
18
4.1.2. Software programs
1) USB Driver install file
USB driver installation is needed to connect the LOOK’ET with PC. After completed installing the USB driver, hyper
terminal and DM can be used to control and debug the LOOK’ET.
Refer to the document [1] and [3] for detail description to install USB driver and DM.
2) DM(Diagnostic Monitor) Program
LBS_DM.exe, configuration text file and several DLL files are provided by SOC. These files must be copied together
in one directory of your DM PC. Just execute LBS_DM.exe to invoke the DM program.
Refer to the document [3] for detail description for DM.
3) CC(Control Center) Program
LBS_CONTROL_CENTER.exe, configuration text file and several DLL files are provided by SOC. These files must
be copied together in one directory of your control center PC. Just execute LBS_CONTROL_CENTER.exe to invoke
the DM program.
Refer to the document [3] for detail description for CC.
4) UPGS(Update Server) Program
LBS_REMOTE_UPGRADE_SERVER.exe, binary LOOK’ETfile and several DLLfiles are provided by SOC.
Binary LOOK’ET file must be placed in the C:\LBS_FLASH_FILE directory and other exe and DLL files must be
copied together in one directory of your upgrade server PC.
Refer to the document [4] for detail description for upgrade server.

SysOnChip
SOC LBS LOOK’ET User Manual
19
4.2. Testing environment & Installation
4.2.1. Testing environment
The testing environment of LOOK’ET is as followings.
Basic period report message, which is occurred by period during ignition on or off, is reported to the control center.
History report & logging message can be checked at DM and control center at any time during GPRS connection is
established.Also daily history report can be sent E-mail server or other GPRS server by configuration setting.
Program updating can be executed at DM and Upgrade server. Alarm messages can be transferred to the specified
SMS user by configuration setting. To test this basic environment, DM and GPRS capable Control center and
upgrade server software will be provided by SOC.
DM
USB
GSM/GPRS
Network
Control Center
(GPRS capable)
Upgrade Server
SW
E-mail or Other
GPRS Server
LOOK’ET RF : GPRS Packet/
GSM SMS
Internet network
GPRS
RF:GSMSMS
Pre-defined
SMS user
RF:GSM SMS
Control Center
( GPRS / GSM capable)
Fig 16. Operation environment

SysOnChip
SOC LBS LOOK’ET User Manual
20
4.2.2. Installation & Usage
4.2.2.1. Component connection
(1) Connect the external GSM antenna and external GPS antenna
(2) Connect the USB connector LOOK’ET and PC.
(3) Connect the 12 pin vehicle interface connector LOOK’ET and Vehicle.
The VIN,GND and IGNITION signals of vehicle interface must be connected to the vehicle. If this signals are not
connected with vehicle, use power supply or 12V/24V battery.
