Systemline SN2030 Programming manual

NetServer
NetAmp
Systemline 7
NetServer & NetAmp
Systemline 7 NetServer, used with S7 NetAmp only &
Systemline 7 NetAmp, 2 zone smart multi-roon amplifier
Quick start instructions
SN2030 / SN2100
SN2200 & SN1100

Important safety instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarised or grounding-type plug. A polarised plug
has two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer
12. Use only with the cart, stand, tripod, bracket or table specied by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally or has been dropped.
WARNINGS
To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.
This apparatus shall not be exposed to dripping or splashing and no objects lled with liquids,
such as vases, shall be placed on the apparatus.
Apparatus with CLASS1 construction shall be connected to a MAINS socket outlet with a
protective earthing connection.

Instructions de sécurité importantes
1. Veuillez lire ces instructions.
2. Veuillez conserver ces instructions.
3. Veuillez prendre connaissance de tous les avertissements.
4. Veuillez suivre toutes les instructions.
5. N’utilisez pas cet appareil a proximite de l’eau.
6. Nettoyez uniquement avec un chion sec.
7. N’obstruez pas les grilles de ventilation. Suivez attentivement les instructions du fabricant lors
de l’installation.
8. N’installez pas cet appareil a proximite d’une source de chaleur telle que des radiateurs, des
bouches d’air chaud, des fours, ou tout autre appareil (y compris des amplicateurs) produisant
de la chaleur.
9. Ne supprimez pas la securite apportee par la prise polarisee ou de type B. Une prise polarisee
possede deux broches, dont une plus large que l’autre. Une prise de type B possede deux broches
et une che terre. La broche la plus large ou la che terre sont la pour votre securite. Si la prise
fournie ne convient pas, adressez-vous a un electricien pour une mise aux normes de votre
installation electrique.
10. Evitez de marcher sur le cordon d’alimentation ou de le pincer, en particulier, a l’extremite du
cordon, de la prise et a la sortie de l’appareil.
11. Utilisez uniquement des accessoires species par le fabricant.
12. Utilisez uniquement les chariots, pieds, tripodes, supports ou les tables recommandes par
le fabricant ou vendus avec l’appareil. Si vous utilisez un chariot, faites tres attention lors du
transport de l’appareil et evitez de le faire tomber pour ne pas vous blesser.
13. Debranchez cet appareil en cas d’orage ou lorsque vous ne vous en servez pas pendant une
periode prolongee.
14. Pour toute reparation, adressez-vous a un professionnel. Faites reparer cet appareil pour des
dommages de n’importe quelle nature : cordon d’alimentation abime, liquide ou objet introduit
dans l’appareil, exposition a la pluie ou a l’humidite, fonctionnement inhabituel, chutes diverses.
AVERTISSEMENT
An de diminuer les risques d’incendie ou de choc electrique, conservez cet appareil a l’abri de la
pluie et de l’humidite.
Evitez toute eclaboussure et ne posez pas d’objets contenant des liquides, comme des vases, sur
cet appareil.
L’appareil de construction de CLASS1 doit être connecté à une prise secteur dotée d’une
protection par mise à la terre.

1.0 NetServer pack contents
1 x NetServer
2 x Mounting brackets
4 x Bracket xing screws
1 x Power supply
1 x Mains cable
1 x Quick start instruction manual
2.0 NetAmp pack contents
1 x NetAmp
2 x Mounting brackets
4 x Bracket xing screws
4 x IMO speaker connectors
4 x HomeNet cabinet xing screws
1 x Right angled mains cable
2 x USB A-B cables
3.0 Introduction
These quick start instructions describe how to congure the S7 NetServer with 2 zones of an S7
NetAmp. Please refer to the detailed instructions available on the Systemline website for other
conguration, connectivity and mounting options.
4.0 Connections
4.1 Use an Ethernet patch cable (not supplied) to plug the Local Area Network connection of the
NetServer and NetAmp into the router network sockets. The router should have an active DHCP
server (automatically assigning IP addresses).
4.2 Use two USB A-B cables to connect inputs 3 and 3A of the NetAmp to two of the NetServer’s
USB sockets.
4.3 Once the speakers are connected correctly in the two zones, use the green speaker plugs
included with the NetAmp to terminate the zone speaker cables and plug into the speaker
sockets on the NetAmp.
4.4 Plug in the mains cable for the NetAmp.
4.5 Plug in the NetServer power supply and switch on.
Please note: It is important that you connect the USB cables and switch the NetAmp on before
switching the NetServer on.

Basic connection diagram showing 2 zones

5.0 Set up server inputs on NetAmp
5.1 Once booted up you can nd the IP address of the NetServer using a FREE App called Fing.
Type the IP address into a browser and open up the web set up page.
e.g. enter: 192.168.1.120
5.2 Press the Congure Player button.
Each NetAmp USB socket has a unique serial number. These should be listed down the left side of
the table followed by an assigned MAC address.
5.3 Press the Select button on the front of the NetAmp to display its’ IP address.

5.4 Open up another page on the web browser and enter the IP address of the NetAmp.
e.g. enter: 192.168.1.133
5.5 Press Source Setup and you will be prompted to enter a user name and password. By default
these are set as follows:
User Name: admin
Password: password
5.6 You must obtain the MAC addresses associated with sources 3 and 3A from the server. This
ensures that the server and S7 App always link together and the correct audio stream is delivered
to the correct zone.
Type in the IP address of the server discovered in section 5.1 in the Source IP box and then press
Save.

5.7 It is now possible for the NetAmp to obtain its corresponding MAC addresses by pressing
Get MAC for sources 3 and 3A.
You will nd that the address that gets populated corresponds to that listed on the server, but
using lower case letters. This is correct so please do not edit it!
This ensures that the server always uses the same player MAC address ID each time it is powered
up or reconnected. It also ensures the App associates the server player ID with the NetAmp zone
name.
This process must be completed for the App to operate and show the correct zones.

6.0 Name the zones
6.1 Press Zone 1 Setup from the open window, accessing the NetAmp from the list on the left hand
side.
6.2 Rename the zone by entering text and press Save.
6.3 Repeat the process for Zone 2.
7.0 Rip a CD
7.1 Plug a USB CD drive into the 3rd USB socket on the NetServer.
7.2 Insert a CD. Ripping will automatically start. An internet connection is needed for the server to
nd album, artist, track and cover art information.
7.3 When the CD has nished ripping, it will eject.
7.4 Repeat steps 7.2 and 7.3 for a number of CDs.
Note: If you know how to transfer electronically stored music from one device to another, you may also
use this method to load content. In this case, the les should be placed in the folder \les\music\ac

8.2 8.3 8.4
7.5 Press System Conguration on the NetServer web page.
7.6 Press Reboot and then OK when prompted. This will initiate a music database rescan.
8.0 Use the App
8.1 Download the Systemline 7 App from the App Store and open it.
8.2 Select a zone by pressing on the zone name.
8.3 Press the house button to open the full browsing page.
8.4 Select Albums from the list and then select an album to play.
8.5 Adjust the volume from the now playing screen.
9.0 More settings and features
More features, settings and plugins are available for the NetServer. For more detailed instructions
see the detailed setup available on the Systemline7 website: www.systemline.co.uk
